Delayed Entry Lighting
When you open the door, the interior lamps will come
on. When you close the door with the ignition off, the
interior lamps will stay on for 25 seconds or until the
ignition is turned to an on position. Locking the doors
with the power door lock switch will override the
delayed entry lighting feature and the lamps will
turn off right away.
Using the remote keyless entry transmitter to lock the
door will not cancel delayed lighting.
Theater Dimming
This feature allows for a three to five-second fade out
of the courtesy lamps instead of immediate turn off.
Delayed Exit Lighting
With this feature, the interior lamps will come on for
25 seconds after you remove the key from the ignition.
This will give you time to find the door handle or
lock switches.
Parade Dimming
This feature prohibits the dimming of your instrument
panel displays during daylight while your headlamps are
on. This feature operates with the light sensor for the
Twilight Sentinel and is fully automatic. When the light
sensor reads darkness outside, you will be able to dim
your instrument panel displays once again.
Perimeter Lighting
When the button with the unlock symbol on the remote
keyless entry transmitter is pressed, the DRL, parking
lamps and back
-up lamps will come on if it is dark
enough outside.
This feature will only be activated when the security
feedback feature is programmed to be in Modes 1, 3 or 5
on the transmitter. Modes 0, 2 and 4 do not respond with
exterior lights flashing when unlocking the vehicle so
perimeter lighting will not be active.
This feature can be programmed on or off for
each transmitter.

2-49
To turn the feature off do the following:
1. Press and hold LOCK on the door lock switch on the
door throughout this procedure. All doors will lock.
2. Press the instant alarm button on the transmitter to enter
the programming mode. Perimeter lighting remains on
at this time and the horn will chirp two times.
3. Press the instant alarm button on the transmitter
again. Perimeter lighting is disabled and the horn
will chirp one time.
4. Release the door lock switch. The perimeter lighting
feature is now off.
To turn the feature on do the following:
1. Press and hold LOCK on the door lock switch
throughout this procedure. All doors will lock.
2. Press the instant alarm button on the transmitter to
enter the programming mode. Perimeter lighting
remains off at this time and the horn will chirp
one time.
3. Press the instant alarm button on the transmitter
again. Perimeter lighting is now enabled and the
horn will chirp two times.
4. Release the door lock switch. The perimeter lighting
feature is now on.Perimeter lighting can also be activated through the
DIC. See ªPersonal Choice Featuresº or ªDriver
Information Center (DIC)º in the Index.
Front Reading Lamps
The front reading lamps, located on the headliner, and
the interior courtesy lamps will come on when you open
a door. They will turn off when you turn on the ignition.
To turn on the front seat reading lamps when the doors
are closed, press the button behind the lamp you want
on. Press it again to turn the lamp off.
These lamps work even when the ignition is off.

2-50
Rear Reading Lamps
To turn on a rear seat reading lamp, press the button
above that rear door. To turn off the reading lamp, press
the button again.
Trunk Lamp
When you open the trunk to its full open position, a
lamp will come on inside the trunk. This lamp will
automatically turn off when the trunk is closed.
Glove Box Lamp
When you open the glove box, a lamp will come on
inside the glove box. This will automatically turn off
when the glove box is closed.
Battery Rundown Protection
This feature shuts off all lamps that are left on for more
than 10 minutes when the ignition is off. This will keep
your battery from running down.
Mirrors
Inside Manual Day/Night Rearview Mirror
When you are sitting in a comfortable driving position,
adjust the mirror so you can see clearly behind your
vehicle. Grip the mirror in the center to move it up or
down and side to side. The day/night adjustment allows
you to adjust the mirror to avoid glare from the lamps
behind you. Pull the tab forward for daytime use; push it
back for night use.

2-51 Electrochromic Day/Night Rearview Mirror
with Compass (If Equipped)
Your vehicle may have an electrochromic inside
rearview mirror with a compass. Your vehicle's mirror
may also contain OnStar

controls.
(On/Off): This is the on/off button for mirrors
equipped with OnStar controls.
Pressing the MIRROR button (or the on/off button for
mirrors equipped with OnStar controls) located at the
bottom of the mirror, turns the automatic dimming
feature on or off.
The mirror also includes an eight
-point compass
display in the upper right corner of the mirror face.
When on, the compass automatically calibrates as
the vehicle is driven.
When cleaning the mirror, use a paper towel or similar
material dampened with glass cleaner. Do not spray
glass cleaner directly on the mirror as that may cause
the liquid cleaner to enter the mirror housing.Mirror Operation
To turn on the automatic dimming feature, press
MIRROR (or press and hold the on/off button for
about three seconds for mirrors equipped with OnStar
controls). To turn off automatic dimming, press
MIRROR (or press and hold the on/off button for
about three seconds for mirrors equipped with OnStar
controls) again. The green indicator light will be
illuminated when this feature is active. The automatic
dimming feature will be active each time the vehicle
is started.
Compass Operation
Press COMPASS (or the on/off button for mirrors
equipped with OnStar controls) once to turn the
compass on or off.
When the ignition and the compass feature are on,
the compass will show two character boxes for
approximately two seconds. After two seconds, the
mirror will display the compass heading.

2-52
Compass Calibration
If, after two seconds, the display does not show a
compass heading (N for North, for example), there may
be a strong magnetic field interfering with the compass.
Such interference may be caused by a magnetic antenna
mount, magnetic note pad holder or a similar magnetic
item. If the letter C should ever appear in the compass
window, the compass may need calibration.
The mirror can be calibrated by driving the vehicle in
circles at 5 mph (8 km/h) or less until the display reads
a direction.
Mirrors equipped with OnStar controls can be placed in
calibration mode by pressing and holding the on/off
button until a C is shown in the compass display.
Compass Variance
The mirror is set in zone eight upon leaving the factory.
It will be necessary to adjust the compass to compensate
for compass variance if you live outside zone eight.
Under certain circumstances, as during a long distance
cross
-country trip, it will be necessary to adjust for
compass variance. Compass variance is the difference
between earth's magnetic north and true geographic
north. If not adjusted to account for compass variance,
your compass could give false readings.To adjust for compass variance, do the following:
1. Find your current location and variance zone number
on the following zone map.
2. Press and hold COMPASS (or the on/off button for
mirrors equipped with OnStar controls) until a zone
number appears in the display.

2-53
3. Once a zone number appears in the display, press the
COMPASS button (or the on/off button for mirrors
equipped with OnStar controls) quickly until the
correct zone number appears in the display. Stop
pressing the button and the mirror will return to
normal operation. If C appears in the compass
window, the compass may need calibration. See
ªCompass Calibrationº explained previously.
Power Remote Control Outside
Rearview Mirrors
Your vehicle has power mirror controls located on the
driver's door armrest.Press L or R on the selector switch located below the
control pad to choose the right or left mirror. If you
place the switch in the center position, no mirror
movement will occur. To adjust a mirror, use the arrows
located on the control pad to move the mirror in the
direction you want it to go.
Adjust each mirror so you can see some of the side of
your vehicle and the area behind your vehicle.
If your vehicle is equipped with the memory seat and
mirrors feature, these mirror positions, along with the
driver's seat position can be stored in memory. See
ªMemory Seat and Mirrorsº in the Index.
Parallel Park Assist Mirror (If Equipped)
If you have the DIC feature, the passenger's outside
rearview mirror also includes a tilt
-down feature that
operates when the shift lever is in REVERSE (R).
When the vehicle is shifted out of REVERSE (R), the
passenger mirror will return to its original position after
a five
-second delay. This delay prevents movement of
the mirror if multiple gear transitions (reverse to drive to
reverse) occur during a parallel parking maneuver. This
feature can be programmed on or off through the
personal choice selection menu. See ªDriver
Information Centerº or ªPersonal Choice Featuresº
in the Index for programming instructions.

2-54
Convex Outside Mirror
Your passenger's side mirror is convex. A convex
mirror's surface is curved so you can see more from the
driver's seat.
CAUTION:
A convex mirror can make things (like other
vehicles) look farther away than they really are.
If you cut too sharply into the right lane, you
could hit a vehicle on your right. Check your
inside mirror or glance over your shoulder
before changing lanes.
Automatic Dimming/Heated Outside
Rearview Mirror (If Equipped)
If you have this feature, the driver's side outside
rearview mirror will adjust for the glare of headlamps
behind you. This feature is controlled using the on and
off settings on the automatic electrochromic day/night
rearview mirror. See ªAutomatic Electrochromic
Day/Night Rearview Mirrorº earlier in this section.
If you have this feature, the left and right outside mirrors
are also heated when you activate the rear window
defogger. See ªRear Window Defoggerº in the Index.
Both outside mirrors can be folded forward or rearward.
In the rearward position, they will fold flush with the
vehicle. This feature is particularly useful in automatic
car washes.
Storage Compartments
Glove Box
Use the key to lock and unlock the glove box. To
open the glove box, pull the handle upward until the
latch opens.

2-55 Garage Door Opener Compartment
The garage door opener storage area is located in the
headliner near the reading lamps. The following chart
and instructions will help you install your garage door
opener in the overhead storage area.
1. Push the extended tab (above the GARAGE button)
or insert a screwdriver between the tab and outer
edge of the cover. The garage door opener cover will
flip down.
2. Remove the square height adapters from the cover.
Refer to the chart to determine the number and
location of the height adapters for your garage door
opener. If your unit does not appear on the chart, you
will have to try different adapter number and
location combinations.

2-56
Your Garage Door TransmitterVehicle Console Door
NameModelButtonPosition For
Adapter(s)Number Of
Adapter(s)
MULTIELMAC30331ÐÐ
263
363
4ÐÐ
MULTIELMAC1048142
MULTIELMAC1087152
MULTIELMAC3060164
MULTIELMAC1098152
272
OVERHEADOO1-BTN 22311 OR 103 DOOR
OVERHEADOO2-BTN 2651103DOOR213
OVERHEADOO3-BTN 2421103DOOR2103
313
OVERHEADOO4-BTN 2321103DOOR2103
313
413
PULSAR921143
PULSAR931143
Your Garage Door TransmitterVehicle Console Door
NameModelButtonPosition For
Adapter(s)Number Of
Adapter(s)
CHAMBERLAING-3684154
CRUSADER1-BUTTON193
GENIEAT85P133
GENIEAT85154
GENIEAT90154
GENIEMAT85164
GENIEMAT90164
GENIEAT285P1103
213
GENIEAT951103
233
313
LIFTMASTERG3446123
LIFTMASTERG3456123
LINEARDT2A163
263
LINEARD22A143
LINEAREK-11/H142
LINEARET-2164
LINEARD22B163
263
(Continued)

2-57
Your Garage Door TransmitterVehicle Console Door
NameModelButtonPosition For
Adapter(s)Number Of
Adapter(s)
PULSAR832193
233
PULSAR833193
233
PULSAR832C143
233
313
PULSAR833B154
PULSARPDX-9921143
SEARS9B53738164
SEARS9B53708122
SHIMART-18143
STANLEY1047153
STANLEY1050163
STANLEY1076163
263
STANLEY1079163
263
STANLEY1075163
263
STANLEY331-1052164
Your Garage Door TransmitterVehicle Console Door
NameModelButtonPosition For
Adapter(s)Number Of
Adapter(s)
LINEARDT41103
LINEARDT4283
333
413
LINEARD4B1103
283
333
413
MICOMESP-T-9R163
MICOMESP-T-9163
MULTIELMAC3010163
MULTIELMAC3089143
MULTIELMAC3070164
MULTIELMAC3032163
MULTIELMAC3032263
MULTIELMAC1054163
MULTIELMAC30341ÐÐ
263
363
4ÐÐ
