VEHICLE CARE 255
Vehicle Care
General Information
General Information . . . . . . . . . . . . . 256
California Proposition65 Warning . . . . . . . . . . . . . . . . . . . . . 256
California Perchlorate Materials Requirements . . . . . . . . . . . . . . . . . . . 257
Accessories and Modifications . . . . . . . . . . . . . . . . . . . 257
Vehicle Checks
Doing Your OwnService Work . . . . . . . . . . . . . . . . . . . . 257
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 258
Engine Compartment Overview . . . . . . . . . . . . . . . . . . . . . . . . . 260
Engine Oil . . . . . . . . . . . . . . . . . . . . . . . . . 261
Engine Oil Life System . . . . . . . . . . . 263
Automatic Transmission Fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 264
Engine Air Cleaner/Filter . . . . . . . . . 265
Cooling System . . . . . . . . . . . . . . . . . . . 266
Engine Overheating . . . . . . . . . . . . . . 269
Engine Fan . . . . . . . . . . . . . . . . . . . . . . . . 270
Washer Fluid . . . . . . . . . . . . . . . . . . . . . 271
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 271
Brake Fluid . . . . . . . . . . . . . . . . . . . . . . . 272
Battery - North America . . . . . . . . . 273 Four-Wheel Drive . . . . . . . . . . . . . . . . 274
Front Axle . . . . . . . . . . . . . . . . . . . . . . . . 275
Rear Axle . . . . . . . . . . . . . . . . . . . . . . . . . 275
Starter Switch Check . . . . . . . . . . . . . 275
Automatic Transmission Shift
Lock Control Function
Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . 275
Park Brake and P (Park) Mechanism Check . . . . . . . . . . . . . . 276
Wiper Blade Replacement . . . . . . . 276
Glass Replacement . . . . . . . . . . . . . . . 277
Windshield Replacement . . . . . . . . 277
Gas Strut(s) . . . . . . . . . . . . . . . . . . . . . . . 277Headlamp Aiming
Headlamp Aiming . . . . . . . . . . . . . . . . 279
Bulb Replacement
Bulb Replacement . . . . . . . . . . . . . . . . 279
LED Lighting . . . . . . . . . . . . . . . . . . . . . 279
License Plate Lamp . . . . . . . . . . . . . . 279
Electrical System
Electrical System Overload . . . . . . 280
Fuses and Circuit Breakers . . . . . . 280
Engine Compartment Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . . . . . 281
Instrument Panel Fuse Block (Right) . . . . . . . . . . . . . . . . . . . . . . . . . . . 285
Instrument Panel Fuse Block (Left) . . . . . . . . . . . . . . . . . . . . . . 287 Rear Compartment Fuse
Block . . . . . . . . . . . . . . . . . . . . . . . . . . . . 290
Wheels and Tires
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 291
All-Season Tires . . . . . . . . . . . . . . . . . . 292
Winter Tires . . . . . . . . . . . . . . . . . . . . . . 292
Low-Profile Tires . . . . . . . . . . . . . . . . . 293
All-Terrain Tires . . . . . . . . . . . . . . . . . . 293
Tire Sidewall Labeling . . . . . . . . . . . 293
Tire Designations . . . . . . . . . . . . . . . . . 294
Tire Terminology andDefinitions . . . . . . . . . . . . . . . . . . . . . . 295
Tire Pressure . . . . . . . . . . . . . . . . . . . . . . 297
Tire Pressure for High-Speed Operation . . . . . . . . . . . . . . . . . . . . . . . . 299
Tire Pressure Monitor System . . . 299
Tire Pressure Monitor
Operation . . . . . . . . . . . . . . . . . . . . . . . . 300
Tire Inspection . . . . . . . . . . . . . . . . . . . 304
Tire Rotation . . . . . . . . . . . . . . . . . . . . . 304
When It Is Time for New Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 305
Buying New Tires . . . . . . . . . . . . . . . . 306
Different Size Tires and Wheels . . . . . . . . . . . . . . . . . . . . . . . . . . 307
Uniform Tire Quality Grading . . . 308
Wheel Alignment and Tire Balance . . . . . . . . . . . . . . . . . . . . . . . . . . 309
Wheel Replacement . . . . . . . . . . . . . . 309
Tire Chains . . . . . . . . . . . . . . . . . . . . . . . 310

Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
13566588) - 2020 - CRC - 4/24/19
304 VEHICLE CARE
identification code has been
matched to the driver side rear
tire, and the TPMS sensor
matching process is no longer
active. The TIRE LEARNING
ACTIVE message on the DIC
display screen goes off.
11. Turn the vehicle off.
12. Set all four tires to the recommended air pressure level
as indicated on the Tire and
Loading Information label.
Tire Inspection
We recommend that the tires,
including the spare tire, if the
vehicle has one, be inspected for
signs of wear or damage at least
once a month.
Replace the tire if:
.The indicators at three or more
places around the tire can
be seen.
.There is cord or fabric showing
through the tire's rubber.
.The tread or sidewall is
cracked, cut, or snagged deep
enough to show cord or fabric.
.The tire has a bump, bulge,
or split.
.The tire has a puncture, cut,
or other damage that cannot
be repaired well because of the
size or location of the damage.
Tire Rotation
Tires should be rotated every
12 000 km (7,500 mi). See
Maintenance Schedule 0339.
Tires are rotated to achieve a
uniform wear for all tires. The first
rotation is the most important.
Anytime unusual wear is noticed,
rotate the tires as soon as
possible, check for proper tire
inflation pressure, and check for
damaged tires or wheels. If the
unusual wear continues after the
rotation, check the wheel alignment. See
When It Is Time for
New Tires 0305 and
Wheel Replacement 0309.
Use this rotation pattern when
rotating the tires.
Do not include the spare tire in
the tire rotation.
Adjust the front and rear tires to
the recommended inflation
pressure on the Tire and Loading
Information label after the tires
have been rotated. See Tire
Pressure 0297 and
Vehicle Load Limits 0178.

Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
13566588) - 2020 - CRC - 4/24/19
VEHICLE CARE 309
due to variations in driving habits,
service practices and differences
in road characteristics and
climate.
Traction
The traction grades, from highest
to lowest, are AA, A, B, and C.
Those grades represent the tire's
ability to stop on wet pavement as
measured under controlled
conditions on specified
government test surfaces of
asphalt and concrete. A tire
marked C may have poor traction
performance. Warning: The
traction grade assigned to this tire
is based on straight-ahead braking
traction tests, and does not
include acceleration, cornering,
hydroplaning, or peak traction
characteristics.
Temperature
The temperature grades are A (the
highest), B, and C, representing
the tire's resistance to thegeneration of heat and its ability
to dissipate heat when tested
under controlled conditions on a
specified indoor laboratory test
wheel. Sustained high temperature
can cause the material of the tire
to degenerate and reduce tire life,
and excessive temperature can
lead to sudden tire failure. The
grade C corresponds to a level of
performance which all passenger
car tires must meet under the
Federal Motor Safety Standard
No. 109. Grades B and A represent
higher levels of performance on
the laboratory test wheel than the
minimum required by law.
Warning: The temperature grade
for this tire is established for a tire
that is properly inflated and not
overloaded. Excessive speed,
underinflation, or excessive
loading, either separately or in
combination, can cause heat
buildup and possible tire failure.Wheel Alignment and Tire
Balance
The tires and wheels were aligned and
balanced at the factory to provide the
longest tire life and best overall
performance. Adjustments to wheel
alignment and tire balancing are not
necessary on a regular basis. Consider
an alignment check if there is unusual
tire wear or the vehicle is significantly
pulling to one side or the other. Some
slight pull to the left or right,
depending on the crown of the road
and/or other road surface variations
such as troughs or ruts, is normal.
If the vehicle is vibrating when driving
on a smooth road, the tires and
wheels may need to be rebalanced.
See your dealer for proper diagnosis.
Wheel Replacement
Replace any wheel that is bent,
cracked, or badly rusted or corroded.
If wheel nuts keep coming loose, the
wheel, wheel bolts, and wheel nuts
should be replaced. If the wheel leaks

Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
13566588) - 2020 - CRC - 4/24/19
348 SERVICE AND MAINTENANCE
Wheel Alignment
Wheel alignment is critical for
ensuring that the tires deliver optimal
wear and performance.
.Signs that the alignment may need
to be adjusted include pulling,
improper vehicle handling,
or unusual tire wear.
. Your dealer has the required
equipment to ensure proper wheel
alignment. Windshield
For safety, appearance, and the best
viewing, keep the windshield clean
and clear.
.
Signs of damage include scratches,
cracks, and chips.
. Trained dealer technicians can
inspect the windshield and
recommend proper replacement if
needed. Wiper Blades
Wiper blades need to be cleaned and
kept in good condition to provide a
clear view.
.
Signs of wear include streaking,
skipping across the windshield,
and worn or split rubber.
. Trained dealer technicians can
check the wiper blades and replace
them when needed.

Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
13566588) - 2020 - CRC - 4/24/19
INDEX 389
StrutsGas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 277
Stuck Vehicle . . . . . . . . . . . . . . . . . . . . . . . 178
Sun Visors . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Sunglass Storage . . . . . . . . . . . . . . . . . . . . 101
Sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
System Forward Collision Alert (FCA) . . . . 226
Infotainment . . . . . . . . . . . . . . . . . 156, 369
Roof Rack . . . . . . . . . . . . . . . . . . . . . . . . . 103
Systems Driver Assistance . . . . . . . . . . . . . . . . . 218
T
Tachometer . . . . . . . . . . . . . . . . . . . . . . . . . 118
Text Telephone (TTY) Users . . . . . . . 358
Theft-Deterrent Systems . . . . . . . . . . . . 31Immobilizer . . . . . . . . . . . . . . . . . . . . . . . . . 31
Third-Row Seats . . . . . . . . . . . . . . . . . . . . . 55
Throttle, Adjustable . . . . . . . . . . . . . . . . 183
Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 291 All-Season . . . . . . . . . . . . . . . . . . . . . . . . . 292
All-Terrain . . . . . . . . . . . . . . . . . . . . . . . . . 293
Buying New Tires . . . . . . . . . . . . . . . . . 306
Chains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 310
Changing . . . . . . . . . . . . . . . . . . . . . . . . . . 312 Tires (cont'd)
Designations . . . . . . . . . . . . . . . . . . . . . . 294
Different Size . . . . . . . . . . . . . . . . . . . . . . 307
Full-Size Spare . . . . . . . . . . . . . . . . . . . . 321
If a Tire Goes Flat . . . . . . . . . . . . . . . . 311
Inspection . . . . . . . . . . . . . . . . . . . . . . . . . 304
Low Profile . . . . . . . . . . . . . . . . . . . . . . . . 293
Pressure . . . . . . . . . . . . . . . . . . . . . . 297, 299
Pressure Light . . . . . . . . . . . . . . . . . . . . . 127
Pressure Monitor Operation . . . . . . 300
Pressure Monitor System . . . . . . . . 299
Rotation . . . . . . . . . . . . . . . . . . . . . . . . . . . 304
Sidewall Labeling . . . . . . . . . . . . . . . . . 293
Terminology and Definitions . . . . 295
Uniform Tire Quality Grading . . . . 308
Wheel Alignment and Tire
Balance . . . . . . . . . . . . . . . . . . . . . . . . . . 309
Wheel Replacement . . . . . . . . . . . . . . 309
When It Is Time for New
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 305
Winter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 292
Top Tier Fuel . . . . . . . . . . . . . . . . . . . . . . . . 234
Tow/Haul Mode . . . . . . . . . . . . . . . . . . . . . 195
Tow/Haul Mode Light . . . . . . . . . . . . . . 125
Towing Driving Characteristics . . . . . . . . . . . 237
Equipment . . . . . . . . . . . . . . . . . . . . . . . . 247
General Information . . . . . . . . . . . . . . 237 Towing (cont'd)
Recreational Vehicle . . . . . . . . . . . . . . 326
Trailer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 242
Trailer Sway Control (TSC) . . . . . . . 251
Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 325
Traction Control System(TCS)/StabiliTrak Light . . . . . . . . . 126
Off Light . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
Traction Control/Electronic Stability Control . . . . . . . . . . . . . . . . . . . 203
Trailer Sway Control (TSC) . . . . . . . . . . . . . . . 251
Towing . . . . . . . . . . . . . . . . . . . . . . . . . . . . 242
Transfer Case . . . . . . . . . . . . . . . . . . . . . . . 196
Transmission Automatic . . . . . . . . . . . . . . . . . . . . . . . . . 191
Fluid, Automatic . . . . . . . . . . . . . . . . . . 264
Transportation Program, Courtesy . . . . . . . . . . . . . . . . . . . . . . . . . . . 362
Trip Odometer . . . . . . . . . . . . . . . . . . . . . . 117
Turn and Lane-Change Signals . . . . 152
U
Uniform Tire Quality Grading . . . . . . 308
Universal Remote System . . . . . . . . . . 145 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . 147

Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
13566588) - 2020 - CRC - 4/24/19
390 INDEX
Universal Remote System (cont'd)Programming . . . . . . . . . . . . . . . . . . . . . . 145
Using This Manual . . . . . . . . . . . . . . . . . . . . 2
V
Vehicle Alarm System . . . . . . . . . . . . . . . . . . . . . . . 28
Canadian Owners . . . . . . . . . . . . . . . . . . . . 2
Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . 168
Identification Number (VIN) . . . . . 352
Load Limits . . . . . . . . . . . . . . . . . . . . . . . 178
Messages . . . . . . . . . . . . . . . . . . . . . . . . . . 135
Personalization . . . . . . . . . . . . . . . . . . . 136
Remote Start . . . . . . . . . . . . . . . . . . . . . . . . 15
Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Speed Messages . . . . . . . . . . . . . . . . . . . 136
Towing . . . . . . . . . . . . . . . . . . . . . . . . . . . . 325
Vehicle Ahead Indicator . . . . . . . . . . . . 126
Vehicle Care Tire Pressure . . . . . . . . . . . . . . . . . . . . . . 297
Vehicle Data Recording and Privacy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 367
Vehicle Security Steering Column Lock . . . . . . . . . . . . . . 30
Ventilation, Air . . . . . . . . . . . . . . . . . . . . . 163
Visors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
W
Warning Brake System Light . . . . . . . . . . . . . . . 123
Caution and Danger . . . . . . . . . . . . . . . . . 2
Warning Lights, Gauges, and
Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . 114
Warnings Hazard Flashers . . . . . . . . . . . . . . . . . . . 152
Washer Fluid . . . . . . . . . . . . . . . . . . . . . . . . 271
Wheels Alignment and Tire Balance . . . . . 309
Different Size . . . . . . . . . . . . . . . . . . . . . . 307
Replacement . . . . . . . . . . . . . . . . . . . . . . 309
When It Is Time for New Tires . . . . 305
Where to Put the Restraint . . . . . . . . . 85
Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Windshield Replacement . . . . . . . . . . . . . . . . . . . . . . 277
Wiper/Washer . . . . . . . . . . . . . . . . . . . . . 105
Winter Driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177
Winter Driving Mode Light . . . . . . . . 125
Winter Tires . . . . . . . . . . . . . . . . . . . . . . . . . 292
Wiper Blade Replacement . . . . . . . . . . 276
Wipers Rear Washer . . . . . . . . . . . . . . . . . . . . . . 107
Wireless Charging . . . . . . . . . . . . . . . . . . 111
