60 Seats and Restraints
Front Seats Power Seat Adjustment
{ WarningYou can lose control of the
vehicle if you try to adjust a driver
seat while the vehicle is moving.
Adjust the driver seat only when
the vehicle is not moving.
Platinum Seat Shown To adjust:
.
Move the seat forward or
rearward by sliding the control
forward or rearward.
.
Raise or lower the front part of
the seat cushion by moving the
front of the control up or down.
.
Raise or lower the seat by
moving the rear of the control up
or down.
To adjust the seatback, see
Reclining Seatbacks 0 62 .
To adjust the lumbar support, see
Lumbar Adjustment 0 60 .
Some vehicles are equipped with a
feature that activates a vibrating
pulse alert in the driver seat to help
avoid crashes. See Driver
Assistance Systems 0 230 .
Lumbar Adjustment Uplevel Lumbar and Bolster
Adjustment
If equipped, the ignition must be on
to use all uplevel seat features. Platinum Seat
1. Feature Select
2. Up
3. Forward
4. Down
5. Rearward
.
Toggle the Feature Select (1),
if equipped, to view adjustable
seat options on the center stack
display.
.
Select lumbar support.
.
Press Up (2) to move lumbar
support upward.
.
Press Forward (3) to move
lumbar support inward.

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-9235592) -
2016 - crc - 11/6/15
Seats and Restraints 61.
Press Down (4) to move lumbar
support down.
.
Press Rearward (5) to move
lumbar support outward.
To adjust upper back support,
if equipped:
.
Toggle the Feature Select (1),
if equipped, to view adjustable
seat options on the center stack
display.
.
Press Forward (3) to move
support inward or Rearward (5)
to move support outward. Base Lumbar Adjustment
Base Seat Shown
To adjust lumbar support,
if equipped:
1. Forward
2. Rearward
.
Press Forward (1) to move
lumbar support inward.
.
Press Rearward (2) to move
lumbar support outward. Thigh Support
Adjustment
To adjust thigh support, if equipped:
1. Turn the selection control (3) to
view seat options on the center
stack display.
2. Select cushion length adjuster.
3. Press and hold the control
forward (2) to increase or
rearward (1) to decrease
cushion length.

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-9235592) -
2016 - crc - 11/6/15
62 Seats and Restraints
Reclining Seatbacks
Platinum Seat Shown
To adjust:
.
Tilt the top of the control
rearward to recline.
.
Tilt the top of the control forward
to raise the seatback. { WarningSitting in a reclined position when
the vehicle is in motion can be
dangerous. Even when buckled
up, the safety belts cannot do
their job.
The shoulder belt will not be
against your body. Instead, it will
be in front of you. In a crash, you
could go into it, receiving neck or
other injuries.
The lap belt could go up over
your abdomen. The belt forces
would be there, not at your pelvic
bones. This could cause serious
internal injuries.
For proper protection when the
vehicle is in motion, have the
seatback upright. Then sit well
back in the seat and wear the
safety belt properly. Do not have a seatback reclined if
the vehicle is moving.

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-9235592) -
2016 - crc - 11/6/15
Seats and Restraints 63
Memory Seats
Platinum Driver Seat Buttons
Shown, Passenger Buttons
Similar
If equipped, the SET, 1, 2, and
B(Exit) buttons on the driver door and
front passenger door are used to
manually store and recall memory
settings for the driver and
passenger seats. The driver
memory buttons also store outside
mirror, power tilt and telescoping
steering column positions, and
massage settings, if equipped. Storing Memory Positions
To store positions to the 1 and 2
buttons:
1. The ignition must be in ON/
RUN or ACC/ACCESSORY.
2. Adjust the driver seat, power tilt
and telescoping steering
column, if equipped, massage
type and intensity, if equipped,
and the outside mirrors on
some vehicles.
3. Press and release SET. A beep
will sound.
4. Immediately press and hold 1
until two beeps sound.
5. Repeat Steps 1 – 4 for a second
driver using 2.
To store exit positions and easy exit
features to the
B (Exit) button,
repeat Steps 1 – 4 using
B to store
your positions for getting out of the
vehicle (driver only). Manually Recalling Memory
Positions
Press and hold 1, 2, or
B to
manually recall the previously
stored memory positions. Releasing
1, 2, or
B before the stored
positions are reached stops the
recall.
If the massage feature is off when
the memory recall is performed, the
previously stored type and intensity
will be recalled, but it will remain off
until activated with the On/Off
control or through the center stack
with the platinum seat controls.
Automatically Recalling Memory
Positions (Auto Memory Recall)
(Driver Only)
If programmed on in the vehicle
personalization menu, the Auto
(Automatic) Memory Recall feature
automatically recalls the current
driver ’ s previously stored 1 or 2
position when the ignition is
changed from OFF to ON/RUN or
ACC/ACCESSORY.

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-9235592) -
2016 - crc - 11/6/15
64 Seats and Restraints See “ Auto Memory Recall ’ under
“ Comfort and Convenience ” in
Vehicle Personalization 0 157 .
To stop recall movement, press one
of the memory, power mirror,
or power seat controls; or press the
power tilt and telescoping steering
column control.
If the vehicle ’ s driver has changed,
in some vehicles the Driver ID may
be displayed for the first few ignition
cycles.
RKE transmitters are not labeled
with a number. If your memory seat
position is stored to 1 or 2 but this
position is not automatically
recalling, then store your positions
to the other button or switch RKE
transmitters with the other driver.
Easy Exit Recall (Driver Only)
If programmed on in the vehicle
personalization menu, the easy exit
feature automatically recalls the
previously stored exit positions
when leaving the vehicle. See
“ Storing Memory Positions ” earlier in
this section. See also Vehicle
Personalization 0 157 . Easy exit recall automatically
activates when one of the following
occurs:
.
The vehicle is turned off and the
driver door is opened within a
short time.
.
The vehicle is turned off with the
driver door open.
Obstructions
If something has blocked the driver
seat while recalling a memory
position, the recall may stop.
Remove the obstruction. Then do
one of the following:
.
If automatically or manually
recalling the stored memory
position, press and hold the
appropriate manual control for
two seconds. Try recalling again
by pressing the appropriate
memory button. If automatically
recalling the position, try
recalling again by opening the
driver door and pressing
K on
the RKE transmitter.
.
If recalling the exit position,
press and hold the appropriate
manual control for the exit feature not recalling for
two seconds. Then try recalling
the exit position again.
If the memory position is still not
recalling, see your dealer for
service.
Heated and Ventilated
Front Seats
{ WarningIf you cannot feel temperature
change or pain to the skin, the
seat heater may cause burns. To
reduce the risk of burns, people
with such a condition should use
care when using the seat heater,
especially for long periods of
time. Do not place anything on
the seat that insulates against
heat, such as a blanket, cushion,
cover, or similar item. This may
cause the seat heater to
overheat. An overheated seat
heater may cause a burn or may
damage the seat.

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-9235592) -
2016 - crc - 11/6/15
Seats and Restraints 65
If equipped, the buttons are near the
climate controls on the center stack.
To operate, the ignition must be on.
Press
J or
z to heat the driver or
passenger seat cushion and
seatback.
Press
I or
+ to heat the driver or
passenger seatback only.
Press
C or
{ to ventilate the driver
or passenger seat.
Press the button once for the
highest setting. With each press of
the button, the seat will change to
the next lower setting, and then to
the off setting. The indicator lights next to the buttons indicate three for
the highest setting and one for the
lowest. If the front heated seats are
on high, the level may automatically
be lowered after approximately
30 minutes.
When this feature is off, the heated
and ventilated seat symbols on the
buttons are white. A ventilated seat
has a fan that pulls or pushes air
through the seat. The air is not
cooled. When a heated seat is
turned on, the symbol turns red.
When a ventilated seat is turned on,
the symbol turns blue.
The passenger seat may take
longer to heat up.
Auto Heated Seats
When the vehicle is on, this feature
will automatically activate the
heated seats at the level required by
the vehicle ’ s interior temperature.
The active high, medium, low, or off
heated seat level will be indicated
by the manual heated seat buttons
on the center stack. Use the manual
heated seat buttons on the center
stack to turn auto heated seats off. If the passenger seat is unoccupied,
the auto heated seats feature will
not activate that seat. The auto
heated seats feature can be
programmed to always be enabled
when the vehicle is on.
See Vehicle Personalization 0 157 .
Remote Start Heated and
Ventilated Seats
During a remote start, the heated or
ventilated seats, if equipped, can be
turned on automatically. When it is
cold outside, the heated seats turn
on, and when it is hot outside the
ventilated seats turn on. The heated
or ventilated seats are canceled
when the ignition is turned on. Press
the heated or ventilated seat button
to use the heated or ventilated seats
after the vehicle is started.
The heated or ventilated seat
indicator lights do not turn on during
a remote start.
The temperature performance of an
unoccupied seat may be reduced.
This is normal.

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-9235592) -
2016 - crc - 11/6/15
66 Seats and Restraints The heated or ventilated seats may
be enabled or disabled in the
vehicle personalization menu. See
Remote Vehicle Start 0 36 and
Vehicle Personalization 0 157 .
Massage Massage
Platinum Driver Seat Shown,
Passenger Seat Similar
If equipped, the ignition must be on
to use the massage feature. To activate and adjust the massage
feature:
1. Toggle the center selection
control (2) located on the door
to view adjustable massage
options on the center stack
display.
2. Select massage feature.
3. Press the control up (3) or
down (5) to select the
massage type.
4. Press the control forward (4) or
rearward (6) to change the
intensity.
5. Press the massage control
button (1) to recall the last
massage type and intensity.
See Massage 0 66 .Rear Seats
{ WarningThe power seats will work with
the ignition off. Children could
operate the power seats and be
injured. Never leave children
alone in the vehicle.
CautionDo not adjust the power seat
when a child restraint is installed.
Adjusting the seat may cause
damage to the installed child
restraint. Use the window lockout
button on the driver door to
prevent adjustment of the seat
whenever a child restraint is
installed.

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-9235592) -
2016 - crc - 11/6/15
Seats and Restraints 67
Platinum Rear Seat Shown
If equipped, the armrest may have
seat adjustment controls.
1. Seatback Display and Lumbar
Adjustment Control
2. Power Seat Adjustment
3. Seatback Recline
4. Massage
When one of the seat controls is
triggered, a panel display will be
activated from the driver or
passenger seatback. To adjust the seat, if equipped:
.
Move the seat forward or
rearward by sliding the
control (2) forward or rearward.
.
Raise or lower the front part of
the seat cushion by moving the
front of the control (2) up
or down.
.
Raise or lower the seat by
moving the rear of the control (2)
up or down.
To recline the rear seatback,
if equipped:
.
Tilt the top of the control (3)
rearward to recline.
.
Tilt the top of the control (3)
forward to raise.
To activate the massage feature,
if equipped:
1. Press the massage control
button (4).
2. Press up or down (1) to select
the massage type.
3. Press forward or rearward (1)
to change the intensity. 4. Press the massage control
button (4) to recall the last
massage type and intensity.
Easy Exit
Platinum Seat Shown
If equipped, press
S to return the
seat to the full rearward and full tilt
down position. The seat will also
move to this position when the rear
door is opened.

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-9235592) -
2016 - crc - 11/6/15
68 Seats and Restraints
Lumbar Adjustment If a child restraint is installed, see
Rear Seats 0 66 .
Platinum Rear Seat Shown
If equipped, the armrest may have
controls for lumbar and upper back
support.
When one of the seat controls is
triggered, a panel display will be
activated from the driver or
passenger seatback. To adjust lumbar support,
if equipped:
1. Toggle the center selection
control to view adjustable seat
options on the display.
2. Select lumbar support.
3. Press and hold the control
forward to increase or rearward
to decrease support.
4. Press and hold the control
upward to raise or downward to
lower the height of the support.
To adjust upper back support,
if equipped:
1. Toggle the center selection
control to view adjustable seat
options on the display.
2. Select upper back support.
3. Press and hold the control
forward to increase or rearward
to decrease support. Rear Seat Armrest
Fixed Center Seat Shown,
Adjustable Center Seat Similar
The rear seat has an armrest in the
center of the seatback. Lower the
armrest and press the button at the
front of the armrest to access the
cupholders.
To fold, press the cupholders into
the seat if they have been opened,
lift the armrest up, and push it
rearward until it is flush with the
seatback.

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-9235592) -
2016 - crc - 11/6/15
Seats and Restraints 69
Heated and Ventilated
Rear Seats
{ WarningIf you cannot feel temperature
change or pain to the skin, the
seat heater may cause burns.
See the Warning under Heated
and Ventilated Front Seats 0 64 .
Platinum Seat
If equipped, the buttons are on the
rear passenger doors. With the ignition in ON/RUN, press
M or
L to heat the left or right
outboard seat cushion.
With the ignition in ON/RUN, press
C or
{ to ventilate the left or right
outboard seat.
On vehicles without rear climate
controls, an indicator light on the
button will turn on when the heated
or ventilated seat is on. On vehicles
with rear climate controls, an
indicator on the climate control
display appears when this feature
is on.
On vehicles without rear climate
controls, press the button again to
turn this feature off. The light on the
button will turn off. On vehicles with
rear climate controls, this feature
turns on the heated seat at the
highest setting. With each press of
the button, the heated seat changes
to the next lower setting, and then
the off setting. Three lights indicate
the highest setting, and one light
indicates the lowest. If the heated
seats are on high, the level may
automatically be lowered after
approximately 30 minutes. Rear Seat
Pass-Through Door
Some vehicles have a rear seat
pass-through door in the center of
the rear seatback. Fold down the
center armrest and pull the latch to
open the door.
