VERSIONS WITH RECONFIGURABLE MULTIFUNCTION DISPLAY
A Speedometer
B Reconfigurable multifunction display
C Rev counter
D Fuel level gauge with reserve warning light
E Engine coolant temperature gauge with overheating warning light
mcWarning lights present on diesel versions only. On diesel versions, the end of scale for the rev counter is 6000 rpm
IMPORTANT The illumination of the instrument panel graphics may vary according to versions.
A0K0003m
290
RIGHT-HAND DRIVE VERSIONS
281-292 Alfa Giulietta EN 5ed 26-07-2010 16:37 Pagina 290

291
RIGHT-HAND DRIVE VERSIONS
CHANGING A FUSE
FUSEBOX ON DASHBOARD
Insert a hand in the seat A-fig. 1 and lower the flap B to access the fuses. The fuses are located in the fusebox shown in fig. 2.
NOTE For fuse protected devices refer to the description of “In an emergency” chapter.
fig. 1A0K0246mfig. 2A0K0245m
281-292 Alfa Giulietta EN 5ed 26-07-2010 16:37 Pagina 291

CUSTOMER SERVICESTECHNICAL SERVICES - SERVICE ENGINEERING
Largo Senatore G. Agnelli, 5 - 10040 Volvera - Torino (Italia)
Fiat Group Automobiles S.p.A.
Print n. 60438182 - 5 Edition - 07/2010
All rights reserved. Reproduction, even partial, without written authorisation
from Fiat Group Automobiles S.p.A. is prohibited
