2-81
Most messages can be removed from the display by
pressing the INFO or INFO RESET button while the
message is being displayed.
DIC messages can also be displayed in French, German,
Spanish and Japanese. Contact your dealer to have the
language display adjusted for your vehicle.
BATTERY NOT CHARGING
- 7: This message
will appear if the battery is not being charged. Have the
electrical system checked by your dealership at your
earliest convenience.
BATTERY SAVER ACTIVE
- 27: This message is
displayed when the vehicle has detected that the battery
voltage is dropping beyond a reasonable point. The
battery saver system will start reducing certain features
of the vehicle that you may not be able to notice. At the
point that features are disabled, this message is displayed.
It means that the vehicle is trying to save the charge in
the battery. Turn off unnecessary accessories to allow the
battery to recharge.
BATTERY VOLTAGE HIGH
- 8: This message
shows that the electrical charging system is overcharging
(more than 16 volts). To avoid being stranded, have the
electrical system checked by your dealership. You can
reduce the charging overload by using the accessories.
Turn on the lamps and radio, set the climate control on
AUTO and the fan speed on HI, and turn the rear windowdefogger on. You can monitor battery voltage on the
DIC by pressing the INFO button. The normal range is
11.5 to 15.5 volts when the engine is running.
BATTERY VOLTAGE LOW
- 6: This message
will appear when the electrical system is charging less
than 10.5 volts or if the battery has been drained. If this
message appears immediately after starting, it is possible
that the generator can still recharge the battery. The
battery should recharge while driving but may take a
few hours to do so. Consider using an auxiliary charger
(be sure to follow the manufacturer's instructions) to
boost the battery after returning home or to a final
destination. If this message appears while driving or
after starting your vehicle and stays on, have it checked
immediately to determine the cause of this problem. To
help the generator recharge the battery quickly, you can
reduce the load on the electrical system by turning off
the accessories. You can monitor battery voltage on the
DIC by pressing the INFO button. The normal range is
11.5 to 15.5 volts.
CHANGE BRAKE PADS
- 125: This message is
used to notify you that the brake pads may have worn
down. A sensor is connected to the brake pads and is
triggered when they wear to a certain point. Have the
front and rear brakes serviced by your dealer as soon
as possible.

2-82
CHANGE ENGINE OIL - 82: This means that
the life of the engine oil has expired and it should be
changed within 200 miles. See ªEngine Oilº and ªFilter
Recommendationsº in the Maintenance Schedule
booklet. After an oil change, the Oil Life Indicator must
be reset. See ªOil Life Indicator, How to Resetº in
the Index.
CHANGE TRANS FLUID
- 47: This message
will appear when it is time to replace the transaxle fluid.
See the Maintenance Schedule booklet for the proper
fluid and change intervals.
CHECK BRAKE FLUID
- 37: This message will
display if the ignition is in ON to inform the driver
that the brake fluid level is low. Have the brake system
serviced by a technician as soon as possible. See ªBrake
System Warning Lightº in the Index.
CHECK COOLANT LEVEL
- 2: This message
will appear when there is a low level of engine coolant.
Have the cooling system serviced by a technician as
soon as possible.
CHECK FUEL GAGE
- 50: This message will appear
when the fuel supply is less than 5 gallons (18.9 L) and
the display is turned off. A single chime will also sound
when this message is displayed.CHECK GAS CAP
- 61: This message will appear if
the gas cap has not been fully tightened. You should
recheck your gas cap to ensure that it's fully tightened.
CHECK OIL LEVEL
- 36: For correct operation of
the low oil sensing system, your vehicle should be on
a level surface. A false CHECK OIL LEVEL message
may appear if the vehicle is parked on grades. The oil
level sensing system does not check for actual oil level
if the engine has been off for a short period of time, and
the oil level is never sensed while the engine is running.
If the CHECK OIL LEVEL message appears, and
your vehicle has been parked on level ground with the
engine off for at least 30 minutes, the oil level should be
checked by observing the oil dipstick. Prior to checking
the oil level, be sure the engine has been off for a
few minutes and your vehicle is on a level surface.
Then check the dipstick and add oil if necessary.
See ªEngine Oilº in the Index.
CHECK WASHER FLUID
- 25: This message
means that you need washer solvent.
DRIVER DOOR AJAR
- 140: This message will
display anytime the key is in ON, the transaxle is not in
PARK (P) and the driver's door is open or ajar. A chime
will also sound when the vehicle's speed is greater than
3 mph (4.8 km/h).

2-83
DRIVER NO. X (1 OR 2) : This message will be
displayed with the key in ON and while entering
FEATURE PROGRAMMING, but only if the vehicle
is equipped with memory seats. The message will show
which driver is activating the personalization feature.
It will only stay on for five seconds. This message can
be customized for you by your dealer.
ENGINE COOLANT HOT, IDLE ENGINE
- 44:
This message will appear when the engine coolant
temperature is over 262
F (128
C). Stop and allow
your vehicle to idle in PARK (P) until it cools down and
the message is removed. Do not increase engine speed
above a normal idle. If it does not cool down, turn off
the engine and have it serviced before driving it again.
Severe engine damage can result from an overheated
engine. See ªEngine Overheatingº in the Index.
ENGINE HOT
-AC OFF - 16: This message displays
when the engine coolant becomes hotter than the normal
operating temperature. To avoid added strain on a hot
engine, the air conditioning compressor is automatically
turned off. When the coolant temperature returns to
normal, the A/C operation will automatically resume.You can continue to drive your vehicle. If this message
continues to appear, have the system repaired as soon as
possible to avoid compressor damage.
ENGINE MISFIRE
-- EASE OFF GAS
PEDAL
- 114: An engine misfire has occurred.
You'll need to ease off the gas pedal.
ENGINE OVERHEATED, STOP ENGINE
- 42:
This message will appear when the engine has
overheated. Stop and turn the engine off immediately to
avoid severe engine damage. See ªEngine Overheatingº
in the Index. A multiple chime will also sound when this
message is displayed.
ENGINE POWER REDUCED
- 41: This message
informs you that the vehicle is reducing engine power
because the transaxle is being placed in gear under
conditions that may cause damage to the vehicle's
engine, transaxle or ability to accelerate.
FUEL LEVEL LOW
- 11 : This message serves as
a warning that the fuel level in the tank is critically low.
Stop for fuel soon. A single chime will also sound when
this message is displayed.

2-84
HEADLAMPS SUGGESTED - 23: If it's dark
enough outside and the headlamps and Twilight
Sentinel

controls are off, a HEADLAMPS
SUGGESTED message will display on the DIC. This
message informs the driver that turning on the exterior
lamps is recommended even though the Daytime
Running Lamps (DRL) are still illuminated. It has
become dark enough outside to require the headlamps
and/or other exterior lamps. This message will also
appear if the optional Rainsense wiping feature is
on and the Twilight Sentinel

is off.
ICE POSSIBLE
- 13: This message appears when
the outside air temperature is cold enough to create
icy road conditions.
LEFT REAR DOOR AJAR
- 142: The left rear door
is open or ajar when this message appears. The ignition
must be in ON and the transaxle not in PARK (P) for
this message to display. A chime will also sound when
the vehicle's speed is greater than 3 mph (4.8 km/h).
OIL PRESSURE LOW STOP ENGINE
- 35: If this
message appears while the engine is running, stop the
engine and do not operate it until the cause of low oil
pressure is corrected. Severe damage to the engine can
result. A multiple chime will also sound when this
message is displayed.PASSENGER DOOR AJAR
- 141: The passenger's door
is open or ajar when this message appears. The ignition
must be in ON and the transaxle not in PARK (P) for
this message to display. A chime will also sound when
the vehicle's speed is greater than 3 mph (4.8 km/h).
RIGHT REAR DOOR AJAR
- 143: The right rear door
is open or ajar when this message appears. The ignition
must be in ON and the transaxle not in PARK (P) for
this message to display. A chime will also sound when
the vehicle's speed is greater than 3 mph (4.8 km/h).
SERVICE AC SYSTEM
- 14: This message
appears when the electronic sensors that control the air
conditioning and heating systems are no longer working.
Have the climate control system serviced if you notice a
drop in heating and air conditioning efficiency.
SERVICE AIR BAG
- 83: There is a problem with
the supplemental inflatable restraint (air bag) system
when this message appears. Let only a qualified
technician work on your vehicle. See your dealership
for service at once.
SERVICE CHARGING SYS
- 102: This message
will display when a problem with the charging system
has been detected. Have your vehicle serviced at
your dealership.

2-85
SERVICE ELECTRICAL SYS - 106: This message
will display if an electrical problem has occurred within
the Powertrain Control Module (PCM) or the ignition
switch. Have your vehicle serviced by your dealership.
SERVICE FUEL SYSTEM
- 101: The Powertrain
Control Module (PCM) has detected a problem within
the fuel system when this message appears. See your
dealership for service.
SERVICE IDLE CONTROL
- 107: A problem with
the idle control has occurred when this message displays.
Take your vehicle to your dealership for service.
SERVICE STABILITY SYS
- 54 : If you ever see
the SERVICE STABILITY SYS message, it means
there may be a problem with your stability enhancement
system. If you see this message, try to reset the system
(stop; turn off the engine; then start the engine again).
If the SERVICE STABILITY SYS message still
comes on, it means there is a problem. You should see
your dealer for service. Reduce your speed and drive
accordingly. A single chime will also sound when this
message is displayed.STABILITY SYS ENGAGED
- 55: You may see
the STABILITY SYS ENGAGED message on the
Driver Information Center. It means that an advanced,
computer
-controlled system has come on to help your
vehicle continue to go in the direction in which you're
steering. This stability enhancement system activates
when the computer senses that your vehicle is just
starting to spin, as it might if you hit a patch of ice or
other slippery spot on the road. When the system is on,
you may hear a noise or feel a vibration in the brake
pedal. This is normal.
When the STABILITY SYS ENGAGED message is on,
you should continue to steer in the direction you want to
go. The system is designed to help you in bad weather or
other difficult driving situations by making the most of
whatever road conditions will permit. If the STABILITY
SYS ENGAGED message comes on, you'll know that
something has caused your vehicle to start to spin, so
you should consider slowing down.
SERVICE STEERING SYS
- 127: This message
is displayed when a problem has been detected in
the Magnasteer

variable effort steering system.
Service is required.

2-86
SERVICE SUSPENSION SYS - 84: This message is
displayed to indicate that the suspension system is not
operating properly. To correct this problem, have your
vehicle serviced at your dealership.
SERVICE THEFT SYSTEM
- 34: This message
means there is a problem in the Personalized Automotive
Security System (PASS
-Key
III). A fault has been
detected in the system which means that the PASS
-Key
III system is disabled and is not protecting the vehicle.
The vehicle usually restarts, however, you may want to
take your vehicle to a proper service center before turning
off the engine.
SERVICE TRANSMISSION
- 100: See your dealer
for repair.
SERVICE VEHICLE SOON
- 3: This message is
displayed when a non
-emissions related powertrain
malfunction occurs. Have your vehicle serviced by a
technician as soon as possible.
SPEED LIMITED TO 90
- 113: A failure in the
suspension control system has occurred when this
message appears. The Powertrain Control Module (PCM)
determines the speed to which your vehicle is limited.
Have your vehicle serviced if this message appears.STARTING DISABLED REMOVE KEY
- 33: This
message will appear when the Personalized Automotive
Security System (PASS
-Key
III) senses that an
improper ignition key is being used to try to start the
vehicle. Check the ignition key for damage. If it is
damaged, it may need to be replaced. If you see no
damage, remove the key and try to start the vehicle
again. If it still does not start, try another ignition key.
THEFT ATTEMPTED
- 40: This message is
displayed if the theft system has detected a break
-in
attempt while you were away from your vehicle.
TOP SPEED FUEL CUT
-OFF - 111 : This message
will appear when the Powertrain Control Module (PCM)
senses that the maximum speed for your vehicle has
been reached. The speed of your vehicle will surge as
the fuel supply is cut off. This allows your vehicle to
stay in a safe tire operating range. The top speed is set
based on the top speed rating of the tires.
TRACTION ENGAGED
- 91 : When your traction
control system is limiting wheel spin, the TRACTION
ENGAGED message will be displayed. Slippery road
conditions may exist if this message is displayed, so
adjust your driving accordingly. This message will stay
on for a few seconds after the traction control system
stops limiting wheel spin.

2-87
TRACTION OFF - 89: This message will be displayed
after the traction control has been turned off by the
button on the center console.
TRACTION READY
- 90: This message informs
the driver that the traction control system is available.
This occurs when the traction control switch on the
console has been returned to ON (pressing the button
once turns the traction control system off: pressing the
button again turns the system back on). This message
will automatically disappear from the display after
five seconds.
TRACTION SUSPENDED
- 56: This message
displays when the traction control system has been
temporarily shut off because your vehicle's brakes
have overheated. This message does not indicate a
problem with your vehicle's traction control system.
After a few minutes, the traction control system will be
available again and the TRACTION READY message
will appear.TRANS HOT IDLE ENGINE
- 112: This message
indicates that the transaxle fluid in your vehicle is too
hot. Stop and allow your vehicle to idle until it cools
down or until this message is removed.
TRUNK OPEN
- 24: This message indicates that the
trunk is open when the ignition is on.
TURN SIGNAL ON
- 20: This message is a reminder,
after driving about a mile, that you have the turn signal
on. A multiple chime will also sound when this message
is displayed.
VEHICLE OVERSPEED
- 52: This message is
displayed when the vehicle speed exceeds a certain limit
as required by some export countries. A continuous
chime will also sound when this message is displayed.

2-88
Vehicle Programming and
Personalization Features (If Equipped)
If your vehicle is equipped with personalization, you
can program certain features to a preferred setting
for up to two people. If your vehicle does not have
personalization, then some of the features on your
vehicle have been programmed for all drivers. On all
vehicles, certain features such as HVAC settings, radio
preset settings, exterior lighting at unlock, remote lock
and unlock confirmation and automatic door locks have
already been programmed for your convenience. If the
vehicle is equipped with Personalization, then the seat
position, steering column position (if equipped) and
the outside mirror positions can also be programmed.
The navigation screen preferences (if equipped) will
remain at the last set position.
If your vehicle is equipped with personalization, the
driver's preferences are recalled by pressing the unlock
button on the Remote Keyless Entry (RKE) transmitter
or by pressing the appropriate memory button ª1º or ª2º
located on the driver's door. Please note that certain
features can be programmed not to recall until the key is
placed in the ignition. To change feature preferences you
must enter FEATURE PROGRAMMING (see below).
All vehicles that have memory seats, have personalization.
Entering FEATURE PROGRAMMING
To begin programming, the ignition must be in ON
and your vehicle in PARK (P). If your vehicle has
memory, you must press the appropriate memory button
ª1º or ª2º, located on the driver's door panel before
programming. Press the INFO button one or more times
until the FEATURE PROGRAMMING prompt appears
on the DIC display. Press the ON/OFF button to enter
FEATURE PROGRAMMING. To exit, press the INFO
RESET button.
Remote Recall Memory (If Equipped)
Enter FEATURE PROGRAMMING by following the
previous instructions and then press the down arrow on
the INFO button one or more times until the REMOTE
RECALL MEMORY prompt appears. To turn the
feature on, press the ON/OFF button until ON is
displayed on the DIC. The seat and mirror memory
settings that have been previously programmed can be
recalled by pressing the unlock button on the RKE
transmitter. The steering column will move when the
key is inserted in the ignition and turned to ON.
To turn the feature off, press the ON/OFF button
until OFF is displayed.

2-89 Key in Recall (If Equipped)
Enter FEATURE PROGRAMMING by following the
previous instructions and then press the down arrow on
the INFO button one or more times until the KEY IN
RECALL prompt appears on the DIC display. To turn
the feature on, press the ON/OFF button until ON
appears. The seat and mirror memory settings that have
been previously programmed will be recalled when the
key is inserted in the ignition. The steering column
(if equipped) will move when the key is turned to ON.
To turn the feature off, press the ON/OFF button until
OFF appears.
Auto Exit Seat (If Equipped)
Enter FEATURE PROGRAMMING by following the
previous instructions and then press the down arrow on
the INFO button one or more times until the AUTO
EXIT SEAT prompt shows on the DIC display. This
feature will move the seat to the driver's exit position
when the key is turned out of ON (away from START)
and the driver's door is opened. To turn this feature on,
press the ON/OFF button until ON appears on the DIC.
To turn this feature off, press the ON/OFF button until
OFF shows.
Auto Exit Steering Wheel (If Equipped)
Enter FEATURE PROGRAMMING by following the
previous instructions and then press the down arrow on
the INFO button one or more times until the AUTO
EXIT STRG WHEEL prompt appears on the DIC
display. This feature will move the column to the
driver's exit position when the key is turned out of ON
(away from START) and the driver's door is opened.
Lights Flash at Unlock
Enter FEATURE PROGRAMMING by following the
previous instructions and then press the down arrow on
the INFO button one or more times until the LIGHTS
FLASH AT UNLOCK prompt appears. To turn this
feature on, press the ON/OFF button until ON is
displayed on the DIC. If all the doors are closed, the
parking lamps will flash twice when the unlock button
on the RKE transmitter is pressed. The lamps will not
flash if the manual parking lamps or headlamps are
active. To turn the feature off, press the ON/OFF
button until the OFF prompt appears.
This feature will not work if any door is open.

2-90 Lights Flash at Lock
Enter FEATURE PROGRAMMING by following the
previous instructions and then press the down arrow on
the INFO button one or more times until the LIGHTS
FLASH AT LOCK prompt appears on the DIC display.
To turn the feature on, press the ON/OFF button until
ON appears. If all the doors are closed, the parking
lamps will flash once when the lock button on the RKE
transmitter is pressed. The lamps will not flash if the
manual parking lamps are active. To turn the feature off,
press the ON/OFF button until OFF appears.
This feature will not work if any door is open.
Horn Sounds at Lock
Enter FEATURE PROGRAMMING by following the
previous instructions and then press the down arrow on
the INFO button one or more times until the HORN
SOUNDS AT LOCK prompt appears on the DIC
display. To turn the feature on, press the ON/OFF
button until ON appears. If all the doors are closed,
the horn will sound once when the lock button on the
RKE transmitter is pressed. To turn the feature off,
press the ON/OFF button until OFF appears.
This feature will not work if any door is open.
Exterior Lights at Unlock
This personalization feature enables the driver to
program the exterior lamps to turn on or to remain off
when using the RKE transmitter to unlock the vehicle.
During dark or night conditions, if exterior lighting is
selected, the parking lamps, taillamps, reverse lamps,
high
-beam headlamps, etc. will turn on for about
20 seconds or until a door is opened, the key is turned
out of OFF or the RKE transmitter is used to lock
the vehicle.
Enter FEATURE PROGRAMMING by following
the previous instructions and then press the INFO
button one or more times until the FEATURE
PROGRAMMING prompt appears on the DIC
display. Press the ON/OFF button to enter FEATURE
PROGRAMMING. To exit, press the INFO RESET
button. Press the down arrow on the INFO button one
or more times until the EXT LIGHTS AT UNLOCK
prompt appears.
To turn the feature on, press the ON/OFF button until
ON is displayed. To turn the feature off, press the
ON/OFF button until OFF is displayed.
