Allroad quattro control strategies
4-level air suspension + additional shift stage
0203580 60
5100 120 130 200
30
General overview
Control unit 4Z7 907 553A/B
ESP safety-switching
Automatic lowering
Parking level
control
v >70 km/h: Engine intervention
v >50 km/h: Acoustic and visual warning in low range
Air supply: control primarily via
pressure accumulator <36 km/hVehicle speed v
in km/h
v <30 km/h: shift to low range possible
Additional shift stage
Air supply: control primarily via compressor >36 km/h
Pressure accumulator filled >36 km/h
Motorway mode:Lowering: >120 km/h >30 seconds
Raising: <70 km/h >120 seconds
<35 km/h >30 seconds
<5 km/h immediately
Manual mode:- no parking level control
- no motorway mode
- automatic lowering from HL2
and HL1; ESP safety-
switching remains active
Automatic mode:- parking level control (HL1)
- motorway mode:
- automatic lowering from HL2 and HL1.
- ESP safety-switching
LL NL HL1 HL2243_040
Control unit 4Z7 907 553B: Automatic mode:- no parking level control
- automatic raising to HL1
<60 km/h >30 seconds
<30 km/h immediately
