CHRYSLER CONCORDE 2004 2.G Owners Manual

UNDERSTANDING YOUR INSTRUMENT PANEL
CONTENTS
Instruments And Controls................105
Instruments And Controls
(Concorde Limited Only)
................106
Instrument Cluster.....................107
Instrument Cluster (Concorde Limited Only). . 108
Instrument Cluster Description............109
Setting The Analog Clock—If Equipped.....113
Electronic Digital Clock.................113
▫Clock Setting Procedure.................114
Sales Code RAZ—AM/ FM Stereo Radio With
Cassette Tape Player And CD Player — If
Equipped
............................114
▫Operating Instructions — Radio...........114▫Power Switch, Volume Control............114
▫Seek Button (Radio Mode)...............115
▫Tuning.............................115
▫PTY (Program Type) Button..............115
▫Balance............................116
▫Fade..............................116
▫Tone Control........................116
▫AM/FM Selection.....................117
▫Scan Button.........................117
▫To Set The Radio Push-Button Memory......117
▫To Change From Clock To Radio Mode......117
▫Operating Instructions — Tape Player.......117
4

▫Seek Button.........................118
▫Fast Forward (FF).....................118
▫Rewind (RW)........................118
▫Tape Eject...........................118
▫Scan Button.........................118
▫Changing Tape Direction................118
▫Metal Tape Selection...................118
▫Pinch Roller Release...................118
▫Noise Reduction......................119
▫Operating Instructions — CD Player........119
▫Inserting The Compact Disc..............119
▫Seek Button.........................119
▫EJT CD (Eject) Button..................120
▫FF/Tune/RW Button...................120
▫Program Button 4 (Random Play)..........120
▫Mode..............................120▫Tape CD Button......................121
▫Time Button.........................121
▫Scan Button.........................121
Sales Code RBB—AM/FM Stereo Radio With
Cassette Tape Player And CD Changer
Capability
...........................121
▫Operating Instructions..................121
▫Power Button........................122
▫Electronic Volume Control...............122
▫Seek..............................122
▫Tune ..............................122
▫To Set The Push-Button Memory..........122
▫Balance............................123
▫Fade..............................123
▫Bass And Treble Tone Control............123
▫AM/FM Selection.....................123
102 UNDERSTANDING YOUR INSTRUMENT PANEL

▫Mode Button........................123
▫Cassette Player Features................123
▫CD Changer Control Capability — If
Equipped...........................124
▫Radio Display Messages................126
Sales Code RBK—AM/ FM Stereo Radio With
CD Player And CD Changer Controls
.......126
▫Radio Operation......................126
▫CD Player Operation...................128
▫CD Changer Operation — If Equipped......130
6 Disc CD Changer — If Equipped.........131
▫Loading The CD Changer...............131
▫Playing Discs........................131
▫Seek Button.........................132
▫FF/Tune/RW........................132
▫Mode Button........................132▫Program Button 1.....................132
▫Program Button 4 (Random Play)..........132
▫Program Button 5.....................132
▫Time Button.........................132
▫Changing Modes......................132
▫Removing Discs From The CD Changer.....133
▫CD Changer Operation With The Changer
Off ...............................133
Remote Sound System Controls — If
Equipped
............................133
▫Radio Operation......................134
▫Tape Player.........................134
▫CD Player — Single Disc In Radio.........134
▫CD Player — 6 Disc CD Changer..........134
Cassette Tape And Player Maintenance......135
Compact Disc Maintenance...............136
UNDERSTANDING YOUR INSTRUMENT PANEL 103
4

Radio Operation And Cellular Phones.......136
Climate Controls......................137
▫Manual Air Conditioning/Heater Operation . . 137▫Automatic Temperature Control (ATC) — If
Equipped...........................140
104 UNDERSTANDING YOUR INSTRUMENT PANEL

INSTRUMENTS AND CONTROLS
UNDERSTANDING YOUR INSTRUMENT PANEL 105
4

INSTRUMENTS AND CONTROLS (Concorde Limited Only)
106 UNDERSTANDING YOUR INSTRUMENT PANEL

INSTRUMENT CLUSTER
UNDERSTANDING YOUR INSTRUMENT PANEL 107
4

INSTRUMENT CLUSTER (CONCORDE LIMITED ONLY)
108 UNDERSTANDING YOUR INSTRUMENT PANEL

INSTRUMENT CLUSTER DESCRIPTION
1. Fuel Gauge
When the ignition is in the ON position, the
pointer will show the level of fuel remaining in
the tank.
2. Low Fuel Warning Light
When the fuel level drops to about 2 gallons (8
liters), the Low Fuel symbol will light and re-
main lit until fuel is added. A warning chime will
sound when the light comes on.
3. Low Oil Pressure Light
This light indicates low engine oil pressure. The
light should come on briefly as a bulb check
when the engine is first started. If the light stays on or
comes on while driving, stop the vehicle and shut off
the engine. DO NOT operate the vehicle until the
cause is corrected.This light does not show how
much oil is in the engine.The engine oil level must be
checked under the hood.4. TRAC ON/OFF Lights
The Traction Control On light (TRAC ON) will come on
momentarily as a bulb check when the ignition switch is
first turned ON. If the light does not come on, have the
bulb replaced.
The TRAC ON light also will come on when the system
is controlling traction.
The Traction Control Off light (TRAC OFF) will come on
momentarily as a bulb check when the ignition switch is
first turned ON. If the TRAC OFF light does not come on,
have the bulb checked.
The TRAC OFF light will also come on when the Traction
Control switch has been used to turn the system off.
5. Trunk Ajar Light
This light indicates that the trunk is not latched
6. Tachometer
Measures engine revolutions-per-minute (RPM). The red
numbers at the end on the scale show the maximum
permissible RPM’s. Ease off on the accelerator before
reaching the red area.
UNDERSTANDING YOUR INSTRUMENT PANEL 109
4

7. Turn Signal Indicators
The arrow will flash in unison with the exterior
turn signal, when using the turn signal lever.
8. High Beam Indicator
This light shows that the headlights are on high
beam. Pull the turn signal lever towards the
steering wheel to switch the headlights from high or
low beam.
9. Seat Belt Reminder Light
The light will come on after the ignition is
turned on. The light will remain lit until the
seatbelt is fastened.
10. Door Ajar Light
This light shows that a door is not completely
closed. A warning chime will sound if the vehicle
is moving with a door partially closed.
11. Speedometer
Shows vehicle speed in miles-per-hour or kilometers-per-
hour.
12. Low Washer Fluid Light
This symbol will light whenever the fluid reser-
voir is less than 1/4 filled. Adding washer fluid
will cause the light to go out the next time the
ignition is cycled. A warning chime will sound when
the light comes on.
13. Cruise (Speed Control) Light
This light shows that the Speed Control System is ON.
14. Engine Coolant Temperature Light
This light warns of an overheated engine cool-
ant condition. A warning chime will sound
when the light comes on.
15. Engine Coolant Temperature Gauge
The temperature gauge shows engine coolant
temperature. Any reading within the 5 gauge
marks between Hot and Cold shows that the
cooling system is operating properly. The gauge
pointer may show a higher than normal temperature
when driving in hot weather, up mountain grades, in
heavy stop and go traffic, or when towing a trailer.
