Mode 2:Exterior Lamps Flash Only
•When you use the remote keyless entry transmitter
to lock or unlock your vehicle, your headlamps and
parking lamps willflash briefly to let you know
the command has been received.
Mode 3:Exterior Lamps Flash and Horn Sound
•When you use the remote keyless entry transmitter
to lock your vehicle, your headlamps and parking
lamps willflash briefly on each press and your horn
will sound briefly on the second or any other
press to let you know the command has been
received.
•When you use the remote keyless entry transmitter
to unlock your vehicle, your headlamps and parking
lamps willflash briefly to let you know the
command has been received.
Your vehicle was originally programmed to Mode 3. The
mode may have been changed since then. To
determine the current mode, or to change the mode, do
the following:
1. Follow the instructions forEntering Programming
Mode on page 2-46.
2. Press the LOCK button on the remote keyless entry
transmitter.
3. Count the number of chimes you hear. The number
of chimes indicates the vehicle’s current
programmed mode. If you do not wish to changethe current mode, you can either exit the
programming mode by following the instructions
later in this section or program the next feature
available on your vehicle.
4. Press LOCK on the remote keyless entry transmitter
to change the current mode until you hear the
number of chimes corresponding to the mode
selection you want.
The mode you selected is now set. You can now exit
the programming mode by following the instructions next
in this section.Exiting Programming Mode
To exit programming mode, do one of the following:
•Press the odometer button, while in odometer mode
for two seconds, or
•turn the ignition key out of ON, or
•do not program any commands for one minute
while in programming mode, or
•shift out of PARK (P). SeeShifting Out of Park (P)
on page 2-28.
The programming mode message will turn off to let you
know that you are no longer in the programming mode.
2-51
2003 - Rendezvous OM

Instrument Panel Overview...............................3-4
Hazard Warning Flashers................................3-5
Other Warning Devices...................................3-6
Horn .............................................................3-6
Tilt Wheel.....................................................3-6
Turn Signal/Multifunction Lever.........................3-7
Exterior Lamps.............................................3-12
Interior Lamps..............................................3-14
Instrument Panel Switchbank..........................3-18
Head-Up Display (HUD).................................3-18
Ultrasonic Rear Parking Assist (URPA)............3-21
Accessory Power Outlets...............................3-23
Ashtrays and Cigarette Lighter........................3-24
Climate Controls............................................3-24
Climate Control System.................................3-24
Dual Climate Control System..........................3-27
Dual Automatic Climate Control System...........3-29
Outlet Adjustment.........................................3-32
Warning Lights, Gages and Indicators.............3-33
Instrument Panel Cluster................................3-34
Speedometer and Odometer...........................3-35
Tachometer.................................................3-36
Safety Belt Reminder Light.............................3-37
Air Bag Readiness Light................................3-37
Brake System Warning Light
..........................3-38
Anti-Lock Brake System Warning Light
.............3-39Traction Control System (TCS) Warning Light......3-39
Engine Coolant Temperature Gage..................3-40
Malfunction Indicator Lamp.............................3-40
Cruise Control Light......................................3-43
Fuel Gage...................................................3-43
Message Center.............................................3-44
Service Traction System Warning Message......3-44
Traction Active Message................................3-45
Engine Coolant Temperature Warning
Message..................................................3-45
Charging System Indicator Message................3-46
Low Oil Pressure Message............................3-46
Low Engine Oil Level Message.......................3-47
Change Engine Oil Message..........................3-47
Low Tire Message........................................3-48
Door Ajar Warning Message...........................3-48
Rear Hatch Ajar Warning Message..................3-48
PASS-Key
®III Security Message....................3-49
All-Wheel Drive Disable Warning Message.......3-49
Low Washer Fluid Warning Message...............3-50
Low Fuel Warning Message
...........................3-50
Low Brake Fluid Warning Message
.................3-51
Service Vehicle Soon Message
.......................3-51
Program Mode Message
................................3-52
Remote Keyless Entry Transmitter Battery
Low Warning Message
...............................3-52
Section 3 Instrument Panel
3-1
2003 - Rendezvous OM

The hazard warning
flasher button is located on
top of the steering
column.
Your hazard warningflashers work no matter what
position your key is in, and even if the key isn’t in.
Press the button to make the front and rear turn signal
lampsflash on and off. Press the button again to
turn theflashers off.
When the hazard warningflashers are on, the turn
signals won’t work.
Other Warning Devices
If you carry reflective triangles, you can set one up at
the side of the road about 300 feet (100 m) behind your
vehicle.
Horn
You can sound the horn by pressing the center of your
steering wheel.
Tilt Wheel
A tilt wheel allows you to adjust the steering wheel
before you drive. You can raise it to the highest level to
give your legs more room when you exit and enter
the vehicle.
The lever that allows you to tilt the steering wheel is
located on the left side of the steering column.
To tilt the wheel, hold the
steering wheel and pull the
lever.
Then move the steering wheel to a comfortable position
and release the lever to lock the wheel in place.
3-6
2003 - Rendezvous OM

Fog Lamps
The fog lamp button is
located on the exterior
lamp control.
Push the FOG PUSH button to turn the fog lamps on.
The FOG light next to the fog lamp button indicates the
fog lamps are on. To turn off the fog lamps, press the
fog lamp button or turn the ignition off.
If you turn on the fog lamps while the DRL are on, the
parking lamps will turn on automatically.
Your fog lamps will go off when you switch to high
beams. When you return to low beam, the fog lamps
will come back on. Using your high beams in fog is not
recommended.
Interior Lamps
Your interior lamps control
is located below the
exterior lamps control.
Instrument Panel Brightness
Press the knob to extend it. Turn the knob to adjust the
instrument panel brightness. Press the knob in when
not in use.
Interior Lamps Control
OFF:Turn the control to this position to turn off the
interior lamps.
DOOR:Turn the control to this position to turn on the
interior lamps while any door is opened and while
the ignition key is removed from the ignition.
ON:Turn the control to this position to turn on the
interior lamps.
3-14
2003 - Rendezvous OM

Headlamp Exit Delay
If your vehicle has headlamp exit delay, it will keep the
headlamps and parking lamps on at night for
30 seconds if:
•The ignition is turned to OFF,
•the exterior lamp control is in the AUTO position,
•LOCK is pressed on the remote keyless entry
transmitter, and
•it is dark enough outside.
After 30 seconds, the headlamps and parking lamps will
turn off.
The lamps will turn off before the 30 seconds if:
•The ignition is turned to ON, or
•the exterior lamp control is turned out of the AUTO
position.
To program the headlamp exit delay feature, see
Vehicle Personalization on page 2-46. If your vehicle is
equipped with the Driver Information Center (DIC),
seeDIC Vehicle Personalization on page 3-57.
Entry Lighting
If your vehicle has entry lighting, the interior of your
vehicle will illuminate for 25 seconds so you can
see inside your vehicle before you enter. To activate
entry lighting, do the following:
•Unlock a door using the key when the interior lamp
control is in the DOOR position, and when the
ignition is in OFF, or
•press UNLOCK on the remote keyless entry
transmitter when the interior lamp control is in the
DOOR position, and when the ignition is in OFF.
After 25 seconds, the interior lamps will fade out.
The lamps will turn off before 25 seconds if you:
•Press LOCK on the remote keyless entry
transmitter, or
•press the front of the power door lock switch, or
•turn the ignition to ON.
When any door is opened, entry lighting is cancelled.
The interior lamps will stay on while any door or
the liftgate is open, and fade out when all the doors are
closed.
3-15
2003 - Rendezvous OM

Delayed Lighting
If your vehicle has delayed lighting, it will continue to
illuminate the interior for 25 seconds after all doors have
been closed. The lamps will continue to illuminate when:
•A door is opened then closed,
•the interior lamp control is in the DOOR position, and
•the ignition is in OFF.
After 25 seconds, the interior lamps will fade out.
The lamps will fade out before the 25 seconds if:
•The ignition is turned to ON,
•LOCK is pressed on the remote keyless entry
transmitter, or
•the front of the power door lock switch is pressed.
If your vehicle is equipped with the Driver Information
Center (DIC), you can program this feature on or
off. SeeDIC Vehicle Personalization on page 3-57.
Exit Lighting
If your vehicle is equipped with exit lighting, the interior
lamps will come on for about 30 seconds whenever
you remove the key from the ignition if:
•The vehicle is in PARK (P),
•the key is out of the ignition,
•the interior lamp control is in the DOOR position,
and
•all of the doors are closed.
After 30 seconds, the interior lamps will fade out.
The interior lamps will fade out before 30 seconds if:
•The ignition is turned to ON,
•LOCK is pressed on the remote keyless entry
transmitter, or
•the front of the power door lock switch is pressed.
If your vehicle is equipped with the Driver Information
Center (DIC), you can program this feature on or
off. SeeDIC Vehicle Personalization on page 3-57.
Perimeter Lighting
If your vehicle has perimeter lighting, it will turn on the
headlamps and parking lamps for 25 seconds when:
•The ignition is turned to OFF,
•the exterior lamp control is in the AUTO position,
•UNLOCK is pressed on the remote keyless
entry transmitter, and
•it is dark enough outside.
3-16
2003 - Rendezvous OM

Safety Belt Reminder Light
When the key is turned to ON or START, a chime will
come on for several seconds to remind people to fasten
their safety belts.
The safety belt light will
also come on and stay on
for several seconds. If
the driver’s belt is already
buckled, neither the
chime nor the light will
come on.
Air Bag Readiness Light
There is an air bag readiness light on the instrument
panel, which shows the air bag symbol. The system
checks the air bag’s electrical system for malfunctions.
The light tells you if there is an electrical problem.
The system check includes the air bag sensor, the air
bag modules, the wiring and the diagnostic module. For
more information on the air bag system, seeAir Bag
Systems on page 1-67.This light will come on
when you start your
vehicle, and it willflash for
a few seconds. Then
the light should go out.
This means the system is
ready.
If the air bag readiness light stays on after you start the
vehicle or comes on when you are driving, your air
bag system may not work properly. Have your vehicle
serviced right away.
{CAUTION:
If the air bag readiness light stays on after you
start your vehicle, it means the air bag system
may not be working properly. The air bags in
your vehicle may not inflate in a crash, or they
could even inflate without a crash. To help
avoid injury to yourself or others, have your
vehicle serviced right away if the air bag
readiness light stays on after you start your
vehicle.
3-37
2003 - Rendezvous OM

The air bag readiness light shouldflash for a few
seconds when you turn the ignition key to ON. If the
light doesn’t come on then, have itfixed so it will
be ready to warn you if there is a problem.
Brake System Warning Light
When the ignition is on, the brake system warning light
will come on when you set your parking brake. The
light will stay on if your parking brake doesn’t release
fully. If it stays on after your parking brake is fully
released, it means you have a brake problem.
Your vehicle’s hydraulic brake system is divided into two
parts. If one part isn’t working, the other part can still
work and stop you. For good braking, though, you need
both parts working well.
If the warning light comes on, there could be a brake
problem. Have your brake system inspected right away.This light should come on briefly when you turn the
ignition key to ON. If it doesn’t come on then, have it
fixed so it will be ready to warn you if there’s a problem.
If the light comes on while you are driving, pull off the
road and stop carefully. You may notice that the pedal is
harder to push. Or, the pedal may go closer to the
floor. It may take longer to stop. If the light is still on,
have the vehicle towed for service. SeeAnti-Lock Brake
System Warning Light on page 3-39andTowing Your
Vehicle on page 4-31.
{CAUTION:
Your brake system may not be working
properly if the brake system warning light is
on. Driving with the brake system warning light
on can lead to an accident. If the light is still
on after you’ve pulled off the road and stopped
carefully, have the vehicle towed for service.
United States
Canada
3-38
2003 - Rendezvous OM

Anti-Lock Brake System Warning
Light
Your vehicle may have an anti-lock brake system
warning light. If it does, the light should come on for a
few seconds when you turn the ignition key to ON. If the
anti-lock brake system warning light stays on longer
than normal after you’ve started your engine, turn
the ignition off. Or, if the light comes on and stays on
when you’re driving, stop as soon as possible and turn
the ignition off. Then start the engine again to reset
the system. If the light still stays on, or comes on again
while you’re driving, the anti-lock brake system needs
service and you don’t have anti-lock brakes.
The anti-lock brake system warning light should come
on briefly when you turn the ignition key to ON. If
the light doesn’t come on then, have itfixed so it will be
ready to warn you if there is a problem.
Traction Control System (TCS)
Warning Light
Your vehicle may have a traction control system
warning light. The traction control system warning light
may come on for the following reasons:
•If you turn the system off by pressing the TRAC
OFF button located in the instrument panel
switchbank the warning light will come on and stay
on. To turn the system back on, press the button
again. The warning light should go off. SeeTraction
Control System (TCS) on page 4-10for more
information.
•If there’s an engine-related and brake system
problem that is specifically related to traction control,
the traction control system will turn off and the
warning light will come on. United States
CanadaUnited StatesCanada
3-39
2003 - Rendezvous OM

your vehicle. This system is also designed to assist your
service technician in correctly diagnosing any
malfunction.
Notice:If you keep driving your vehicle with this
light on, after a while, your emission controls
may not work as well, your fuel economy may not
be as good and your engine may not run as
smoothly. This could lead to costly repairs that may
not be covered by your warranty.
Notice:Modifications made to the engine,
transaxle, exhaust, intake or fuel system of your
vehicle or the replacement of the original tires with
other than those of the same Tire Performance
Criteria (TPC) can affect your vehicle’s emission
controls and may cause this light to come on.
Modifications to these systems could lead to costly
repairs not covered by your warranty. This may
also result in a failure to pass a required Emission
Inspection/Maintenance test.
This light should come on, as a check to show you it is
working, when the ignition is on and the engine is
not running. If the light doesn’t come on, have it
repaired. This light will also come on during a
malfunction in one of two ways:
•Light Flashing—Amisfire condition has been
detected. A misfire increases vehicle emissions
and may damage the emission control system on
your vehicle. Dealer or qualified service center
diagnosis and service may be required.
•Light On Steady—An emission control system
malfunction has been detected on your vehicle.
Dealer or qualified service center diagnosis
and service may be required.
If the Light Is Flashing
The following may prevent more serious damage to
your vehicle:
•Reducing vehicle speed.
•Avoiding hard accelerations.
•Avoiding steep uphill grades.
•If you are towing a trailer, reduce the amount of
cargo being hauled as soon as it is possible.
If the light stopsflashing and remains on steady, see“If
the Light Is On Steady”following.
If the light continues toflash, when it is safe to do so,
stop the vehicle.Find a safe place to park your vehicle.
Turn the key off, wait at least 10 seconds and restart
the engine. If the light remains on steady, see“If
the Light Is On Steady”following. If the light is still
flashing, follow the previous steps, and drive the vehicle
to your dealer or qualified service center for service.
3-41
2003 - Rendezvous OM
