CHRYSLER ASPEN 2007 2.G Owners Manual

INSTRUMENT PANEL AND CONTROLS
CONTENTS
Instruments And Controls.................185
Instrument Cluster......................186
Instrument Cluster Description.............187
Electronic Digital Clock..................197
▫Clock Setting Procedure.................197
Setting The Analog Clock.................198
Radio General Information................198
▫Radio Broadcast Signals.................198
▫Two Types Of Signals..................198▫Electrical Disturbances..................199
▫AM Reception.......................199
▫FM Reception........................199
Sales Code REF — AM/FM/CD (Single Disc)
Radio With Optional Satellite Radio And Hands
Free Phone Capability...................200
▫Operating Instructions - Radio Mode.......200
▫Operation Instructions - CD Mode.........204
▫Operation Instructions - Auxiliary Mode.....2064

▫Operating Instructions - Hands Free Phone —
If Equipped.........................207
▫Operating Instructions - Satellite Radio —
If Equipped.........................207
Sales Code RAQ – AM/FM/CD (6-Disc) Radio
With Optional Satellite Radio, Hands Free Phone,
And Vehicle Entertainment Systems (VES)
Capabilities...........................208
▫Operating Instructions - Radio Mode.......208
▫Operation Instructions - (CD Mode For CD
Audio Play).........................213
▫Load/Eject Button (CD Mode For CD
Audio Play).........................215
▫Notes On Playing MP3 Files.............217
▫Operation Instructions - (CD Mode For MP3
Audio Play).........................219▫Load/Eject Button (CD Mode For MP3 Play) . . 219
Sales Code REC — AM/FM/CD (6–Disc) Radio
With Navigation System..................222
▫Operating Instructions — Satellite Radio
(If Equipped)........................222
▫REC Setting The Clock.................222
▫Audio Clock Display...................225
Video Entertainment System (Sales Code XRV) —
If Equipped...........................226
Satellite Radio — If Equipped..............226
▫System Activation.....................226
▫Electronic Serial Number/Sirius Identification
Number (ESN/SID)....................227
▫Selecting Satellite Mode In REF, RAQ, And RAK
Radios.............................228
182 INSTRUMENT PANEL AND CONTROLS

▫Selecting a Channel....................228
▫Storing And Selecting Pre-Set Channels......229
▫Using The PTY (Program Type) Button
(If Equipped)........................229
▫PTY ButtonScan.....................229
▫PTY ButtonSeek.....................229
▫Satellite Antenna......................229
▫Reception Quality.....................230
Remote Sound System Controls — If Equipped . . 230
▫Radio Operation......................231
▫CD Player..........................231
Compact Disc Maintenance................232
Radio Operation And Cellular Phones........232Climate Controls.......................233
▫Manual Control......................233
▫Air Conditioning Operation..............233
▫Front Blower Control...................234
▫Front Mode Control...................234
▫Rear Temperature Control — If Equipped....237
▫Rear Window Defrosting And Rear Window
Washer/Wiper.......................237
▫Automatic Temperature Control (ATC) —
If Equipped.........................238
▫Automatic Control....................238
▫Level Of Automatic Control..............239
▫Manual Control (ATC)..................240
▫Rear Zone Climate Control — If Equipped . . . 244
INSTRUMENT PANEL AND CONTROLS 183
4

▫Rear Rotary Temperature Control..........245
▫Front Unit To Rear Unit Chart............246
▫Operating Tips.......................246
▫Operating Tips Chart...................248Rear Window Features...................249
▫Rear Window Wiper/Washer.............249
▫Rear Window Defrosting................250
184 INSTRUMENT PANEL AND CONTROLS

INSTRUMENTS AND CONTROLS
INSTRUMENT PANEL AND CONTROLS 185
4

Instrument Cluster
186 INSTRUMENT PANEL AND CONTROLS

INSTRUMENT CLUSTER DESCRIPTION
1. Fuel Gage
The fuel gauge shows level of fuel in tank when
ignition switch is in the ON position.
2. Temperature Gage
The temperature gage indicates engine coolant
temperature. Any reading within the normal
range indicates that the cooling system is operat-
ing satisfactorily. The gage needle in V6 and V8 engines
will likely indicate a high temperature when driving in
hot weather, up mountain grades, in heavy traffic, or
when towing a trailer. If the needle rises to the “H” mark,
stop the vehicle, shift into N (Neutral) increase engine
speed for 2-3 minutes. If the temperature reading does
not return to normal, seek authorized service immedi-
ately.
CAUTION!
Do not leave your vehicle unattended with the
engine running as you would not be able to react to
the temperature indicator if the engine overheats.
The gage pointer will remain near its last reading when
the engine is turned off. It will return to a true reading
when the engine is restarted.
3. Turn Signal Indicators
When a turn signal is activated, a right-pointing or
left-pointing arrow lights up and flashes to indicate the
direction of the turn. These indicators also indicate
proper operation of the front and rear turn signal lights.
If either indicator flashes at a faster rate than normal,
check for a defective bulb. If either indicator fails to light
up when the lever is moved, check for a defective fuse or
turn signal LED. A single chime is activated when the
INSTRUMENT PANEL AND CONTROLS 187
4

left/right turn signal is left on with the engine RPM
vehicle speed greater than 15 mph (24 km/h) for more
than one mile.
4. Low Fuel Warning Light
This indicator lights when the fuel gauge reads 1/8
of a tank or less.
5. High Beam Indicator
Indicates that headlights are on high beam.
6. Seat Belt Reminder Light
This light comes on for several seconds after the
ignition is turned ON as a reminder to “buckle
up.” This light will remain on as long as the seat
belt remains unbuckled. If this light flashes, it indicates a
fault in the airbag system. Have the system checked by
an authorized dealer.7. Fog Light Indicator
This light shows when the fog lights are ON.
8. Coolant Temperature Light
This light warns of an overheated engine condi-
tion. For a bulb check, this light will come on
momentarily when the ignition is turned On. If the
light turns on while driving, stop the vehicle, shift into N
(Neutral) and increase the engine speed for 2 to 3
minutes. If the temperature reading does not return to
normal, seek authorized service immediately.
188 INSTRUMENT PANEL AND CONTROLS

CAUTION!
Driving with a hot engine cooling system could
damage your vehicle. If the temperature light is on,
safely pull over and stop the vehicle. Idle the vehicle
in neutral with the air conditioner turned off until
the light turns off. If the if the light remains on, turn
the engine off immediately, and call for service.
WARNING!
A hot engine cooling system is dangerous. You or
others could be badly burned by steam or boiling
coolant. You may want to call a service center if your
vehicle overheats. If you decide to look under the
hood yourself, see Section 7 of this manual. Follow
the warnings under the Cooling System Pressure
Cap paragraph.
9. Speedometer
Shows the vehicles speed.
10. Voltage Light
This light monitors the electrical system voltage.
The light should turn on momentarily as the
engine is started. If the light stays on or turns on while
driving, it indicates a problem with the charging system.
Immediate service should be obtained.
INSTRUMENT PANEL AND CONTROLS 189
4

11. Security Light
This light will flash rapidly for approximately 15 seconds
when the vehicle theft alarm is arming. The light will
flash at a slower speed continuously after the alarm is set.
The security light will also come on for about three
seconds when the ignition is first turned on.
12. ABS Warning Light
This light monitors the Anti-Lock Brake System
which is described elsewhere in this manual.
This light will come on when the ignition key is
turned to the ON position and may stay on for
approximately 3 seconds. If this light remains on or
comes on during driving, it indicates that the Anti-Lock
portion of the brake system is not functioning and that
service is required. See your authorized dealer immedi-
ately. With the ABS malfunctioning, the BAS and ESP are
also switched off. Both malfunction indicator lights illu-
minate with the engine running. If the charging voltage
falls below 10 volts, the malfunction indicator lightilluminates and the ABS is switched off. When the
voltage is above this value again, the malfunction indi-
cator light should go out and the ABS is operational. If
the malfunction indicator light stays illuminated, have
the system checked at your authorized dealer as soon as
possible.
13. Engine Oil Pressure Indicator Light
This light indicates that the engine oil pressure has
become too low. For a bulb check, this light will
come on momentarily when the ignition is turned On. If
the light turns on while driving, stop the vehicle and shut
off the engine as soon as possible. Immediate service
should be obtained.
14. Tachometer
This gauge measures engine revolutions-per-minute
(rpm x 1000).
190 INSTRUMENT PANEL AND CONTROLS
