{CAUTION:
Someone standing too close during the
procedure could be injured by the jack.
If the spare tire does not slide off the jack
completely, make sure no one is behind you
or on either side of you as you pull the jack
out from under the spare.
13. Disconnect the jack handle from the jack and
carefully remove the jack. Use one hand to push
against the spare while rmly pulling the jack out
from under the spare tire with the other hand.
If the spare tire is hanging from the cable, insert
the hoist end of extension, and wheel wrench into
the hoist shaft hole in the bumper and turn the
wheel wrench counterclockwise to lower the spare
the rest of the way.14. Tilt the tire retainer at the end of the cable and
pull it through the wheel opening. Pull the tire
out from under the vehicle.
15. Turn the wheel wrench in the hoist shaft hole in
the bumper clockwise to raise the cable back up
if the cable is hanging under the vehicle.
Have the hoist assembly inspected as soon as you can.
You will not be able to store a spare or at tire using
the hoist assembly until it has been replaced.
To continue changing the at tire, seeRemoving the
Flat Tire and Installing the Spare Tire on page 5-84.
5-93

3. Assemble the two jack handle extensions (I)
and wheel wrench (H) as shown.
4. Insert the open end
of the extension (F)
through the hole in
the rear bumper (G)
(hoist shaft
access hole).
5. Raise the tire part way upward. Make sure the
retainer is seated in the wheel opening.6. Raise the tire fully against the underside of the
vehicle by turning the wheel wrench clockwise
until you hear two clicks or feel it skip twice.
You cannot overtighten the cable.
7. Make sure the tire is stored securely. Push, pull (A),
and then try to turn (B) the tire. If the tire moves,
use the wheel wrench to tighten the cable.
8. Reinstall the spare tire lock.
9. Close the hoist shaft access cover.
5-96

A
Accessories and Modications............................ 5-3
Adding Equipment to Your Airbag-Equipped
Vehicle.......................................................1-70
Additives, Fuel................................................. 5-6
Add-On Electrical Equipment...........................5-107
Adjustable Throttle and Brake Pedal..................2-34
Air Cleaner/Filter, Engine.................................5-17
Air Conditioning..............................................3-24
Airbag
Passenger Status Indicator...........................3-33
Readiness Light..........................................3-32
Airbag System................................................1-56
What Will You See After an Airbag Inates?........1-64
When Should an Airbag Inate?....................1-61
Where Are the Airbags?...............................1-59
Airbag Systems
Adding Equipment to Your Airbag-Equipped
Vehicle...................................................1-70
How Does an Airbag Restrain?......................1-63
Passenger Sensing System...........................1-65
Servicing Your Airbag-Equipped Vehicle..........1-70
What Makes an Airbag Inate?......................1-63
All-Wheel Drive...............................................5-45
All-Wheel-Drive (AWD) System........................... 4-8
Analog Clock..................................................3-23
Antenna, Fixed Mast......................................3-105Antenna, XM™ Satellite Radio Antenna
System.....................................................3-105
Antilock Brake System (ABS)............................. 4-4
Antilock Brake, System Warning Light................3-37
Appearance Care
Aluminum or Chrome-Plated Wheels.............5-103
Care of Safety Belts...................................5-100
Chemical Paint Spotting..............................5-104
Cleaning Exterior Lamps/Lenses..................5-101
Fabric/Carpet..............................................5-99
Finish Care...............................................5-101
Finish Damage..........................................5-104
Instrument Panel, Vinyl, and Other
Plastic Surfaces.....................................
5-100
Interior Cleaning..........................................5-97
Leather......................................................5-99
Sheet Metal Damage..................................5-104
Speaker Covers.........................................5-100
Tires........................................................5-104
Underbody Maintenance.............................5-104
Vehicle Care/Appearance Materials...............5-105
Washing Your Vehicle.................................5-101
Weatherstrips............................................5-100
Windshield and Wiper Blades......................5-102
Wood Panels............................................5-100
Appointments, Scheduling Service....................... 7-9
Ashtray.........................................................3-23
1

Audio System.................................................3-66
Audio Steering Wheel Controls....................3-103
Fixed Mast Antenna...................................3-105
Navigation/Radio System,
see Navigation Manual..............................3-91
Radio Reception........................................3-104
Rear Seat Audio (RSA)...............................3-101
Setting the Clock.........................................3-67
Theft-Deterrent Feature...............................3-102
XM™ Satellite Radio Antenna System...........3-105
Audio System(s).............................................3-68
Automatic Headlamp System............................3-18
Automatic Transmission
Fluid..........................................................5-20
Operation...................................................2-36
Autoride
®.......................................................4-42
B
Battery..........................................................5-39
Electric Power Management..........................3-21
Run-Down Protection...................................3-21
Brake
Emergencies................................................ 4-5
Brakes..........................................................5-36
System Warning Light..................................3-36Braking........................................................... 4-3
Braking in Emergencies..................................... 4-5
Break-In, New Vehicle.....................................2-30
Bulb Replacement...........................................5-51
Headlamp Aiming........................................5-48
High Intensity Discharge (HID) Lighting...........5-51
License Plate Lamps....................................5-52
Replacement Bulbs......................................5-53
Taillamps, Turn Signal, Sidemarker,
Stoplamps, and Back-Up Lamps.................5-51
Buying New Tires...........................................5-71
C
Calibration.............................................2-46, 2-48
California Fuel.................................................. 5-6
California Perchlorate Materials Requirements....... 5-4
California Proposition 65 Warning....................... 5-4
Canadian Owners................................................ ii
Capacities and Specications..........................5-115
Carbon Monoxide...........2-13, 2-23, 2-44, 4-30, 4-43
Care of
Safety Belts..............................................5-100
Cargo Area, All-Weather..................................2-82
Cargo Cover Panels........................................2-69
CD, MP3 .......................................................3-86
2

Center Console Storage Area...........................2-67
Chains, Tire...................................................5-76
Charging System Light....................................3-35
Check
Engine Light...............................................3-40
Checking Things Under the Hood......................5-10
Chemical Paint Spotting.................................5-104
Child Restraints
Child Restraint Systems...............................1-39
Infants and Young Children...........................1-35
Lower Anchors and Tethers for Children..........1-43
Older Children.............................................1-32
Securing a Child Restraint in a
Rear Seat Position...................................1-50
Securing a Child Restraint in the
Right Front Seat Position..........................1-53
Where to Put the Restraint...........................1-42
Cigarette Lighter.............................................3-23
Cleaning
Aluminum or Chrome-Plated Wheels.............5-103
Exterior Lamps/Lenses................................5-101
Fabric/Carpet..............................................5-99
Finish Care...............................................5-101
Instrument Panel, Vinyl, and Other
Plastic Surfaces.....................................5-100
Interior.......................................................5-97
Leather......................................................5-99Cleaning (cont.)
Speaker Covers.........................................5-100
Tires........................................................5-104
Underbody Maintenance.............................5-104
Washing Your Vehicle.................................5-101
Weatherstrips............................................5-100
Windshield and Wiper Blades......................5-102
Wood Panels............................................5-100
Climate Control System
Dual Automatic............................................3-24
Outlet Adjustment........................................3-28
Clock............................................................3-23
Clock, Setting.................................................3-67
Collision Damage Repair..................................7-11
Compass...............................................2-46, 2-48
Content Theft-Deterrent....................................2-26
Control of a Vehicle.......................................... 4-3
Coolant
Engine Temperature Gage............................3-39
Heater, Engine............................................2-35
Surge Tank Pressure Cap.............................5-26
Cooled Seats................................................... 1-5
Cooling System..............................................5-29
Cruise Control................................................3-11
Cruise Control Light........................................3-44
Cupholder(s)..................................................2-67
3

Passing.........................................................4-11
PASS-Key®III+..............................................2-28
PASS-Key®III+ Operation................................2-29
Perchlorate Materials Requirements, California...... 5-4
Power
Door Locks.................................................2-11
Electrical System.......................................5-107
Lumbar Controls........................................... 1-3
Reclining Seatbacks...................................... 1-8
Retained Accessory (RAP)............................2-32
Running Boards..........................................2-23
Seat............................................................ 1-2
Steering Fluid.............................................5-34
Windows....................................................2-25
Privacy..........................................................7-16
Event Data Recorders..................................7-17
Navigation System.......................................7-18
OnStar.......................................................7-18
Radio Frequency Identication.......................7-18
Programmable Automatic Door Locks.................2-11
R
Radio Frequency Identication (RFID),
Privacy......................................................7-18
Radios..........................................................3-66
Radio(s)........................................................3-68Radios
Navigation/Radio System,
see Navigation Manual..............................3-91
Rear Seat Audio........................................3-101
Reception.................................................3-104
Setting the Clock.........................................3-67
Theft-Deterrent..........................................3-102
Rainsense™ II Wipers.....................................3-10
Reading Lamps..............................................3-20
Rear Axle......................................................5-46
Rear Door Security Locks................................2-12
Rear Seat Armrest..........................................2-69
Rear Seat Audio (RSA)..................................3-101
Rear Seat Entertainment System.......................3-91
Rear Seat Operation.......................................1-10
Rearview Mirror, Automatic Dimming with
OnStar
®, Compass and Temperature Display.....2-48
Reclining Seatbacks, Power............................... 1-8
Recommended Fluids and Lubricants.................6-13
Recovery Hooks.............................................4-34
Recreational Vehicle Towing.............................4-42
Remote Keyless Entry (RKE) System.................. 2-4
Remote Keyless Entry (RKE) System,
Operation..................................................... 2-5
Remote Vehicle Start........................................ 2-8
Removing the Flat Tire and Installing
the Spare Tire.............................................5-84
10
