Lumbar Support
This feature allows you to increase or decrease the
amount of lumbar support. Turn the control level for-
ward to increase and rearward to decrease the desired
amount of lumbar support.
Heated Seats— If Equipped
The front driver’s and passenger seats are heated. The
control for the heater is located on the outboard side of
each seat. After turning on the ignition, you can choose
from High, Off, or Low heat settings. An indicator on the
switch shows which setting has been chosen.Press the switch once to select a heat setting (high or low)
and press the switch a second time to turn the heated seat
off.
NOTE:Once a heat setting is selected, heat will be felt
within 2 to 3 minutes.
Memory Feature
This feature allows the driver to recall one of two
pre-selected seat/outside mirror settings as well as radio
station preset buttons. The radio display will show which
memory position is being recalled.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 61
3

The memory feature switch is located on the outboard
side of the driver’s seat, next to the heated seat switch.
To Set The Memory Feature:
1. Use the seat and driver mirror switches to adjust the
seat and driver mirror to the desired positions. Program
the radio preset buttons to the desired stations.
2. Press and release the Set (S) button on the memory
seat switch, then press either button 1 or 2 within 5
seconds. The radio display will show which memory
position is being set.3. A second memory setting can be stored in the vehicle
memory. Begin with pressing 2 on the memory seat
switch for driver 2. Select a second seat/radio setting,
press the Set (S) button, then press button 2 within 5
seconds.
Each time the Set and a numbered button are pressed, the
old memory is erased, and a new one is stored.
NOTE:The vehicle must be in Park to activate the
Memory feature.
Programming the Remote Keyless Transmitter for
the Memory Feature
Your remote transmitters can be programmed to return
the driver’s seat, mirror, and radio presets to the saved
position when the Unlock button is pressed and released.
To program your transmitters, perform the following:
1. Insert the key into the ignition and turn the key to the
Run position.
2. Adjust the seat and side view mirror to the desired
position. Program the radio preset buttons to the desired
stations.
62 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

3. Press and release the Set (S) button on the memory
seat switch, then press and release button 1 or 2.
4. Press and release the Lock button on the transmitter.
5. Do not press any buttons for 10 seconds.
NOTE:Your transmitters may be unlinked to your
memory settings by pressing the Unlock button on the
transmitter in step 4 above. On vehicles equipped with an
EVIC (Electronic Vehicle Information Center), these func-
tions can be selected at the EVIC using the Customer
Programmable Features. Refer to EVIC-Customer Pro-
grammable Features for details. When newly purchased
(or replacement) transmitters are programmed into the
vehicle, the first transmitter trained will be associated
with memory setting 1, and the second transmitter
trained will be associated with memory setting 2. Addi-
tional transmitters will not be associated with a memory
setting.
Head Restraints
Head restraints can reduce the risk of whiplash injury in
the event of impact from the rear. Adjustable restraints
should be adjusted so that the upper edge is as high as
practical.
The head restraints have a locking button which must be
pushed in to lower the head restraint. The restraints may
be raised without pushing in the button.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 63
3

TO OPEN AND CLOSE THE HOOD
To open the hood, two latches must be released. First pull
up on the hood release lever located under the instru-
ment panel.
Then lift up on the catch located under the front edge of
the hood, near the center.To prevent possible damage, do not slam the hood to
close it. Use a firm downward push at the center frone
edge of the hood to ensure that both latches engage.
Never drive your vehicle unless the hood is fully closed,
with both latches engaged.
64 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

WARNING!
If the hood is not fully latched, it could fly up when
the vehicle is moving and block your forward vision.
You could have a collision. Be sure all hood latches
are fully latched before driving.
INTERIOR LIGHTS
To Turn The Interior Lights On:
Rotate the Dimmer Control upward to the second detent.
Rotate the switch downward to turn the interior lights
off.
NOTE:The interior lights have a “fade to off” feature.
When the lights are turned off, they gradually “fade” off.
Battery Saver Feature—Interior Lights
The interior courtesy lights come on when a door is open
or left ajar. To prevent battery drain, if you leave a door
open or ajar these lights will turn off after 15 minutes.
After you close the door, the interior courtesy lights will
again function in the normal matter.
NOTE:The map lights or reading lights that are manu-
ally switched on will not turn off automatically.
Instrument Panel Lighting
The brightness of the instrument panel lighting can be
regulated by rotating the dimmer switch.
Daytime Brightness Feature
Certain instrument panel components can be illuminated
at full brightness during the daytime. These are the
Odometer, Transmission Range Indicator, Radio, Climate
Controls, and the Overhead Travel Information Center.
This can be helpful when driving with your headlights
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 65
3

on during the daytime such as in a parade or a funeral
procession. To activate this feature, rotate the Dimmer
Control upward to the first detent.
Front Map/Reading Lights
These lights are mounted between the sun visors. Each
light is turned On by pressing the lens. Press the lens a
second time to turn the light Off. The lights also come on
when a door is opened or the dimmer switch is turned
fully upward, past the second detent.
NOTE:The lights will remain on until the switch is
pressed a second time, so be sure they have been turned
off before leaving the vehicle. They will not turn off
automatically.
Rear Seat Reading/Courtesy Lights
These lights may be individually operated by a switch
next to the light. The Battery Saver feature will not turn
these lights off. Be sure the lights are off before leaving
the vehicle. The lights also come on when a door is
opened or the dimmer switch is turned to the dome light
position, past the detent.
EXTERIOR LIGHTS
Headlights And Parking Lights
When the headlight switch is turned clockwise
from Off to the first position, the parking lights,
taillights, side marker lights, license plate light and
instrument panel lights are all turned on. The headlights
turn on when the switch is turned to the second position.
66 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Lights-On Reminder
If the headlights or parking lights are left on after the
ignition is turned Off, a chime will sound when the
driver’s door is opened.
Automatic Headlights
This system automatically turns your headlights on at a
preset level of outdoor lighting. To turn the system on,
turn the headlight switch to the extreme left. When the
system is on, the headlight delay feature is also on. This
means that your headlights will stay on for about 90
seconds after you turn the ignition switch off. To turn theAutomatic system off, turn the headlight switch clock-
wise, to the off position.
The engine must be running before the headlights will
come on in the automatic mode.
NOTE:The Automatic Headlight System will turn on
the headlights if it detects that the windshield wipers
have been in operation for more than 10 seconds.
Headlight Time Delay
This feature provides the safety of headlight illumination
for about 90 seconds when leaving your vehicle in an
unlighted area. For vehicles equipped with Electronic
Vehicle Information Center (EVIC), this is customer pro-
grammable to Off, 30, 60, or 90 seconds. (See the Elec-
tronic Vehicle Information Center (EVIC) section of this
manual.)
To activate the delay, turn off the ignition while the
headlights are still on. Then turn off the headlights within
45 seconds. The delay interval begins when the ignition is
turned off.
If the headlights are turned off before the ignition, they
will go off in the normal manner.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 67
3

Battery Saver Feature
If an exterior light is left on when the ignition switch is
moved to the Off position, it will automatically turn off
after 10 minutes. Normal operation will resume when the
ignition is turned On or when the headlight switch is
turned to another position.
Fog Lights
Turn the headlight switch to any ON position,
then pull out the headlight switch knob to turn on
the fog lights. A light near the switch will illumi-
nate to show that the Fog Lights are On.
NOTE:Turning on the high beam headlights will turn
off the fog lights. Fog light operation will resume when
the high beams are turned off and the lights return to the
low beam, parking light, or automatic positions.
Daytime Running Lights (Canada Only)
The headlights are on at a dimmer level whenever the
vehicle is started and the parking brake is released. The
lights remain on until the ignition switch is turned OFF.
MULTIFUNCTION CONTROL LEVER
Turn Signals
The arrows on each side of the instrument cluster flash to
show operation of the front and rear turn signal lights. If
either light flashes at an extremely fast rate, check for a
defective outside light bulb. If both of the indicators fail
to light when the lever is moved, it would suggest that
the fuse or indicator bulbs are defective.
68 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Headlight Dimmer Switch
Pull the multi-function control lever toward the steering
wheel to switch the headlights from high or low beam.
Passing Light
You can signal another vehicle with your headlights by
lightly pulling the multi-function lever toward the steer-
ing wheel. This will cause the headlights to turn on at
high beam and remain on until the lever is released.
Windshield Wipers And Washers
The wipers and washers are operated by a switch in the
control lever. Turn the end of the handle to select the
desired wiper speed.
NOTE:The vehicle electronics will shut the windshield
wiper system off if the wiper motor has been trying to
move a stuck wiper blade for more than 20 seconds. This
feature prevents damage to the wiper motor. If this
occurs, free the stuck blade and then turn the ignition
switch Off, then On. This will reset the system.
To use the washer, push the knob in when spray is
desired. If the button is pushed while in the delay range,
the wiper will operate for several seconds after the knob
is released, and then resume the intermittent interval.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 69
3

If the button is pushed and held while in the OFF
position, the wiper will operate for several wipes then
turn off.
If the button is pushed while in the OFF position, the
wipers will cycle twice.
NOTE:The Automatic Headlight System will turn on
the headlights if it detects that the windshield wipers
have been in operation for more than 10 seconds.
WARNING!
Sudden loss of visibility through the windshield
could lead to an accident. You might not see other
vehicles or other obstacles. To avoid sudden icing of
the windshield during freezing weather, warm the
windshield with the defroster before and during
windshield washer use.
Speed Sensitive Intermittent Wipers System
Use the intermittent feature of this system when weather
conditions make a single wiping cycle, with a variable
pause between cycles, desirable.
For maximum delay between cycles, turn the control
knob into the upper end of the delay range. The delay
interval decreases as you turn the knob until it enters the
LO continual speed position. The delay can be regulated
from a maximum of about 18 seconds between cycles, to
a cycle every 1/2 second.
NOTE:Vehicle speed is monitored to calculate wiper
delay intervals. The delay between cycles is shortened
when the vehicle is moving above 10 mph (16 km/h) and
lengthened below 10 mph (16 km/h).
70 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
