CHRYSLER VOYAGER 2001 Service Manual

8W-51 REAR LIGHTING
Component Page
Back-Up Lamp Switch............... 8Wa-51-5
Battery........................... 8Wa-51-5
Body Control Module........... 8Wa-51-2, 3, 4, 5
Brake Lamp Switch................ 8Wa-51-2, 4
Center High Mounted Stop Lamp....... 8Wa-51-6
Front Control Module............ 8Wa-51-2, 4, 5
Fuse 2 (IPM)..................... 8Wa-51-2, 4
Fuse 3 (IPM)................... 8Wa-51-2, 4, 5
Fuse 26 (IPM).................... 8Wa-51-2, 4
G101............................. 8Wa-51-5
G103............................. 8Wa-51-5
G302....................... 8Wa-51-2, 3, 4, 5
G400............................. 8Wa-51-6
Intelligent Power Module......... 8Wa-51-2, 4, 5
Left Rear Lamp Assembly......... 8Wa-51-3, 4, 5
Left Stop/Turn Signal Relay........... 8Wa-51-3
License Lamp...................... 8Wa-51-6
Park Lamp Relay............... 8Wa-51-2, 4, 5
Right Combination Relay............. 8Wa-51-3
Right Rear Lamp Assembly........ 8Wa-51-2, 4, 5
Trailer Tow Connector................ 8Wa-51-3
RG8W-51 REAR LIGHTING8Wa-51-1
