lock CADILLAC DEVILLE 2000 8.G User Guide

1-35
1. Pick up the latch plate and pull the belt across you.
Don't let it get twisted.
The shoulder belt may lock if you pull the belt across
you very quickly. If this happens, let the belt go back
slightly to unlock it. Then pull the belt across you
more slowly.
2. Push the latch plate into the buckle until it clicks.If the belt stops before it reaches the buckle, tilt the
latch plate and keep pulling until you can buckle it.
Pull up on the latch plate to make sure it is secure.
If the belt is not long enough, see ªSafety Belt
Extenderº at the end of this section. Make sure the
release button on the buckle is positioned so you
would be able to unbuckle the safety belt quickly if
you ever had to.

1-37
The safety belt locks if there's a sudden stop or a crash,
or if you pull the belt very quickly out of the retractor.
The rear outboard seating positions may have a shoulder
belt tightness adjustment feature. You can tell if your
vehicle has this feature by following the steps below. If
you can add a small amount of slack, your vehicle has
this feature.
If the shoulder belt seems too tight:
1. Sit well back in the seat.
2. Pull the shoulder belt all the way out of the retractor.
3. Let belt go back all the way.
4. Now you can add a small amount of slack. Lean
forward slightly, then sit back. If you've added more
than 1 inch (25 mm) of slack, pull the shoulder belt
out as you did before and start again.
If you move around in the vehicle enough or if you pull
out the shoulder belt, the belt will become tight again. If
this happens, you can reset it.

1-54
5. Pull the rest of the lap belt all the way out of the
retractor to set the lock.6. To tighten the belt, feed the lap belt back into the
retractor while you push down on the child restraint.
You may find it helpful to use your knee to push
down on the child restraint as you tighten the belt.
7. Push and pull the child restraint in different
directions to be sure it is secure.
To remove the child restraint, just unbuckle the vehicle's
safety belt and let it go back all the way. The safety belt
will move freely again and be ready to work for an adult
or larger child passenger.

2-
2-1
Section 2 Features and Controls
Here you can learn about the many standard and optional features on your vehicle, and information on starting,
shifting and braking. Also explained are the instrument panel and the warning systems that tell you if everything is
working properly
-- and what to do if you have a problem.
2
-2 Keys
2
-4 Door Locks
2
-7 Remote Keyless Entry System
2
-12 Trunk
2
-15 Theft
2
-16 Theft-Deterrent System
2
-18 PASS-Key
III
2
-20 New Vehicle ªBreak-Inº
2
-20 Ignition Positions
2
-22 Starting Your Engine
2
-24 Engine Coolant Heater (If Equipped)
2
-25 Automatic Transaxle Operation
2
-30 Parking Brake
2
-32 Shifting Into PARK (P)
2
-35 Shifting Out of PARK (P)
2
-36 Parking Over Things That Burn
2
-37 Engine Exhaust
2
-37 Running Your Engine While You're Parked
2
-38 Windows2
-39 Tilt Wheel and Telescopic Column
2
-40 Turn Signal/Multifunction Lever
2
-46 Exterior Lamps
2
-51 Interior Lamps
2
-53 Mirrors
2
-57 Storage Compartments
2
-60 Rear Power Sunshade (If Equipped)
2
-61 Cellular Telephone (Option)
2
-62 Sunroof (Option)
2
-63 HomeLink
Transmitter
2
-68 The Instrument Panel -- Your
Information System
2
-73 Warning Lights, Gages and Indicators
2
-87 Driver Information Center (DIC)
2
-102 Night Vision System (Option)
2
-106 Navigation (Option)
2
-107 Ultrasonic Rear Parking
Assist (URPA) (Option)

2-3
Master Key Valet Key
There is a master key that works all of the lock cylinders
(driver's door, trunk, ignition and glove box).
There is also a VALET key which only operates the
driver's door and the ignition.Both the master and VALET key have a transponder
embedded into the key for security and vehicle theft
deterrence. The keys also come with a bar code tag.
Keep the bar code tag in a safe place. If you lose your
key, you will be able to have a new one made using the
bar code tag. The replacement key must have a vehicle
theft deterrent system transponder embedded in it.
NOTICE:
Your vehicle has a number of new features that
can help prevent theft. You can have a lot of
trouble getting into your vehicle if you ever lock
your keys inside. You may even have to damage
your vehicle to get in. So be sure you have
extra keys.

2-4
Door Locks
CAUTION:
Unlocked doors can be dangerous.
Passengers -- especially children -- can easily
open the doors and fall out. When a door is
locked, the inside handle won't open it.
Outsiders can easily enter through an unlocked
door when you slow down or stop your vehicle.
This may not be so obvious: You increase the
chance of being thrown out of the vehicle in a
crash if the doors aren't locked. Wear safety belts
properly, lock your doors, and you will be far
better off whenever you drive your vehicle.
There are several ways to lock and unlock your vehicle.
From the outside, use either of the keys or the remote
keyless entry transmitter.
With the theft
-deterrent system, you must unlock the
doors with the key or remote keyless entry transmitter to
avoid setting off the alarm.
Push down on the manual
lock button to lock the door
from the inside. To unlock
the door, pull up on
the button.

2-5
Central Door Unlocking System
Your vehicle has a central door unlocking mode and a
theft
-deterrent system. When unlocking the driver's
door, you can unlock the other doors by holding the key
in the turned position for a few seconds or by quickly
turning the door key twice in the lock cylinder.
Power Door Locks
Press the power door lock
button to lock or unlock all
the doors at once. The
power door lock buttons
located on the rear doors
can lock all the doors at
once, but cannot unlock
the doors.
Automatic Door Locks
Your vehicle is equipped with a default mode, so that
every time your doors are closed, the ignition is on and
you move the shift lever out of PARK (P), all the doors
will lock. The doors will unlock every time you stop the
vehicle and move the shift lever back into PARK (P).
If someone needs to get out while your vehicle is not in
PARK (P), have that person use the manual or power
lock. When the door is closed again, it will not lock
automatically. Use the manual or power lock to lock the
door again. If you need to lock the doors before shifting
out of PARK (P), use the manual or power lock button
to lock the doors.
Programmable Automatic Door Locks
With the ignition in ON, the door locks can be
programmed through prompts displayed by the Driver
Information Center (DIC). These prompts allow the
driver to choose various lock settings. For programming
information, see ªMemory and Personalization
Featuresº in the Index.

2-6
Rear Door Security Locks
Your vehicle is equipped
with rear door security
locks that help prevent
passengers from opening
the rear doors of your
vehicle from the inside.
To use this lock:
1. Turn the knob on the passenger's side rear
door clockwise all the way down to the
ENGAGED position.
2. Close the door.
3. Turn the knob on the driver's side rear door
counterclockwise all the way down to the
engaged position.
The rear doors of your vehicle cannot be opened from
the inside when this feature is in use.When you want to open a rear door when the security
lock is on:
1. Unlock the door from the inside.
2. Then open the door from the outside.
To cancel the rear door lock:
1. Unlock the door and open it from the outside.
2. Turn the passenger's side rear door knob
counterclockwise all the way back to the
original position.
3. Turn the driver's side rear door knob clockwise all
the way back to the original position.
The rear door locks will now work normally.
Anti-Lockout Feature
Leaving your key in any ignition position with any door
open will disable the use of the power door lock buttons
as well as the lock button on the remote keyless entry
transmitter. If you close the doors, you can lock them
using the remote keyless entry transmitter. It is always
recommended that you remove the ignition key when
locking your vehicle.
Also, the anti
-lockout feature can be overridden by
holding the driver's power door lock button for three
seconds or longer.

2-7
Leaving Your Vehicle
If you are leaving the vehicle, open the door, set the
locks from the inside, get out and close the door.
Remote Keyless Entry System
With this feature, you can lock and unlock your doors
or unlock your trunk from about 3 feet (1 m) up to
30 feet (9 m) away using the remote keyless entry
transmitter supplied with your vehicle.
Your remote keyless entry transmitter operates on a
radio frequency subject to Federal Communications
Commission (FCC) Rules and with Industry Canada.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference,
and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This device complies with RSS
-210 of Industry Canada.
Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation of
the device.
Changes or modifications to this system by other than an
authorized service facility could void authorization to
use this equipment.

2-8
The average range of this system is about 10 feet (3 m).
At times you may notice a decrease in range. This is
normal for any remote keyless entry transmitter. If the
transmitter does not work or if you have to stand closer
to your vehicle for the transmitter to work, try this:

Check the distance. You may be too far from your
vehicle. You may need to stand closer during rainy
or snowy weather.

Check the location. Other vehicles or objects may be
blocking the signal. Take a few steps to the left or
right, hold the transmitter higher, and try again.

Check to determine if battery replacement is
necessary. See the instructions that follow.

If you're still having trouble, see your dealer or a
qualified technician for service.Operation
When you press this
symbol to unlock the
driver's door, the parking
lamps on your vehicle will
flash twice. (You can
program your vehicle so the
parking lamps will not
flash. They will also not
flash if the manual park
lamps are on.
For more information, see ªLock/Unlock Confirmationº
in the Index.) Pressing this symbol again within
five seconds will unlock the other doors. Pressing this
symbol will also disarm the theft
-deterrent system and
turn on the interior lamps at night.
