2. Locate in the garage, the garage door openerreceiver (motor-head unit). Locate the“Learn”or“Smart”button. It can usually be found wherethe hanging antenna wire is attached to themotor-head unit and may be a colored button.Press this button. After pressing this button,complete the following steps in less than30 seconds.
3. Immediately return to the vehicle. Press and holdthe Universal Home Remote button that will beused to control the garage door until the garagedoor moves. The indicator light, above the selectedbutton, should slowly blink. This button may needto be held for up to 20 seconds.
4. Immediately, within one second, release the buttonwhen the garage door moves. The indicator lightwill blink rapidly until programming is complete.
5. Press and release the same button again.The garage door should move, confirming thatprogramming is successful and complete.
To program another Rolling Code device such as anadditional garage door opener, a security device,or home automation device, repeat Steps 1 through 5,choosing a different function button in Step 3 than whatwas used for the garage door opener.
If these instructions do not work, the garage dooropener is probably a Fixed Code unit. Follow theProgramming instructions that follow for a Fixed Codegarage door opener.
3-57

Programming Universal Home
Remote—Fixed Code
For questions or help programming the Universal HomeRemote System, call 1-866-572-2728 or go tolearcar2u.com.
Most garage door openers sold before 1996 are FixedCode units.
Programming a garage door opener involvestime-sensitive actions, so read the entire procedurebefore starting. Otherwise, the device will time out andthe procedure will have to be repeated.
To program up to three devices:
1. To verify that the garage door opener is a FixedCode unit, remove the battery cover on the handheld transmitter supplied by the manufacturer ofthe garage door opener motor. If there are a rowof dip switches similar to the graphic above, thegarage door opener is a Fixed Code unit. If youdo not see a row of dip switches, return to theprevious section for Programming Universal HomeRemote–Rolling Code.
3-58

Your hand held transmitter can have betweeneight to 12 dip switches depending on the brandof transmitter.
The garage door opener receiver (motor head unit)could also have a row of dip switches that can beused when programming the Universal HomeRemote. If the total number of switches on themotor head and hand held transmitter are different,or if the dip switch settings are different, use thedip switch settings on the motor head unit toprogram the Universal Home Remote. The motorhead dip switch settings can also be used whenthe original hand held transmitter is not available.
Example of Eight Dip Switches with Two Positions
3-59

Example of Eight Dip Switches with Three Positions
The panel of switches might not appear exactlyas they do in the examples above, but they shouldbe similar.
The switch positions on the hand-held transmittercould be labeled, as follows:
.A switch in the up position could be labeledas“Up,”“+,”or“On.”
.A switch in the down position could be labeledas“Down,”“!,”or“Off.”
.A switch in the middle position could be labeledas“Middle,”“0,”or“Neutral.”
2. Write down the eight to 12 switch settings fromleft to right as follows:
.When a switch is in the up position,write“Left.”
.When a switch is in the down position,write“Right.”
.If a switch is set between the up and downposition, write“Middle.”
The switch settings written down in Step 2 nowbecome the button strokes to be entered intothe Universal Home Remote in Step 4. Be sureto enter the switch settings written down inStep 2, in order from left to right, into theUniversal Home Remote, when completingStep 4.
3. From inside your vehicle, first firmly press allthree buttons at the same time for aboutthree seconds. Release the buttons to put theUniversal Home Remote into programming mode.
3-60

4. The indicator lights will blink slowly. Enter eachswitch setting from Step 2 into your vehicle'sUniversal Home Remote. You will have two andone-half minutes to complete Step 4. Now pressone button on the Universal Home Remote foreach switch setting as follows:
.If you wrote“Left,”press the left button inthe vehicle.
.If you wrote“Right,”press the right button inthe vehicle.
.If you wrote“Middle,”press the middle button inthe vehicle.
5. After entering all of the switch positions, again,firmly press and release all three buttons at thesame time. The indicator lights will turn on.
6. Press and hold the button that will be used tocontrol the garage door until the garage doormoves. The indicator light above the selectedbutton should slowly blink. This button may need tobe held for up to 55 seconds.
7. Immediately release the button when the garagedoor moves. The indicator light will blink rapidlyuntil programming is complete.
8. Press and release the same button again.The garage door should move, confirming thatprogramming is successful and complete.
To program another Fixed Code device such as anadditional garage door opener, a security device,or home automation device, repeat Steps 1-8, choosinga different button in Step 6 than what was used for thegarage door opener.
3-61

Using Universal Home Remote
Press and hold the appropriate button for at least halfof a second. The indicator light will come on while thesignal is being transmitted.
Reprogramming Universal Home
Remote Buttons
Any of the three buttons can be reprogrammed byrepeating the instructions.
Erasing Universal Home Remote
Buttons
The programmed buttons should be erased when thevehicle is sold or the lease ends.
To erase either Rolling Code or Fixed Code on theUniversal Home Remote device:
1. Press and hold the two outside buttons at thesame time for approximately 20 seconds, until theindicator lights, located directly above the buttons,begin to blink rapidly.
2. Once the indicator lights begin to blink, releaseboth buttons. The codes from all buttons willbe erased.
For help or information on the Universal Home RemoteSystem, call the customer assistance phone numberunderCustomer Assistance Offices on page 9!6.
Storage Areas
Glove Box
Pull the bottom of the glove box handle upward toopen it. Use the key to lock and unlock the glove box.
Cupholders
Cupholders are located in the center console for thefront passengers. Press down on the access doorrelease to open and use the front cupholders. Push thedoor back down to close it. Push down and then backon the front cupholder to remove it for cleaning.
Heated and Cooled Cupholders
For vehicles with heated and cooled cupholders, theseare located in the front center console.
Press down on the access door release button to openthe cupholder door.
3-62

To set to cool mode, press and release the button theishows blue. Press and release again to turn it off.
To set to heat mode, press and release the button thehshows red. Press and release again to turn it off.
Insulated containers will not work properly. Use onlynon-insulated containers.
Notice:When the cuphholder is turned on, theinside receptacles are hot or cold. Temperaturevariations in the cupholders may causecondensation. To avoid damage, do not storeelectronic devices or other items here.
Rear Passenger Cupholders
Pull down on the lid to access the cupholders inthe rear floor console.
Vehicles with the rear seat armrest may alsocontain cupholders. Pull down the armrest to usethe cupholders.
3-63

Center Console Storage
A console compartment is located between thebucket seats.
The console has both an upper and lower storage binaccessed by lifting up on the latches located at the frontof the console lid.
The console may have an accessory power outletinside. SeeAccessory Power Outlet(s) on page 4!19.
The rear of the console also has a cupholder thatswings down for the rear seat passengers to use.
Assist Handles
Assist handles located above the rear passenger doorscan be used when getting out of the vehicle. Pull thehandles downward to use them.
Garment Hooks
There are garment hooks located on the assist handles.
Roof Rack System
{WARNING:
If something is carried on top of the vehicle that is
longer or wider than the roof rack—like paneling,
plywood, or a mattress—the wind can catch it
while the vehicle is being driven. The item being
carried could be violently torn off, and this could
cause a collision, and damage the vehicle. Never
carry something longer or wider than the roof rack
on top of the vehicle unless using a GM Certified
accessory carrier.
For vehicles with a roof rack, the rack can be used toload items. For roof racks that do not have crossrailsincluded, GM Certified crossrails can be purchased asan accessory. See your dealer/retailer for additionalinformation.
For vehicles with crossrails, they can be movedback and forth to help secure cargo. To adjust them,turn the knob located at each end of the crossrailcounterclockwise until the crossrail can move freely.To secure the crossrail, turn the knob located at eachend of the crossrail clockwise until tightened. Tie theload to the siderails or siderail supports.
3-64

Notice:Loading cargo on the roof rack that weighsmore than 91 kg (200 lbs) or hangs over the rear orsides of the vehicle may damage the vehicle. Loadcargo so that it rests evenly between the crossrails,making sure to fasten cargo securely.
To prevent damage or loss of cargo when driving,check to make sure crossrails and cargo are securelyfastened. Loading cargo on the roof rack will make thevehicle’s center of gravity higher. Avoid high speeds,sudden starts, sharp turns, sudden braking or abruptmaneuvers, otherwise it may result in loss of control.If driving for a long distance, on rough roads, or at highspeeds, occasionally stop the vehicle to make sure thecargo remains in its place.
Do not exceed the maximum vehicle capacity whenloading the vehicle. For more information on vehiclecapacity and loading, seeLoading the Vehicleonpage 6!32.
To prevent damage or loss of cargo, check now andthen to make sure the luggage and cargo are stillsecurely fastened.
Be sure the cargo is properly loaded.
.If small heavy objects are placed on the roof, placethe load in the area over the rear wheels (behindthe rear side door on extended models). If needed,cut a piece of 3/8 inch plywood to fit inside thecrossrails and siderails to spread the load.If plywood is used, tie it to the siderail supports.
.Tie the load to the crossrails or the siderailsupports. Use the crossrails only to keep theload from sliding. To move the crossrails, pull outon the latch release handle at each end. Slide thecrossrail to the desired position balancing the forceside to side. Push the release handle back into thelatched position and slide the crossrail back andforth slightly to be sure the latch snaps securelyinto place.
.If needed to carry long items, move the crossrailsas far apart as they will go. Tie the load to thecrossrails and the siderails or siderail supports.Also tie the load to the bumpers. Do not tie theload so tightly that the crossrails or siderailsare damaged.
.After moving a crossrail, be sure it is securelylocked into the siderail.
A Center High-Mounted Stoplamp (CHMSL) is locatedabove the glass or above the rear load doors.
If items are loaded on the roof of the vehicle, careshould be taken not to block or damage theCHMSL unit.
3-65

Rear Storage Area
For vehicles with a rear storage area, it is located inthe rear cargo area of the vehicle on the driver's sidetrim panel.
Turn the knobs and swing the storage door to accessthe storage compartment. The door can be removed.
Rear Seat Armrest
For vehicle with an armrest/storage compartmentlocated by the second row seat, pull the loop at the topof the armrest out to lower the armrest.
Push the button on the front of the armrest and pull thetop up to open the compartment.
Sunroof
Your vehicle may be equipped with a power slidingsunroof. To open or close the sunroof, the ignitionneeds to be turned to ON/RUN, or Retained AccessoryPower (RAP) must be active. When RAP is active, thesunroof will work for 10 minutes after the ignition isturned off, or until a front door is opened. SeeRetainedAccessory Power (RAP)on page 3!28for moreinformation.
There are two switches inthe overhead console thatoperate the sunroof.
Manual-Open/Manual-Close :To open the sunroofpress and hold the rear of the driver's side switch untilthe sunroof reaches the desired position. To close thesunroof, press and hold the front of the driver's sideswitch until the sunroof reaches the desired position.The sunshade will open automatically with the sunroof,but can also be opened manually.
The sunroof has a comfort stop feature which stops thesunroof from opening to the full-open position. From thecomfort stop position, press the rear of the driver's sideswitch a second time to open the sunroof to thefull-open position.
When the sunroof is opened, an air deflector willautomatically raise. The air deflector will retract whenthe sunroof is closed.
