BMW MOTORRAD K 1200 S 2007 Rider's Manual (in English)

Engine-oil level too lowOil-level symbol appears on
the display.Check Oil
appears on the
display.
The electronic oil-level sensor
has registered an excessively low
oil level.
Checking the oil sight glass is
the only way of ascertaining the
exact engine-oil level. The next
time you stop for fuel:
Check the engine oil level
( 97)
If the oil level is too low:
Top up the engine oil ( 98)
The oil sensor might be defective
if the "Check oil level" message
appears even though a check of
the oil sight glass shows that the
oil level is correct. Seek the advice of a specialist
workshop, preferably an author-
ised BMW Motorrad dealer. Ice warning
Ice-crystal symbol appears
on the display.
The air temperature measured
at the motorcycle is lower than
3°C. The ice warning does not
mean that there is no risk
of black ice forming at measured
temperatures above 3 °C.
Always take extra care and think
well ahead when temperatures
are low; remember that the
danger of black ice is particularly
high on bridges and where the
road is in the shade.
Ride carefully and think well
ahead.
ABS warningsMode of presentation
ABS warnings are indicated by
ABS warning light 1.
The way in which the ABS warn-
ing light indicates status can dif-
fer in some countries.
Possible national variant.
The detailed descriptions relating
to BMW Motorrad Integral ABS
start on page ( 80), and you
will find an overview listing the
possible warnings on the next
page.
329zStatus indicators

Warnings, overviewMeaning
Flashes ABS self-diagnosis not completed
( 31)
Lights up ABS fault ( 31)
330zStatus indicators

ABS self-diagnosis not
completedABS warning light flashes.
The ABS function is not
available, because self-
diagnosis did not complete. The
motorcycle has to move forward
a few metres for the wheel
sensors to be tested. Pull away slowly. Bear in mind
that the ABS function is not
available until self-diagnosis has
completed.
ABS fault ABS warning light shows.
The ABS control unit has detec-
ted a fault. The ABS function is
not available. You can continue to ride the
motorcycle, but make due pro-
vision for the fact that the ABS
function is not available. Bear in mind the more detailed in-
formation on situations that can
lead to an ABS fault ( 81).
Have the fault rectified as
quickly as possible by a
specialist workshop, preferably
an authorised BMW Motorrad
dealer.
ASC warnings
OE
Mode of presentation
ASC warnings are indicated by a
combination of the ASC warning
symbol 2and 'General' warning
light 1. The detailed descriptions relating
to BMW Motorrad ASC start on
page ( 82), and you will find
an overview listing the possible
warnings on the next page.
331zStatus indicators

Warnings, overviewMeaning
Quick-flashes yel-
lowAppears on the dis-
play
ASC intervention ( 33)
Slow-flashes Self-diagnosis not completed ( 33)
Appears on the dis-
play ASC switched off ( 33)
Lights up yellow Appears on the dis- playASC fault ( 33)
332zStatus indicators

ASC interventionGeneral warning light quick-
flashes yellow.
ASC symbol appears on
the display.
The ASC has detected a degree
of instability at the rear wheel
and has intervened to reduce
torque. The warning light flashes
for longer than ASC intervention
lasts. This affords the rider visual
feedback on control intervention
even after the critical situation
has been dealt with.
Self-diagnosis not completed ASC symbol flashes.
Self-diagnosis did not complete,
so the ASC function is not avail-
able. The engine must be run-
ning and the motorcycle must
reach a speed of at least 5 km/h
in order for ASC self-diagnosis to
complete. Pull away slowly. Bear in mind
that the ASC function is not
available until self-diagnosis has
completed.
ASC switched off ASC symbol appears on
the display.
The rider has switched off the
ASC system.
with OE Automatic Stability
Control (ASC): Activate the ASC function
( 56)
ASC fault General warning light shows
yellow.
ASC symbol appears on
the display.
The ASC control unit has detec-
ted a fault. The ASC function is
not available. You can continue to ride. Bear
in mind that the ASC function is not available. Bear in mind
the more detailed information
on situations that can lead to
an ASC fault ( 83).
Have the fault rectified as
quickly as possible by a
specialist workshop, preferably
an authorised BMW Motorrad
dealer.
RDC warnings
OE
Mode of presentation
Warning symbol 2indicates a
critical tyre pressure, and the cor-
responding reading for the front
333zStatus indicators

tyre pressure3or the rear tyre
pressure 4flashes.
If the critical value is close to the
limit of the permissible tolerance
range, 'General' warning light 1
shows yellow. If the tyre pres-
sure registered by the sensor is
outside the permissible tolerance
range, the 'General' warning light
flashes red.
The detailed descriptions relating
to BMW Motorrad RDC start on
page ( 84), and you will find
an overview listing the possible
warnings on the next page.
334zStatus indicators

Warnings, overviewMeaning
Lights up yellow Tyre pressure close to limit of permitted
tolerance ( 36)
the critical tyre
pressure flashes.
Flashes red Tyre pressure outside permitted toler- ance ( 36)
the critical tyre
pressure flashes.
"
--
"or"
-- --
"
appears on the dis-
play Signal transmission disrupted ( 36)
Lights up yellow Sensor defective or system error
( 37)
"
--
"or"
-- --
"
appears on the dis-
play
Lights up yellow
RDC!
appears on
the display. Battery of tyre-pressure sensor weak
( 37)
335zStatus indicators

Tyre pressure close to limit
of permitted toleranceGeneral warning light shows
yellow.
Tyre symbol appears on
the display.
The critical tyre pressure flashes.
Measured tyre pressure is close
to the limit of permitted toler-
ance. Correct the tyre pressure as
stated on the inside cover of
the Rider's Manual.
The tyre-pressures listed
on the inside cover are
temperature-compensated; the
reference tyre temperature for
these readings is always 20 °C.
The procedure for correcting tyre
pressures when the tyres are not
at this reference temperature is
as follows:
Calculate the difference between
the specified value stated in the
Rider's Manual and the reading shown by the RDC system. Use
the public air line at a petrol sta-
tion or motorway service area to
adjust the tyre pressure by this
amount.
Tyre pressure outside
permitted tolerance
General warning light
flashes red.
Tyre symbol appears on
the display.
The critical tyre pressure flashes.
Measured tyre pressure is out-
side permitted tolerance. Check the tyre for damage and
to ascertain whether the mo-
torcycle can be ridden with the
tyre in its present condition.
If the motorcycle can be ridden
with the tyre in its present condi-
tion:
Incorrect tyre pressures im-
pair the motorcycle's hand-
ling characteristics. If tyre pressure is incorrect it is
essential to adapt your style of
riding accordingly.
Correct the tyre pressure at the
earliest possible opportunity.
Have the tyre checked for
damage by a specialist
workshop, preferably an
authorised BMW Motorrad
dealer.
If you are unsure whether the
motorcycle can be ridden with
the tyre in its present condition: Do not continue your journey.
Notify the breakdown service.
Have the tyre checked for
damage by a specialist
workshop, preferably an
authorised BMW Motorrad
dealer.
Signal transmission
disrupted
"
--
"or"
-- --
" appears on
the display.
336zStatus indicators

The motorcycle has not yet ac-
celerated past the threshold of
approximately 30 km/h. The
RDC sensors do not start trans-
mitting signals until the motor-
cycle reaches a speed above this
threshold ( 84).Increase speed above this
threshold and observe the RDC
readings. Assume that a per-
manent fault has not occurred
unless the 'General' warning
light comes on to accompany
the symptoms. Under these
circumstances:
Have the fault rectified by a
specialist workshop, preferably
an authorised BMW Motorrad
dealer.
Wireless communication with the
RDC sensors has been disrupted.
Possible causes include radio-
communication systems operat-
ing in the vicinity and interfering with the link between the RDC
control unit and the sensors.
Move to another location and
observe the RDC readings. As-
sume that a permanent fault
has not occurred unless the
'General' warning light comes
on to accompany the symp-
toms. Under these circum-
stances:
Have the fault rectified by a
specialist workshop, preferably
an authorised BMW Motorrad
dealer.
Sensor defective or system
error General warning light shows
yellow.
Tyre symbol appears on
the display.
"
--
"or"
-- --
" appears on
the display. Motorcycle is fitted with wheels
not equipped with RDC sensors.
Fit wheels and tyres equipped
with RDC sensors.
One or two RDC sensors have
failed. Have the fault rectified by a
specialist workshop, preferably
an authorised BMW Motorrad
dealer.
A system error has occurred. Have the fault rectified by a
specialist workshop, preferably
an authorised BMW Motorrad
dealer.
Battery of tyre-pressure
sensor weak General warning light shows
yellow.
RDC!
appears on the display.
This error message appears
only briefly after the pre-
ride check completes.
337zStatus indicators

The integral battery in the tyre-
pressure sensor has lost a sig-
nificant proportion of its original
capacity. There is no assurance
of how long the tyre pressure
control system can remain opera-
tional.Seek the advice of a specialist
workshop, preferably an author-
ised BMW Motorrad dealer.
Anti-theft alarm
warnings
OE
Mode of presentation
Anti-theft alarm warnings appear
as plain-text warnings 2in com-
bination with the 'General' warn-
ing light 1showing after the Pre-
Ride Check and relate to the ca-
pacity of the internal battery that
supplies power to the anti-theft
alarm.
The possible warnings are listed
on the next page.
338zStatus indicators
