KEYS
The keyless ignition system consists of a Key Fob with
Remote Keyless Entry (RKE) transmitter (RKE Key Fob)
with a built in emergency key and a keyless push button
Ignition system.
RKE Key Fob
This system allows you to lock or unlock the doors and
liftgate, and activate the Panic Alarm, optional power
liftgate, left power sliding door, and right power sliding
door from distances up to approximately 66 ft (20 m)
using a hand-held RKE Key Fob. The RKE key fob does
not need to be pointed at the vehicle to activate the
system.NOTE:
The emergency key allows for entry into the
vehicle should the battery in the vehicle or the RKE Key
Fob go dead. The emergency key is also for locking/
unlocking the glove compartment. You can keep the
emergency key with you when valet parking.
Three Button RKE Key Fob
3
GETTING TO KNOW YOUR VEHICLE 19
Page 22 of 828
Four Button RKE Key FobFive Button RKE Key Fob
20 GETTING TO KNOW YOUR VEHICLE
Page 23 of 828
Six Button RKE Key FobSeven Button RKE Key Fob
3
GETTING TO KNOW YOUR VEHICLE 21
Page 24 of 828
General Information
The following regulatory statement applies to all radio
frequency (RF) devices equipped in this vehicle:
This device complies with Part 15 of the FCC Rules and
with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received,including interference that may cause undesired op-
eration.
NOTE: Changes or modifications not expressly approved
by the party responsible for compliance could void the
user ’s authority to operate the equipment.
To Unlock The Doors
NOTE: Uconnect Settings lets you program the system
to unlock either the driver’s side doors on the first push
(default) or unlock all doors on the first push of the
UNLOCK button on the RKE Key Fob. To change the
default setting, refer to “Uconnect Settings” in “Multime-
dia” for further information.
1st Push Of Key Fob Unlocks
Push and release the UNLOCK button on the RKE Key
Fob once to unlock the front and rear driver doors or
twice within five seconds to unlock all doors liftgate. The
hazard lights will flash to acknowledge the unlock signal.
The illuminated entry system will be activated.
22 GETTING TO KNOW YOUR VEHICLE
Page 25 of 828
2nd Push Of Key Fob Unlocks
Push and release the UNLOCK button on the RKE Key
Fob twice within five seconds to unlock all doors and
liftgate. The turn signal lights will flash to acknowledge
the unlock signal. The illuminated entry system will be
activated.
First Push Unlock
Second Push Unlock
3
GETTING TO KNOW YOUR VEHICLE 23
Page 26 of 828
This feature lets you program the system to unlock either
the driver’s door or all doors on the first push of the
UNLOCK button on the RKE Key Fob. To change the
current setting, refer to “Uconnect Settings” in “Multime-
dia” for further information.
NOTE:If the vehicle is equipped with Passive Entry,
refer to “Keyless Enter-N-Go — Passive Entry” in “Get-
ting To Know Your Vehicle” for further information.
Emergency Key Feature
The RKE Key Fob also contains and an emergency key,
which stores in the bottom of the RKE Key Fob.
The emergency key allows for entry into the vehicle
should the battery in the vehicle or the RKE Key Fob go
dead. The emergency key is also for locking/unlocking
the glove compartment. You can keep the emergency key
with you when valet parking.
Mechanical Latch To Release Emergency Key
24 GETTING TO KNOW YOUR VEHICLE
Page 27 of 828
To remove the emergency key, press the mechanical
button on the side of the RKE Key Fob with your thumb
and pull the emergency key out with your other hand
while pushing the mechanical button.
To Lock The Doors And Liftgate
Push and release the LOCK button on the RKE Key Fob
to lock all doors and liftgate. The hazard lights will flash
once and the horn will chirp once to acknowledge the
signal. Settings in radio can change to lights only, chirp
only, or both.
If the vehicle is equipped with Passive Entry, refer to
“Keyless Enter-N-Go — Passive Entry” in “Getting To
Know Your Vehicle” for further information.Key Fob With Remote Control And Integrated Vehicle
Key
If one or more doors are open, or the liftgate is open, the
doors will lock. This is signaled by a quick flash of the
turn signals.
Vehicles Equipped With Keyless Enter-N-Go — Passive
Entry
If one or more doors are open, or the liftgate is open, the
doors will lock. The doors will unlock again only if the
key is inside the passenger compartment.
3
GETTING TO KNOW YOUR VEHICLE 25
Page 28 of 828
Transmitter Battery Replacement
The recommended replacement battery is one CR2032
battery.
NOTE:
•Perchlorate Material — special handling may apply.
See www.dtsc.ca.gov/hazardouswaste/perchlorate
• Do not touch the battery terminals that are on the back
housing or the printed circuit board.
1. Remove the emergency key by pushing the mechani- cal release button on the side of the RKE Key Fob with
your thumb and then pull the key out with your other
hand. 2. Insert the tip of the emergency key or a #2 flat blade
screwdriver into the slot and gently pry the two halves
of the RKE Key Fob apart. Make sure not to damage
the plastic mechanical attachment points.
Emergency Key Removal
26 GETTING TO KNOW YOUR VEHICLE
Page 29 of 828
3. Remove the battery by turning the back cover over(battery facing downward) and tapping it lightly on a
solid surface such as a table or similar, then replace the
battery. When replacing the battery, match the + sign
on the battery to the + sign on the inside of the battery
clip, located on the back cover. Avoid touching the new battery with your fingers. Skin oils may cause
battery deterioration. If you touch a battery, clean it
with rubbing alcohol.
4. To assemble the RKE Key Fob case, snap the two halves together.
Programming Additional Transmitters
If you do not have a programmed RKE Key Fob, contact
your authorized dealer for details.
Request For Additional Remote Controls
NOTE: Only RKE Key Fobs that are programmed to the
vehicle electronics can be used to start and operate the
vehicle. Once a RKE Key Fob is programmed to a vehicle,
it cannot be programmed to any other vehicle.Separating The RKE Key Fob Case
3
GETTING TO KNOW YOUR VEHICLE 27
Page 30 of 828
CAUTION!
•Always remove the Key Fobs from the vehicle and
lock all doors when leaving the vehicle unat-
tended.
• For vehicles equipped with Keyless Enter-N-Go,
always remember to place the ignition in the OFF
position.
At the time of purchase, the original owner is provided
with a four-digit Personal Identification Number (PIN).
Keep the PIN in a secure location. This number is
required for authorized dealer replacement of RKE Key
Fobs. Duplication of RKE Key Fobs may be performed at
an authorized dealer. This procedure consists of pro-
gramming a blank RKE Key Fob to the vehicle electron-
ics. A blank RKE Key Fob is one that has never been
programmed. NOTE:
When having the Sentry Key Immobilizer System
serviced, bring all vehicle keys with you to an authorized
dealer.
KeySense Features — If Equipped
This feature provides the vehicle owner with the ability
to identify a specific vehicle key for which a customized
category of vehicle settings can be applied to determine
the driving experience for other drivers of the vehicle.
The vehicle settings are protected by a unique 4-digit
PIN, which the vehicle owner creates when accessing the
specific settings for the first time.
This feature also has additional features that are always
enabled when the specific key is in use that cannot be set
by the vehicle owner. While this specific RKE Key Fob is
in use, the vehicle will respond accordingly to the cus-
tomized vehicle settings and mandatory features. This
includes enhanced driving assistance features, increased
driver alerts, and the locking of certain optional features.
