Driver Set Temperature Knob
The DRIVER knob changes the temperature on
the driver's and passenger's side of the vehicle.
Turn the knob clockwise to increase the temperature
and counterclockwise to decrease the temperature.
Whenever you turn this knob, the temperature will be
displayed for approximately five seconds along with
the current fan speed and air delivery mode.
When adjusting the temperature, start with a driver
-set
temperature of 73
F (23
C) until you determine
your comfort zone. If you choose 60
F (16
C),
the system will remain at maximum cooling and will
not automatically adjust fan speed or air delivery.
If you choose 90
F (32
C), the system will remain at
maximum heating and will not automatically adjust fan
speed or air delivery. Choosing either maximum setting
will not cause the system to heat or cool any faster.
Turning the knob past either maximum setting has
no effect on the operation of the system.Passenger Temperature Offset
The PASSENGER knob changes the temperature on the
passenger's side of the vehicle. When the knob is in the
12 o'clock position, the passenger's temperature is the
same as the driver's. Turn the knob clockwise for warmer
air on the passenger's side, counterclockwise for cooler
air. If the driver
-set temperature is set at 60
F (16
C) or
90
F (32
C), turning the passenger knob has no effect
because the system is locked at a maximum setting.
Automatic Operation
Press the AUTO button to place the entire system in
the automatic mode. After a five
-second display of the
current settings, only the word AUTO and the outside
temperature will be shown on the digital display
unless you are in full cold 60
F (16
C) or full hot
90
F (32
C), then the word AUTO will not display.
The system will operate to achieve your comfort set
temperature as quickly as possible. The AUTO control
system works best with the windows up and the
removable roof installed or the convertible top up.

3-6
A Typical Cold Weather Example:
Your vehicle has been parked outside overnight in
cold weather (below 32
F/ 0
C) and you have set the
driver temperature at 73
F (23
C) and have selected
the AUTO mode. The system will automatically adjust
the temperature output to maximum heating. The fan
will start at a low speed. This is to avoid blowing cold
air into the vehicle. The length of the delay depends on
the amount of time since the engine was last started, the
outside temperature and the engine coolant temperature.
As the coolant warms up, the fan speed will gradually
increase. Air will flow to the floor with some air to
the windshield to prevent fogging under most
normal conditions.
As the interior of the vehicle warms up to the set
temperature, the fan speed will decrease and the
temperature output may become cooler. If the interior
temperature continues to warm up due to heating from
the sun or outside temperature increases, the system
may switch to other air delivery modes (typically defog
or bi
-level).A Typical Hot Weather Example:
The vehicle has been parked outside all day in hot
weather (above 80
F/ 27
C) and you have set the
driver temperature at 73
F (23
C) and have selected the
AUTO mode. The system will automatically adjust the
temperature output to maximum cooling. The fan will
start at a low speed momentarily to push the hot air to
the floor of the vehicle and then go to a higher fan speed
with cold airflow out of the instrument panel outlets.
A small amount of airflow will continue through the
lower ducts to cool the floor area.
The air intake may start in the recirculated mode for
maximum cooling performance. As the interior of the
vehicle cools down to the set temperature, the fan speed
will decrease and the temperature output may become
warmer. The air intake may shift from recirculation to
outside air mode. If the interior continues to cool due to a
decrease in the amount of heat the vehicle is absorbing
from the sun or a decrease in the outside temperature, the
system could switch to other air delivery modes (typically
bi-level or defog).

3-7
Manual Settings
With the automatic electronic dual climate control
system, there are several manual settings you can use
to control the system and override the AUTO operation.
You can program the fan speed, air delivery mode, air
intake mode and control the air conditioning operation
using these settings. The system will still determine the
temperature output level based on the driver
-set
temperature and the passenger temperature offset.
(Fan Speed): Press the button with the fan symbol
on it to manually lock in the current fan speed and to
stop the automatic fan speed control. Pressing the
arrows will delete AUTO from the digital display.
The fan graphics with the fan speed bars will be shown.
To increase the fan speed so that more air flows into
the vehicle, press the up arrow on the fan switch.
To decrease the fan speed and airflow, press the down
arrow. The AUTO button must be pressed to return
to the automatic fan control.MODE: Press the MODE button to manually lock in
the current air delivery setting and to stop the automatic
mode control. Pressing the MODE button will delete
AUTO from the digital display and the mode graphics
will be shown. To change the setting, press the MODE
button again. The AUTO button must be pressed to
return to the automatic mode selection.
(Vent): This setting directs most of the air through
the instrument panel outlets and a very small amount to
the lower outlets.
(Bi-Level): This setting directs air into the vehicle
in two ways. Cooler air is directed toward your upper
body through the instrument panel outlets, while warmer
air is directed through the lower outlets.
(Floor): This setting directs most of the air to the
floor area and some of it toward the windshield and side
window vents.
(Defog): This setting divides the air between
the windshield and lower outlets and a small amount
toward the side window vents. This is useful when fog
appears on the windshield or side glass due to rain or
snowy conditions.

3-8
Function Buttons
These buttons control the climate control ON/OFF,
air intake, front defrost, rear defrost and the air
conditioning operation.
OFF: Press the OFF button to turn off the climate
control system. This is the only setting that fully
shuts off the fan. The digital display will show only the
outside temperature. You can still adjust the driver set
temperature, the passenger temperature offset and the
air intake mode while in OFF.
A/C (Air Conditioning): This button turns
the air conditioning compressor off or on under most
conditions. The light on the A/C button will come on
when the compressor is operating in either the automatic
or manual mode. The air conditioning does not operate
at temperatures below approximately 35
F to 40
F
(2
C to 4
C). The light on the A/C button will flash if
pressed when air conditioning is not available. The air
conditioning cools and dehumidifies the air coming into
the vehicle. The air conditioning cannot be turned off in
defrost and defog, as it helps to remove moisture from
the vehicle. It also helps to keep the windows clear.If the system is operating in the AUTO mode, turning
the air conditioning off will delete AUTO from the
digital display and show current mode and fan settings.
The AUTO button must be pressed to return to the
automatic mode operation.
The air conditioning may be forced off at high engine
speeds or high engine oil or coolant temperatures.
(Outside Air): Press this button to provide outside
air. The light on this air intake button will come on to
show when it is operating. When in the AUTO mode,
the system automatically selects outside air instead of
recirculate, as required, to control the temperature in the
vehicle. By pressing outside air, the system will lock
into the outside air mode. Any adjustment to the air
intake must then be made manually. Outside air should
be used when trying to defrost or defog windows to help
reduce moisture inside of the vehicle.

3-9
(Recirculate): Press this button to limit the
amount of outside air entering the vehicle. The light on
this air intake button will come on to show when it is
operating. Recirculate is helpful when you are trying to
cool the air quickly or trying to limit odors and dust
from entering the vehicle. When in the AUTO mode,
the system automatically selects recirculate to cool the
vehicle's temperature. By pressing this button, the
system will lock into the recirculated air mode.
Any adjustment to the air intake must then be made
manually. Recirculation is not available when using the
defrost or defog mode because outside air is needed to
reduce moisture inside of the vehicle.
Operating the system in the recirculation mode may
cause fogging of the vehicle's windows when the
weather is cold and damp. To clear the fog, switch the
system to either the defog or defrost mode and increase
the fan speed. To avoid re
-fogging of the windows,
operate the system in the outside air mode.
FRONT: Press the FRONT defrost button to
quickly remove fog or frost from the windshield.
This setting directs most of the airflow to the windshield
and a small amount toward the lower and side window
outlets. The light on the button will come on and the
digital display will show the defrost mode symbol and
fan speed when the front defrost mode is being used.
Pressing FRONT defrost again will return the system to
the last operating mode and the air intake mode will be
in outside air.
If the system is in front defrost when you shut the
engine off, it will restart in FRONT defrost unless the
engine is off for longer than 40 minutes. If the engine is
off longer than 40 minutes, the system will restart in the
operating mode you had set prior to FRONT defrost and
the air intake mode will be in outside air.
See ªRear Window Defoggerº later in this section for
more information.

3-10 Sensors
The automatic electronic dual climate control system
uses several sensors to control operation and
display information.
Solar Load Sensor
This sensor is located on the top right side of the
defroster grille. The defroster grille is on the top of
the instrument panel.
The sensor monitors the sun's solar radiation and uses
this information as part of the automatic climate control
system when operating in the AUTO mode.
Be careful not to put anything over the sensor. When
covered, the sensor cannot compensate for changes in
the amount of heat the vehicle is absorbing from the sun.
Outside Air Temperature Sensor
This sensor is located in the air intake under the front
bumper of the vehicle. Information from this sensor is
used for the outside air temperature readings shown on the
digital display for the automatic climate control system.If the outside temperature goes up, the displayed
temperature will not change until:

The vehicle's speed is above 16 mph (26 km/h) for
one and a half minutes.

The vehicle's speed is above 45 mph (72 km/h) for
one minute.
These delays help prevent false readings. If the
temperature goes down, the outside temperature
display is updated immediately.
If the vehicle has been turned off for more than three
hours, the current outside temperature will be shown
when you start the vehicle. If it has been turned off for
less than three hours, the temperature will be recalled
from the previous vehicle operation.
Inside Temperature Sensor
This sensor is located to the left of the ignition switch.
The automatic climate control system uses this sensor
to receive information, so if you block or cover it,
the system will not function properly.

3-11 Air Conditioning
On very hot days, the vehicle will cool down more
quickly and economically if you open the windows
long enough to let hot inside air escape. Then keep the
windows closed in order to allow the air conditioning
to work best. Maximum cooling will occur when the
recirculate setting is operating, airflow direction is in the
upper mode, and the temperature control knob (on a
manual climate control system) is turned all the way to
the blue area. These settings will be selected by the
automatic electronic dual climate control system if
operating in AUTO when maximum cooling is required.
When the air conditioning is on, you may sometimes
notice slight changes in the vehicle's engine performance
and power. This is normal. The system is designed to
help fuel economy while maintaining the desired
cooling level.
The air conditioning removes moisture from the air,
so you may notice water dripping from under the
vehicle when it is idling or after it has been turned off.
This is normal.
Heating
The heater works best if you keep the windows closed.
Maximum heating will occur when airflow direction is
in the lower mode and the temperature control knob
(on a manual climate control system) is all the way in
the red area. These settings will be selected by the
automatic electronic dual climate control system if
operating in AUTO when maximum heating is required.
The bi
-level setting is designed for use on sunny days
when the air is only moderately warm or cool. On days
like these, the sun may adequately warm your upper
body, but your lower body may not be warm enough.
The bi
-level setting will direct cooler airflow to your
upper body and warmer air to the floor area.
If you have the optional engine coolant heater and use it
during cold weather 0
F (
-18
C) or lower, the heating
system will provide heat more quickly because the
coolant is already warmed. See ªEngine Coolant Heaterº
in the Index.

3-12 Defogging and Defrosting
To rapidly defrost the windshield, the FRONT defrost
mode (automatic electronic dual climate control system)
or defrost mode (manual control system) should be used
and the fan speed should be adjusted to the highest
speed. With the manual control system, turn the
temperature control knob all the way to the red area.
To keep the windshield clear and provide heated air to
the floor area of the vehicle, use the defog setting.
Your vehicle is equipped with side window defogger
vents located near the side rearview mirrors.
Rear Window Defogger
REAR: This button turns the rear defogger and the
heated outside mirrors on. The light on the button will
come on when operating. The system automatically
shuts off after approximately 15 minutes. If further
defogging is desired, press the button again and it will
operate for about seven and a half more minutes.
The rear window defogger operates only when the
engine is running.
The rear window defogger uses a warming grid to
remove fog from the rear window. Do not attach
anything like a temporary vehicle license or a decal
across the defogger grid on the rear window.
NOTICE:
Don't use a razor blade or something sharp on
the inside of the rear window. If you do, you
could cut or damage the warming grid, and
repairs wouldn't be covered by your warranty.

3-13 Ventilation System
Your vehicle's flow-through ventilation system supplies
outside air into the vehicle when it is moving. Outside
air will also enter the vehicle when the fan is running.
Ventilation Tips

Keep the hood and front air inlet free of ice, snow or
any other obstruction (such as leaves). The heater
and defroster will work far better, reducing the
chance of fogging the inside of the windows.

When you enter a vehicle in cold weather, turn the
fan to the highest speed for a few moments before
driving off. This helps clear the intake outlets of
snow and moisture, and reduces the chance of
fogging the inside of the windows.

Keep the area around the base of the center
instrument panel console and air path under the seats
clear of objects. This helps air circulate throughout
the vehicle.
Audio Systems
Your audio system has been designed to operate easily
and give years of listening pleasure. You will get the
most enjoyment out of it if you acquaint yourself with it
first. Find out what your audio system can do and how
to operate all of its controls to be sure you're getting the
most out of the advanced engineering that went into it.
Your vehicle has a feature called Retained Accessory
Power (RAP). With RAP, you can play your audio
system even after the ignition is turned off. See
ªRetained Accessory Powerº in the Index.
Setting the Clock
Press and hold HR until the correct hour appears.
Press and hold MN until the correct minute appears.

3-14 AM-FM Stereo with Cassette Tape Player
and Automatic Tone Control (If Equipped)
Your vehicle is equipped with six Bose
amplified
speakers. See your dealer for details.
Playing the Radio
PWR (Power): Press this knob to turn the system on
and off.
VOL (Volume): Turn the knob clockwise to increase
volume. Turn it counterclockwise to decrease volume.RECALL: Pressing this knob will display the station
being played or it will display the clock. Clock display
is available with the ignition turned off.
SCV (Speed
-Compensated Volume): With SCV,
your audio system adjusts automatically to make up for
road and wind noise as you drive. Set the volume at the
desired level. Turn the control ring behind the upper
knob clockwise to adjust the SCV. Each notch on the
control ring allows for more volume compensation
at faster vehicle speeds. Then, as you drive, SCV
automatically increases the volume, as necessary, to
overcome noise at any speed. The volume level should
always sound the same to you as you drive. If you don't
want to use SCV, turn the control all the way down.
Finding a Station
AM FM: Press this button to switch between AM,
FM1 and FM2. The display shows your selection.
TUNE: Press this knob lightly so it extends. Turn it to
choose radio stations. Push the knob back into its stored
position when you're not using it.
