CONVERTIBLE TOP EMERGENCY OPERATION
If the convertible top cannot be closed using the convert-
ible top switch, check the following:
²Is the decklid closed properly?
²Is there sufficient battery voltage? Start the engine if
necessary.
²Is the rear cargo compartment divider secured in the
vertical position?
If the power convertible top operation does not function
properly, you can close the convertible top manually.
NOTE:The multifunction tool from the glovebox is
required for this job.CAUTION!
Manually closing the convertible top is a complicated
and technically demanding procedure. Closing the
convertible top manually should be performed with
great care by two people. Close the convertible top
manually in emergency cases only. Otherwise, visit
an authorized DaimlerChrysler Dealer.
WHAT TO DO IN EMERGENCIES 211
6

Relieving Hydraulic Pressure
NOTE:
The hydraulic pressure must be relieved before
the top can manually be raised or lowered.
1. Turn the ignition to the ªONº position.
2. Push down on the convertible top switch and hold in
that position.
3. Turn the ignition ªOFFº and continue to push down
on the switch for 5 seconds.
4. After 5 seconds the hydraulic system pressure will be
relieved.
WARNING!
It is important that a second person assist you to close
the convertible top manually to prevent injuries.
1. Lower the windows and open the doors.
2. Turn the ignition key off.
CAUTION!
Ensure that the decklid is closed while raising the
convertible top manually to prevent the possibility of
contact between the decklid and the tonneau cover.
WARNING!
Do not place your hands near the convertible top
frame, upper windshield area, or the convertible top
storage compartment while the convertible top is
being raised and locked. Serious personal injury may
occur.
3. Unlock the storage compartment by placing the tool
on the bolt between the backrest and the tonneau cover.
Turn the wrench in the direction of the arrow to its stop
and remove the tool.
212 WHAT TO DO IN EMERGENCIES

4. Open the tonneau cover and secure it in the upright
position.
5. Pull up hard on the upper section of the convertible
top to move it out of its storage compartment.NOTE:Do not let go of the convertible top as it may fall
back into the convertible top storage compartment.
WHAT TO DO IN EMERGENCIES 213
6

6. Move the convertible top toward the windshield
header.
WARNING!
Do not place your hands in the convertible top frame
areas. Serious personal injury may occur.
7. Do not place the convertible top frame onto wind-
shield header.8. Place the rear window section of the convertible top in
its vertical position.
9. Close the tonneau cover by placing hands near the
edges (arrows) and slowly lowering it. The tonneau cover
must lock in the first notch of the compartment cover
catch.
214 WHAT TO DO IN EMERGENCIES

10. Lock the convertible top storage compartment by
placing the tool on the bolt between the backrest and the
tonneau cover. Turn the wrench in the direction of the
arrow to its stop and remove the tool.11. Lower the rear window section of the convertible top
down and lock into the tonneau cover.
12. Fold down the locking latch handle.
WHAT TO DO IN EMERGENCIES 215
6

13. Turn the latch handle just past one quarter turn
clockwise and pull the convertible top frame carefully
down until it meets the windshield header attachment
points.
14. Turn the latch handle counterclockwise to the stop in
order to lock the convertible top.15. Fold the latch handle up.
The convertible top is now locked onto the windshield
header.
NOTE:Have the convertible top operation checked at
your authorized DaimlerChrysler Dealer as soon as pos-
sible.
216 WHAT TO DO IN EMERGENCIES

Opening a Locked Decklid
It is possible for the decklid to become locked if a
convertible top system malfunction occurs. If the top is
manually moved to the full up or full down position
when the hydraulic pressure is relieved, the decklid
should unlock.
WHAT TO DO IN EMERGENCIES 217
6
