CHRYSLER PACIFICA 2008 1.G Manual Online

UNDERSTANDING THE FEATURES OF YOUR VEHICLE
CONTENTS
mMirrors...............................86
NInside Day / Night Mirror................86
NAutomatic Dimming Mirror Ð If Equipped....86
NDriver's Side Outside Mirror Auto Dimmer Ð
If Equipped..........................87
NExterior Mirrors Folding Feature...........87
NOutside Mirror Ð Driver's Side............87
NOutside Mirror Ð Passenger's Side..........88
NPower Remote-Control Mirrors.............88NHeated Remote Control Mirrors Ð
If Equipped..........................89
NIlluminated Vanity Mirrors................89
mHands±Free Communication (UConnectŸ) Ð
If Equipped............................89
NOperations...........................91
NPhone Call Features....................98
NUConnectŸ System Features.............100
NAdvanced Phone Connectivity............105
3

NThings You Should Know About Your
UConnectŸ System....................106
NGeneral Information...................114
mSeats................................115
N10±Way Driver's Power Seat Ð If Equipped . . 115
N8±Way Driver's Power Seat Ð If Equipped . . . 116
N4±Way Passenger's Power Seat............116
NAdjustable Head Restraints..............117
NHeated Seats Ð If Equipped.............118
NSecond Row Manual Seat Recliner Ð
If Equipped.........................120
NSecond Row Manual Seat Adjuster Ð
If Equipped.........................121NSecond Row Bench Seating Ð
If Equipped.........................122
NSecond Row Fold & Tumble Seats Ð
If Equipped.........................123
NThird Row Easy Exit Ð If Equipped........124
NThird Row Seating Ð If Equipped.........126
NLoad Floor Ð If Equipped...............127
NPlastic Grocery Bag Retainer.............128
mDriver Memory Seat Ð If Equipped.........129
NEasy Exit Seat (Available With Memory Seat
Only)..............................132
NTilt Mirrors In Reverse (Available With
Memory Seat Only) Ð If Equipped.........133
mTo Open And Close The Hood.............133
82 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

mLights...............................134
NOverhead Console Map/Reading Lights.....134
NInterior Lights.......................135
NMulti-Function Lever...................136
NHeadlights, Parking Lights, Instrument Panel
Lights.............................136
NAutomatic Headlights..................137
NDaytime Running Lights (Canada Only).....138
NLights-On Reminder...................138
NHeadlight Time Delay..................138
NFog Lights Ð If Equipped...............138
NTurn Signals.........................139
NHighbeam/Lowbeam Select Switch.........139NPassing Light........................139
mWindshield Wipers And Washers...........140
NWindshield Washers...................140
NMist Feature.........................140
NWindshield Wiper Operation.............141
NIntermittent Wiper System...............141
NRear Window Wiper/Washer.............141
mTilt Steering Column....................143
mElectronic Speed Control..................144
NTo Activate..........................144
NTo Set a Desired Speed.................145
NTo Deactivate........................145
NTo Resume Speed.....................145
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 83
3

NTo Vary The Speed Setting...............145
NTo Accelerate For Passing...............146
mGarage Door Opener Ð If Equipped.........146
NProgramming HomeLinkt...............147
NCanadian Programming/Gate Programming . . 150
NUsing HomeLinkt.....................151
NReprogramming a Single HomeLinkt
Buttons............................151
NSecurity............................151
NTroubleshooting Tips...................152
NGeneral Information...................152
mAnti-Lock Brake System (ABS).............153
mElectronic Brake Control System -
ABS/TCS/BAS/ESP.....................154NTraction Control System (TCS)............154
NBrake Assist System (BAS)...............154
NESP (Electronic Stability Program).........155
mAdjustable Pedals Ð If Equipped...........159
mRear Park Sense System Ð If Equipped.......160
NRear Park Assist Sensors................161
NRear Park Assist Warning Display.........162
NEnable/Disable The Rear Park Assist System Ð
If Equipped.........................165
NService The Rear Park Assist System........165
NCleaning The Rear Park Assist System......166
mRear Camera Ð If Equipped...............166
mOverhead Console Ð If Equipped...........168
84 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

NCourtesy/Reading Lights................168
NSunglasses Storage....................168
mPower Sunroof Ð If Equipped.............169
NExpress Open Feature..................170
NWind Buffeting.......................171
NSunroof Comfort Position Ð If Equipped....171
NSunroof Maintenance...................172
mElectrical Power Outlets..................172
NElectrical Outlet Use With Engine Off.......173
mCupholders...........................174
NFront Seat Cupholders..................174NSecond Row Seat Cupholders.............174
NThird Row Seat Cupholders Ð If Equipped . . . 175
mStorage..............................175
NConsole Features......................175
NRear Cargo Storage Bin Ð If Equipped......175
NRetractable Cargo Area Cover Ð
If Equipped.........................176
NCargo Tie-Down Hooks.................177
mRoof Luggage Rack Ð If Equipped..........178
mLoad Leveling System...................180
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 85
3

MIRRORS
Inside Day / Night Mirror
Adjust the mirror to center on the view through the rear
window. A two point pivot system allows for horizontal
and vertical adjustment of the mirror.Annoying headlight glare can be reduced by moving the
small control under the mirror to the night position
(toward rear of vehicle). The mirror should be adjusted
while set in the day position (toward windshield).
Automatic Dimming Mirror Ð If Equipped
When using this feature the mirror will automatically
adjust for annoying headlight glare from vehicles behind
you. You can turn the feature on or off by pressing the
button at the base of the mirror. A light will illuminate to
indicate when this feature is on.
MANUAL REARVIEW MIRROR
86 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

CAUTION!
To avoid damage to the mirror during cleaning, never
spray any cleaning solution directly onto the mirror.
Apply the solution onto a clean cloth and wipe the
mirror clean.
Driver's Side Outside Mirror Auto Dimmer Ð If
Equipped
This mirror automatically adjusts for annoying headlight
glare from vehicles behind you. You can turn this feature
on or off by pressing the button at the base of the
Rearview Mirror.
Exterior Mirrors Folding Feature
All exterior mirrors are hinged and may be moved either
forward or rearward to resist damage. The hinges have
three detent positions; full forward, full rearward, and
normal.
Outside Mirror Ð Driver's Side
Adjust the outside mirror to center on the adjacent lane of
traffic, with a slight overlap of the view obtained on the
inside mirror.
Automatic Dimming Mirror
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 87
3

Outside Mirror Ð Passenger's Side
Adjust the convex outside mirror so you can just see the
side of your vehicle in the portion of the mirror closest to
the vehicle. This type of mirror will give a much wider
view to the rear, and especially of the lane next to your
vehicle.
WARNING!
Vehicles and other objects seen in the right side
convex mirror will look smaller and farther away
than they really are. Relying too much on your right
side mirror could cause you to collide with another
vehicle or other object.
Use your inside mirror when judging the size or
distance of a vehicle seen in this convex mirror.
Power Remote-Control Mirrors
Use the mirror select switch, located on the driver's door
trim panel above the power window switches, to adjust
the view obtained in the outside mirrors.
Power Mirror Switches
88 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Press the rocker switch to the L or R for Left or Right
mirror selection. Use the center off position to guard
against accidentally moving a mirror position.
Select a mirror and press one of the four arrows for the
direction you want the mirror to move.
Power mirror preselected positions can be controlled by
the optional Driver Memory Seat Feature. Refer to
ªDriver Memory Seatº in section 3 of this manual.
Heated Remote Control Mirrors Ð If Equipped
These mirrors are heated to melt frost or ice. This feature
is activated whenever you turn on the Rear Window
Defrost.
Illuminated Vanity Mirrors
An illuminated vanity mirror is on the sun visor. To use
the mirror, rotate the sun visor down and swing the
mirror cover upward. The lights turn on automatically.
Closing the mirror cover turns off the lights.
Sun Visor Extension
The sun visors may be pulled out to provide extended
coverage of the side glass.
HANDS±FREE COMMUNICATION (UConnectŸ) Ð
IF EQUIPPED
UConnectŸ is a voice-activated, hands-free, in- vehicle
communications system. UConnectŸ allows you to dial
a phone number with your cellular phone using simple
voice commands (e.g.,9Callº{ªMikeº{ºWork9or9Dialº
{ª248-555-12129). Your cellular phone's audio is trans-
mitted through your vehicle's audio system; the system
will automatically mute your radio when using the
UConnectŸ system.
NOTE:The UConnectŸ system use requires a cellular
phone equipped with the Bluetooth9Hands-Free Profile,9
version 0.96 or higher. See www.chrysler.com/uconnect
for supported phones.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 89
3

UConnectŸ allows you to transfer calls between the
system and your cellular phone as you enter or exit your
vehicle, and enables you to mute the system's micro-
phone for private conversation.
The UConnectŸ phonebook enables you to store up to 32
names and four numbers per name. Each language has a
separate 32-name phonebook accessible only in that
language. This system is driven through your Blue-
toothŸ Hands-Free profile cellular phone. UConnectŸ
features BluetoothŸ technology - the global standard
that enables different electronic devices to connect to
each other without wires or a docking station, so UCon-
nect works no matter where you stow your cellular
phone (be it your purse, pocket, or briefcase), as long as
your phone is turned on and has been paired to the
vehicle's UConnectŸ system. The UConnectŸ system
allows up to seven cellular phones to be linked to system.
Only one linked (or paired) cellular phone can be usedwith the system at a time. The system is available in
English, Spanish, or French languages (as equipped).
The rearview mirror contains the microphone for the
system and the radio has the two control buttons that will
UConnectŸ Switches
90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
