1. This device may not cause harmful interference.
2. This device must accept any interference that may be
received including interference that may cause undesired
operation.
NOTE:Changes or modifications not expressly ap-
proved by the party responsible for compliance could
void the user’s authority to operate the equipment.
HomeLinkis a trademark owned by Johnson Controls,
Inc.
GARAGE DOOR OPENER — IF EQUIPPED
Equipped in vehicles that have the optional Electronic
Vehicle Information Center (EVIC)
The HomeLinkUniversal Transceiver replaces up to
three remote controls (hand-held transmitters) that oper-
ate devices such as garage door openers, motorized
gates, or home lighting. It triggers these devices at the
push of a button, located on the overhead console. The
universal transceiver operates off your vehicle’s battery
and charging system; no batteries are needed.For additional information on HomeLink, call
1–800–355–3515, or on the internet at www.homelink.com.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 81
3

WARNING!
A moving garage door can cause injury to people and
pets in the path of the door. People or pets could be
seriously or fatally injured. Use this transceiver with
a garage door opener that has a “stop and reverse”
feature as required by federal safety standards. This
includes most garage door opener models manufac-
tured after 1982. Contact HomeLinkat
1–800–355–3515 for safety information or assistance
or on the internet at www.homelink.com.
Programming The Universal Transceiver
For best results, install a new battery in the hand held
transmitter before programming. If your garage door
opener (located in the garage) is equipped with an
antenna, make sure that the antenna is hanging straight
down.
1. Turn off the engine.
WARNING!
Vehicle exhaust contains carbon monoxide, a danger-
ous gas. Do not run the vehicle’s engine while
programming the universal transceiver. Exhaust gas
can cause serious injury or death.
WARNING!
Your motorized door or gate will open and close
while you are programming the universal trans-
ceiver. Do not program the universal transceiver if
people or pets are in the path of the door or gate. A
moving door or gate can cause serious injury or
death to people and pets or damage to objects.
82 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

2. Erase the factory test codes by pressing and holding
channels button one and three, of the universal trans-
ceiver, until CLEARED CHANNELS displays (about 20
seconds). Release the buttons.
NOTE:Step 2 does not have to be followed to program
additional hand held transmitters.3. Choose one of the three universal transceiver buttons
to program. Place the hand-held controller at the lower
left corner of the display and approximately 1 to 3 inches
away from the surface of the universal transceiver while
keeping the display in view.
4. Using both hands, simultaneously press and hold the
button on the hand-held transmitter and the button you
would like to program on the universal transceiver. The
display on the universal transmitter will show TRAIN-
ING. When TRAINED appears in the display, release
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 83
3

both buttons. Your universal transceiver is now pro-
grammed. After a button has been trained, TRANSMIT
will appear in the display when the button is pressed.
NOTE:Some entry gates and garage door openers may
require you to replace step 4 with the procedures listed
under Canadian Programming.
5. To program the other buttons, repeat steps 3 and 4. Be
sure to keep your hand-held transmitters in case you
need to reprogram the universal transceiver.
NOTE:If you do not successfully program the
Universal Transceiver to learn the signal of the hand-
held transmitter, refer to the Rolling Code Paragraph, or
call toll-free for customer assistance at 1-800-355-3515 or
on the internet at www.homelink.com.
“Rolling Code” Programming
NOTE:
If your hand held transmitter appears to pro-
gram the universal transceiver, but your garage door or
other device does not operate, and your device was
manufactured after 1996, your garage door opener or
other device may have a “Rolling Code” system.
On garage door openers with the “Rolling Code” feature,
the transmitter code changes after each use to prevent the
copying of your code.
To check if your device is protected by a “Rolling Code”
system:
•Check the owner’s manual for the device for mention
of “Rolling Codes”.
•Press and hold the programmed button on the univer-
sal transceiver. If the universal transceiver indicator
84 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

light flashes rapidly and then stays on after 2 seconds,
the device has the “Rolling Code” feature.
To train a garage door opener (or other rolling code
equipped devices) with the rolling code feature, follow
these instructionsaftercompleting theProgramming
portion of this text:
NOTE:The assistance of a second person may make the
following programming procedure quicker and easier.
1. Locate the programming button on the garage door
opener motor head unit. The exact location and color of
the button may vary by garage door opener brand. If
there is difficulty locating the programming button,
reference the garage door opener owner’s manual or
contact HomeLinkat 1-800-355-3515 or on the internet
at www.homelink.com.
2. Press and hold the training button on the garage door
opener head unit This will activate the “training” light.
NOTE:After completing step 2, you have 30 seconds to
start step 3.3. Return to the universal transceiver in the vehicle and
firmly press and release the garage door button. Press
and release the button a second time to complete the
training process. Some garage door openers may require
you to do this procedure a third time to complete the
training.
Your garage door opener should now recognize your
universal transceiver. The remaining two buttons may
now be programmed if this has not previously been
done. Refer to the Programming instructions. You may
use either your universal transceiver or your original
hand-held transmitter to open you garage door.
Canadian Programming/Gate Programming
Canadian frequency laws, and the technology of some
entry gates, require you to press and release the hand
held transmitter button every two seconds during pro-
gramming
NOTE:When programming such a garage door opener
or gate, unplug the device to prevent possible damage to
the garage door or gate motor.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 85
3

Continue to press and hold the Universal Transceiver
button while you press and release the hand held trans-
mitter button until the frequency signal has been learned.
Release both buttons when TRAINED appears in the
display.
Operation
Press the desired universal transceiver button. The dis-
play shows that the appropriate channel signal is being
transmitted and the programmed device should operate.
For convenience, the hand-held transmitter of the device
may also be used at any time.
Reprogramming a Single Universal Transceiver
Button
1. Press and hold the desired universal transceiver but-
ton for about 20 seconds.
2. When TRAINING appears in the display, position the
hand-held transmitter one to three inches away from the
universal transceiver surface.
3. Press and hold the hand-held transmitter button.4. When TRAINED appears in the display, the previous
programming for the button has now been erased and a
new device has been programmed to the button. This
procedure will not affect any other programmed buttons.
Security
If you sell your vehicle, be sure to erase the frequencies.
To erase all of the previously programmed frequencies,
hold down buttons one and three until CLEARED
CHANNELS appears in the display.
NOTE:Individual channels can not be erased. You
must erase all three channels.
This device complies with part 15 of FCC rules and with
RS-210 of Industry Canada. Operation is subject to the
two following conditions: (1) This device may not cause
harmful interference and (2) this device must accept any
interference that may be received including interference
that may cause undesired operation.
NOTE:Changes or modifications not expressly ap-
proved by the party responsible for compliance could
void the user’s authority to operate the equipment.
86 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

HomeLinkis a registered trademark owned by Johnson
Controls, Inc.
POWER SUN ROOF — IF EQUIPPED
The sun roof controls are located on the overhead console.
To Open the sunroof from the Closed position, press and
release the OPEN button. The sunroof will open fully,
then stop automatically.
To Close the sunroof from an open or vent position, press
andholdthe CLOSE button. The sunroof will close fully
and stop automatically. Release the CLOSE button to stop
sunroof travel at any point.If the sun roof is vented and you wish to open it, press
and hold the OPEN button. If the sun roof is open and
you wish to vent it, press and hold the VENT button.
The sunshade can be opened manually. It will also open
as the sun roof opens. The sunshade cannot be closed if
the sun roof is open.
WARNING!
In an accident, there is a greater risk of being thrown
from a vehicle with an open sun roof. You could also
be seriously injured or killed. Always fasten your
seatbelt properly and make sure all passengers are
properly secured too.
Do not allow small children to operate the sun roof.
Never allow fingers or other body parts, or any
object to project through the sun roof opening.
Injury may result.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 87
3

Wind Buffeting
Wind buffeting can be described as the perception of
pressure on the ears or a helicopter type sound in the
ears. Your vehicle may exhibit wind buffeting with the
windows down, or the sunroof (if so equipped) in certain
open or partially open positions. This is a normal occur-
rence and can be minimized. If the buffeting occurs with
the rear windows open, open the front and rear windows
together to minimize the buffeting. If the buffeting occurs
with the sunroof open, adjust the sunroof opening to
minimize the buffeting.
Sun Roof Maintenance
Use only a non abrasive cleaner and a soft cloth to clean
the glass panel.
ELECTRONIC VEHICLE INFORMATION CENTER
(EVIC) — IF EQUIPPED
The vehicle information center, when the appropriate
conditions exist, displays the following WARNING mes-
sages and symbols. Each message is accompanied by a
series of beeps:
•TURN SIGNALS ON (with graphic)
•PERFORM SERVICE
•DOOR OPEN (one or more, with graphic)
88 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

•WASHER FLUID LOW (with graphic)
•MEMORY SEAT DISABLED VEHICLE (not in Park)
Customer Programmable Features
Press the MENU button until one of the display choices
following appears:
Language
When in this display you may select one of five lan-
guages for all display nomenclature, including the trip
computer functions. Press the STEP button while in this
display selects English, Francaise, Deutsch, Italiano, orEspanol. As you continue the displayed information will
be shown in the selected language.
US or Metric
Pressing the STEP button when in this display selects US
or Metric. The overhead console and instrument panel
displays will be in the selected units.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 89
3

Auto Door Locks
When this feature is selected, all doors lock automatically
when the speed of the vehicle reaches 15 mph (25 km/h).
Pressing the STEP button when in this display will select
“Yes” or “No.”
Auto Unlock On Exit (Available Only When the
AUTO DOOR LOCKS Feature is Turned On )
When this feature is selected all the vehicle’s doors will
unlock when the driver’s door is opened if the vehicle is
stopped and the transmission is in P (Park) or N (Neu-
tral) position. Pressing the STEP button when in this
display will select “Yes” or “No.”
Remote Unlock Driver’s Door 1st
When this feature is selected only the driver’s door will
unlock on the first press of the remote keyless entry
unlock button and require a second press to unlock the
remaining locked door. WhenREMOTE UNLOCK ALL
DOORSis selected all of the doors will unlock at the first
press of the remote keyless entry unlock button. Pressing
the STEP button when in this display will select DRIV-
ER’S DOOR 1ST or ALL DOORS.
Remote Linked To Memory (Available with
Memory Seat Only)
When this feature is selected the memory seat, mirror,
and radio settings will return to the memory set position
when the remote keyless entry “Unlock” button is
pressed. If this feature is not selected then the memory
seat, mirror, and radio settings can only return to the
memory set position using the door mounted switch.
Pressing the STEP button when in this display will select
“Yes” or “No.”
Sound Horn with Lock
When this feature is selected a short horn sound will
occur when the remote keyless entry “Lock” button is
pressed. This feature may be selected with or without the
flash lights on lock/unlock feature. Pressing the STEP
button when in this display will select “Yes” or “No.”
Flash Lights with Lock/Unlock
When this feature is selected, the front and rear turn
signals will flash when the doors are locked or unlocked
using the remote keyless entry transmitter. This feature
may be selected with or without the sound horn on lock
90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
