VEHICLE CARE 315
Appearance Care
Exterior Care
Locks
Locks are lubricated at the factory.
Use a de-icing agent only when
absolutely necessary, and have the
locks greased after using. See
Recommended Fluids and Lubricants
0334.
Washing the Vehicle
To preserve the vehicle's finish, wash
it often and out of direct sunlight.
Caution
Do not use petroleum-based, acidic,
or abrasive cleaning agents as they
can damage the vehicle's paint,
metal, or plastic parts. If damage
occurs, it would not be covered by
the vehicle warranty. Approved
cleaning products can be obtained
from your dealer. Follow all
manufacturer directions regarding
(Continued)
Caution (Continued)
correct product usage, necessary
safety precautions, and appropriate
disposal of any vehicle care
product.
Caution
Avoid using high-pressure washes
closer than 30 cm (12 in) to the
surface of the vehicle. Use of power
washers exceeding 8,274 kPa
(1,200 psi) can result in damage or
removal of paint and decals.
Caution
Do not power wash any component
under the hood that has this
e
symbol.
This could cause damage that
would not be covered by the vehicle
warranty. If using an automatic car wash, follow
the car wash instructions. The
windshield wiper and rear window
wiper, if equipped, must be off.
Remove any accessories that may be
damaged or interfere with the car
wash equipment.
Rinse the vehicle well, before washing
and after, to remove all cleaning
agents completely. If they are allowed
to dry on the surface, they could stain.
Dry the finish with a soft, clean
chamois or an all-cotton towel to
avoid surface scratches and water
spotting.
Finish Care
Application of aftermarket clearcoat
sealant/wax is not recommended.
If painted surfaces are damaged, see
your dealer to have the damage
assessed and repaired. Foreign
materials such as calcium chloride
and other salts, ice melting agents,
road oil and tar, tree sap, bird
droppings, chemicals from industrial
chimneys, etc., can damage the
vehicle's finish if they remain on
painted surfaces. Wash the vehicle as

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12017481) - 2019 - CRC - 11/5/18
316 VEHICLE CARE
soon as possible. If necessary, use
non-abrasive cleaners that are marked
safe for painted surfaces to remove
foreign matter.
Occasional hand waxing or mild
polishing should be done to remove
residue from the paint finish. See your
dealer for approved cleaning products.
Do not apply waxes or polishes to
uncoated plastic, vinyl, rubber, decals,
simulated wood, or flat paint as
damage can occur.
Caution
Machine compounding or
aggressive polishing on a basecoat/
clearcoat paint finish may damage
it. Use only non-abrasive waxes and
polishes that are made for a
basecoat/clearcoat paint finish on
the vehicle.
To keep the paint finish looking new,
keep the vehicle garaged or covered
whenever possible. Protecting Exterior Bright Metal
Moldings
Caution
Failure to clean and protect the
bright metal moldings can result in
a hazy white finish or pitting. This
damage would not be covered by
the vehicle warranty.
The bright metal moldings on the
vehicle are aluminum, chrome,
or stainless steel. To prevent damage
always follow these cleaning
instructions:
. Be sure the molding is cool to the
touch before applying any cleaning
solution.
. Use only approved cleaning
solutions for aluminum, chrome,
or stainless steel. Some cleaners
are highly acidic or contain
alkaline substances and can
damage the moldings.
. Always dilute a concentrated
cleaner according to the
manufacturer’s instructions. .
Do not use cleaners that are not
intended for automotive use.
. Use a nonabrasive wax on the
vehicle after washing to protect
and extend the molding finish.Cleaning Exterior Lamps/Lenses,
Emblems, Decals, and Stripes
Use only lukewarm or cold water, a
soft cloth, and a car washing soap to
clean exterior lamps, lenses, emblems,
decals, and stripes. Follow instructions
under "Washing the Vehicle"
previously in this section.
Lamp covers are made of plastic, and
some have a UV protective coating. Do
not clean or wipe them when dry.
Do not use any of the following on
lamp covers:
.Abrasive or caustic agents.
. Washer fluids and other cleaning
agents in higher concentrations
than suggested by the
manufacturer.
. Solvents, alcohols, fuels, or other
harsh cleaners.
. Ice scrapers or other hard items.

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12017481) - 2019 - CRC - 11/5/18
VEHICLE CARE 317
.Aftermarket appearance caps or
covers while the lamps are
illuminated, due to excessive heat
generated.
Caution
Failure to clean lamps properly can
cause damage to the lamp cover
that would not be covered by the
vehicle warranty.
Caution
Using wax on low gloss black finish
stripes can increase the gloss level
and create a non-uniform finish.
Clean low gloss stripes with soap
and water only.
Air Intakes
Clear debris from the air intakes,
between the hood and windshield,
when washing the vehicle.
Shutter System
The vehicle may have a shutter
system designed to help increase fuel
economy. Keep the shutter system
clean for proper operation.
Windshield and Wiper Blades
Clean the outside of the windshield
with glass cleaner.
Clean rubber blades using a lint-free
cloth or paper towel soaked with
windshield washer fluid or a mild
detergent. Wash the windshield
thoroughly when cleaning the blades. Bugs, road grime, sap, and a buildup
of vehicle wash/wax treatments may
cause wiper streaking.
Replace the wiper blades if they are
worn or damaged. Damage can be
caused by extreme dusty conditions,
sand, salt, heat, sun, snow, and ice.
Weatherstrips
Apply weatherstrip lubricant on
weatherstrips to make them last
longer, seal better, and not stick or
squeak. Lubricate weatherstrips at
least once a year. Hot, dry climates
may require more frequent
application. Black marks from rubber
material on painted surfaces can be
removed by rubbing with a clean
cloth. See
Recommended Fluids and
Lubricants 0334.
Tires
Use a stiff brush with tire cleaner to
clean the tires.

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12017481) - 2019 - CRC - 11/5/18
326 SERVICE AND MAINTENANCE
Maintenance Schedule
Owner Checks and Services
At Each Fuel Stop
.Check the engine oil level. See
Engine Oil 0257.
Once a Month
. Check the tire inflation pressures.
See Tire Pressure 0288.
. Inspect the tires for wear. See Tire
Inspection 0295.
. Check the windshield washer fluid
level. See Washer Fluid 0266.
Engine Oil Change
When the CHANGE ENGINE OIL
SOON message displays, have the
engine oil and filter changed within
the next 1 000 km/600 mi. If driven
under the best conditions, the engine
oil life system may not indicate the
need for vehicle service for up to a
year. The engine oil and filter must be
changed at least once a year and the
oil life system must be reset. Your
trained dealer technician can perform
this work. If the engine oil life system is reset accidentally, service the
vehicle within 5 000 km/3,000 mi since
the last service. Reset the oil life
system when the oil is changed. See
Engine Oil Life System
0259.
Air Conditioning Desiccant
(Replace Every Seven Years)
The air conditioning system requires
maintenance every seven years. This
service requires replacement of the
desiccant to help the longevity and
efficient operation of the air
conditioning system. This service can
be complex. See your dealer.
Tire Rotation and Required
Services Every 12 000 km/
7,500 mi
Rotate the tires, if recommended for
the vehicle, and perform the following
services. See Tire Rotation0295.
. Check engine oil level and oil
life percentage. If needed, change
engine oil and filter, and reset oil
life system. See Engine Oil0257
and Engine Oil Life System 0259. .
Check engine coolant level. See
Cooling System 0262.
. Check windshield washer fluid
level. See Washer Fluid 0266.
. Check tire inflation pressures. See
Tire Pressure 0288.
. Inspect tire wear. See Tire
Inspection 0295.
. Visually check for fluid leaks.
. Inspect engine air cleaner filter.
See Engine Air Cleaner/Filter 0261.
. Inspect brake system. See Exterior
Care 0315.
. Visually inspect steering,
suspension, and chassis
components for damage, including
cracks or tears in the rubber boots,
loose or missing parts, or signs of
wear at least once a year. See
Exterior Care 0315.
. Inspect power steering for proper
attachment, connections, binding,
leaks, cracks, chafing, etc.

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12017481) - 2019 - CRC - 11/5/18
332 SERVICE AND MAINTENANCE
Battery
The 12-volt battery supplies power to
start the engine and operate any
additional electrical accessories.
.To avoid break-down or failure to
start the vehicle, maintain a
battery with full cranking power.
. Trained dealer technicians have
the diagnostic equipment to test
the battery and ensure that the
connections and cables are
corrosion-free.
Belts
. Belts may need replacing if they
squeak or show signs of cracking
or splitting.
. Trained dealer technicians have
access to tools and equipment to
inspect the belts and recommend
adjustment or replacement when
necessary. Brakes
Brakes stop the vehicle and are crucial
to safe driving.
.
Signs of brake wear may include
chirping, grinding, or squealing
noises, or difficulty stopping.
. Trained dealer technicians have
access to tools and equipment to
inspect the brakes and recommend
quality parts engineered for the
vehicle.
Fluids
Proper fluid levels and approved fluids
protect the vehicle’s systems and
components. See Recommended Fluids
and Lubricants 0334 for GM approved
fluids.
. Engine oil and windshield washer
fluid levels should be checked at
every fuel fill.
. Instrument cluster lights may
come on to indicate that fluids
may be low and need to be filled. Hoses
Hoses transport fluids and should be
regularly inspected to ensure that
there are no cracks or leaks. With a
multi-point inspection, your dealer
can inspect the hoses and advise if
replacement is needed.
Lamps
Properly working headlamps,
taillamps, and brake lamps are
important to see and be seen on
the road.
.
Signs that the headlamps need
attention include dimming, failure
to light, cracking, or damage. The
brake lamps need to be checked
periodically to ensure that they
light when braking.
. With a multi-point inspection,
your dealer can check the lamps
and note any concerns.

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12017481) - 2019 - CRC - 11/5/18
SERVICE AND MAINTENANCE 335
UsageFluid/Lubricant
Weatherstrip Conditioning Weatherstrip Lubricant (GM Part No. 3634770, in Canada 10953518) or equivalent.
Windshield Washer Automotive windshield washer fluid that meets regional freeze protection
requirements.
Maintenance Replacement Parts
Replacement parts identified below by name, part number, or specification can be obtained from your dealer.
Part GM Part Number ACDelco Part Number
Engine Air Cleaner/Filter 23430313 A3210C
Engine Oil Filter 55495105 PF66
Passenger Compartment Air Filter 13508023 CF185
Spark Plugs 55504354 41–103–IP
Wiper Blades Driver Side –60 cm (23.62 in) 84142870 —
Passenger Side –50 cm (19.68 in) 23360287 —
Rear –30 cm (11.81 in) 84215609 —

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12017481) - 2019 - CRC - 11/5/18
INDEX 369
Driving the Vehicle . . . . . . . . . . . . . . . . . . . . 3
Dual Automatic ClimateControl System . . . . . . . . . . . . . . . . . . . . 166
E
Electric Parking Brake . . . . . . . . . . . . . . 201
Electric Parking Brake Light . . . . . . . 136
Electrical Equipment, Add-On . . . . . 250
Electrical SystemEngine Compartment FuseBlock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 276
Fuses and Circuit Breakers . . . . . . . 275
Instrument Panel Fuse Block . . . . 279
Overload . . . . . . . . . . . . . . . . . . . . . . . . . . . 275
Emergency OnStar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 355
Engine
Air Cleaner/Filter . . . . . . . . . . . . . . . . . 261
Check Light (MalfunctionIndicator) . . . . . . . . . . . . . . . . . . . . . . . . 133
Compartment Overview . . . . . . . . . . 256
Coolant Temperature Gauge . . . . . 130
Coolant Temperature
Warning Light . . . . . . . . . . . . . . . . . . . 139
Cooling System . . . . . . . . . . . . . . . . . . . 262
Drive Belt Routing . . . . . . . . . . . . . . . . 339
Exhaust . . . . . . . . . . . . . . . . . . . . . . . . . . . . 193
Heater . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 188 Engine (cont'd)
Oil Life System . . . . . . . . . . . . . . . . . . . . 259
Oil Pressure Light . . . . . . . . . . . . . . . . . 140
Overheating . . . . . . . . . . . . . . . . . . . . . . . 265
Power Messages . . . . . . . . . . . . . . . . . . 148
Running While Parked . . . . . . . . . . . 194
Starting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 186
Engine Air Filter Life System . . . . . . 260
Entry Lighting . . . . . . . . . . . . . . . . . . . . . . 163
Equipment, Towing . . . . . . . . . . . . . . . . . 247
Event Data Recorders . . . . . . . . . . . . . . 352
Exit Lighting . . . . . . . . . . . . . . . . . . . . . . . . 164
Extended Parking . . . . . . . . . . . . . . . . . . . 192
Extender, Seat Belt . . . . . . . . . . . . . . . . . . 79
Exterior Lamp Controls . . . . . . . . . . . . 158
Exterior Lamps Off Reminder . . . . . . 160
Exterior Lighting Battery Saver . . . . 164
F
Features Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Filter, Engine Air Cleaner . . . . . . . . . . . . . . . . 261
Flash-to-Pass . . . . . . . . . . . . . . . . . . . . . . . . 160
Flashers, Hazard Warning . . . . . . . . . . 161
Flat Tire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 302
Changing . . . . . . . . . . . . . . . . . . . . . . . . . . 303
Floor Mats . . . . . . . . . . . . . . . . . . . . . . . . . . . 322 Fluid
Automatic Transmission . . . . . . . . . 260
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 268
Washer . . . . . . . . . . . . . . . . . . . . . . . . . . . . 266
Folding Mirrors . . . . . . . . . . . . . . . . . . . . . . 53
Forward Automatic Braking . . . . . . . . 228
Forward Collision Alert (FCA) System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 226
Frequency Statement Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 350
Front Pedestrian Braking (FPB)
System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 230
Front Seats Heated and Ventilated . . . . . . . . . . . . . 69
Front Storage . . . . . . . . . . . . . . . . . . . . . . . 111
Front Turn Signal Lamps . . . . . . . . . . 273
Fuel Additives . . . . . . . . . . . . . . . . . . . . . . . . . . 237
Economy Driving . . . . . . . . . . . . . . . . . . . 26
Filling a Portable FuelContainer . . . . . . . . . . . . . . . . . . . . . . . . 239
Filling the Tank . . . . . . . . . . . . . . . . . . . 238
Foreign Countries . . . . . . . . . . . . . . . . . 237
Gauge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
Low Fuel Warning Light . . . . . . . . . 140
Management, Active . . . . . . . . . . . . . . 192
Prohibited Fuels . . . . . . . . . . . . . . . . . . 237
Recommended . . . . . . . . . . . . . . . . . . . . 237

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12017481) - 2019 - CRC - 11/5/18
INDEX 373
Pregnancy, Using Seat Belts . . . . . . . . . 79
PrivacyVehicle Data Recording . . . . . . . . . . 352
Program Courtesy Transportation . . . . . . . . . 346
Prohibited Fuels . . . . . . . . . . . . . . . . . . . . 237
Proposition 65 Warning,
California . . . . . . . . . . . . . . .253, 269, 309, Back Cover
Publication Ordering
Information . . . . . . . . . . . . . . . . . . . . . . . . 349
R
Radio Frequency Statement . . . . . . . . 350
Reading Lamps . . . . . . . . . . . . . . . . . . . . . 163
Rear Camera Mirror . . . . . . . . . . . . . . . . . 55
Rear Seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71Heated . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Rear Storage . . . . . . . . . . . . . . . . . . . . . . . . 112
Rear Vision Camera (RVC) . . . . . . . . . 219
Rear Window Washer/Wiper . . . . . . . 120
Rearview Mirrors . . . . . . . . . . . . . . . . . . . . 54 Automatic Dimming . . . . . . . . . . . . . . . . 54
Reclining Seatbacks . . . . . . . . . . . . . . . . . 65
Recommended Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 237 Recommended Fluids and
Lubricants . . . . . . . . . . . . . . . . . . . . . . . . . 334
Records Maintenance . . . . . . . . . . . . . . . . . . . . . . 336
Recreational Vehicle Towing . . . . . . . 312
Reimbursement Program, GM Mobility . . . . . . . . . . . . . . . . . . . . . . . . . . . . 344
Remote Keyless Entry (RKE) System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Remote Vehicle Start . . . . . . . . . . . . . . . . 36
Replacement Parts Airbags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Maintenance . . . . . . . . . . . . . . . . . . . . . . 335
Replacing Airbag System . . . . . . . . . . . . 92
Replacing LATCH System Parts after a Crash . . . . . . . . . . . . . . . . . . . . . . . 106
Replacing Seat Belt System Parts after a Crash . . . . . . . . . . . . . . . . . 80
Reporting Safety Defects Canadian Government . . . . . . . . . . . . 351
General Motors . . . . . . . . . . . . . . . . . . . 351
U.S. Government . . . . . . . . . . . . . . . . . . 350
Restraints Where to Put . . . . . . . . . . . . . . . . . . . . . . . . 98
Retained Accessory
Power (RAP) . . . . . . . . . . . . . . . . . . . . . . . 189
Reverse Tilt Mirrors . . . . . . . . . . . . . . . . . 54 Roads
Driving, Wet . . . . . . . . . . . . . . . . . . . . . . . 177
Roadside Service . . . . . . . . . . . . . . . . . . . . 344
Roof Sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Roof Rack System . . . . . . . . . . . . . . . . . . 114
Rotation, Tires . . . . . . . . . . . . . . . . . . . . . . 295
Routing, Engine Drive Belt . . . . . . . . . 339
Running the Vehicle While Parked . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 194
S
Safety Defects ReportingCanadian Government . . . . . . . . . . . . 351
General Motors . . . . . . . . . . . . . . . . . . . 351
U.S. Government . . . . . . . . . . . . . . . . . . 350
Safety Locks . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Safety System Check . . . . . . . . . . . . . . . . 79
Scheduling Appointments . . . . . . . . . . 346
Seat Belts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73 Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Extender . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
How to Wear Seat Belts
Properly . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Lap-Shoulder Belt . . . . . . . . . . . . . . . . . . . 76
Reminders . . . . . . . . . . . . . . . . . . . . . . . . . 131
Replacing after a Crash . . . . . . . . . . . . . 80
Use During Pregnancy . . . . . . . . . . . . . . 79

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12017481) - 2019 - CRC - 11/5/18
376 INDEX
Ventilation, Air . . . . . . . . . . . . . . . . . . . . . 170
Visors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
W
WarningBrake System Light . . . . . . . . . . . . . . . 135
Caution and Danger . . . . . . . . . . . . . . . . . 3
Lane Departure (LDW) . . . . . . . . . . . 234
Warning Lights, Gauges, and Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . 125
Warnings Hazard Flashers . . . . . . . . . . . . . . . . . . . 161
Washer Fluid . . . . . . . . . . . . . . . . . . . . . . . . 266
Wheels Alignment and Tire Balance . . . . . 300
Different Size . . . . . . . . . . . . . . . . . . . . . . 298
Replacement . . . . . . . . . . . . . . . . . . . . . . 300
When It Is Time for New Tires . . . . 296
Where to Put the Restraint . . . . . . . . . 98
Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57 Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Windshield Replacement . . . . . . . . . . . . . . . . . . . . . . 272
Wiper/Washer . . . . . . . . . . . . . . . . . . . . . 118
Winter Driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . 178 Winter Tires . . . . . . . . . . . . . . . . . . . . . . . . . 282
Wiper Blade Replacement . . . . . . . . . . 271
Wipers
Rear Washer . . . . . . . . . . . . . . . . . . . . . . 120
Wireless Charging . . . . . . . . . . . . . . . . . . 122
