CHRYSLER ASPEN 2007 2.G Owners Manual

WARNING!
A moving garage door can cause injury to people and
pets in the path of the door. People or pets could be
seriously or fatally injured. Only use this transceiver
with a garage door opener that has a “stop and
reverse” feature as required by federal safety stan-
dards. This includes most garage door opener mod-
els manufactured after 1982. Do not use a garage
door opener without these safety features it could
cause injury or death. Call toll-free 1–800–355–3515
or, on the Internet at www.homelink.com for safety
information or assistance.
WARNING!
Vehicle exhaust contains carbon monoxide, a danger-
ous gas. Do not run the vehicle’s exhaust while
training the transceiver. Exhaust gas can cause seri-
ous injury or death.
WARNING!
Your motorized door or gate will open and close
while you are training the Universal Transceiver. Do
not train the transceiver if people or pets are in the
path of the door or gate. A moving door or gate can
cause serious injury or death to people and pets or
damage to objects.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 161
3

Programming HomeLink
The Electronic Vehicle Information Center (EVIC) fea-
tures a driver–interactive display which includes
HomeLink system messages. The EVIC display is located
in the overhead console.
NOTE:When programming a garage door opener, it is
advised to park outside the garage. It is also recom-
mended that a new battery be placed in the hand-held
transmitter of the device being programmed to
HomeLink for quicker training and accurate transmis-
sion of the radio-frequency signal.
1. Press and hold the two outer HomeLink buttons, and
the EVIC will display “CLEARING CHANNELS”, do not
release the buttons until “CHANNELS CLEARED” is
displayed on the EVIC (after approximately 20 seconds).
Do nothold the buttons for longer than 30 seconds anddo notrepeat step one to program a second and/or third
hand-held transmitter to the remaining two HomeLink
buttons.
2. Position the end of your hand-held transmitter 1-3
inches (3-8 cm) away from the HomeLink buttons while
keeping the EVIC display in view.
162 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

3. Simultaneously press and hold both the HomeLink
button that you want to train and the hand-held trans-
mitter button.Do not release the buttons until step 4 has
been completed.The EVIC will display “CHANNEL X
TRAINING”, once the transmitter is programmed the
EVIC will display “CHANNEL X TRAINED”. X refers to
the desired channel being trained (1,2 or 3).
NOTE:Some gate operators and garage door openers
may require you to replace this Programming Step 3 with
procedures noted in theGate Operator/Canadian Pro-
grammingsection.
4. Once “CHANNEL X TRAINED” is displayed on the
EVIC, release both buttons. Programming is now com-
plete. When the HomeLink button is subsequently
pressed, “CHANNEL X TRANSMIT” is displayed on the
screen and your device should be activated, (garage door
should open).NOTE:To program the remaining two HomeLink but-
tons, begin withProgrammingstep two. Do not repeat
step one.
NOTE:If the EVIC display shows “CHANNEL X TR-
ASMIT” (where X is channel 1,2 or 3) but your device
does not activate, the device may be equipped with a
“rolling code” system. Continue with the following steps
five through seven to complete the programming of a
rolling code equipped device (most commonly a garage
door opener manufactured after 1995). The assistance of
a second person may make the following programming
steps quicker and easier.
5.Programming a Rolling Code System
At the garage door opener receiver (motor-head unit) in
the garage, locate thelearnorsmartbutton. This can
usually be found where the hanging antenna wire is
attached to the motor-head unit.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 163
3

6. Firmly press and release thelearnorsmartbutton.
(The name and color of the button may vary by manu-
facturer.)
NOTE:There are 30 seconds in which to initiate step
eight.
7. Return to the vehicle and firmlypress, hold for two
seconds and releasethe programmed HomeLink button.
Repeat thepress/hold/releasesequence a second time,
and, depending on the brand of the garage door opener
(or other rolling code equipped device), repeat this
sequence a third time to complete the programming.
HomeLink should now activate your rolling code
equipped device.
NOTE:To program the remaining two HomeLink but-
tons, begin withProgrammingstep two. Do not repeat
step one. For questions or comments, please contact
HomeLink atwww.homelink.com or 1-800-355-3515.Canadian Programming/Gate Programming
Canadian radio-frequency laws require transmitter sig-
nals totime-out(or quit) after several seconds of
transmission which may not be long enough for
HomeLink to pick up the signal during programming.
Similar to this Canadian law, some U.S. gate operators are
designed totime-outin the same manner.
If you live in Canada or you are having difficulties
programming a gate operator by using theProgram-
mingprocedures (regardless of where you live),replace
Programming HomeLinkstep 3with the following:
3. Continue to press and hold the HomeLink button
while youpress and release every two seconds(cycle)
your hand-held transmitter until the frequency signal has
successfully been accepted by HomeLink. (The EVIC will
display “CHANNEL X TRAINING” and then “CHAN-
NEL X TRAINED”.) Proceed withProgrammingstep
four to complete.
164 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

NOTE:If programming a garage door opener or gate
operator, it is advised to unplug the device during the
cyclingprocess to prevent possible overheating.
Using HomeLink
To operate, simply press and release the programmed
HomeLink button. Activation will now occur for the
trained device (i.e. garage door opener, gate operator,
security system, entry door lock, home/office lighting,
etc.). For convenience, the hand-held transmitter of the
device may also be used at any time. In the event that
there are still programming difficulties or questions, con-
tact HomeLink at:www.homelink.com or 1-800-355-3515
.
Erasing HomeLink Buttons
To erase programming from the three buttons (individual
buttons cannot be erased but can bereprogrammed-
note below), follow the step noted:
•Press and hold the two outer HomeLink buttons, and
the EVIC will display “CLEARING CHANNELS”, donot release the buttons until “CHANNELS
CLEARED” is displayed on the EVIC (after approxi-
mately 20 seconds). Release both buttons. Do not hold
for longer that 30 seconds. HomeLink is now in the
train (or learning) mode and can be programmed at
any time beginning withProgramming- step 2.
Reprogramming a Single HomeLink Button
To program a device to HomeLink using a HomeLink
button previously trained, follow these steps:
1. Press and hold the desired HomeLink button.DO
NOTrelease the button.
2. The EVIC will display “CHANNEL X TRANSMIT” for
20 seconds and then change to “CHANNEL X TRAIN-
ING”. Without releasing the HomeLink button, proceed
withProgrammingstep 2
For questions or comments, contact HomeLink at:
www.homelink.com or 1-800-355-3515.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 165
3

Security
Garage Door Opener Operation with Security
Alarm (if equipped)
If your vehicle is equipped with the Security Alarm
feature, the operation of the HomeLink feature will be
purposely inhibited if the Security Alarm isArmed.
This prevents HomeLink operation due to un-authorized
vehicle entry. HomeLink operation will be re-stored
when the Security Alarm has beenDisarmed(pressing
the unlock button on the remote keyless entry key fob).
If you sell your vehicle, be sure to erase the HomeLink
buttons, by following the “Erasing HomeLink Buttons”
instructions in this section..
To erase all previously trained frequencies, press and
hold the two outer HomeLink buttons, and the EVIC will
display “CLEARING CHANNELS”, do not release the
buttons until “CHANNELS CLEARED” is displayed on
the EVIC (after approximately 20 seconds). Release both
buttons. Do not hold for longer that 30 seconds.This device complies with part 15 of FCC rules and with
RSS-210 of Industry Canada. Operation is subject to the
following conditions:•This device may not cause harmful interference.
•This device must accept any interference that may be
received including interference that may cause undes-
ired operation.
NOTE:Changes or modifications not expressly ap-
proved by the party responsible for compliance could
void the user’s authority to operate the equipment.
In the event that you are still having programming
difficulties, questions, or comments, call toll free 1–800–
355–3515, or on the internet at www.homelink.com for
information or assistance.
HomeLinkis a trademark owned by Johnson Controls,
Inc.
166 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

POWER SUNROOF — IF EQUIPPED
The power sunroof control is located between the sun
visors on the overhead console.
Pressing theopenend of the rocker switch once moves
the panel to a comfort stop position short of full opening.
Pressing the switch a second time causes the panel to
continue moving rearward, up to the full-open position.
To close the panel, thecloseend of the switch must be
pressed and held.
Pressing the “vent” button from a fully closed position,
raises the trailing edge of the panel for ventilation. When
the panel is venting, pressing the “close” end or the
rocker switch returns it to the closed position. Both
opening and closing operations in the vent mode occur
only while the switch is held.NOTE:The sunroof will continue to operate for ten
minutes after the ignition is turned OFF or until the
driver door is opened. This feature may be disabled by
your authorized dealer.
Express Open Feature
During the Express Open operation, any movement of
the switch will stop the sunroof and it will remain in a
partial open position. Again, momentarily pressing the
switch rearward will activate the Express Open Feature.
To close the sunroof, hold the switch in the forward
position. Again, any release of the switch will stop the
movement and the sunroof will remain in a partial open
condition until the switch is pushed forward again. To
close fully, hold the switch in the forward position until
the glass movement has stopped.
The sunshade can be opened manually. It will also open
as the sunroof opens. The sunshade cannot be closed if
the sunroof is open.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 167
3

WARNING!
Never leave children alone in a vehicle. Leaving
children in a vehicle unattended is dangerous for a
number of reasons. A child or others could be
seriously or fatally injured. Don’t leave the keys in
the ignition. A child could operate power windows,
other controls, or move the vehicle.
WARNING!
In an accident, there is a greater risk of being thrown
from a vehicle with an open sunroof. You could also
be seriously injured or killed. Always fasten your
seat belt properly and make sure all passengers are
properly secured too.
Do not allow small children to operate the sunroof.
Never allow fingers or other body parts, or any
object to project through the sunroof opening. Injury
may result.
Wind Buffeting
Wind buffeting can be described as the perception of
pressure on the ears or a helicopter type sound in the
ears. Your vehicle may exhibit wind buffeting with the
windows down, or the sunroof (if equipped) in certain
open or partially open positions. This is a normal occur-
rence and can be minimized. If the buffeting occurs with
168 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

the rear windows open, open the front and rear windows
together to minimize the buffeting. If the buffeting occurs
with the sunroof open, adjust the sunroof opening to
minimize the buffeting or open any window.
Sunroof Maintenance
Use only a nonabrasive cleaner and a soft cloth to clean
the glass panel.
ELECTRICAL POWER OUTLETS
This vehicle has three auxiliary power outlets that can
provide up to 20 Amps of current for accessories de-
signed for use with the standard power outlet adapters.
The outlet located in the lower portion of the instrument
panel has a snap on plastic cap so that it can be covered
when not in use. As a safety precaution, the outlet in the
instrument panel only operates with the ignition switch
ON. When the optional Cigar Lighter heating element isused, it heats when pushed in and pops out automati-
cally when ready for use.To preserve the heating
element, do not hold the lighter in the heating position.
There are two additional 12 V/(20 total Amps for both
outlets) power outlets, one located in the storage bin of
the center console and another located in the right rear
cargo area. These outlets can be reconfigured by the
customer to operate only when the ignition is ON
(switched battery fed) or with the ignition ON or OFF
(battery fed) to allow for cellular telephone charging and
or operation while the ignition is off.
NOTE:All accessories connected to these outlets should
be removed or turned OFF when the vehicle is not in use
to protect the battery against discharge (unless the cus-
tomer has reconfigured the fuse block to switched battery
feed).
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 169
3

115V Inverter Outlet – If Equipped
This vehicle may also be equipped with a 115 Volt (150
Watts Maximum) outlet on the rear of the front center
console. These outlets can power cell phones, electronics
and other low power devices. This plug is controlled by
a switch located in left lower instrument panel.NOTE:Due to build in overload protection the inverter
will shut down if the power rating is exceeded.
WARNING!
To Avoid Serious Injury or Death:
•Donotusea3—Prong Adaptor.
•Do not insert any objects into the receptacles.
•Do not touch with wet hands.
•Close the lid when not in use.
•If this outlet is mishandled it may cause an
electric shock and failure.
115 V Inverter Switch
170 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
