Page 41 of 828
2. Perform one of the following methods to lock thevehicle:
• Push LOCK on the interior power door lock switch
with the driver and/or passenger door open.
• Push the LOCK button on the exterior Passive Entry
Door Handle with a valid RKE Key Fob available in
the same exterior zone (refer to Keyless Enter-N-Go
— Passive Entry inGetting To Know Your Vehicle
for further information).
• Push the LOCK button on the RKE Key Fob.
3. If any doors are open, close them.
To Disarm The System
The Vehicle Security Alarm can be disarmed using any of
the following methods:
• Push the UNLOCK button on the RKE Key Fob. •
Grasp the Passive Entry Unlock Door Handle (if
equipped, refer to Keyless Enter-N-Go — Passive
Entry inGetting To Know Your Vehicle for further
information).
• Cycle the vehicle ignition system out of the OFF
position.
• For vehicles equipped with Keyless Enter-N-Go —
Passive Entry, push the keyless ignition START/
STOP button (requires at least one valid RKE Key
Fob in the vehicle).
NOTE:
• The driver’s door key cylinder and the liftgate button
on the RKE Key Fob cannot arm or disarm the Vehicle
Security Alarm.
• The Vehicle Security Alarm remains armed during
power liftgate entry. Pushing the liftgate button will
3
GETTING TO KNOW YOUR VEHICLE 39
Page 42 of 828
not disarm the Vehicle Security Alarm. If someone
enters the vehicle through the liftgate and opens any
door, the alarm will sound.
• When the Vehicle Security Alarm is armed, the interior
power door lock switches will not unlock the doors.
The Vehicle Security Alarm is designed to protect your
vehicle. However, you can create conditions where the
system will give you a false alarm. If one of the previ-
ously described arming sequences has occurred, the
Vehicle Security Alarm will arm regardless of whether
you are in the vehicle or not. If you remain in the vehicle
and open a door, the alarm will sound. If this occurs,
disarm the Vehicle Security Alarm. If the Vehicle Security Alarm is armed and the battery
becomes disconnected, the Vehicle Security Alarm will
remain armed when the battery is reconnected; the
exterior lights will flash, and the horn will sound. If this
occurs, disarm the Vehicle Security Alarm.
DOORS
Manual Lock
To lock each door, rotate the door lock knob on each door
trim panel forward. To unlock the front doors, pull the
inside door handle to the first detent or rotate the door
lock button until the ribbing is visible. To unlock the rear
doors, rotate the door lock button until the ribbing is
visible.
40 GETTING TO KNOW YOUR VEHICLE
Page 43 of 828
Manual Front Door Lock location
1 — Manual Door Lock
2 — Door Handle
Manual Door Lock Rocker Switch
3
GETTING TO KNOW YOUR VEHICLE 41
Page 44 of 828
If the door lock button is locked (no ribbing is visible)
when you shut the door, the door will lock. Therefore,
make sure the Key Fob is not inside the vehicle before
closing the door.
NOTE:The manual door locks will not lock or unlock
the liftgate.
NOTE:
• For personal security and safety in the event of a
collision, lock the vehicle doors before you drive as
well as when you park and leave the vehicle.
• Never use the PARK position as a substitute for the
parking brake. Always apply the parking brake fully
when parked to guard against vehicle movement and
possible injury or damage.
• When leaving the vehicle, always make sure the key-
less ignition node is in the “OFF” mode, remove the
Key Fob from the vehicle and lock the vehicle.
Manual Rear Door Lock location
1 — Door Handle
2 — Manual Door Lock 42 GETTING TO KNOW YOUR VEHICLE
Page 45 of 828
•Never leave children alone in a vehicle, or with access
to an unlocked vehicle. Allowing children to be in a
vehicle unattended is dangerous for a number of
reasons. A child or others could be seriously or fatally
injured. Children should be warned not to touch the
parking brake, brake pedal or the gear selector.
• Do not leave the Key Fob in or near the vehicle, or in
a location accessible to children, and do not leave the
ignition of a vehicle equipped with Keyless Enter-
N-Go in the ACC or ON/RUN mode. A child could
operate power windows, other controls, or move the
vehicle.
Central Lock/Unlock — If Equipped
A power door lock switch is on each front door trim
panel. Use this switch to lock or unlock the doors. If you push the power door lock switch while the ignition
is in the ACC or ON/RUN position, and any front door
is open, the power locks will not operate. This prevents
Driver Power Door Lock Switches
1 — Unlock Power Switch
2 — Lock Power Switch
3
GETTING TO KNOW YOUR VEHICLE 43
Page 46 of 828
you from accidentally locking your keys in the vehicle.
Placing the ignition in the OFF position or closing the
door will allow the locks to operate. A chime will sound
if the ignition is in the ACC or ON/RUN position and a
door is open, as a reminder to remove the RKE Key Fob.
If you push the power door lock switch while the sliding
door is open, the sliding door will lock.
Unlock Doors Automatically On Exit — If
Equipped
The Unlock Doors Automatically On Exit feature unlocks
all of the vehicle doors when any door is opened. This
will occur only after the gear selector has been placed
into the PARK position, after the vehicle has been driven
(the gear selector has been placed out of PARK and all
doors closed).
The Unlock Doors Automatically On Exit feature will not
operate if there is any manual operation of the power
door locks (lock or unlock).For further information, refer to
Uconnect Settings” in
“Multimedia”.
Keyless Enter-N-Go — Passive Entry
The Passive Entry system is an enhancement to the
vehicle’s Remote Keyless Entry (RKE) system and a
feature of Keyless Enter-N-Go. This feature allows you to
lock and unlock the vehicle’s door(s) without having to
push the RKE key fob lock or unlock buttons.
NOTE:
• Passive Entry may be programmed ON/OFF, dis-
abling passive entry will also disable the hands free
sliding doors and liftgate closures. Refer to “Uconnect
Settings” in “Multimedia” for further information.
• If wearing gloves on your hands, or if it has been
raining on the Passive Entry door handle, the unlock
sensitivity can be affected, resulting in a slower re-
sponse time.
44 GETTING TO KNOW YOUR VEHICLE
Page 47 of 828
•If the vehicle is unlocked by Passive Entry and no door
is opened within 60 seconds, the vehicle will re-lock
and if equipped will arm the security alarm.
• If the child safety locks have been engaged the sliding
side doors can be unlocked from the outside using the
hands free RKE or Passive Entry system.
To Unlock From The Driver’s Side:
With a valid RKE key fob within 3ft (1 m) of the drivers
door handle, grab the drivers front door handle to unlock
the drivers side doors (driver/sliding door) automati-
cally. The interior door panel rocker knob will rotate
when the door is unlocked. NOTE:If “Unlock All Doors 1st Press” is programmed,
all doors and liftgate will unlock when you grab hold of
the driver ’s front door handle. To select between “Unlock
Driver Door 1st Press” and “Unlock All Doors 1st Press,”
refer to “Uconnect Settings” in “Multimedia” for further
information.
Grab The Door Handle To Unlock
3
GETTING TO KNOW YOUR VEHICLE 45
Page 48 of 828
To Unlock From The Passenger Side:
With a valid RKE key fob within 3 ft (1 m) of the
passenger door handle, grab the front passenger door
handle to unlock all four doors and the liftgate automati-
cally. The interior door panel lock knob will raise when
the door is unlocked.
NOTE:All doors will unlock when the front passenger
door handle is grabbed regardless of the driver ’s door
unlock preference setting (“Unlock Driver Door 1st
Press” or “Unlock All Doors 1st Press”).
Preventing Inadvertent Locking Of RKE key fob In
Vehicle (FOBIK-Safe)
To minimize the possibility of unintentionally locking a
RKE key fob inside your vehicle, the Passive Entry
system is equipped with an automatic door unlock
feature which will function if the ignition switch is in the
OFF position. FOBIK-Safe only executes in vehicles with Passive Entry.
There are three situations that trigger a FOBIK-Safe
search in any Passive Entry vehicle:
•
A lock request is made by a valid RKE key fob while a
door is open.
• A lock request is made by the Passive Entry door
handle while a door is open.
• A lock request is made by the door panel switch while
the door is open.
When any of these situations occur, after all open doors
are shut, the FOBIK-Safe search will be executed. If it
finds a RKE key fob inside the car, and it does not find
any RKE key fob outside the car, then the car will unlock
and alert the customer.
46 GETTING TO KNOW YOUR VEHICLE
Page 49 of 828
NOTE:The vehicle will only unlock the doors when a
valid RKE key fob is detected inside the vehicle, and no
valid RKE key fob is detected outside the vehicle. The
vehicle will not unlock the doors when any of the
following conditions are met:
• The doors are manually locked using the door lock
knobs.
• There is a valid RKE key fob outside the vehicle and
within 3 ft (1 m) of either Passive Entry door handle.
• Three attempts are made to lock the doors using the
door panel switch and then close the doors.
NOTE: On the third attempt ALL doors will lock and
the RKE key fob can be locked in the vehicle. To Enter The Liftgate
With a valid RKE key fob within 3 ft (1 m) of the liftgate,
cycle the handle to open the liftgate and pull the liftgate
open with one fluid motion.
NOTE:
If “Unlock Driver Door 1st Press” is pro-
grammed, only the liftgate will unlock when the liftgate
release handle is pushed. If “Unlock All Doors 1st Press”
is programmed, all doors and the liftgate will unlock
when the liftgate release handle is pushed. To select
between “Unlock Driver Door 1st Press” and “Unlock All
Doors 1st Press,” refer to “Uconnect Settings” in “Multi-
media” for further information.
3
GETTING TO KNOW YOUR VEHICLE 47
Page 50 of 828
To Lock The Vehicle’s Doors
With one of the vehicle’s RKE key fobs within 3 ft (1 m)
of the driver or passenger front door handle, push the
door handle LOCK button to lock all four doors and the
liftgate.Do NOT grab the door handle, when pushing the door
handle button. This could unlock the door(s).
Push The Door Handle Button To Lock
Do NOT Grab The Door Handle When Locking
48 GETTING TO KNOW YOUR VEHICLE
