Acura RL 2001 3.5 Owner's Manual

Audio System

To store a frequency:
1. Select the desired band, AM or FM. FM1 and FM2 let you store
two frequencies with each Preset

button.

2. Use the TUNE or SEEK function to tune the radio to a desired
station.

3. Pick the Preset button you want for that station. Press the buttonand hold it until you hear a beep.
4. Repeat steps 1 to 3 to store a total of six stations on AM and twelve
on FM.
Once a station's frequency is stored,
simply press and release the proper
Preset button to tune to it.
The preset frequencies will be lost if your car's battery goes dead, isdisconnected, or the radio fuse is

removed.
AM/FM

BUTTON

PWR/VOL

KNOB
SEEK/SKIP
BUTTONS

PRESET BUTTONS

Comfort and Convenience Features
STEREO

INDICATOR
TUNE
KNOB

Audio System
AUTO SELECT — If you are traveling far from home and can no
longer receive the stations you
preset, you can use the Auto Select
feature to find stations in the local
area.

To activate Auto Select, press the
A. SELECT button. A. SELECT will appear in the display, and the system
will go into scan mode for several seconds. It automatically scans both
bands, looking for stations with strong signals. It stores the frequen-
cies of six AM stations and twelve
FM stations in the preset buttons.
You can then use the preset buttons to select those stations.
If you are in a remote area. Auto
Select may not find six strong AM
stations or twelve strong FM stations.
If this happens, you will see a "0"
displayed when you press any preset
button that does not have a station stored. With Auto Select on, you cannot
manually store any frequencies in
the preset buttons. If you do not like
the stations found by Auto Select,
you can use the TUNE and SEEK

functions to find other stations.
Auto Select does not erase the
frequencies that you preset pre-

viously. When you return home, turn
off Auto Select by pressing the
A. SELECT button. The preset
buttons will then select the fre-
quencies you originally set.
Comfort and Convenience Features
AUTO SELECT INDICATOR
PRESET BUTTONS
SEEK/SKIP

BUTTONS
TUNE

KNOB

AUTO SELECT BUTTON
AM/FM BUTTON

Audio System

Adjusting the Sound
Balance/Fader — These twocontrols adjust the strength of the
sound coming from each speaker.
The Balance control adjusts the side- to-side strength, while the Fadercontrol adjusts the front-to-back
strength.
To adjust the fader, push on the BASS/FADER control knob to get it
to pop out. Pull it out slightly farther, and adjust the front-to-back sound to
your liking. Push the knob back in when you are done so you cannotchange the setting by accidentally
bumping it.
To adjust the balance, push on the
TREBLE/BALANCE control knob to get it to pop out. Pull it out slightly
farther, and adjust the side-to-sidesound to your liking. Push the knob
back in when you are done so you
cannot change the setting by
accidentally bumping it. Treble/Bass — Use these controls
to adjust the tone to your liking.
To adjust the Treble level, push on the TREBLE/BALANCE control
knob to get it to pop out. Without
pulling it out farther, turn the knob
to adjust the treble level. Push the
knob back in when you are done so
you cannot change the setting by accidentally bumping it. To adjust the Bass level, push on the
BASS/FADER control knob to get it
to pop out. Without pulling it out
farther, turn the knob to adjust the bass level. Push the knob back in
when you are done so you cannot change the setting by accidentally
bumping it.
Comfort and Convenience Features
BASS/FADER

CONTROL
TREBLE/BALANCE

CONTROL

Audio System

Audio System Lighting
You can use the instrument panel brightness control dial to adjust the il-
lumination of the audio system (see
page 66). The audio system illuminates when the parking lightsare on, even if the radio is turned off.
Radio Frequencies and Reception

For information, See page 149.
Operating the Cassette Player

The ignition switch must be in
ACCESSORY (I) or ON (II). Make sure the tape opening on the
cassette is facing to the right, then
insert the cassette most of the way
into the slot. The system will pull it
in the rest of the way, and begin to

play.

The tape direction indicator will light to show you which side of the cassette is playing. The indicates
the side you inserted facing upward is now playing. If you want to play
the other side, press the PROG/ PLAY button.
Dolby noise reduction turns on when
you insert a cassette. If the tape was not recorded with Dolby noise reduc-
tion, turn it off by pressing the
button.
When the system reaches the end of
the tape, it will automatically reversedirection and play the other side. If
you want to remove the cassette
from the drive, press the EJECT button.
If you turn the system off while a
tape is playing, either with the PWR/ VOL knob or by turning off the
ignition, the cassette will remain in
the drive. When you turn the system
back on, the tape will begin playing
where it left off.
To switch to the radio or CD changer while listening to a tape,
press the AM/FM or CD/TAPE but-
ton. To change back to the cassette
player, press the CD/TAPE button.
Comfort and Convenience Features

Audio System

Tape Search Functions
With a cassette playing, you can usethe FF, REW, TMS, or REPEAT
function to find a desired program.
FF/REW — Fast Forward and Re-
wind move the tape rapidly. To re- wind the tape, push the REW button.
You will see REW in the display. To fast forward the tape, push the FFbutton. You will see FF displayed.
Press the PROG/PLAY button to
take the system out of rewind or fast
forward. When the system reaches the end of the tape, it reversesdirection and begins to play if in fast
forward, or it begins to play if in
rewind.

Comfort and Convenience Features
AM/FM BUTTON

CASSETTE SLOT

PWR/VOL KNOB
TMS INDICATOR

DOLBY INDICATOR

EJECT

BUTTON

REPEAT
INDICATOR

REPEAT
BUTTON

TMS BUTTON

DOLBY BUTTON

PROG/PLAY

BUTTON

TAPE

DIRECTION
INDICATOR

REWIND
BUTTON
CD/TAPE BUTTON
FAST FORWARD

BUTTON

Audio System

TMS — The Tape Music Search Function allows you to find the begin-
ning of a song or passage. To acti-
vate TMS, press the TMS button.
You will see TMS displayed. To find the beginning of the song or passagecurrently playing, push the REW but-
ton. You will see REW flashing in the
display as the tape rewinds. To find
the beginning of the next song, push
the FF button. You will see FF
flashing in the display as the tape
fast forwards. When the system
finds the beginning of a song or pas- sage, it goes back to PLAY mode.
Press the TMS button again to turn
it off.

CONTINUED

Comfort and Convenience Features

CASSETTE SLOT

PWR/VOL KNOB TMS INDICATOR

TAPE DIRECTION

INDICATOR
EJECT

BUTTON

REPEAT
INDICATOR

TMS BUTTON REPEAT
BUTTON
FAST FORWARD BUTTON
REWIND
BUTTON

Audio System

REPEAT — The Repeat functioncontinuously replays the currentsong or passage. Press the REPEAT
button to activate it; you will see RPT displayed as a reminder. When the
system reaches the end of the song
or passage currently playing, it will
automatically go into rewind.
When it senses the beginning of the same song or passage, the system
returns to PLAY mode. It will continue to repeat this same
program until you deactivate REPEAT by pressing the button

again.

Pressing the REW or FF button also
turns off REPEAT. The TMS and REPEAT functions
use silent periods on the tape to find
the end of a song or passage. These
features may not work to your satisfaction if there is almost no gap
between selections, a high noise
level between selections, or a silent period in the middle of a selection.

Caring for Cassettes
Damaged cassettes can jam inside

the drive or cause other problems.
See page 156 for information on
cassette care and protection.
Operating the CD Changer
A Compact Disc changer is standard equipment. It holds up to six discs,
providing several hours of continu- ous entertainment. You operate theCD changer with the same controls
used for the radio and cassette
player.
To load the CDs in the magazine and load the magazine into the CDchanger, refer to page 159. Play only
standard round discs. Odd-shapedCDs may jam in the drive or cause
other problems.
Do not play discs with disc
accessories such as protective seals
or rubbers. Using them may also
cause the audio system to
malfunction.
Comfort and Convenience Features

Audio System

To operate the CD changer, the igni- tion switch must be in ACCESSORY (I) or ON (II).
Select the CD mode by pressing the
CD/TAPE button. You will see "CD"
in the display. The system will start
to play the first track of the first disc
in the magazine. You will see the disc and track number displayed.
When that disc ends, the next disc in the magazine is loaded and played.
After the last disc finishes, the system returns to disc 1.
To select a different disc, press the appropriate preset button (1 — 6). If
you select an empty slot in the magazine, the changer will, after
finding that slot empty, try to load
the CD in the next slot. This continues until it finds a CD to load
and play.
CONTINUED

Comfort and Convenience Features

A. SELECT INDICATOR
CD/TAPE BUTTON
REPEAT INDICATOR

REPEAT

BUTTON

SEEK/SKIP
BUTTONS

AUTO

SELECTBUTTON

PRESET BUTTONS

AM/FM

BUTTON
PWR/VOL

KNOB

Audio System

You can use the SEEK/SKIP buttonsto select tracks within a disc. If you
push and release cither side of theSEEK/SKIP buttons ( — or +),the
system will move to the beginning of
a track. Push the + button to move
to the beginning of the next track,
and push the — button to move to
the beginning of the current track.
If you push and hold the SEEK/
SKIP button, you will hear a beep
and the system will continue to move
across tracks. Release the button
when you think it has reached the de- sired place on the disc. REPEAT — When you activate the
Repeat feature by pressing the
REPEAT button, the system continu-
ously replays the current track. You
will see RPT in the display as a
reminder. Press the REPEAT button again to turn it off.
RANDOM PLAY — This feature,
when activated, plays the tracks on a CD in random order, rather than in
the order they are recorded on the CD. To activate Random Play, press
the A. SELECT button. You will see
A. SELECT in the display. The sys- tem will then select and play tracks
randomly on the current disc. Whenall tracks on that disc have been
played, the next disc is loaded and
played randomly. This continues un-
til you deactivate Random Play by
pressing A. SELECT again. To take the system out of CD mode,
press the AM/FM button or insert acassette in the player. If a tape is
already in the cassette player, press
the CD/TAPE button. When you return to CD mode, play will contin-
ue at the same point that it left off.
If you turn the system off while a CD
is playing, either with the PWR/VOL
knob or the ignition switch, play will continue at the same point when you
turn it back on.

Protecting Compact Discs

For information on how to handle

and protect compact discs, see page
161
.
Comfort and Convenience Features

Audio System

3.5 RL with Navigation System

Operating the Radio

The ignition switch must be in
ACCESSORY (I) or ON (II) to operate the audio system. Turn the
system on by pushing the PWR/
VOL knob or the AM/FM button.
Adjust the volume by turning the
knob.

The band and frequency that the ra- dio was last tuned to is displayed. To
change bands, press the AM/FM but-
ton. On the FM band, ST will be dis- played if the station is broadcastingin stereo. ST will flash if you are driv-
ing in an area where the radio signal
is weak. Stereo reproduction on AM
is not available. You can use any of three methods to
find radio stations on the selected
band: TUNE, SEEK, or the Preset

buttons.

TUNE — Use the TUNE bar to tune the radio to a desired frequency.Push and release the appropriateside of the bar quickly. The
frequency numbers will change in small increments.
SEEK — The SEEK function searches the band for a station with
a strong signal. To activate it, push
either side of the SEEK bar (— or +) until you hear a beep. Push the
bar on the + side to scan up from
the current frequency, and on the — side to scan down. It stops when it
finds a station with a strong signal. Preset — You can store the
frequencies of your favorite radio
stations in the six preset buttons.
Each button will store one frequency
on the AM band, and two

frequencies on the FM band.

CONTINUED

Comfort and Convenience Features
