1. Open the hoist shaft access cover on the
bumper to access the spare tire lock (J).
2. Insert the ignition key, turn it clockwise and
then pull it to remove the spare tire lock.
3. Assemble the two jack handle extensions (I)
and wheel wrench (H) as shown.4. Insert the open end
of the extension (F)
through the hole
in the rear
bumper (G) (hoist
shaft access hole).
Be sure the hoist end (F) of the extension
connects to the hoist shaft. The ribbed square
end of the extension is used to lower the
spare tire.
5. Turn the wheel wrench counterclockwise to
lower the spare tire to the ground. Continue
to turn the wheel wrench until the spare
tire can be pulled out from under the vehicle.
If the spare tire does not lower to the
ground, the secondary latch is engaged
causing the tire not to lower. SeeSecondary
Latch System on page 489for more
information.
481

6. Use the wheel
wrench hook that
allows you to
pull the hoist cable
towards you, to
assist in reaching
the spare tire.
7. Tilt the tire retainer
at the end of the
cable when the tire
has been lowered,
so it can be
pulled up through
the wheel opening.
8. Put the spare tire near the at tire.Removing the Flat Tire and
Installing the Spare Tire
Use the following pictures and instructions to
remove the at tire and raise the vehicle.
The tools you will be using include the jack (A),
the wheel blocks (B), the jack handle (C), the jack
handle extensions (D), and the wheel wrench (E).
482

1. If the wheel has a smooth center cap, place
the chisel end of the wheel wrench in the slot
on the wheel and gently pry it out.2. Use the wheel
wrench to loosen all
the wheel nuts. Turn
the wheel wrench
counterclockwise to
loosen the wheel
nuts. Do not remove
the wheel nuts yet.
483

A. Front Position
B. Rear Position
{CAUTION:
Getting under a vehicle when it is jacked
up is dangerous. If the vehicle slips off
the jack you could be badly injured or
killed. Never get under a vehicle when it is
supported only by a jack.
{CAUTION:
Raising your vehicle with the jack
improperly positioned can damage the
vehicle and even make the vehicle fall. To
help avoid personal injury and vehicle
damage, be sure to t the jack lift head
into the proper location before raising the
vehicle.
3. Position the jack under the vehicle as shown.
Jacking Locations (Overall View)
484

Front Tire Flat:If the at tire is on a front tire
of the vehicle, you will need to use the jack
handle (B) and only one jack handle
extension (C). Attach the wheel wrench (D) to
the jack handle extension (C). Attach the
jack handle (B) to the jack (A). Position the jack
on the frame behind the at tire near the
front body mount (E) as shown. Turn the wheel
wrench (D) clockwise to raise the vehicle.
Raise the vehicle far enough off the ground so
there is enough room for the spare tire to
clear the ground.
Front Position
485

Rear Tire Flat:If the at tire is on a rear tire
of the vehicle, you will need to use the
jack handle (B) and both jack handle
extensions (C). Attach the wheel wrench (D) to
the jack handle extensions (C). Attach the
jack handle (B) to the jack (A). Use the jacking
pad provided on the rear axle. Turn the
wheel wrench (D) clockwise to raise the
vehicle. Raise the vehicle far enough off the
ground so there is enough room for the spare
tire to clear the ground.
4. Remove all the
wheel nuts.
5. Take off the at tire.
Rear Position
486

{CAUTION:
Rust or dirt on the wheel, or on the parts
to which it is fastened, can make the
wheel nuts become loose after a time. The
wheel could come off and cause an
accident. When you change a wheel,
remove any rust or dirt from the places
where the wheel attaches to the vehicle. In
an emergency, you can use a cloth or a
paper towel to do this; but be sure to use
a scraper or wire brush later, if needed, to
get all the rust or dirt off.
6. Remove any rust or
dirt from the wheel
bolts, mounting
surfaces, and spare
wheel.7. Install the spare tire.{CAUTION:
Never use oil or grease on studs or nuts.
If you do, the nuts might come loose.
Your wheel could fall off, causing a
serious accident.
8. Put the wheel nuts back on with the rounded
end of the nuts toward the wheel after
mounting the spare tire.
9. Tighten each wheel nut by hand. Then use
the wheel wrench to tighten the wheel nuts
until the wheel is held against the hub.
10. Turn the wheel wrench counterclockwise to
lower the vehicle. Lower the jack completely.
487

{CAUTION:
Incorrect wheel nuts or improperly
tightened wheel nuts can cause the wheel
to come loose and even come off. This
could lead to an accident. Be sure to use
the correct wheel nuts. If you have to
replace them, be sure to get new GM
original equipment wheel nuts. Stop
somewhere as soon as you can and have
the nuts tightened with a torque wrench to
the proper torque specication. See
Capacities and Specifications on page 518
for wheel nut torque specication.
Notice:Improperly tightened wheel nuts can
lead to brake pulsation and rotor damage.
To avoid expensive brake repairs, evenly
tighten the wheel nuts in the proper sequence
and to the proper torque specication. See
Capacities and Specifications on page 518for
the wheel nut torque specication.11. Tighten the nuts
rmly in a crisscross
sequence as
shown by turning
the wheel wrench
clockwise.
When you reinstall the full-size wheel and tire, you
must also reinstall the wheel cover with attached
plastic nuts, the plastic nut caps, or the smooth
center cap.
If you are reinstalling a wheel cover with
attached plastic nuts, place it on the wheel and
tighten the nuts by hand to get them started.
Then tighten the nut caps with the wheel
wrench until they are snug. Do not overtighten
the nut caps or they may break.
If you are reinstalling plastic nut caps, tighten
the nuts by hand to get them started. Then
tighten the nut caps with the wheel wrench
until they are snug. Do not overtighten the nut
caps or they may break.
488

If you are reinstalling the smooth center cap,
place it on the wheel and tap it into place
until it seats ush with the wheel.
Secondary Latch System
Your vehicle has an underbody-mounted tire hoist
assembly equipped with a secondary latch
system. It is designed to stop the spare tire from
suddenly falling off your vehicle. For the secondary
latch to work, the spare must be installed with
the valve stem pointing down. SeeStoring a Flat
or Spare Tire and Tools on page 492.
{CAUTION:
Before beginning this procedure read all
the instructions. Failure to read and follow
the instructions could damage the hoist
assembly and you and others could get
hurt. Read and follow the instructions
listed next.To release the spare tire from the secondary latch,
do the following:
1. Check under the
vehicle to see if the
cable end is
visible. If the cable
is not visible
proceed to Step 6.
2. If it is visible, rst try to tighten the cable by
turning the wheel wrench clockwise until you
hear two clicks or feel it skip twice. You
cannot overtighten the cable.
3. Loosen the cable by turning the wrench
counterclockwise three or four turns.
4. Repeat this procedure at least two times.
If the spare tire lowers to the ground,
continue with Step 5 ofRemoving the Spare
Tire and Tools on page 478.
489

5. If the spare does not lower, turn the wrench
counterclockwise until approximately 6 inches
(15 cm) of cable is exposed.
6. Stand the wheel blocks on their shortest ends,
with the backs facing each other.
7. Place the bottom
edge of the jack (A)
on the wheel
blocks (B),
separating them so
that the jack is
balanced securely.
8. Attach the jack handle, extension, and wheel
wrench to the jack and place it (with the
wheel blocks) under the vehicle toward the
front of the rear bumper.
