headrest Alfa Romeo 156 2004 Owner handbook (in English)

GETTING TO KNOW YOUR CAR23
ADJUSTING THE HEADRESTS (fig. 24)
To increase the safety of passengers, the
headrests are adjustable in height and, for
versions with Recaro seats they are also ad-
justable in rake.
To adjust the height: move the headrest
up or down, then release it and make sure
that it is locked in one of the pre-established
positions.
For angle adjustment (where applicable):
take hold of the headrest and turn it to the
most suitable position.
WARNINGThe shape of the headrest
may vary depending on the version and/or
market. The example shown is used only to
demonstrate the methods by which it can
be adjusted.
REAR POCKETS (where
required)
(fig. 25)
The front seats are provided with a pocket
in the rear of the seat back.
REAR SEATCENTRE ARMREST
(fig. 26)
(where required)
To use the centre armrest, lower it holding
the grip (A) as illustrated.
fig. 24
A0B0050m
fig. 25
A0B0320m
fig. 27
A0B0565m
fig. 26
A0B0564m
Remember that the head
restraints must be posi-
tioned so that they are supporting
the back of the head and not the
neck. They will only be able to pro-
vide effective protection in the
event of a collision if they are in
this position.
WARNING

GETTING TO KNOW YOUR CAR24
SKI COMPARTMENT (optional for versions/markets
where applicable)
The compartment may be used for carry-
ing long loads.To gain access to this compartment, lower
the armrest, pull the grip (A-fig. 27) of
the lid and lower it onto the armrest
(fig. 28).
The compartment can be extended by re-
moving the armrest: with the armrest low-
ered, press the two small handles (B-
fig. 29) at the base of the armrest inwards
and remove it. Then pull the grip of the lid
and lower it onto the rear seat (fig. 30).
HEADREST The car is fitted with two headrests for the
side seats. On request, for versions/markets
where applicable, a third headrest is avail-
able for the centre seat.
If necessary the headrests can be removed
as follows:
– raise the headrest to the maximum
height (where required);
– press both buttons (Aand B-fig. 31)
and remove the headrests.
fig. 28
A0B0322m
fig. 29
A0B00323m
fig. 30
A0B0324m
fig. 31
A0B0566m

CORRECT USE OF THE CAR
192
SAFE DRIVINGIn designing your Alfa 156, Alfa
Romeo has worked thoroughly to achieve a
vehicle able to offer top levels of safety to
its passengers. However, the behaviour of
the driver is still a decisive factor for road
safety.
Below you will find a few simple rules for
travelling safely under different conditions.
You are certainly familiar with many of them
but it is still helpful to read them all care-
fully.BEFORE DRIVING OFF– Make sure the lights and headlights are
working properly.
– Adjust the seat, steering wheel and
rearview mirrors, in order to obtain a correct
position for driving.
– Adjust the seat back upright and keep
your head as close as possible to the head
restraint.– Carefully adjust the headrests so that
the head and not the neck rests on them.
Check that nothing (mats, etc.) can get un-
der the foot pedals.
– Make sure that any child restraint sys-
tem (seats, cradles, etc.) are correctly fas-
tened on the rear seat.
– Place any objects in the boot with care
to prevent abrupt braking from throwing
them forwards.
– Avoid heavy meals before a journey. A
light meal will help to keep reflexes ready.
Above all avoid alcohol.
Routinely remember to check:
– tyre pressure and conditions;
– engine oil level;
– engine coolant level and system condi-
tions;
– brake fluid level;
– power steering oil level;
– windscreen washer fluid level.
WHEN TRAVELLING– The first rule for safe driving is care.
– Care also means being able to predict
the actions of other road users.
– Strictly respect the traffic regulations in
all countries, especially the speed limits.
– Ensure that both yourself and your pas-
sengers are wearing their seat belts, that
children are carried with the appropriate
seats and that any animals are in appropri-
ate compartments.
– Long distances should be trackled in
good health.
Driving under the influence
of drugs and/or some
medicines is highly dangerous for
oneself and for others.
WARNING

ALFA 156 SPORTWAGON
279
CHILD SAFETY DEVICE
(fig. 4)
The rear doors are fitted with a locking de-
vice (A) which prevents them from being
opened from inside.
WARNINGEach device only acts on the
door on which it is installed.
The device can only be engaged with the
doors open raising or lowering the control
with the ignition key.
Position 1(control up) = Device engaged.
Position 2(control down) = Device re-
leased.
WARNINGAlso follow the instructions
given in the chapter “getting to know your
car” under the paragraph “Child safety de-
vice”.The third headrest (centre) is not remov-
able, whereas the side headrests may be re-
moved as follows:
– Raise the headrests about 2 cm.
– Press the buttons (Aand B-fig. 5) at
the same time and remove the headrests.
– To refit the headrests keep the buttons
pressed (Aand B-fig. 5) and insert them
completely.
fig. 6
A0B0095m
SEATSREAR SEATHeadrest
The car is fitted with two headrests for the
side seats (fig. 5). On request for ver-
sions/markets where applicable, the car
may also be fitted with a third headrest for
the central seat (fig. 6).
To pull out the third headrest, push it up-
wards until hearing the stopping click.
fig. 4
A0B0080m
fig. 5
A0B0094m

ALFA 156 SPORTWAGON
280
Centre armrest (where required)
To use the centre armrest, lower it as il-
lustrated (fig. 7), using the handle (A).fig. 7
A0B0564m
fig. 8
A0B0097m
Ski compartment
This compartment can be used for carry-
ing long loads.
To gain access to the compartment lower
the armrest, pull the handle (A-fig. 8) and
lower the lid on the armrest (fig. 9).
On versions fitted with the third headrest,
before lowering the lid on the armrest, lift
the headrest completely and set the fabric
protection.On request for versions/markets where
applicable, the compartment can be fitted
with a bag for carrying skis.
WARNINGLay the bag in the passen-
ger compartment before putting the skis in.
After carrying skis, let the bag dry (if wet),
then fold it correctly and insert it in the com-
partment.
fig. 9
A0B0600m
Remember that the third
headrest (central) should
be pulled out completely so that
the nape and not the neck rests on
it. Only in this position does it ex-
ert its protective action if the car
is hit from behind.
WARNING
Always check that the load
are anchored properly to
prevent them being thrown against
the passengers in case of accident
or sharp braking.
WARNING

ALFA 156 SPORTWAGON
290
Total extension (fig. 37)
Completely folding the rear seat makes the
maximum load volume available.– Tilt the cushions forward pulling from
the handle (A-fig. 39) at the centre of
each cushion.
– remove the side headrests from the rear
seat and insert them in the special housings
on the cushions (fig. 40).
– If the car is fitted with the third head-
rest from the centre of the seat, lower it
completely.
fig. 40
A0B0120m
To extend the boot
– Check that the lateral safety belt buck-
les (A-fig. 38) are located in their pock-
ets on the seat back and that the tab (B-
fig. 38) of the central abdominal safety
belts is hooked onto the support (C-
fig. 38).
– Remove the roll with the luggage cover.
fig. 37
A0B0607m
fig. 38
A0B0118m
fig. 39
A0B0119m

ALFA 156 SPORTWAGON
291
– Release the seat back catch raising the
handle (A-fig. 41) for the right seat back
and handle (B-fig. 42) for the left seat
back.
– Fold the seat backs forward to obtain
a single loading surface with the boot floor.To take the seats back to the
normal position
– Move the seat backs to the vertical po-
sition making sure that they are caught cor-
rectly.
WARNINGThe seat backs are correct-
ly caught when the button (A-fig. 43)
next to each handle (B-fig. 43) is back in
the handle.– Remove the headrest and tilt the cush-
ion backward, making sure that the safety
belts do not remain twisted in the hidden
section between the cushion and seat back.
– Refit the headrest on the seat back.
– Refit the roll with the luggage cover.
fig. 42
A0B0122m
fig. 41
A0B0121m
fig. 43
A0B0123m

ALPHABETICAL INDEX
329
Front light units
– bulb arrangement................... 220
Front roof light ............................ 162
– changing bulbs ...................... 230
Front seats .................................. 21
– adjustments .......................... 21
– centre armrest ....................... 22
– electric heating ..................... 22
– headrests .............................. 23
– rear pockets .......................... 23
Fuel
– consumption ......................... 322
– emergency flap opening
device ............................ 186-292
– fuel cap ............................... 186
– fuel flap................................ 137
– inertial fuel cut-off switch ........ 137
– level gauge and reserve
warning light ......................... 62
– refilling ................................ 319
– refuelling ........................ 185-292
– specifications ......................... 319
Fuel reserve ......................... 62-319
Fuel supply (technical data)........... 303
Fuel tank (capacity) .................... 319
Fuses and relays
– fuse summary table................ 238– fuses above the main fusebox.. 236
– fuses and relays accessible from
the glovebox ......................... 236
– fuses and relays in engine bay . 236
– fuses and relays in the main
fusebox ................................ 235
– generalities and cautions ........ 234
– list of protected devices .......... 238
– specific fuses for Sportwagon
versions ................................ 299
G
earshift lever ........................... 139
Getting to know your car.... 6
Glovebox light
– changing bulbs ..................... 232
Grab handles .......................... 161-292
H
andbrake lever......................... 138
Hazard lights
– switching on ......................... 135
Headlight aiming device
(corrector)................................ 138
Headlight washer ................... 52-274
Headlights
– beam adjustment .................. 138
– beam adjustment abroad ........ 177
– bulb replacement ............. 217-220– compensation for tilt............... 175
– gas discharge headlights ......... 176
Headrests
– front .................................... 23
– rear ............................... 24-279
Horn .......................................... 56
Identification data ....................... 299
Identification labels ...................... 300
Ignition device and steering lock 17-18
In an emergency.................... 205
In the event of a puncture ....... 207-294
– changing a wheel................... 209
– FIX&GO (quick tyre repair kit) . 212
– general instructions ................ 207
In the event of an accident ............ 246
– first aid kit ............................ 247
– if anybody is injured .............. 246
Inertial fuel cut-off switch .............. 137
Infocenter ................................... 64
– access to main menu screen .... 72
– control buttons ...................... 66
– date setting/time setting ........ 76
– default value reset ................. 85
– display ................................. 64
– display contrast adjustment ..... 84

ALPHABETICAL INDEX
331
N
umber plate lights
– changing bulbs ................ 229-296
O
ddment recesses
– in the boot ........................... 285
– on centre console ................... 165
– on dashboard ........................ 165
Odometer ................................... 59
Paintwork (maintenance) ............ 275
– colour label ........................... 301
Parking....................................... 191
Parking sensors............................ 187
Partial odometer .......................... 63
Performance................................ 314
Pockets and compartments
on front doors ........................... 165
Pollen filter ................................ 266
Power steering
– checking fluid level
and topping up ..................... 262
Power windows ........................... 27
Pre-tensioning devices ................... 32
Protecting emission reducing
devices ....................................... 198
Q
-system automatic gearbox........ 152
– acoustic warning .................... 159
– automatic operation ............... 154
– checking the oil level .............. 260
– fault signalling ....................... 158
– manual operating mode/
Q-System activation................ 157
– moving off ............................ 152
– push starting ......................... 159
– selecting automatic/
manual gearshifting................ 153
– selecting the driving modes ..... 156
– starting the engine ................. 152
– stopping the car ..................... 157
– towing the car ....................... 160
R
adio transmitters and cellular
telephones ............................... 167
Rain sensor ................................. 51
Rear fog guards
– changing bulbs ............... 227-294
– switching on.......................... 136
Rear light units
– bulb replacement ................... 227
Rear roof lights ............................ 163
– changing bulbs ...................... 231
Rear seats................................... 23– centre armrest ................. 23-280
– headrests ....................... 24-279
– ski compartment.............. 24-280
Rear suspensions
(automatic geometry control) ..... 293
Rearscreen heating................. 26-133
Rearscreen washer ....................... 281
– spray jet ............................... 281
Rearscreen wiper
– blade replacement ................. 281
– operation .............................. 281
Reducing running costs
and environment pollution .......... 197
Refilling ..................................... 319
Remote control ............................ 7-12
– additional remote controls ...... 12
– alarm system ........................ 11
– boot opening ......................... 8
– changing the battery .............. 10
– door opening-closing ............... 7
– ministerial homologation ......... 325
– remote door locking/
unlocking .............................. 16
Rev counter................................. 62
Reversing lights
– changing bulbs ................ 227-294
