CADILLAC XT6 2023 Owners Manual

Cadillac XT6 Owner Manual (GMNA-Localizing-U.S./Canada-16405819) -
2023 - CRC - 3/22/22
450 Vehicle Care
{Warning
Do not bleach or dye seat
belt webbing. It may severely
weaken the webbing. In a
crash, they might not be
able to provide adequate
protection. Clean and rinse
seat belt webbing only with
mild soap and lukewarm
water. Allow the webbing
to dry.
Floor Mats
{Warning
If a floor mat is the wrong
size or is not properly
installed, it can interfere
with the pedals. Interference
with the pedals can cause
unintended acceleration
and/or increased stopping
distance which can cause a
crash and injury. Make sure
the floor mat does not
interfere with the pedals.Use the following guidelines
for proper floor mat use:
.The original equipment floor
mats are designed for your
vehicle. If the floor mats
need to be replaced, it is
recommended that
GM-certified floor mats are
purchased. Non-GM floor
mats may not fit properly
and may interfere with the
pedals. Always check that
the floor mats do not
interfere with the pedals.
.Do not use a floor mat if the
vehicle is not equipped with
a floor mat retainer on the
driver side floor.
.Use the floor mat with the
correct side up. Do not turn
it over.
.Do not place anything on top
of the driver side floor mat.
.Use only a single floor mat
on the driver side.
.Do not place one floor mat
on top of another.
Removing and Replacing
the Floor Mats
The driver side floor mat is
held in place by two
button-type retainers.
1. Pull up on the rear of the
driver side floor mat to
unlock each retainer and
remove.
2. Reinstall by lining up the floor mat retainer openings
over the carpet retainers
and snapping into position.

Cadillac XT6 Owner Manual (GMNA-Localizing-U.S./Canada-16405819) -
2023 - CRC - 3/22/22
Vehicle Care 451
3. Make sure the floor mat isproperly secured in place.
Verify the floor mat does
not interfere with the
pedals.
Cleaning Rubber Floor
Mats (All-Weather Mats
and Floor Liners)
See “Vinyl/Rubber” under
Interior Care 0446 for
important cleaning
information.

Cadillac XT6 Owner Manual (GMNA-Localizing-U.S./Canada-16405819) -
2023 - CRC - 3/22/22
452 Service and Maintenance
Service and
Maintenance
General Information
General Information . . . . . . 452
Maintenance Schedule
MaintenanceSchedule . . . . . . . . . . . . . . . . . . . 454
Multi-Point Vehicle
Inspection (MPVI)
Multi-Point VehicleInspection (MPVI) . . . . . . . . 456
Special Application
Services
Special ApplicationServices . . . . . . . . . . . . . . . . . . . . 457
Recommended Fluids,
Lubricants, and Parts
Recommended Fluids andLubricants . . . . . . . . . . . . . . . . . 458
Maintenance Replacement Parts . . . . . . 459
Maintenance Records
Maintenance Records . . . . 461
General
Information
Your vehicle is an important
investment. This section
describes the required
maintenance for the vehicle.
Follow this schedule to help
protect against major repair
expenses resulting from
neglect or inadequate
maintenance. It may also help
to maintain the value of the
vehicle if it is sold. It is the
responsibility of the owner to
have all required maintenance
performed.
Your dealer has trained
technicians who can perform
required maintenance using
genuine replacement parts.
They have up-to-date tools
and equipment for fast and
accurate diagnostics. Many
dealers have extended
evening and Saturday hours,
courtesy transportation, and
online scheduling to assist
with service needs. Your dealer recognizes the
importance of providing
competitively priced
maintenance and repair
services. With trained
technicians, the dealer is the
place for routine maintenance
such as oil changes and tire
rotations and additional
maintenance items like tires,
brakes, batteries, and wiper
blades.
Caution
Damage caused by improper
maintenance can lead to
costly repairs and may not
be covered by the vehicle
warranty. Maintenance
intervals, checks,
inspections, recommended
fluids, and lubricants are
important to keep the
vehicle in good working
condition.
Do not have chemical
flushes that are not
approved by GM performed
(Continued)

Cadillac XT6 Owner Manual (GMNA-Localizing-U.S./Canada-16405819) -
2023 - CRC - 3/22/22
Service and Maintenance 453
Caution (Continued)
on the vehicle. The use of
flushes, solvents, cleaners,
or lubricants that are not
approved by GM could
damage the vehicle,
requiring expensive repairs
that are not covered by the
vehicle warranty.
The Tire Rotation and
Required Services are the
responsibility of the vehicle
owner. It is recommended to
have your dealer perform
these services every
12 000 km/7,500 mi. Proper
vehicle maintenance helps to
keep the vehicle in good
working condition, improves
fuel economy, and reduces
vehicle emissions.
Because of the way people
use vehicles, maintenance
needs vary. There may need to
be more frequent checks and
services. The Additional
Required Services - Normal
are for vehicles that:
.Carry passengers and cargo
within recommended limits
on the Tire and Loading
Information label. See
Vehicle Load Limits 0252.
.Are driven on reasonable
road surfaces within legal
driving limits.
.Use the recommended fuel.
See Recommended Fuel
(2.0L L4 Turbo Engine)
0343 or Recommended Fuel
(3.6L V6 Engine) 0343.
Refer to the information in the
Maintenance Schedule
Additional Required Services -
Normal Service.
The Additional Required
Services - Severe are for
vehicles that are:
.Mainly driven in heavy city
traffic in hot weather.
.Mainly driven in hilly or
mountainous terrain.
.Frequently towing a trailer.
.Used for high speed or
competitive driving.
.Used for taxi, police,
or delivery service.
Refer to the information in the
Maintenance Schedule
Additional Required Services -
Severe Service.
{Warning
Performing maintenance
work can be dangerous and
can cause serious injury.
Perform maintenance work
only if the required
information, proper tools,
and equipment are available.
If they are not, see your
dealer to have a trained
technician do the work. See
Doing Your Own Service
Work 0364.

Cadillac XT6 Owner Manual (GMNA-Localizing-U.S./Canada-16405819) -
2023 - CRC - 3/22/22
454 Service and Maintenance
Maintenance
Schedule
Tire Rotation and
Required Services Every
12 000 km (7,500 mi)
Tires are rotated to achieve a
more uniform wear for all tires.
The first rotation is the most
important.
Anytime unusual wear is
noticed, rotate the tires as
soon as possible, check for
proper tire inflation pressure,
and check for damaged tires
or wheels. If the unusual wear
continues after the rotation,
check the wheel alignment.
See When It Is Time for New
Tires0418 and Wheel
Replacement 0423.
.Perform Multi-Point Vehicle
Inspection. See Multi-Point
Vehicle Inspection (MPVI)
0456.
.Lubricate body components.
See Exterior Care 0440.
Additional Required
Services —Normal
Service
Every 12 000 km (7,500 mi)
.Check engine oil level and oil
life percentage. If needed,
change engine oil and filter,
and reset oil life system. Or
when the CHANGE ENGINE
OIL SOON message displays,
have the engine oil and filter
changed within the next
1 000 km (600 mi). If driven
under the best conditions,
the engine oil life system
may not indicate the need
for vehicle service for up to
a year. The engine oil and
filter must be changed at
least once a year and the oil
life system must be reset.
Your trained dealer
technician can perform this
work. If the engine oil life
system is reset accidentally,
service the vehicle within
5 000 km (3,000 mi) since
the last service. Reset the oil life system when the oil is
changed. See Engine Oil Life
System
0373.
.When the REPLACE AT
NEXT OIL CHANGE
message displays, the engine
air filter should be replaced
at the next engine oil
change. When the REPLACE
ENGINE AIR FILTER SOON
message displays, the engine
air filter should be replaced
at the earliest convenience.
Reset the engine air filter life
system after the engine air
filter is replaced. See Engine
Air Filter Life System 0374.
Every 36 000 km (22,500 mi)
.Passenger compartment air
filter replacement (or every
24 months, whichever
occurs first). More frequent
replacement may be needed
if the vehicle is driven in
areas with heavy traffic,
poor air quality, areas with
high dust levels or are
sensitive to environmental
allergens. Filter replacement

Cadillac XT6 Owner Manual (GMNA-Localizing-U.S./Canada-16405819) -
2023 - CRC - 3/22/22
Service and Maintenance 455
may also be needed if you
notice reduced airflow,
windows fogging up,
or odors. Your local GM
Service location can help you
determine when it is the
right time to replace your
filter.
Every 96 000 km (60,000 mi)
.Replace spark plugs. Inspect
spark plug wires and/or
boots. (2.0L Engine)
Every 156 000 km
(97,500 mi)
.Replace spark plugs. Inspect
spark plug wires and/or
boots. (3.6L Engine)
Every 161 000 km
(100,000 mi)
.Replace hood and/or body
lift support gas struts. Or
every 10 years, whichever
comes first. See Gas Strut(s)
0 388. Every 240 000 km
(150,000 mi)
.Change rear axle fluid,
if equipped with AWD. Do
not directly power wash the
transfer case and/or front/
rear axle output seals. High
pressure water can
overcome the seals and
contaminate the transfer
case fluid. Contaminated
fluid will decrease the life of
the transfer case and/or
axles and should be
replaced.
.Drain and fill engine cooling
system. Or every six years,
whichever comes first. See
Cooling System
0376.
Severe Conditions
Requiring More Frequent
Maintenance*
.Public service, military,
or commercial use vehicles
to include the following:
‐ Ambulances, police cars,
and emergency rescue
vehicles. ‐
Civilian vehicles such as
light duty pick-up trucks,
SUVs, and passenger cars
that are used in military
applications.
‐ Recovery vehicles such as
tow trucks and flatbed
single vehicle carriers or
any vehicle that is
consistently used in towing
trailers or other loads.
‐ High use commercial
vehicles such as courier
delivery vehicles, private
security patrol vehicles,
or any vehicles that
operate on a 24–hour
basis.
‐ Any vehicle consistently
operated in a high sand or
dust environment such as
those used on oil pipelines
and similar applications..Vehicles that are regularly
used for short trips of 6 km
(4 mi) or less.
The oil life indicator will show
you when to change the oil
and filter. Under severe

Cadillac XT6 Owner Manual (GMNA-Localizing-U.S./Canada-16405819) -
2023 - CRC - 3/22/22
456 Service and Maintenance
conditions the indicator may
come on before 12 000 km
(7,500 mi).
* Footnote: Under extreme
driving conditions listed
above, it may be necessary
to replace your spark plugs
at more frequent intervals.
For further assistance in
determining the most
suitable service maintenance
intervals for your vehicle,
please contact your
authorized GM Dealer.
Extreme service is for
vehicles mainly driven
off-road in four-wheel drive
or used in farming, mining,
forestry, or snow plowing.
Additional Required
Services—Severe Service
Every 72 000 km (45,000 mi)
.Change automatic
transmission fluid. Every 75 000 km
(120,000 mi)
.Change rear axle fluid,
if equipped with AWD. Do
not directly power wash the
transfer case and/or front/
rear axle output seals. High
pressure water can
overcome the seals and
contaminate the transfer
case fluid. Contaminated
fluid will decrease the life of
the transfer case and/or
axles and should be
replaced.
Owner Checks and
Services
Every Five Years
.Replace brake fluid every
five years. See Brake Fluid
0
384.
Every Seven Years
.Replace Air Conditioning
Desiccant every seven years.
The air conditioning system
requires maintenance every
seven years. This service
requires replacement of the desiccant to help the
longevity and efficient
operation of the air
conditioning system. This
service can be complex. See
your dealer.
Multi-Point Vehicle
Inspection (MPVI)
A Multi Point Vehicle
Inspection (MPVI) completed
by a GM dealer technician is a
maintenance assessment of
your vehicle. The benefit of
the MPVI is to identify and
inform the customer of service
items that require immediate
attention and those that may
require attention in the future.
The technician will perform the
following checks on your
vehicle. For a complete list of
checks, inspections, and
services, see your dealer.
Some items may not apply to
your vehicle and/or region.

Cadillac XT6 Owner Manual (GMNA-Localizing-U.S./Canada-16405819) -
2023 - CRC - 3/22/22
Service and Maintenance 457
Diagnostics
.OnStar active, if equipped
.Service history/recall check
Engine Oil and Filter
.Engine oil
.Oil life monitor
‐Reset oil life monitor
Exterior Lights
.Visual inspection
Windshield and Wipers
.Visual inspection
Battery
.Battery visual inspection
.Battery test results
.Battery cables and
connections
Systems, Fluids, and
Visible Leak Inspection
.Engine oil
.Transmission
.Drive axle
.Transfer case
.Engine cooling system
.Power steering, if equipped
.Fuel system
.Windshield washer fluid
Tire Inspection
.Tire pressure, tread depth,
and wear
.Rotation, if applicable
.Alignment check, optional
.Reset tire pressure monitor
.Check tire sealant expiration
date, if equipped
.Check spare tire, if equipped
Brakes
.Check brake system
Visible and Functional
Inspections
.Seat belt components
.Exhaust system
.Accelerator pedal
.Passenger compartment air
filter, if equipped
.Engine air filter
.Hoses
.Belts
.Shocks and struts
.Steering components
.Axle boots or driveshaft and
u-joints
.Compartment lift struts,
if equipped
.Floor mats secured, no
interference with pedals
.Horn
.Ignition lock, if equipped
.Starter switch
.Evaporative control system
Lubricate
.Chassis components
Special Application
Services
.Severe Commercial Use
Vehicles Only: Lubricate
chassis components every
oil change.
.Have underbody flushing
service performed. See
"Underbody Maintenance" in
Exterior Care 0440.

Cadillac XT6 Owner Manual (GMNA-Localizing-U.S./Canada-16405819) -
2023 - CRC - 3/22/22
458 Service and Maintenance
Recommended Fluids, Lubricants, and Parts
Recommended Fluids and Lubricants
Fluids and lubricants identified below by name or specification, including fluids or lubricants not
listed here, can be obtained from your dealer.Usage Fluid/Lubricant
Automatic Transmission DEXRON-VI Automatic Transmission Fluid. Chassis Lubrication Lubricant meeting requirements of NLGI #2, Category LB or GC-LB. See your dealer.
Engine Coolant 50/50 mixture of clean, drinkable water and use only DEX-COOL Coolant. See Cooling System 0376.
Engine Oil Engine oil meeting the dexos1 specification of the proper SAE viscosity grade. ACDelco dexos1 full synthetic is recommended.
See Engine Oil0370.
Fuel Additive Fuel System Treatment PLUS or equivalent.
Hood and Door Hinges, Key Lock Cylinders Multi-Purpose Lubricant. See your dealer.
Hydraulic Brake System DOT 4 Hydraulic Brake Fluid.
Power Liftgate Actuator Ball Joint, Hood Latch Assembly,
Secondary Latch, Pivots, Spring Anchor, and Release Pawl Lubricant meeting requirements of NLGI #2, Category LB or
GC-LB. See your dealer.

Cadillac XT6 Owner Manual (GMNA-Localizing-U.S./Canada-16405819) -
2023 - CRC - 3/22/22
Service and Maintenance 459
UsageFluid/Lubricant
Rear Axle (If equipped with AWD) See your dealer.
Weatherstrip Conditioning Weatherstrip Lubricant. See your dealer. Windshield Washer Automotive windshield washer fluid that meets regional freeze protection requirements.
Maintenance Replacement Parts
Replacement parts identified below by name, part number, or specification can be obtained from
your dealer.
Part GM Part NumberACDelco
Part Number
Engine Air Cleaner/Filter 23321606A3212C
Engine Oil Filter
I2.0L L4 Engine 55495105
PF66
I3.6L V6 Engine 12693541
UPF63R
Passenger Compartment Air Filter 13508023CF185
