EBD SYSTEM
FAILURE
(red)
(amber)
With the engine running the
turning on at the same time of
the
>andxwarning lights (on cer-
tain versions together with the message
on the display) indicates that the EBD
system is inefficient; in this case heavy
braking may cause the rear wheels to
lock before time, with the possibility of
skidding.
Drive with the utmost care to the near-
est Alfa Romeo Authorized Service to
have the system checked.
VDC SYSTEM
(where provided)
(amber)
Fitting the key into the ignition device
the warning light turns on, but it should
go off after few seconds.
The warning light flashes when the VDC
cuts in, to alert the driver that the sys-
tem is adapting to the road surface grip
conditions.
VDC deactivation
When the VDC is deactivated manually
(pressing the ASR/VDC button for 2 sec-
onds) (see paragraph “VDC system” in
section “Dashboard and controls”) the
instrument panel warning light turns on
(on certain versions a message is dis-
played).
VDC failure
In case of failure, the VDC system will
deactivate automatically and the in-
strument panel warning light
áwill turn
on glowing steadily (on certain versions
a message will also be displayed). In
this case contact Alfa Romeo Authorized
Services as soon as possible.
ABS SYSTEM
FAILURE (amber)
Fitting the key into the ignition
device the warning light turns on, but
it should go off after few seconds.
The warning light turns on (on certain
versions a dedicated message is dis-
played) when the system is inefficient.
In this case the braking system keeps
its effectiveness unchanged, but without
the potential offered by the ABS system.
Drive carefully and contact Alfa Romeo
Authorized Services as soon as possible.
>
>
xá
165-180 Alfa 159 GB 4-06-2008 9:42 Pagina 175

ASR SYSTEM
(WHEEL ANTISKID
SYSTEM)
(amber)
Fitting the key into the ignition device
the warning light turns on, but it should
go off after few seconds. The warning
light flashes when the system cuts in, to
alert the driver that the system is adapt-
ing to the road surface grip conditions.
ASR deactivation
When the ASR is deactivated manually
(pressing the ASR/VDC button) (see
paragraph “ASR system” in section
“Dashboard and controls”) the
ASR/VDC button turns on (on versions
fitted with “Reconfigurable multifunction
display” symbol
Vis also displayed).
ASR failure
In the event of a failure the ASR system
is deactivated automatically and on ver-
sions fitted with “Reconfigurable multi-
function display” the symbol
Vis dis-
played. In this case contact Alfa Romeo
Authorized Services as soon as possible.
176
SAFETY
DEVICES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
CORRECT USE
OF THE CAR
DASHBOARD
AND
CONTROLS
WARNING
LIGHTS AND
MESSAGES
á
EXTERNAL LIGHTS
FAILURE
(amber)
The warning light (where provided)
turns on (on certain versions a message
is displayed) when one of the following
lights is failing:
– sidelights
– direction indicators
– rear fog guards
– number plate lights.
The failure referring to these lights could
be: one or more blown bulbs, a blown
protection fuse or an electric connection
cut-off.
W
HILL HOLDER
FAILURE
(where provided)
(amber)
Fitting the key into the ignition device,
the warning light (where provided) turns
on, but it should go off after a few sec-
onds.
If the warning light stays on (on certain
versions a message is displayed) there
is a failure in the Hill Holder system. Con-
tact Alfa Romeo Authorized Services.
*
165-180 Alfa 159 GB 4-06-2008 9:42 Pagina 176

177
SAFETY
DEVICES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
CORRECT USE
OF THE CAR
DASHBOARD
AND
CONTROLS
WARNING
LIGHTS AND
MESSAGES
BRAKE LIGHTS
FAILURE
(amber)
The warning light (where provided) turns
on (on certain versions a message is dis-
played) when a failure at brake lights
(stop) is detected. The failure could be
due to: blown bulb, blown protection fuse
or electric connection cut-off.
T
REAR FOG LIGHTS
(amber)
The warning light turns on
when the rear fog lights are turned on.
FRONT FOG LIGHTS
(green)
The warning light turns on
when the front fog lights are turned on.
4
5
SIDE/TAILLIGHTS
(green)
FOLLOW ME HOME
(green)
Sidelights
The warning light turns on when
side/taillights are turned on.
Follow me home
The warning light comes on (together with
the message on the display) when the
Follow me home device is activated (see
paragraph “Follow me home” in section
“Dashboard and controls”).
3
2
DIPPED BEAM
HEADLIGHTS
(green)
The warning light turns on when the
dipped beams are turned on.
MAIN BEAM
HEADLIGHTS (blue)
The warning light turns on
when the main beams are turned on.
1
LEFT-HAND
DIRECTION
INDICATOR
(green)
The warning light turns on when the di-
rection indicator stalk is moved down-
wards or, together with the right indi-
cator, when the hazard light button is
pressed.
RIGHT-HAND
DIRECTION
INDICATOR (green)
The warning light turns on when the di-
rection indicator stalk is moved upwards
or, together with the left indicator, when
the hazard light button is pressed.
R
E
165-180 Alfa 159 GB 4-06-2008 9:42 Pagina 177

178
SAFETY
DEVICES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
CORRECT USE
OF THE CAR
DASHBOARD
AND
CONTROLS
WARNING
LIGHTS AND
MESSAGES
FUEL RESERVE –
LIMITEDCRUISING
RANGE(amber)
The warning light on the fuel level gauge
turns on when about 10 litres fuel are
left in the tank. On certain versions. the
display will show a warning message
when the cruising range is less than 50
km (or 31 mi).
If warning light K
starts flashing when
travelling contact Alfa
Romeo Authorized Services.
CRUISE CONTROL
(where provided)
(green)
The warning light turns on (on certain
versions a dedicated message is dis-
played) when turning the the knurled
ring of the Cruise Control to
Ü.
LIGHT SENSOR
FAILURE
(where provided)
(amber)
The warning light (or as an alternative,
on certain versions, a symbol and a mes-
sage are displayed) turns on to indicate
a failure at the light sensor.
PARKING SENSOR
FAILURE
(where provided)
(amber)
The warning light (or as an alternative,
on certain versions, a symbol and a mes-
sage are displayed) turns on to indicate
a failure at parking sensors.
RAIN SENSOR
FAILURE
(where provided)
(amber)
The warning light(where provided) turns
on (on certain versions a message is dis-
played) when the rain sensor is failing.
1
u
t
K
Ü
DIESEL PARTICULATE
FILTER CLOGGED
(diesel versions)
(amber)
The warning light (or as an alternative,
on certain versions, a symbol and a mes-
sage are displayed) turns on when the
diesel particulate filter is clogged and the
driving conditions do not enable to ac-
tivate automatically the reclaiming pro-
cedure.
To enable the cleaning procedure, keep
the car running until the warning light
turns on (or, on certain versions, sym-
bol
hdisappears from the display).
h
165-180 Alfa 159 GB 4-06-2008 9:42 Pagina 178

179
SAFETY
DEVICES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
CORRECT USE
OF THE CAR
DASHBOARD
AND
CONTROLS
WARNING
LIGHTS AND
MESSAGES
ANTIPINCH SYSTEM
FAILURE
(amber)
The warning light (or as an alternative,
on certain versions, a symbol and a mes-
sage are displayed) turns on when a fail-
ure is detected in the antipinch system.
Contact Alfa Romeo Authorized Services.
WINDSCREEN
WASHER FLUID
LOW LEVEL (amber)
The warning light (where provided)
turns on (on certain versions a message
is displayed) when the windscreen
washer fluid level falls down the preset
min. level.
5
)
SPEED LIMIT
EXCEEDED
The display will show a warn-
ing message + symbol (red) and the
buzzer will sound when the car exceeds
the speed limit set through the “Setup
menu” (e.g.: 120 km/h) (see para-
graphs “Multifunction Display” or “Re-
configurable Multifunction Display” in
section “Dashboard and controls”).
T.P.M.S. SYSTEM
FAILURE
(where provided)
On certain versions the display will show
a warning message + symbol (amber)
when a failure is detected in the T.P.M.S.
system (Tyre Pressure Monitoring Sys-
tem). Contact Alfa Romeo Authorized
Services as soon as possible.
Should one or more wheels without sen-
sor be fitted, the display will show a
warning message until initial conditions
are restored.
CHECK TYRE
PRESSURE
(where provided)
On some versions, the display shows a
message + symbol (amber) to indicate
that the tyre pressure is below the rec-
ommended value which ensures the
long life of the tyre and optimum fuel
consumption, and/or to indicate a slow
pressure leak. If two or more tyres are
in one of the above-mentioned condi-
tions, the display will show the message
relating to each tyre in succession. In
this case, it is advisable to check and ad-
just the tyre pressures (see “Technical
Specification” section).
X
n
n
165-180 Alfa 159 GB 4-06-2008 9:42 Pagina 179

180
SAFETY
DEVICES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
CORRECT USE
OF THE CAR
DASHBOARD
AND
CONTROLS
WARNING
LIGHTS AND
MESSAGES
LOW TYRE
PRESSURE
(where provided)
On certain versions the display will show
a warning message + symbol (red) (and
buzzer will sound) when the pressure of
one or more tyres falls below the preset
threshold. In this way the T.P.M.S. sys-
tem warns the driver that tyre/s is/are
dangerously flat; possible puncture.
IMPORTANTStop immediately with
one or more tyres flat, avoid braking
sharply and abrupt turns. Replace im-
mediately the punctured tyre with the
space-saver spare wheel (where provid-
ed) or repair the puncture tyre using the
proper kit (see paragraph “If a tyre is
punctured” in section “In an emer-
gency”) and then contact Alfa Romeo Au-
thorized Services as soon as possible.
TYRE PRESSURE
UNSUITABLE FOR
SPEED
(where provided)
Should it be required to journey at a
speed higher than 160 km/h, inflate
tyres at full load pressures (see paragraph
“Cold inflation pressures” in section "Tech-
nical Specifications").
On certain versions, if the T.P.M.S. sys-
tem detects that the pressure of one or
more tyres is unsuitable for the current
speed the display will show a message +
symbol (amber) that will stay on until the
car speed slow downs below the preset
threshold.IMPORTANT In this case slow down
immediately since tyre overheating could
impair tyre performance and life beyond
repair, and even make the tyre to blow-
out.
IMPORTANT Should you have to jour-
ney anyway a speed higher than 160
km/h, stop the car when the display
shows the warning symbol to inflate tyres
to the proper pressure values (see para-
graph "Cold inflation pressures" in section
"Technical Specifications ").
nn
165-180 Alfa 159 GB 4-06-2008 9:42 Pagina 180

181
SAFETY
DEVICES
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
CORRECT USE
OF THE CAR
DASHBOARD
AND
CONTROLS
IN AN
EMERGENCY
I I
N N
A A
N N
E E
M M
E E
R R
G G
E E
N N
C C
Y Y
In an emergency we recommend that you call the toll-free number found
on the Warranty Booklet. You can also connect to the site www.alfaromeo.com
to search for the nearest Alfa Romeo Authorized Services point.
JUMP STARTING ............................................... 182
IF A TYRE IS PUNCTURED................................... 183
QUICK TYRE REPAIR KIT
FIX&GO automatic............................................ 190
WHEN NEEDING TO CHANGE A BULB ................... 196
IF AN EXTERIOR LIGHT BURNS OUT ...................... 199
IF AN INTERIOR LIGHT BURNS OUT ...................... 205
IF A FUSE BLOWS ............................................. 209
IF THE BATTERY IS FLAT...................................... 219
JACKING THE CAR.............................................. 220
TOWING THE CAR ............................................. 221
181-222 Alfa 159 GB 4-06-2008 9:43 Pagina 181

182
SAFETY
DEVICES
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
CORRECT USE
OF THE CAR
DASHBOARD
AND
CONTROLS
IN AN
EMERGENCY
JUMP STARTING
If the battery is flat, it is possible to start
the engine using an auxiliary battery
with the same capacity or a little high-
er than the flat one.
Proceed as follows fig. 1:
❒ Connect positive terminals (+ near
the terminal) of the two batteries
with a jump lead;
❒ With a second lead, connect the neg-
ative terminal (–) of the auxiliary
battery and to an earthing point
E
on the engine of the car to be start-
ed;
❒Start the engine;
❒When the engine has been started,
remove the leads reversing the or-
der above.If after a few attempts the engine does
not start, do not insist but contact Alfa
Romeo Authorized Service.
IMPORTANTDo not directly connect
the negative terminals of the two bat-
teries: sparks could ignite the flamma-
ble gas from the battery. If the other bat-
tery is fitted in another car, prevent ac-
cidental contacts between the metal
parts of the two cars.
Under no circumstances
should a battery charger
be used to start the en-
gine: it could damage the elec-
tronic systems and in particular
the ignition and injection control
units.
Do not carry out this
procedure if you lack
experience; if it is not done
correctly it can cause very in-
tense electrical discharges. In
addition, the fluid contained in
the battery is poisonous and
corrosive. Avoid contact with
skin and eyes. You are also ad-
vised not to put naked flames
or lighted cigarettes near the
battery and not to cause
sparks.
WARNING
A0E0201mfig. 1
181-222 Alfa 159 GB 4-06-2008 9:43 Pagina 182

183
SAFETY
DEVICES
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
CORRECT USE
OF THE CAR
DASHBOARD
AND
CONTROLS
IN AN
EMERGENCY
IF A TYRE
IS PUNCTURED
For versions/markets where applicable,
the car can be equipped with the “Quick
tyre repair kit Fix&Go automatic“. Op-
erations required to change a wheel are
described in the following chapter.
As an alternative to the kit “Fix & Go
automatic”, the car can be provided (up-
on request) with space-saver spare
wheel or standard size spare wheel;
wheel changing and correct use of the
jack and space-saver spare wheel call for
some precautions as listed below.
BUMP STARTING
Never bump start the engine (by push-
ing, towing, or coasting downhill) as this
could cause fuel to flow into the catalytic
exhaust system and damage it beyond
repair.
Remember that the
brake booster and the
power steering system are not
operating until the engine is
started, a greater effort will
therefore be required to press
the brake pedal or turn the
steering wheel.
WARNING
Alert other drivers that
the car is stationary in
compliance with local regula-
tions: hazard warning lights,
warning triangle etc. Any pas-
sengers on board should leave
the car, especially if it is heav-
ily laden. Passengers should
stay away from oncoming
traffic while the wheel is be-
ing changed on. If the wheel is
being changed on a steep or
badly surfaced road, place the
wedges or other suitable ma-
terial under the wheel to stop
the car. Never start the engine
when the car is jacked up. If
you were towing a trailer, un-
couple the trailer before jack-
ing the car.
WARNING
181-222 Alfa 159 GB 4-06-2008 9:43 Pagina 183

184
SAFETY
DEVICES
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
CORRECT USE
OF THE CAR
DASHBOARD
AND
CONTROLS
IN AN
EMERGENCY
The space-saver spare
wheel (for versions/
markets where applicable) is
specific to your car; do not use
it on other models, or use the
spare wheel of other models
on your car. The space-saver
spare wheel shall only be used
in an emergency. It shall only
be used for the distance nec-
essary to reach a service point
and the car speed shall not ex-
ceed 80 Km/h. The spare
wheel has a sticker that sum-
marises the main cautions for
use and limitations. The stick-
er should never be removed or
covered!. Never fit a wheel
cap on a space-saver spare
wheel.
WARNING
When driving with a
space-saver spare
wheel fitted, the driving per-
formance of the car changes.
Avoid accelerating or braking
sharply, abrupt turns or fast
cornerings. The life of the
spare wheel is approx. 3000
Km, after this distance it
should be replaced with an-
other of the same type. Nev-
er attempt to fit a conven-
tional tyre on a rim designed
for use as a space-saver spare
wheel. Have the punctured
wheel repaired and refitted as
soon as possible. Two or more
space-saver spare wheels
should never be used togeth-
er. Do not grease the threads
of bolts before installing them:
they might slip out.
WARNING
The jack shall only be
used for changing
wheels on the car with which
it is provided or on cars of the
same model. It must not be used
for other purposes such as for
instance raising cars of other
models. In no case should it be
used for repairs under the car.
Incorrect positioning of the jack
may cause the jacked car to fall.
Do not use the jack for higher
capacities than stated on its la-
bel. Snow chains cannot be fit-
ted to the space-saver spare
wheel. So, if a front (drive)
wheel is punctured and chains
are needed, a rear wheel should
be fitted to the front of the car
and the spare wheel should be
fitted to the rear. This way with
two normal drive wheels, snow
chains can be fitted to them to
solve an emergency.
WARNING
181-222 Alfa 159 GB 4-06-2008 9:43 Pagina 184
