2-74
This light should come on, as a check to show you it is
working, when the ignition is on and the engine is not
running. If the light doesn't come on, have it repaired.
This light will also come on during a malfunction in one
of two ways:

Light Flashing
-- A misfire condition has been
detected. A misfire increases vehicle emissions and
may damage the emission control system on your
vehicle. Dealer or qualified service center diagnosis
and service may be required.

Light On Steady
-- An emission control system
malfunction has been detected on your vehicle.
Dealer or qualified service center diagnosis and
service may be required.
If the Light Is Flashing
The following may prevent more serious damage to
your vehicle:

Reducing vehicle speed.

Avoiding hard accelerations.

Avoiding steep uphill grades.

If you are towing a trailer, reduce the amount of
cargo being hauled as soon as it is possible.If the light stops flashing and remains on steady,
see ªIf the Light Is On Steadyº following.
If the light continues to flash, when it is safe to do so,
stop the vehicle. Find a safe place to park your vehicle.
Turn the key off, wait at least 10 seconds and restart the
engine. If the light remains on steady, see ªIf the Light
Is On Steadyº following. If the light is still flashing,
follow the previous steps, and drive the vehicle to your
dealer or qualified service center for service.
If the Light Is On Steady
You may be able to correct the emission system
malfunction by considering the following:
Did you recently put fuel into your vehicle?
If so, reinstall the fuel cap, making sure to fully
install the cap. See ªFilling Your Tankº in the Index.
The diagnostic system can determine if the fuel cap
has been left off or improperly installed. A loose or
missing fuel cap will allow fuel to evaporate into the
atmosphere. A few driving trips with the cap properly
installed should turn the light off.
Did you just drive through a deep puddle of water?
If so, your electrical system may be wet. The condition
will usually be corrected when the electrical system
dries out. A few driving trips should turn the light off.

2-75
Are you low on fuel?
As your engine starts to run out of fuel, your engine
may not run as efficiently as designed since small
amounts of air are sucked into the fuel line causing a
misfire. The system can detect this. Adding fuel
should correct this condition. Make sure to install the
fuel cap properly. See ªFilling Your Tankº in the Index.
It will take a few driving trips to turn the light off.
Have you recently changed brands of fuel?
If so, be sure to fuel your vehicle with quality fuel.
See ªFuelº in the Index. Poor fuel quality will cause
your engine not to run as efficiently as designed.
You may notice this as stalling after start
-up,
stalling when you put the vehicle into gear, misfiring,
hesitation on acceleration or stumbling on acceleration.
(These conditions may go away once the engine is
warmed up.) This will be detected by the system and
cause the light to turn on.
If you experience one or more of these conditions,
change the fuel brand you use. It will require at least
one full tank of the proper fuel to turn the light off.
If none of the above steps have made the light turn off,
have your dealer or qualified service center check the
vehicle. Your dealer has the proper test equipment and
diagnostic tools to fix any mechanical or electrical
problems that may have developed.Emissions Inspection and Maintenance Programs
Some state/provincial and local governments have
or may begin programs to inspect the emission
control equipment on your vehicle. Failure to pass
this inspection could prevent you from getting a
vehicle registration.
Here are some things you need to know in order to
help your vehicle pass an inspection:
Your vehicle will not pass this inspection if the
SERVICE ENGINE SOON light is on or not
working properly.
Your vehicle will not pass this inspection if the
OBD (on-board diagnostic) system determines
that critical emission control systems have not been
completely diagnosed by the system. The vehicle would
be considered not ready for inspection. This can happen
if you have recently replaced your battery or if your
battery has run down. The diagnostic system is
designed to evaluate critical emission control systems
during normal driving. This may take several days of
routine driving. If you have done this and your vehicle
still does not pass the inspection for lack of OBD system
readiness, see your dealer or qualified service center to
prepare the vehicle for inspection.

2-76 Oil Pressure Light
CAUTION:
Don't keep driving if the oil pressure is low.
If you do, your engine can become so hot that
it catches fire. You or others could be burned.
Check your oil as soon as possible and have your
vehicle serviced.
NOTICE:
Damage to your engine from neglected oil
problems can be costly and is not covered by
your warranty.
This light tells you if there
could be a problem with
your engine oil pressure.
The light goes on when you turn your key to RUN
or START. It goes off once you start your engine.
That's a check to be sure the light works. If it doesn't
come on, be sure to have it fixed so it will be there to
warn you if something goes wrong.
When the light comes on and stays on, it means
that oil isn't flowing through your engine properly.
You could be low on oil and you might have some
other system problem.

2-77 Security Light
This light works with
the PASS
-Key II system.
See ªPASS
-Key IIº in the
Index for more information.
Fuel Gage
The fuel gage shows
approximately how much
fuel is in the tank. It works
only when the ignition is
in RUN.Here are a few concerns some owners have had about
the fuel gage. All of these situations are normal and do
not indicate that anything is wrong with the fuel gage.

At the gas station the gas pump shuts off before
the gage reads full.

It takes more (or less) gas to fill the tank than the
gage said. For example, the gage read half a tank,
but it took more (or less) than the tank's remaining
capacity to fill it.

The gage may change when you turn, stop or
speed up.
Fuel Data Display
Everything you need to know about the fuel
economy and how far you can travel with your
vehicle's remaining fuel is displayed on the Driver
Information Center (DIC). Fuel data can be
obtained by pressing the SKIP INFO button
located on the instrument panel above the audio
system. See ªDIC Controls and Displaysº later
in this section for more information.

2-78
Driver Information Center (DIC)
This display gives you the status of many of your
vehicle's systems. The DIC is also used to display driver
personalization features and warning/status messages.
DIC Controls and Displays
YES TRIP RESET: By using this button, you can tell
how far you've gone since you last set the YES TRIP
RESET back to zero. To reset, press and hold this button
until zeros appear. If your vehicle is domestic, the trip
odometer will return to zero after 999.9 miles (1 609 km).
If your vehicle is Canadian, the trip odometer will return
to zero after 1 999.9 km (1,242 miles).NO INFO RESET: Pressing this button will reset the
MPG AVG, GAL FUEL USED, AVG MPH, TIMER,
OIL LIFE LEFT and ENGLISH/METRIC RESET.
Pressing NO INFO RESET when a non
-resettable
display appears will cause a ªrecallº mode to occur.
When this happens, all Driver Information Center (DIC)
warning messages that have been displayed since the
ignition key was turned to RUN will redisplay. If no
messages were displayed, a MONITORED SYSTEMS
OK message will appear.
SKIP INFO: Pressing this button repeatedly will
display the RANGE, MPG AVG, MPG INST, GAL
FUEL USED, AVG MPH, TIMER, BATTERY VOLTS,
OIL LIFE LEFT and ENGLISH/METRIC RESET.

MPG AVG (Reset): Press the SKIP INFO button
to display the MPG AVG (Average Fuel Economy),
then press and hold the NO INFO RESET button
until 0.0 MPG AVG is displayed.

GAL FUEL USED (Reset): Press the SKIP INFO
button to display the GAL FUEL USED on the
Driver Information Center (DIC), then press and
hold the NO INFO RESET button until 0.0 GAL
FUEL USED is displayed.

2-79

AVG MPH (Reset): Press the SKIP INFO button to
display the AVG MPH (Average Speed), then press
and hold the NO INFO RESET button until 0.0 AVG
MPH is displayed.

TIMER: This feature is like a stopwatch in that
you can clock the time it takes to get from one point
to another.
To operate, press the SKIP INFO button to display
TIMER. Each of the fields for the hours, minutes and
seconds are two numeric digits.
Once TIMER OFF 00:00:00 is displayed, press the
NO INFO RESET button to toggle between ON and
OFF. Once the TIMER is in OFF, press and hold
NO INFO RESET to reset the timer. If you will be
starting and stopping your vehicle
-- during a trip
for instance
-- the TIMER feature will automatically
start timing where it left off when you last stopped.
To reset it, press and hold the NO INFO RESET
button until the display reads TIMER 00:00:00.
Press the SKIP INFO button to exit from the
TIMER function.
ENGLISH/METRIC (Reset): Press the SKIP INFO
button to display ENGLISH/METRIC RESET,
then press the NO INFO RESET button to select.
The display will change from English (miles) to
metric (kilometers).

OIL LIFE LEFT (Reset): Press the SKIP INFO
button to display the OIL LIFE LEFT, then press and
hold the NO INFO RESET button until 100% OIL
LIFE LEFT is displayed. (This only needs to be reset
after you have had the oil changed.)
FUEL DOOR: Press this button to open the fuel
door. (This feature will work only when the shift lever is
in PARK (P) and the VALET lockout feature is turned
off, regardless of whether or not the vehicle is running.)
TRUNK: Press this button to open the trunk.
(This feature will work only when the shift lever is
in PARK (P) and the VALET lockout feature is
turned off, regardless of whether or not the vehicle
is running.)

2-80 DIC Messages
These messages will appear if there is a problem sensed
in one of your vehicle's systems. Vehicles that are first
sold in Canada will have a number after each message.
This number helps to identify the message which is
only displayed in English.
Pressing the INFO or NO INFO RESET button(s)
will remove most of the following messages from the
DIC display:
APPLY BRAKE TO SHIFT
- 46: This message
will appear if your vehicle is in PARK (P) for about
15 seconds and the brake is not pressed. On the climate
control panel, press the OFF button (next to the MODE
button) and the down arrow on the PASS TEMP button
for about five seconds. Hold the same two buttons to
display the message again.
BATTERY NOT CHARGING
- 7: This message will
appear if the battery is not being charged. Have the
electrical system checked by your dealership at your
earliest convenience.BATTERY VOLTAGE HIGH
- 8: This message
shows that the electrical charging system is
overcharging (more than 16 volts). To avoid being
stranded, have the electrical system checked by your
dealership. You can reduce the charging overload by
using the accessories. Turn on the lamps and radio, set
the climate control on AUTO and the fan speed on HI,
and turn the rear window defogger on. You can monitor
battery voltage on the DIC by pressing the SKIP INFO
button. The normal range is 11.5 to 15.5 volts when the
engine is running.
BATTERY VOLTAGE LOW
- 6: This message
will appear when the electrical system is charging
less than 10 volts or if the battery has been drained.
If this message appears immediately after starting,
it is possible that the generator can still recharge the
battery. The battery should recharge and may take a
few hours to do so. Consider using an auxiliary charger
to boost the battery after returning home or to a final
destination. (Be sure to follow the manufacturer's
instructions when using a battery charger.)

2-81
If this message appears and stays on while driving or
after starting your vehicle, have it checked immediately
to determine the cause of this problem. To help the
generator recharge the battery quickly, you can reduce
the load on the electrical system by turning off the
accessories. You can monitor battery voltage on the
DIC by pressing the SKIP INFO button. The normal
range is 11.5 to 15.5 volts.
CHANGE ENGINE OIL
- 82: This means that
the life of the engine oil has expired and it should be
changed within 200 miles (322 km). See ªEngine Oilº
in the Index. After an oil change, the Oil Life Indicator
must be reset. See ªOil Life Indicator, How to Resetº
in the Index.
CHANGE TRANS FLUID
- 47: This message will
appear when it is time to replace the transaxle fluid.
See ªMaintenance Scheduleº in the Index for the proper
fluid and change intervals.CHECK BRAKE FLUID LEVEL
- 37: This message
will display if the ignition is in RUN to inform the
driver that the brake fluid level is low. Have the brake
system serviced by a technician as soon as possible.
See ªBrake System Warning Lightº in the Index.
CHECK COOLANT LEVEL
- 2: This message
will appear when there is a low level of engine coolant.
Have the cooling system serviced by a technician as
soon as possible.
CHECK FUEL GAUGE
- 39: This message will
appear when the fuel supply is less than 3.5 gallons
(13.2 L) remaining. A single chime will also sound
when this message is displayed.
CHECK GAS CAP
- 61: This message will appear
if the gas cap has not been fully tightened. You should
recheck your gas cap to ensure that it's fully tightened.

2-82
CHECK OIL LEVEL - 36: For correct operation
of the low oil sensing system, your vehicle should be on
a level surface. A false CHECK OIL LEVEL message
may appear if the vehicle is parked on grades. The oil
level sensing system does not check for actual oil level
if the engine has been off for a short period of time, and
the oil level is never sensed while the engine is running.
If the CHECK OIL LEVEL message appears and
your vehicle has been parked on level ground with the
engine off for at least 30 minutes, the oil level should
be checked by observing the oil dipstick. Prior to
checking the oil level, be sure the engine has been off
for five minutes and your vehicle is on a level surface.
Then check the dipstick and add oil if necessary.
See ªEngine Oilº in the Index.
CHECK WASHER FLUID
- 25: This message
will appear for several seconds indicating that you
need windshield washer solvent.
CRUISE ENGAGED
- 43: This message will
appear for a few seconds when you select a speed at
which to cruise.DOOR AJAR
- 141: A door other than the driver's is
open or ajar when this message appears. The vehicle's
engine must be running and the transaxle not in
PARK (P) for this message to display. A chime will
also sound when the vehicle's speed is greater than
5 mph (8 km/h).
DRIVER DOOR AJAR
- 140: This message will
display when the vehicle is being shifted out of
PARK (P) with the engine running to signal that the
driver's door is open or ajar. A chime will also sound
when the vehicle's speed is greater than 5 mph (8 km/h).
ENGINE COOLANT HOT, IDLE ENGINE
- 44:
This message will appear when the engine coolant
temperature is over 248
F (126
C). To avoid added
strain on a hot engine, turn off the climate control
system. Stop and allow your vehicle to idle until it cools
down or the message is removed. If it does not cool
down, turn off the engine and have it serviced before
driving it again. Severe engine damage can result from
an overheated engine. See ªEngine Overheatingº in
the Index.

2-83
ENGINE HOT - A/C OFF - 16: This message
displays when the engine coolant becomes hotter than
the normal operating temperature. To avoid added strain
on a hot engine, the air conditioning compressor is
automatically turned off so that air conditioned air is
not delivered. If the coolant temperature returns to
normal, you must select AC to return to a normal A/C
compressor operation. If this message continues to
appear, have the system repaired as soon as possible to
avoid compressor damage.
ENGINE MISFIRE
-- EASE OFF GAS
PEDAL
- 114: An engine misfire has occurred.
You'll need to ease off the gas pedal.
ENGINE OVERHEATED, STOP ENGINE
- 42:
This message will appear when the engine has overheated.
Stop and turn the engine off immediately to avoid severe
engine damage. See ªEngine Overheatingº in the Index.
A multiple chime will also sound when this message
is displayed.
ENGINE POWER REDUCED
- 41: This message
informs you that your vehicle is reducing engine power
because the transaxle is being placed in gear under
conditions that may cause damage to the vehicle
powertrain or vehicle acceleration.FUEL LEVEL LOW
- 11 : This message serves as
a warning that the fuel level in the tank is critically low.
Stop for fuel soon.
HEADLAMPS SUGGESTED
- 23: If it's dark enough
outside and Twilight Sentinel is off, a HEADLAMPS
SUGGESTED message will display on the DIC.
This message informs the driver that turning on the
exterior lamps is recommended even though the
Daytime Running Lamps (DRL) are still illuminated
(it's become dark enough outside to require the
headlamps and/or other exterior lamps).
ICE POSSIBLE
- 13: This message appears when
the outside air temperature is cold enough to create icy
road conditions.
LOW REFRIG A/C OFF
- 12: This message means
that the air conditioning system detects a refrigerant
level that is low enough to cause damage to the air
conditioning compressor. Have the air conditioning
system serviced if this message appears.
MONITORED SYSTEMS OK
- 1: This message only
appears in the ªrecallº mode by pressing the NO INFO
RESET button. It lets you know that no other messages
are stored or are currently active.
