CADILLAC XT4 2023 Owners Manual

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
410 Vehicle Care
Dinghy Towing
Caution
If the vehicle is towed with
all four wheels on the
ground, the drivetrain
components could be
damaged. The repairs would
not be covered by the
vehicle warranty. Do not tow
the vehicle with all four
wheels on the ground.
The vehicle is neither designed
nor intended to be towed with
all four wheels on the ground.
If the vehicle must be towed, a dolly should be used. See the
following information on dolly
towing.
Dolly Towing
Loading up to the Dolly
1. On level ground start the engine.
2. Release the park brake.
3. Apply the brake pedal and hold until the end of step 5.
4. Push and hold the Electric Parking Brake (EPB)
switch. After 15 seconds, the EPB amber telltale will
begin flashing in the IP
cluster.
5. When the indicator flashes amber, release the EPB
within five seconds. Then,
push and release the EPB
switch and release the
brake pedal.
6. The EPB amber telltale will remain flashing and
parking brake will be
released if process is
successful.
7. Put the front wheels on the dolly.
8. Shift the transmission to P (Park).
9. Turn the vehicle off.
10. Secure the vehicle to the dolly.
11. Follow the dolly manufacturer's
instructions for preparing
the vehicle and dolly for
towing.
12. Open the hood.

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
Vehicle Care 411
13. Disconnect the negative (-)terminal connector from
the 12–volt battery.
14. Close and latch the hood.
Unloading from the Dolly 1. On level ground open the hood.
2. Connect the negative (-) terminal connector to the
12–volt battery.
3. Close the hood.
4. Follow the dolly manufacturer's
instructions for preparing
the vehicle and dolly for
unloading.
5. Unsecure the vehicle from the dolly.
6. Start the engine.
7. Shift the transmission to R (Reverse).
8. Drive vehicle off of the dolly.
9. Shift the transmission to P (Park).
10. Apply the brake pedal and hold until step 12. 11. Push and hold the EPB
switch for 5 seconds.
12. The EPB amber telltale in the IP cluster will go out.
13. Apply and release Parking Brake by pushing the EPB
switch.
Towing the Vehicle from
the Rear
Caution
Towing the vehicle from the
rear could damage it. Also,
repairs would not be
covered by the vehicle
warranty. Never have the
vehicle towed from the rear.
Do not tow the vehicle from
the rear.

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
412 Vehicle Care
Appearance Care
Exterior Care
Locks
Locks are lubricated at the
factory. Use a de-icing agent
only when absolutely
necessary, and have the locks
greased after using. See
Recommended Fluids and
Lubricants0429.
Washing the Vehicle
To preserve the vehicle's
finish, wash it often and out of
direct sunlight.
Caution
Do not use
petroleum-based, acidic,
or abrasive cleaning agents
as they can damage the
vehicle's paint, metal,
or plastic parts. If damage
occurs, it would not be
covered by the vehicle
warranty. Approved cleaning
(Continued)
Caution (Continued)
products can be obtained
from your dealer. Follow all
manufacturer directions
regarding correct product
usage, necessary safety
precautions, and
appropriate disposal of any
vehicle care product.
Caution
Avoid using high-pressure
washes closer than 30 cm
(12 in) to the surface of the
vehicle. Use of power
washers exceeding
8 274 kPa (1,200 psi) can
result in damage or removal
of paint and decals.
If using an automatic car wash,
follow the car wash
instructions. The windshield
wiper and rear window wiper,
if equipped, must be off. Remove any accessories that
may be damaged or interfere
with the car wash equipment.
Rinse the vehicle well, before
washing and after, to remove
all cleaning agents completely.
If they are allowed to dry on
the surface, they could stain.
Dry the finish with a soft, clean
chamois or an all-cotton towel
to avoid surface scratches
and water spotting.
Cleaning Underhood
Components
Caution
Do not power wash any
component under the hood
that has this
esymbol.
This could cause damage
that would not be covered
by the vehicle warranty.
Solvents or aggressive
cleaners may harm underhood
components. The usages of
these chemicals should be
avoided.

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
Vehicle Care 413
Recommend water only.
A pressure washer may be
used, but care must be utilized.
The following criteria must be
followed:
.Water pressure must be
kept below 14 000 KPa
(2,000 PSI).
.Water temperature must be
below 80 °C (180 °F).
.Spray nozzle with a
40 degree wide angle spray
pattern or wider must
be used.
.Nozzle must be kept at least
30 cm (1 ft) away from all
surfaces.
Finish Care
Application of aftermarket
clearcoat sealant/wax is not
recommended. If painted
surfaces are damaged, see
your dealer to have the
damage assessed and
repaired. Foreign materials
such as calcium chloride and
other salts, ice melting agents,
road oil and tar, tree sap, birddroppings, chemicals from
industrial chimneys, etc., can
damage the vehicle's finish if
they remain on painted
surfaces. Wash the vehicle as
soon as possible. If necessary,
use non-abrasive cleaners that
are marked safe for painted
surfaces to remove foreign
matter.
Occasional hand waxing or
mild polishing should be done
to remove residue from the
paint finish. See your dealer
for approved cleaning
products.
Do not apply waxes or
polishes to uncoated plastic,
vinyl, rubber, decals, simulated
wood, or flat paint as damage
can occur.
Caution
Machine compounding or
aggressive polishing on a
basecoat/clearcoat paint
finish may damage it. Use
only non-abrasive waxes and
(Continued)
Caution (Continued)
polishes that are made for a
basecoat/clearcoat paint
finish on the vehicle.
To keep the paint finish
looking new, keep the vehicle
garaged or covered whenever
possible.
Protecting Exterior Bright
Metal Moldings
Caution
Failure to clean and protect
the bright metal moldings
can result in a hazy white
finish or pitting. This damage
would not be covered by the
vehicle warranty.
The bright metal moldings on
the vehicle are aluminum,
chrome, or stainless steel. To
prevent damage always follow
these cleaning instructions:
.Be sure the molding is cool
to the touch before applying
any cleaning solution.

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
414 Vehicle Care
.Use only approved cleaning
solutions for aluminum,
chrome, or stainless steel.
Some cleaners are highly
acidic or contain alkaline
substances and can damage
the moldings.
.Always dilute a concentrated
cleaner according to the
manufacturer’s instructions.
.Do not use cleaners that are
not intended for
automotive use.
.Use a nonabrasive wax on
the vehicle after washing to
protect and extend the
molding finish.
Cleaning Exterior Lamps/
Lenses, Emblems, Decals,
and Stripes
Use only lukewarm or cold
water, a soft cloth, and a car
washing soap to clean exterior
lamps, lenses, emblems,
decals, and stripes. Follow
instructions under "Washing
the Vehicle" previously in this
section.Lamp covers are made of
plastic, and some have a UV
protective coating. Do not
clean or wipe them when dry.
Do not use any of the
following on lamp covers:
.Abrasive or caustic agents.
.Washer fluids and other
cleaning agents in higher
concentrations than
suggested by the
manufacturer.
.Solvents, alcohols, fuels,
or other harsh cleaners.
.Ice scrapers or other hard
items.
.Aftermarket appearance
caps or covers while the
lamps are illuminated, due to
excessive heat generated.
Caution
Failure to clean lamps
properly can cause damage
to the lamp cover that would
not be covered by the
vehicle warranty.
Caution
Using wax on low gloss black
finish stripes can increase
the gloss level and create a
non-uniform finish. Clean low
gloss stripes with soap and
water only.
Air Intakes
Clear debris from the air
intakes, between the hood and
windshield, when washing the
vehicle.
Shutter System

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
Vehicle Care 415
The vehicle may have a
shutter system designed to
help improve fuel economy.
Keep the shutter system clear
of debris, snow and ice. If the
check engine light is activated,
please check to see if the
shutter system is clear of
debris, snow or ice.
Windshield and Wiper
Blades
Clean the outside of the
windshield with glass cleaner.
Clean rubber blades using a
lint-free cloth or paper towel
soaked with windshield
washer fluid or a mild
detergent. Wash the
windshield thoroughly when
cleaning the blades. Bugs,
road grime, sap, and a buildup
of vehicle wash/wax
treatments may cause wiper
streaking.
Replace the wiper blades if
they are worn or damaged.
Damage can be caused byextreme dusty conditions,
sand, salt, heat, sun, snow,
and ice.
Weatherstrips
Apply weatherstrip lubricant
on weatherstrips to make
them last longer, seal better,
and not stick or squeak.
Lubricate weatherstrips at
least once a year. Hot, dry
climates may require more
frequent application. Black
marks from rubber material on
painted surfaces can be
removed by rubbing with a
clean cloth. See
Recommended Fluids and
Lubricants
0429.
Tires
Use a stiff brush with tire
cleaner to clean the tires.
Caution
Using petroleum-based tire
dressing products on the
vehicle may damage the
paint finish and/or tires.
(Continued)
Caution (Continued)
When applying a tire
dressing, always wipe off
any overspray from all
painted surfaces on the
vehicle.
Wheels and Wheel Trim
Use a soft, clean cloth with
mild soap and water to clean
the wheels. After rinsing
thoroughly with clean water,
dry with a soft, clean towel.
A wax may then be applied.
Caution
Chrome wheels and chrome
wheel trim may be damaged
if the vehicle is not washed
after driving on roads that
have been sprayed with
magnesium chloride or
calcium chloride. These are
used on roads for conditions
such as dust and ice. Always
wash the chrome with soap
and water after exposure.

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
416 Vehicle Care
Caution
To avoid surface damage on
wheels and wheel trim, do
not use strong soaps,
chemicals, abrasive polishes,
cleaners, or brushes. Use
only GM approved cleaners.
Do not drive the vehicle
through an automatic car
wash that uses silicon
carbide tire/wheel cleaning
brushes. Damage could
occur and the repairs would
not be covered by the
vehicle warranty.
Brake System
Visually inspect brake lines
and hoses for proper hook-up,
binding, leaks, cracks, chafing,
etc. Inspect disc brake pads
for wear and rotors for
surface condition. Inspect
drum brake linings/shoes for
wear or cracks. Inspect all
other brake parts.
Steering, Suspension, and
Chassis Components
Visually inspect steering,
suspension, and chassis
components for damaged,
loose, or missing parts or signs
of wear at least once a year.
Inspect power steering for
proper attachment,
connections, binding, leaks,
cracks, chafing, etc.
Visually check constant
velocity joint boots and axle
seals for leaks.
Body Component
Lubrication
Lubricate all key lock cylinders,
hood hinges, liftgate hinges,
and the steel fuel door hinges,
unless the components are
plastic. Applying silicone
grease on weatherstrips with
a clean cloth will make them
last longer, seal better, and
not stick or squeak.
Underbody Maintenance
At least twice a year, spring
and fall, use plain water to
flush any corrosive materials
from the underbody. Take care
to thoroughly clean any areas
where mud and other debris
can collect.
Do not directly power wash
the transfer case and/or
front/rear axle output seals.
High pressure water can
overcome the seals and
contaminate the fluid.
Contaminated fluid will
decrease the life of the
transfer case and/or axles and
should be replaced.
Sheet Metal Damage
If the vehicle is damaged and
requires sheet metal repair or
replacement, make sure the
body repair shop applies
anti-corrosion material to
parts repaired or replaced to
restore corrosion protection.

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
Vehicle Care 417
Original manufacturer
replacement parts will provide
the corrosion protection while
maintaining the vehicle
warranty.
Finish Damage
Quickly repair minor chips and
scratches with touch-up
materials available from your
dealer to avoid corrosion.
Larger areas of finish damage
can be corrected in your
dealer's body and paint shop.
Chemical Paint Spotting
Airborne pollutants can fall
upon and attack painted
vehicle surfaces causing
blotchy, ring-shaped
discolorations, and small,
irregular dark spots etched
into the paint surface. See
“Finish Care”previously in this
section.
Interior Care
To prevent dirt particle
abrasions, regularly clean the
vehicle's interior. Before using cleaners, read and follow all
safety instructions on the
label. While cleaning the
interior, open the doors and
windows to get proper
ventilation. Newspapers or
dark garments can transfer
color to the vehicle’s interior.
Caution
Immediately remove
cleaners, hand lotions,
sunscreen, and insect
repellent from all interior
surfaces or permanent
damage may result.
Caution
Use cleaners specifically
designed for the surfaces
being cleaned to prevent
permanent damage to the
vehicle. Apply all cleaners
directly to a cleaning cloth.
Do not spray cleaners on
any switches or controls.
When using liquid soap
cleaners, follow the directions
on the specific cleaner or soap
solution for dilution
instructions.
Caution
To prevent damage:
.Never use a razor or any
other sharp object to
remove soil from any
interior surface
.Never use a brush with
stiff bristles.
.Never rub any surface
aggressively or with too
much pressure.
.Do not get any exposed
electrical components wet.
.Do not use laundry
detergents or dishwashing
soaps with degreasers. Do
not use solutions that
contain strong or
caustic soap.
(Continued)

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
418 Vehicle Care
Caution (Continued)
.Do not heavily saturate
the upholstery when
cleaning.
.Do not use solvents or
cleaners containing
solvents.
.Do not use disinfecting
wipes that are scented or
contain bleach. Do not use
wipes or cleaners that
show a color transfer to
the wipe or change the
appearance of the interior
surface when used.
.Do not use scented or
gel-type hand sanitizers.
If hand sanitizer comes in
contact with interior
surfaces of the vehicle,
blot immediately and clean
with a soft cloth
dampened with a mild
soap and water solution.
Interior Glass
To clean, use a microfiber
cloth fabric dampened with
water. Wipe droplets left
behind with a clean dry cloth.
If necessary, use a commercial
glass cleaner after cleaning
with plain water.
Caution
To prevent scratching, never
use abrasive cleaners on
automotive glass. Abrasive
cleaners or aggressive
cleaning may damage the
rear window defogger.
Cleaning the windshield with
water during the first three to
six months of ownership will
reduce tendency to fog.
Speaker Covers
Vacuum around a speaker
cover gently, so that the
speaker will not be damaged.
Clean spots with water and
mild soap.
Coated Moldings
Coated moldings should be
cleaned.
.When lightly soiled, wipe
with a sponge or soft,
lint-free cloth dampened
with water.
.When heavily soiled, use
warm soapy water.
Vinyl/Rubber
If equipped with vinyl floor and
rubber floor mats, use a soft
cloth and/or brush dampened
with water to remove dust and
loose dirt. For more thorough
cleaning, use a mild soap and
water solution.
{Warning
Do not use cleaners that
contain silicone, wax-based
products, or cleaners that
increase gloss on vinyl/
rubber floor and mats.
These cleaners can
permanently change the (Continued)

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
Vehicle Care 419
Warning (Continued)
appearance and feel of the
vinyl/rubber and can make
the floor slippery. Your foot
could slip while operating
the vehicle, and you could
lose control, resulting in a
crash. You or others could
be injured.
Fabric/Carpet/Suede
Start by vacuuming the
surface using a soft brush
attachment. If a rotating
vacuum brush attachment is
being used, only use it on the
floor carpet. Before cleaning,
gently remove as much of the
soil as possible:
.Gently blot liquids with a
paper towel. Continue
blotting until no more soil
can be removed.
.For solid soils, remove as
much as possible prior to
vacuuming.To clean:
1. Saturate a clean, lint-free colorfast cloth with water.
Microfiber cloth is
recommended to prevent
lint transfer to the fabric
or carpet.
2. Remove excess moisture by gently wringing until
water does not drip from
the cleaning cloth.
3. Start on the outside edge of the soil and gently rub
toward the center. Fold
the cleaning cloth to a
clean area frequently to
prevent forcing the soil
into the fabric.
4. Continue gently rubbing the soiled area until there
is no longer any color
transfer from the soil to
the cleaning cloth.
5. If the soil is not completely removed, use a mild soap
solution followed only by
plain water. If the soil is not completely
removed, it may be necessary
to use a commercial
upholstery cleaner or spot
lifter. Test a small hidden area
for colorfastness before using
a commercial upholstery
cleaner or spot lifter. If ring
formation occurs, clean the
entire fabric or carpet.
After cleaning, use a paper
towel to blot excess moisture.
Cleaning High Gloss
Surfaces and Vehicle
Information and Radio
Displays
Use a microfiber cloth on high
gloss surfaces or vehicle
displays. First, use a soft
bristle brush to remove dirt
that can scratch the surface.
Then gently clean by rubbing
with a microfiber cloth. Never
use window cleaners or
solvents. Periodically hand
wash the microfiber cloth
separately, using mild soap. Do
