8W-40 INSTRUMENT CLUSTER
Component Page
Airbag Control Module................ 8W-40-2
Body Control Module . . . 8W-40-2, 3, 4, 5, 6, 7, 8, 9,
10, 12, 13
Brake Fluid Level Switch............. 8W-40-10
Clockspring........................ 8W-40-11
Controller Antilock Brake.......... 8W-40-11, 15
Engine Control Module.......... 8W-40-9, 11, 15
Engine Coolant Temp Sensor....... 8W-40-7, 8, 9
Engine Oil Pressure Sensor........... 8W-40-15
Engine Oil Pressure Switch........... 8W-40-15
Front Control Module....... 8W-40-10, 11, 14, 15
Fuel Pump Module................... 8W-40-2
Fuse 24............................ 8W-40-2
G200..................... 8W-40-2, 12, 13, 14
G300............................. 8W-40-10
Instrument Cluster...... 8W-40-2, 3, 4, 5, 6, 7, 8,
9, 10, 12, 13, 14
Integrated Power Module........ 8W-40-2, 7, 8, 9,
10, 11, 14, 15
Left Front Door Ajar Switch............ 8W-40-3
Left Front Door Lock Motor/Ajar Switch . . 8W-40-3
Left Sliding Door Control Module........ 8W-40-4Component Page
Left Sliding Door Latch Sensing Switch . . . 8W-40-4
Left Sliding Door Lock Motor/Ajar
Switch.......................... 8W-40-4
Left Speed Control Switch............ 8W-40-11
Liftgate Ajar Switch.................. 8W-40-3
Liftgate Cinch/Release Motor........... 8W-40-3
Message Center.................. 8W-40-6, 14
Multi- Function Switch................ 8W-40-6
Parking Brake Switch............. 8W-40-12, 13
Powertrain Control Module..... 8W-40-7, 8, 11, 15
Right Front Door Ajar Switch........... 8W-40-3
Right Front Door Lock Motor/Ajar
Switch.......................... 8W-40-3
Right Sliding Door Control Module...... 8W-40-5
Right Sliding Door Latch Sensing Switch . . 8W-40-5
Right Sliding Door Lock Motor/Ajar
Switch.......................... 8W-40-5
Traction Control Switch........... 8W-40-7, 8, 9
Transmission Control Module........... 8W-40-8
Vehicle Speed Sensor............... 8W-40-7, 9
Washer Fluid Level Switch............ 8W-40-10
RS8W-40 INSTRUMENT CLUSTER8W-40-1
