CADILLAC ESCALADE 2010 3.G Owners Manual

Capacities and Specifications
The following approximate capacities are given in English and metric conversions. SeeRecommended Fluids andLubricantson page 8!10for more information.
ApplicationCapacities
EnglishMetric
Air Conditioning RefrigerantFor the air conditioning system refrigerant chargeamount, see the refrigerant caution label locatedunder the hood. See your dealer for more information.
Cooling System17.6 qt16.7 L
Engine Oil with Filter6.0 qt†5.7 L†
Fuel Tank
Regular26.0 gal98.4 L
Extended31.5 gal119.2 L
7-115

ApplicationCapacities
EnglishMetric
Transmission Fluid (Pan Removal and Replacement)6.0 qt5.7 L
Transfer Case Fluid1.5 qt1.4 L
Wheel Nut Torque140 lb ft190Y
All capacities are approximate. When adding, be sure to fill to the approximate level, as recommended in this manual.Recheck fluid after filling.†Oil filter should be changed at every oil change.
Engine Specifications
EngineVIN CodeTransmissionSpark Plug Gap
6.2L V8FAutomatic0.040 in (1.02 mm)
7-116

Section 8 Maintenance Schedule
Maintenance Schedule. . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2Scheduled Maintenance . . . . . . . . . . . . . . . . . . . . . . . . 8-3Owner Checks and Services . . . . . . . . . . . . . . . . . . . . 8-8
Recommended Fluids and Lubricants . . . . . . . . . . 8-10Maintenance Replacement Parts . . . . . . . . . . . . . . 8-12Engine Drive Belt Routing . . . . . . . . . . . . . . . . . . . . . 8-13Maintenance Record . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-14
8-1

Maintenance Schedule
Introduction
Notice:Maintenance intervals, checks, inspections,recommended fluids, and lubricants are necessaryto keep this vehicle in good working condition.Damage caused by failure to follow scheduledmaintenance might not be covered by the vehiclewarranty.
Proper vehicle maintenance helps to keep the vehicle ingood working condition, improves fuel economy, andreduces vehicle emissions for better air quality.
Because of all the different ways people use vehicles,maintenance needs vary. The vehicle might need morefrequent checks and services. Please read theinformation under Scheduled Maintenance. To keep thevehicle in good condition, see your dealer/retailer.
The maintenance schedule is for vehicles that:
.carry passengers and cargo within recommendedlimits on the Tire and Loading Information label.SeeLoading the Vehicle on page 6!32.
.are driven on reasonable road surfaces within legaldriving limits.
.are driven off!road in the recommended manner.SeeOff-Road Driving on page 6!13.
.use the recommended fuel. SeeGasoline Octaneo n p a g e 7!8.
{WARNING:
Performing maintenance work on a vehicle can be
dangerous. In trying to do some jobs, you can be
seriously injured. Do your own maintenance work
only if you have the required know-how and the
proper tools and equipment for the job. If you
have any doubt, see your dealer/retailer to have a
qualified technician do the work. SeeDoing Your
Own Service Work on page 7!6.
8-2

At your General Motors dealer/retailer, you can becertain that you will receive the highest level of serviceavailable. Your dealer/retailer has specially trainedservice technicians, uses genuine GM replacementparts, as well as, up to date tools and equipment toensure fast and accurate diagnostics.
The proper replacement parts, fluids, and lubricants touse are listed inRecommended Fluids and Lubricantson page 8!10andMaintenance Replacement Partsonpage 8!12. We recommend the use of genuine partsfrom your dealer/retailer.
Rotation of New Tires
To maintain ride, handling, and performance of thevehicle, it is important that the first rotation service fornew tires be performed when they have 8 000 to13 000 km (5,000 to 8,000 miles). SeeTire Inspectionand Rotation on page 7!71.
Scheduled Maintenance
When the Change Engine Oil Soon
Message Displays
Change engine oil and filter. SeeEngine Oilonpage 7!17.An Emission Control Service.
When the Change Engine Oil Soon message displays,service is required for the vehicle as soon as possible,within the next 1 000 km/600 miles. If driving under thebest conditions, the engine oil life system might notindicate the need for vehicle service for more than ayear. The engine oil and filter must be changed at leastonce a year and the oil life system must be reset. Yourdealer/retailer has trained service technicians who willperform this work and reset the system. If the engine oillife system is reset accidentally, service the vehiclewithin 5 000 km/3,000 miles since the last service. Resetthe oil life system whenever the oil is changed. SeeEngine Oil Life System on page 7!20.
When the Change Engine Oil Soon message displays,certain services, checks, and inspections are required.
8-3

Every Engine Oil Change
.Change engine oil and filter. SeeEngine Oilonpage 7!17.An Emission Control Service.
.Engine coolant level check. SeeEngine Coolanton page 7!29.
.Windshield washer fluid level check. SeeWindshield Washer Fluid on page 7!39.
.Tire inflation check. SeeInflation - Tire Pressureon page 7!65.
.Tire wear inspection. SeeTire Inspection andRotation on page 7!71.
.Rotate tires. SeeTire Inspection and Rotationonpage 7!71.
.Fluids visual leak check (or every 12 months,whichever occurs first). A leak in any system mustbe repaired and the fluid level checked.
.Engine air cleaner filter inspection. SeeEngine AirCleaner/Filter on page 7!22.
.Brake system inspection (or every 12 months,whichever occurs first).
.Lubricate the front suspension, steering linkage,and parking brake cable guides. Control arm balljoints are maintenance!free.
.Steering and suspension inspection. Visualinspection for damaged, loose, or missing parts orsigns of wear.
.Engine cooling system inspection. Visualinspection of hoses, pipes, fittings, and clamps andreplacement, if needed.
.Windshield wiper blade inspection for wear,cracking, or contamination and windshield andwiper blade cleaning, if contaminated. SeeWindshield, Backglass, and Wiper Bladesonpage 7!104. Worn or damaged wiper bladereplacement. SeeWindshield Wiper BladeReplacement on page 7!57.
.Body hinges and latches, key lock cylinders, rearcompartment hinges, outer tailgate handle pivotpoints, and folding seat hardware lubrication. SeeRecommended Fluids and Lubricantsonpage 8!10. More frequent lubrication may berequired when vehicle is exposed to a corrosiveenvironment. Applying silicone grease onweatherstrips with a clean cloth makes them lastlonger, seal better, and not stick or squeak.
.Restraint system component check. SeeCheckingthe Restraint Systems on page 2!91.
.Automatic transmission fluid level check andadding fluid, if needed. SeeAutomaticTransmission Fluid on page 7!24.
8-4

Additional Required Services
At Each Fuel Stop
.Engine oil level check. SeeEngine Oilonpage 7!17.
.Engine coolant level check. SeeEngine Coolanton page 7!29.
.Windshield washer fluid level check. SeeWindshield Washer Fluid on page 7!39.
Once a Month
.Tire inflation check. SeeInflation - Tire Pressureon page 7!65.
.Tire wear inspection. SeeTire Inspection andRotation on page 7!71.
Once a Year
.Starter switch check. SeeOwner Checks andServices on page 8!8.
.Parking brake and automatic transmission P (Park)mechanism check. SeeOwner Checks andServices on page 8!8.
.Automatic transmission shiftlock control systemcheck. SeeOwner Checks and Servicesonp a g e 8!8.
.Ignition transmission lock check. SeeOwnerChecks and Services on page 8!8.
.Engine cooling system and pressure cap pressurecheck. Radiator and air conditioning condenseroutside cleaning. SeeCooling Systemonpage 7!28.
.Exhaust system and nearby heat shieldsinspection for loose or damaged components.
.Accelerator pedal check for damage, high effort,or binding. Replace if needed.
.Hood and liftgate support gas strut inspection forsigns of wear, corrosion, cracks, loss of lubricant,or other damage. Check the hold open ability ofthe gas strut. If necessary, replace with genuineparts from your dealer/retailer.
8-5

First Engine Oil Change After Every
40 000 km/25,000 Miles
.Fuel system inspection for damage or leaks.
First Engine Oil Change After Every
80 000 km/50,000 Miles
.Engine air cleaner filter replacement. SeeEngineAir Cleaner/Filter on page 7!22.
.Automatic transmission fluid and filter change(severe service) for vehicles mainly driven in heavycity traffic in hot weather, in hilly or mountainousterrain, when frequently towing a trailer, or used fortaxi, police, or delivery service. SeeAutomaticTransmission Fluid on page 7!24.
.Four!wheel drive only: Transfer case fluid change(severe service) for vehicles mainly driven whenfrequently towing a trailer, or used for taxi, police,or delivery service. Check vent hose at transfercase for kinks and proper installation. Check to besure vent hose is unobstructed, clear, and free of
debris. During any maintenance, if a power washeris used to clean mud and dirt from the underbody,care should be taken to not directly spray thetransfer case output seals. High pressure watercan overcome the seals and contaminate thetransfer case fluid. Contaminated fluid willdecrease the life of the transfer case and shouldbe replaced.
.Evaporative control system inspection. Check allfuel and vapor lines and hoses for proper hook!up,routing, and condition. Check that the purge valve,if the vehicle has one, works properly. Replace asneeded.An Emission Control Service. The U.S.Environmental Protection Agency or the CaliforniaAir Resources Board has determined that thefailure to perform this maintenance item will notnullify the emission warranty or limit recall liabilityprior to the completion of the vehicle's useful life.We, however, urge that all recommendedmaintenance services be performed at theindicated intervals and the maintenance berecorded.
8-6

First Engine Oil Change After Every
160 000 km/100,000 Miles
.Automatic transmission fluid and filter change(normal service). SeeAutomatic TransmissionFluid on page 7!24.
.Four!wheel drive only: Transfer case fluid change(normal service). Check vent hose at transfer casefor kinks and proper installation. Check to be surevent hose is unobstructed, clear, and free ofdebris. During any maintenance, if a power washeris used to clean mud and dirt from the underbody,care should be taken to not directly spray thetransfer case output seals. High pressure watercan overcome the seals and contaminate thetransfer case fluid. Contaminated fluid willdecrease the life of the transfer case and shouldbe replaced.
.Spark plug replacement and spark plug wiresinspection.An Emission Control Service.
First Engine Oil Change After Every
240 000 km/150,000 Miles
.Engine cooling system drain, flush, and refill,cooling system and cap pressure check, andcleaning of outside of radiator and air conditioningcondenser (or every 5 years, whichever occursfirst). SeeEngine Coolanton page 7!29.AnEmission Control Service.
.Engine accessory drive belt inspection for fraying,excessive cracks, or obvious damage andreplacement, if needed.An Emission ControlService.
8-7

Owner Checks and Services
Starter Switch Check
{WARNING:
When you are doing this inspection, the vehicle
could move suddenly. If the vehicle moves, you or
others could be injured.
1. Before starting this check, be sure there is enoughroom around the vehicle.
2. Firmly apply both the parking brake and the regularbrake. SeeParking Brake on page 3!38.
Do not use the accelerator pedal, and be ready toturn off the engine immediately if it starts.
3. Try to start the engine in each gear. The vehicleshould start only in P (Park) or N (Neutral). If thevehicle starts in any other position, contact yourdealer/retailer for service.
Automatic Transmission Shift Lock
Control System Check
{WARNING:
When you are doing this inspection, the vehicle
could move suddenly. If the vehicle moves, you or
others could be injured.
1. Before starting this check, be sure there is enoughroom around the vehicle. It should be parked on alevel surface.
2. Firmly apply the parking brake. SeeParking Brakeon page 3!38.
Be ready to apply the regular brake immediately ifthe vehicle begins to move.
3. With the engine off, turn the ignition to ON/RUN,but do not start the engine. Without applying theregular brake, try to move the shift lever out ofP (Park) with normal effort. If the shift lever movesout of P (Park), contact your dealer/retailer forservice.
8-8
