CHRYSLER ASPEN 2007 2.G Owners Manual

Electrical Outlet Use With Engine OFF (Battery
Fed Configuration)
CAUTION!
•Many accessories that can be plugged in draw power
from the vehicle’s battery, even when not in use (i.e.
cellular phones, etc.). Eventually, if plugged in long
enough, the vehicle’s battery will discharge suffi-
ciently to degrade battery life and/or prevent engine
starting.
•Accessories that draw higher power (i.e. coolers,
vacuum cleaners, lights, etc.), will discharge the bat-
tery even more quickly. Only use these intermittently
and with greater caution.
•After the use of high power draw accessories, or long
periods of the vehicle not being started (with accesso-
ries still plugged in), the vehicle must be driven a
sufficient length of time to allow the generator to
recharge the vehicle’s battery.
115V Inverter Plug
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 171
3

Reconfiguring Power Outlets
To reconfigure the outlets, be sure the ignition is OFF
before removing the fuse. The reconfigurable fuse loca-
tion is a special design that allows the fuse to be installed
in two different ways. If the fuse is located in theUpper
or Top Positionthe outlets will work at all times. If the
fuse is located in theLower or Bottom Positionthe
power outlets will only work when the ignition is ON.
NOTE:The fuse block is located in the left side kick
panel behind a removable cover near the park brake
pedal. A fuse puller is attached to the inside surface of the
fuse panel cover to aid in removing fuses, if necessary.
FLOOR CONSOLE
Front Floor Console Features
The Floor Console between the driver’s and front pas-
senger’s seat, has the following features:
•Miscellaneous storage compartments
•Flexible cup holder inserts
172 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

•Portable phone storage bin
•Portable phone cord routing between lid and base on
forward edge
•12 Volt reconfigurable power outlet inside storage
compartment
•Side open armrest lid
•Tissue holder & pen holder
•Coin slots
•Removable CD bin
The coin slots are located under the instrument panel
center stack.
Cup Holders
Your vehicle has 8 cupholders. four are located in the
center console, two are located in the second row armrest
or rear floor console (if equipped), and two are located in
the left hand quarter panel for third row occupants. Thecupholders and storage bin located in the front of the
center console can be accessed by pressing on the access
doors.
NOTE:In colder temperatures you may experience a
slight delay on console doors opening, the console door
speed will come back to normal after 1–2 cycles.
Cup Holder Doors
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 173
3

The front storage bin in the center console is equipped
with a removable bin mat. This mat can be removed by
pulling on the tab located on the front edge of the bin
mat. Removing this mat will allow you to retrieve any
lost item that are between the bin doors.Power Outlet and Portable Phone Storage
The console is equipped with a power outlet, portable
phone storage bin, and phone cord routing. The phone
storage bin can be used when easy access to the phone is
needed. Also, the power outlet inside the console com-
partment can be used to power up the phone while it is
Front Center ConsoleBin Mat Tab
174 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

being stored in the bin. To use, plug in the portable power
recharge cord and place the cord along the opening
under the forward portion of the storage bin. Close the
console armrest lid and plug the power cord into the
phone while resting the phone in the bin. The power
outlet may be used for any portable item with a standard
12 volt power outlet adaptor, requiring up to 20 Amps of
current.
Rear Floor Console Features – If Equipped
The Rear Floor Console located between the second row
bucket seat, has the following features:
•Miscellaneous storage compartments
•Cup holders
•Portable phone cord routing on either side, between
lid and base
•12 Volt power outlet inside storage compartment
•Tissue holder & pen holder
•Second row heated seat switches.
•Four slots for DVD’s
To access the storage bin, lift up on the console door latch.
Rear Floor Console
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 175
3

FACTORY INSTALLED ROOF LUGGAGE RACK
The load carried on the roof when equipped with a
luggage rack must not exceed 68 kg (150 lbs.), and should
be uniformly distributed over the cargo area.
The side rails between the stantions should be used to tie
down cargo. Check the straps frequently to be sure that
the load remains securely attached.NOTE:Crossbars are offered by Moparaccessories.
External racks do not increase the total load carrying
capacity of the vehicle. Be sure that the total occupant
and luggage load inside the vehicle, plus the load on the
luggage rack, do not exceed the maximum vehicle load
capacity.
176 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

CAUTION!
To avoid damage to the roof rack and vehicle, do not
exceed the maximum roof rack load capacity. Always
distribute heavy loads as evenly as possible and
secure the load appropriately.
Long loads which extend over the windshield, such
as wood panels or surfboards, should be secured to
both the front and rear of the vehicle.
Place a blanket or other protection between the
surface of the roof and the load.
Travel at reduced speeds and turn corners carefully
when carrying large or heavy loads on the roof rack.
Wind forces, due to natural causes or nearby truck
traffic, can add sudden upward loads. This is espe-
cially true on large flat loads and may result in
damage to the cargo or your vehicle.
WARNING!
Cargo must be securely tied before driving your
vehicle. Improperly secured loads can fly off the
vehicle, particularly at high speeds, resulting in
personal injury or property damage. Follow the roof
rack Cautions when carrying cargo on your roof rack.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 177
3

CARGO MANAGEMENT SYSTEM—IF EQUIPPED
The cargo management system consists of a removable
cargo liner and removable cargo organizer.To open the side cover, pull on the cover latch, and attach
the cord to the upper cargo net hook.
To open the main cover, pull up on the latch, and attach
the cord to the rear seat head restraint post.
1 — Side Cover Latch
2 — Main Cover Latch
3 — Cargo Divider Handles
178 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

To open the Cargo divider, lift up on the cargo divider
handles, raising the doors to the full open position. Raise
the side panels until they engage into the doors.To remove the cargo management system from the ve-
hicle, pull the right hand side of the organizer towards
you so that the right pin slides out of the slot in the
vehicle. Push the organizer to the right and lift out of the
vehicle.
1 — Cargo Divider Door
2 — Cargo Divider Side PanelUNDERSTANDING THE FEATURES OF YOUR VEHICLE 179
3
