CHRYSLER 300 2005 1.G Owners Manual

Cavity Fuse Circuits
40 5 Amp
OrangePower Mirror
41 10 Amp
RedClimate Control Module/
Headlamp Leveling Ð if
equipped/Rear Park Assist Ð
if equipped/Tire Pressure
Monitoring Ð if equipped
42 30 Amp
PinkAutomatic Temperature Con-
trol (ATC) Blower Motor
43 30 Amp
PinkRear Defroster
44 20 Amp
Lt. BlueAudio AmplifierVEHICLE STORAGE
If you are leaving your vehicle dormant for more than 21
days you may want to take steps to protect your battery.
You may:
²Disconnect the negative cable from the battery.
²Anytime you store your vehicle, or keep it out of
service (i.e. vacation) for two weeks or more, run the
air conditioning system at idle for about five minutes
in the fresh air and high blower setting. This will
insure adequate system lubrication to minimize the
possibility of compressor damage when the system is
started again.
MAINTAINING YOUR VEHICLE 321
7

REPLACEMENT LIGHT BULBS
LIGHT BULBS Ð Interior Bulb Number
Rear Courtesy/Reading Lights.............. W5W
Rear Compartment (Trunk) Light............. 579
Overhead Console Reading Lights............. 578
Visor Vanity Lights.....................A6220
Glove Box Light......................... 194
Door Courtesy.......................... 562
Shift Indicator Light.................JKLE14140
NOTE:For lighted switches, see your dealer for re-
placement instructions.
All of the interior bulbs are glass wedge base or glass
cartridge types. Aluminum base bulbs are not approved
and should not be used for replacement.
LIGHT BULBS Ð Exterior (300, 300 Touring) Bulb
Number
Low Beam Headlamp.....................9006
High Beam Headlamp....................9005
Front Park/Turn Lamp.................3757AK
Front Inner Park Lamp..................194NA
Front Outer Park Lamp..................194NAFront Fog LampÐIf Equipped...........9145/H10
(Serviced at Dealer)
Front Sidemarker......... W5W(Serviced at Dealer)
Tail/Stop/Turn Lamp.....................3057
Rear Sidemarker......................... 168
Backup Lamp..........................3057
Center High Mount Stop Lamp (CHMSL)....... LED
License................................ 168
LIGHT BULBS Ð Exterior (300C) Bulb Number
Low Beam Headlamp (Standard Halogen)....9006XS
Low Beam Headlamp ± High Intensity
Discharge (HID)........... D1S(Serviced at Dealer)
High Beam Headlamp....................9005
Front Park/Turn Lamp.................3157AK
Front Fog Lamp.......9145/H10 (Serviced at Dealer)
Front Sidemarker......... W5W(Serviced at Dealer)
Tail/Stop Lamp.........................3057
Tail Lamp.............................3057
Turn Signal Lamp.......................3057
Backup Lamp..........................3057
Center High Mount Stop Lamp (CHMSL)....... LED
License.............................. W5W
322 MAINTAINING YOUR VEHICLE

BULB REPLACEMENT
Low Beam Headlamp, High Beam Headlamp,
Park/Turn Lamp, Inner Park Lamp, and Outer
Park Lamp ± 300
²
Open the hood.
²Twist the appropriate bulb socket assembly counter-
clockwise and pull out. Pull the bulb out of the socket
assembly.
NOTE:Removal of the air cleaner filter housing may be
necessary prior to replacing bulbs on driver's side head-
lamp assembly.
²Replace the bulb and push into socket assembly.
Reinstall the socket assembly, and turn clockwise.
MAINTAINING YOUR VEHICLE 323
7

CAUTION!
Do not touch the new bulb with your fingers. Oil
contamination will severely shorten bulb life. If the
bulb comes in contact with an oily surface, clean the
bulb with rubbing alcohol.
Low Beam Headlamp, High Beam Headlamp, and
Park/Turn Lamp ± 300C
High Intensity Discharge Headlights (HID) Ð If
Equipped
The headlights are a type of high voltage discharge tube.
High voltage can remain in the circuit even with the
headlight switch off and the key removed.Because of
this, you should not attempt to service a headlight bulb
yourself. If a headlight bulb fails, take your vehicle to
an authorized dealer for service.
WARNING!
A transient high tension occurs at the bulb sockets of
High Intensity Discharge (HID) headlights when the
headlight switch is turned ON. It may cause serious
electrical shock or electrocution if not serviced prop-
erly. See your authorized dealer for service.
324 MAINTAINING YOUR VEHICLE

NOTE:On vehicles equipped with High Intensity Dis-
charge Headlights (HID), when the headlights are turned
on there is a blue hue to the lights. This diminishes and
becomes more white after approximately 10 seconds, as
the system charges.
²Open the hood.
²Twist the appropriate bulb socket assembly counter-
clockwise and pull out. Pull the bulb out of the socket
assembly.
NOTE:Removal of the air cleaner filter housing may be
necessary prior to replacing bulbs on driver's side head-
lamp assembly.
²Replace the bulb and push into socket assembly.
Reinstall the socket assembly, and turn clockwise.
MAINTAINING YOUR VEHICLE 325
7

CAUTION!
Do not touch the new bulb with your fingers. Oil
contamination will severely shorten bulb life. If the
bulb comes in contact with an oily surface, clean the
bulb with rubbing alcohol.
Backup Lamp, Side Marker Lamp, and Tail/Stop
Turn Lamp Ð 300
1. Open the Trunk.
2. Remove two fasteners from the back of the tail lamp
assembly.3. Pull back the trunk liner.
4. Remove the remaining fastener from the back of the
tail lamp assembly.
5. Push the electrical connector locking tab to the side.
326 MAINTAINING YOUR VEHICLE

6. Disconnect the electrical connector. 7. Pull tail lamp assembly clear from vehicle to access
bulbs. Turn bulb sockets counter-clockwise to remove.
MAINTAINING YOUR VEHICLE 327
7

8. Pull the appropriate bulb to remove it from the socket.
9. Replace the bulb, reinstall the socket, and reattach the
tail light assembly.
10. Close the trunk.
328 MAINTAINING YOUR VEHICLE

Tail/Stop, Tail, Turn Signal Lamp, and Backup
Lamp Ð 300C
1. Open the Trunk.
2. Remove two fasteners from the back of the tail lamp
assembly.3. Pull back the trunk liner.
4. Remove the remaining fastener from the back of the
tail lamp assembly.
5. Push the electrical connector locking tab to the side.
6. Disconnect the electrical connector.
MAINTAINING YOUR VEHICLE 329
7

7. Pull tail lamp assembly clear from vehicle to access
bulbs. Turn bulb sockets counter-clockwise to remove.
330 MAINTAINING YOUR VEHICLE
