DIMENSIONS
Dimensions are expressed in inches/mm and refer to the car equipped with its original tyres. Height is measured with an unladen
vehicle, with the driver.
AB C D E F GHI
33.9 / 861110.94
/
281839.68 / 1008184.5 /
468765.78 / 1671(*)65.6 / 1666(**)63.5 / 161365.08 /
165385.16 /
216374.9 /
1903
(*) AWD versions
(**) RWD versions
Small variations with respect to the reported values are possible depending on the dimensions of the rims.
18610106V0001EM
199

WEIGHTS
Weights (lb / kg)2.0 T4 MAir
200 HP 280 HP
Unladen weight (with all fluids, fuel tank filled to 90% and without optional equipment) 3660 / 1660 3660 / 1660
Payload including the driver
(*)1411 / 640 1411 / 640
Maximum permitted loads
(**)
– front axle2359 / 1070 2359 / 1070
– rear axle2910 / 1320 2910 / 1320
– total5070 / 2300 5070 / 2300
Maximum combined load (permitted maximum load + towable weight trailer with brakes)
(***)8580 / 3900 10120 / 4600
Towable loads
– braked trailer3520 / 1600 5070 / 2300
– trailer without brakes1653 / 750 1653 / 750
Maximum load on roof165 / 75 165 / 75
Maximum load on tow hitch (trailer with brakes) 141 / 64 209 / 95
(*) If special equipment is fitted (trailer towing equipment, etc.) the empty weight will increase and consequently the payload will decrease in relation to the maximum
permitted loads.
(**) Loads not to be exceeded. The user is responsible for arranging goods in the luggage compartment and/or on the load platform within the maximum permitted loads.
(***) Never exceed the maximum combined vehicle load value: the maximum towable load is only allowed if it does not exceed the maximum combined vehicleload.
200
TECHNICAL DATA

Weights (lb / kg)2.2 JTD
160 HP/ 190 HP
RWD190 HP / 210 HP
AW D
Unladen weight (with all fluids, fuel tank filled to 90% and without optional equipment) 3652 / 1604 3839 / 1745
Payload including the driver
(*)1474 / 670 1463 / 665
Maximum permitted loads
(**)
– front axle2288 / 1040 2398 / 1090
– rear axle2888 / 1310 2948 / 1340
– total5126 / 2330 5302 / 2410
Maximum combined load (permitted maximum load + towable weight trailer with brakes)
(***)8646 / 3930 10362 / 4710
Towable loads
– braked trailer3527 / 1600 5137 / 2330
– trailer without brakes1653 / 750 1653 / 750
Maximum load on roof165 / 75 165 / 75
Maximum load on tow hitch (trailer with brakes) 141 / 64 209 / 95
(*) If special equipment is fitted (trailer towing equipment, etc.) the empty weight will increase and consequently the payload will decrease in relation to the maximum
permitted loads.
(**) Loads not to be exceeded. The user is responsible for arranging goods in the luggage compartment and/or on the load platform within the maximum permitted loads.
(***) Never exceed the maximum combined vehicle load value: the maximum towable load is only allowed if it does not exceed the maximum combined vehicleload.
201

REFUELLING
80) 81)
2.0 T4 MAir 2.2 JTDPrescribed fuels and original
lubricants
Fuel tank (UK gal / litres) 14 / 64
12.7 (58) / 14 (64)(*)
Unleaded petrol with RON no
lower than 95
(EN228 specifications)
(2.0 T4 MAir engine) / Automotive
diesel fuel (EN590 and
EN16734 specifications)
(2.2 JTD engine) including a reserve of (UK gal /
litres) (2.0 T4 MAir engine)2.11 / 9.6 –
including a reserve of (UK
gal/litres) (2.2 JTD engine with
12.7 UK gal/58 litre fuel tank)– 1.98 / 9.0
including a reserve of (UK
gal/litres) (2.2 JTD engine with
14 UK gal/64 litre fuel tank)– 2.2 / 10
AdBlue® tank (where provided)
(UK gal / litres)– 3.5 / 16.1AdBlue® (DIN 70 070 and ISO
22241-1 specifications)
(2.2 JTD engine)
Main tank cooling system (UK gal/
litres)1.93 (8.8) / 2.03 (9.25)
(**)1.71 (7.8) / 1.75 (8.0)(***)50% mixture of distilled water
and PARAFLU UP(*****)Secondary tank cooling system
(UK gal / litres)0.95 (4.3) / 1.15 (5.25)(**)1.03 (4.7)(****)
(*) For markets, where provided
(**) 280 HP versions
(***) 190 HP / 210 HP versions
(*****) When the vehicle is used in particularly harsh weather conditions, we recommend using a 60% mixture of PARAFLU UP and 40% demineralised water.
(****) Only 2.2 JTD 190 HP / 210 HP AWD versions with automatic transmission
202
TECHNICAL DATA

2.0 T4 MAir 2.2 JTDPrescribed fuels and original
lubricants
Engine oil filter (UK gal / litres) 0.13 / 0.6 0.11 / 0.5SELENIA DIGITEK P.E.
(2.0 T4 MAir engine) / SELENIA
W.R. FORWARD 0W-20 (2.2 JTD
engine) (versions with AdBlue®) /
SELENIA W.R. FORWARD 0W-20
(2.2 JTD 150 HP / 180 HP
engines) (versions without
AdBlue®) / SELENIA W.R.
FORWARD 0W-30 (2.2 JTD
210 HP engines) (versions without
AdBlue®) Engine oil sump (UK gal / litres) 1.01 / 4.6 0.85 / 3.9
Hydraulic brake circuit
(UK gal / litres)0.2 / 0.9 0.02 / 0.9TUTELA BRAKE FLUID
EXTREME HT
Windscreen washer tank
(UK gal / litres)0.9 / 4.1 0.92 /4.2 PETRONAS DURANCE SC 35
Automatic transmission
(UK gal / litres)– 2.0 / 9.1
TUTELA TRANSMISSION AS8 Automatic transmission AWD
(UK gal / litres)2.05 / 9.3 –
Automatic transmission RWD
(UK gal / litres)2.07 / 9.4 –
RDU 230-LSD differential
(UK gal / litres)0.2 / 0.9 0.2 / 0.9
TUTELA TRANSMISSION LS
AXLE FLUID
RDU 210/215-LSD differential
(UK gal / litres)0.24 / 1.1 0.24 / 1.1
203

2.0 T4 MAir 2.2 JTDPrescribed fuels and original
lubricants
AWD System FAD transfer case
(UK gal / litres)0.11 / 0.5 0.11 / 0.5TUTELA TRANSMISSION
HYPOIDE GEAR OIL
AWD System TRANSFER CASE
(UK gal / litres)0.15 / 0.7 0.15 / 0.7TUTELA TRANSMISSION
TRANSFER CASE
IMPORTANT
80)Only use AdBlue®(UREA) compliant with DIN 70 070 and ISO 22241-1. Other fluids may cause damage to the system: also exhaust emissions
would no longer comply with the law.
81)The distribution companies are responsible for the compliance of their product. Observe the precautions of storage and maintenance, in order
to preserve the initial qualities. The manufacturer will not recognise any guarantee in case of malfunctions and damage caused to the car due to
the use of AdBlue
®not in accordance with regulations.
204
TECHNICAL DATA

FLUIDS AND LUBRICANTS
Your vehicle is equipped with an engine oil that has been thoroughly developed and tested in order to meet the requirements of the
Scheduled Servicing Plan. Constant use of the prescribed lubricants guarantees the fuel consumption and emission specifications.
Lubricant quality is crucial for engine operation and duration.
82)
PRODUCT SPECIFICATIONS
ENGINE LUBRICATION
Use Features SpecificationOriginal fluids and
lubricantsReplacement interval
2.0 T4 MAirSAE 0W-30
ACEA C29.55535–GS1SELENIA DIGITEK P.E.
Contractual Technical
Reference No.F020.B12According to Scheduled
Servicing Plan
2.2 JTDSAE 0W-20
ACEA C29.55535–DSXSELENIA W.R. FORWARD
0W-20
Contractual Technical
Reference No. F013.K15According to Scheduled
Servicing Plan
2.2 JTD 210 HP
(*)SAE 0W-30
ACEA C29.55535–DS1SELENIA W.R. FORWARD
0W-30
Contractual Technical
Reference N°842.F13According to Scheduled
Servicing Plan
(*) Versions without AdBlue - UREA.
If lubricants conforming to the specific request are not available, products that meet the indicated specifications can be used to top
up; in this case optimal performance of the engine is not guaranteed.
205

Use Features SpecificationOriginal fluids and
lubricantsApplications
Lubricants and greases
fordrive transmissionATF Synthetic lubricant 9.55550-AV5TUTELA TRANSMISSION
AS 8
Contractual Technical
Reference No. F139.I11Automatic transmission
SAE 75W-85 synthetic
lubricant9.55550-DA9TUTELA TRANSMISSION
LS AXLE FLUID
Contractual Technical
Reference No. F059.N15Differential RDU 230-LSD
and RDU 210/215 -LSD
SAE 75W-85 API
GL-5 synthetic lubricant9.55550-DA8TUTELA TRANSMISSION
AXLE-DRIVE
Contractual Technical
Reference N°F058.N15Differentials and reduction
gears RDU 230-TV
(2.9 V6 engine)
SAE 75W-80 APL
GL-5 synthetic lubricant9.55550-DA10TUTELA TRANSMISSION
HYPOIDE GEAR OIL
Contractual Technical
Reference n° F060.N15AWD System FAD transfer
case
SAE 75W synthetic
lubricant9.55550-DA11TUTELA TRANSMISSION
TRANSFER CASE
Contractual Technical
Reference No. F061.N15AWD System TRANSFER
CASE
Lubricants and greases
for drive transmissionNLGI 0-1 grease for
constant velocity joints
with low friction
coefficient9.55580-GRAS IITUTELA STAR 700
Contractual Technical
Reference No. F701.C07Differential side constant
velocity joints
NLGI 1-2 molybdenum
disulphide grease for high
temperatures9.55580-GRAS IITUTELA ALL STAR
Contractual Technical
Reference No. F702.G07Wheel side constant
velocity joints
Brake fluid DOT 4 9.55597TUTELA BRAKE FLUID
EXTREME HT
Contractual Technical
Reference No. F001.N15Hydraulic brakes and clutch
controls
206
TECHNICAL DATA

Use Features SpecificationOriginal fluids and
lubricantsApplications
Protective agent for
radiatorsP
rotective with antifreeze,
ethylene glycol based
organic formula, free from
amine and 2–EH (2–ethyl
hexanoic acid), containing
corrosion inhibitors and
anti-foam additives. CUNA
NC 956-16, ASTM D 33069.55523 or MS.90032PARAFLU UP
Contractual Technical
Reference N°F101.M01Use rate 50% Not mixable
with different formulation
products
(*)
Windscreen washer
fluidCUNA NC 956-11 9.55522PETRONAS DURANCE SC
35
Contractual Technical
Reference N° F001.D16To be used diluted or
undiluted in windscreen
washer/wiper systems
AdBlue® additive for
diesel emissionsWater-AdBlue® solutionDIN 70 070 and ISO
22241-1AdBlue®To be used for filling the
AdBlue® tank on vehicles
equipped with Selective
Catalytic Reduction (SCR)
system (2.2 JTD engine)
Diesel fuel additiveAntifreeze additive for
diesel fuel for diesel engine
protectionPETRONAS DURANCE
DIESEL ART
Contractual Technical
Reference N°F601.C06To be mixed with diesel fuel
(25 cc per 10 litres)
Automatic climate
control system (HVAC)R1234yf or R134a
(depending on market)
(*) When the vehicle is used in particularly harsh weather conditions, we recommend using a 60% mixture of PARAFLU UP and 40% demineralised water.
IMPORTANT
82)The use of products with different specifications than those indicated above could cause damage to the engine that is not covered by the
warranty.
207

PERFORMANCE
Top performance after the initial period of car usage.
Versions Maximum speed (mph / km/h)Acceleration from 0-60 mph /
(0-100 km/h) (sec.)
2.0 T4 MAir 200 HP AWD134 / 215 7.2
2.0 T4 MAir 280 HP AWD143 / 230 5.7
2.2 JTD 150 HP RWD
(*)123 / 198 8.8
2.2 JTD 160 HP RWD123 / 198 8.8
2.2 JTD 180 HP RWD
(*)130 / 210 7.6
2.2 JTD 190 HP RWD130 / 210 7.6
2.2 JTD 180 HP AWD
(*)130 / 210 7.6
2.2 JTD 190 HP AWD130 / 210 7.6
2.2 JTD 210 HP AWD134 / 215 6.6
(*) For versions/markets where specified
208
