To exit ‘‘DEFAULT ALL,’’ press the
INFO button until you see ‘‘EXIT,’’
then press the SEL/RESET button.
When ‘‘DEFAULT ALL’’ is
completed successf ully, you will see
the above display f or several seconds,
and the display will return to
‘‘CUSTOMIZE ENTRY.’’ If ‘‘DEFAULT ALL’’ is not completed
successf ully, you will see the above
display f or several seconds, then the
display goes back to ‘‘CUSTOMIZE
ENTRY.’’ Repeat the procedure to
select ‘‘DEFAULT ALL.’’
Multi-Inf ormation Display
90
——y
y
(yy

While the multi-information display
is showing ‘‘CHANGE SETTING,’’
press the SEL/RESET button. The
display will start showing the initial
‘‘CUSTOMIZE GROUP.’’ Each time
you press the INFO button, the
display changes as shown in the next
column. Press the INFO button until
you see the setup you want to
customize, and press the SEL/
RESET button to enter your
selection. You can customize some of the
vehicle control settings to your
pref erence. Here are the settings
you can customize:METER SETUP
POSITION SETUP
LIGHTING SETUP
DOOR/WINDOW SETUP
WIPER SETUP
Multi-Inf ormation Display
Change Setting
Inst rument s and Cont rols
91
: Press SEL/RESET Button.
: Press the INFO Button.
——y

y
(yy

There are five custom settings in the
Meter Setup:LANGUAGE SELECTION
ADJUST OUTSIDE TEMP.
DISPLAY
TRIP A & AVG. FUEL A RESET
with REFUEL
ELAP. TIME RESET
CONDITION
PRIMARY DISP SELECTION
While ‘‘METER SETUP’’ is displayed,
press the SEL/RESET button on the
steering wheel. Then, press the
INFO button repeatedly. Each time
you press the INFO button, the
display changes as shown.
To customize a setting, press the
INFO button repeatedly until you see
the setting you want to customize,
and press the SEL/RESET button.
Then f ollow the procedures
described on the f ollowing pages. Meter Setup
Multi-Inf ormation Display
92
: Press the INFO Button.
——y

y
(yy

While the multi-information display
is showing ‘‘METER SETUP,’’ press
the SEL/RESET button on the
steering wheel. The display changes
to ‘‘LANGUAGE SELECTION.’’
Press the SEL/RESET button again
to enter the language selection mode.There are three selectable languages,
English, French, and Spanish. Each
time you press the INFO button, the
display changes as shown.
Select the language you want by
pressing the INFO button, and press
the SEL/RESET button to enter
your selection.
CONT INUED
L anguage Select ion
Multi-Inf ormation Display
Inst rument s and Cont rols
93
: Press the INFO Button.
——y

y
(yy

When language selection is
successf ully completed, the display
changes to the screen shown above
f or several seconds, then goes back
to ‘‘CUSTOMIZE MENU.’’If you f ail to select a language
properly, you will see the above
display f or several seconds, then the
display goes back to ‘‘CUSTOMIZE
MENU.’’ Repeat the setup.To exit ‘‘LANGUAGE SELECTION,’’
press the INFO button repeatedly
until you see ‘‘EXIT,’’ then press the
SEL/RESET button. The display
goes back to ‘‘CUSTOMIZE MENU.’’
All the messages in the multi-
inf ormation display will be in the
language you selected.
Multi-Inf ormation Display
94
——y
y
(yy

Press the SEL/RESET button. The
display changes as shown above.
The highlighted number is the
current adjustment above or below
the outside temperature. Press the
INFO button repeatedly until the
appropriate number appears, then
press the SEL/RESET button to
enter your selection.
If you f ind that the temperature
reading is always a f ew degrees
below or above the actual
temperature, adjust it as described
on the f ollowing columns.
While the multi-information display
shows ‘‘METER SETUP,’’ press the
SEL/RESET button on the steering
wheel. The display changes to the
‘‘CUSTOMIZE MENU.’’ Press the
INFO button once, and you will see
‘‘ADJUST. OUTSIDE TEMP.
DISPLAY’’ as shown above.
CONT INUED
A djust Outside T emp. Display
Multi-Inf ormation Display
Inst rument s and Cont rols
95
U.S. model is shown
——y

y
(yy

If you f ail to enter the desired
adjustment properly, you will see the
above display for several seconds,
then the display goes back to
‘‘CUSTOMIZE MENU.’’ Repeat the
adjustment.To exit ‘‘ADJUST OUTSIDE TEMP.
DISPLAY,’’ press the INFO button
until you see ‘‘EXIT,’’ and press the
SEL/RESET button. The display
goes back to ‘‘CUSTOMIZE MENU.’’
When your selection is successf ully
entered, you will see the above
display f or several seconds, and then
the display goes back to
‘‘CUSTOMIZE MENU.’’
Multi-Inf ormation Display
96
U.S. model is shown
——y
y
(yy

Press the SEL/RESET button. The
display changes as shown above.
The lower segment changes
between ‘‘ON’’ and ‘‘OFF’’ each time
you press the INFO button. Enter
your selection by pressing the SEL/
RESET button.
To reset ‘‘Trip A’’ and ‘‘AVG. FUEL
A’’ to reset every time you ref uel
your vehicle, f ollow the procedure
described f rom the next column.
While the multi-information display
shows ‘‘METER SETUP’’ press the
SEL/RESET button on the steering
wheel. The display changes to
‘‘CUSTOMIZE MENU.’’ Press the
INFO button repeatedly until you see
‘‘TRIP A & AVG. FUEL RESET
WITH REFUEL’’ in the lower
segment as shown above.
CONT INUED
T rip A & A vg. Fuel Reset wit h Ref uel
Multi-Inf ormation Display
Inst rument s and Cont rols
97
——y
y
(y
y

When your selection is successf ully
entered, you will see the above
display f or several seconds, and then
the display goes back to
‘‘CUSTOMIZE MENU.’’If you f ail to enter your selection,
you will see the above display f or
several seconds, then the display
goes back to ‘‘CUSTOMIZE MENU.’’
Repeat the setup.To exit ‘‘TRIP A & AVG. FUEL
WITH REFUEL,’’ press the INFO
button until you see ‘‘EXIT,’’ and
press the SEL/RESET button. The
display goes back to ‘‘CUSTOMIZE
MENU.’’
Multi-Inf ormation Display
98
——y
y
(y

y

‘‘ELAPSED TIME’’ is the driving
time since you last reset the trip
computer. You can customize the
condition of when to reset the
‘‘ELAPSED TIME’’.While the multi-information display
shows ‘‘METER SETUP,’’ press the
SEL/RESET button on the steering
wheel. The display changes to the
‘‘CUSTOMIZE MENU.’’ Press the
INFO button repeatedly until you see
‘‘ELAP. TIME RESET
CONDITION’’ in the lower segment
as shown above.Press the SEL/RESET button. The
display changes as shown above.
The lower segment changes
between ‘‘IGN RESET,’’ ‘‘TRIP A
RESET’’ and ‘‘TRIP B RESET’’ each
time you press the INFO button.
Enter your selection by pressing the
SEL/RESET button.
CONT INUED
Elap. T ime Reset Condit ion
Multi-Inf ormation Display
Inst rument s and Cont rols
99
—
—y


y
(y
y
