CHRYSLER VOYAGER 2001 Service Manual

8W-53 WIPERS
Component Page
Accessory Relay..................... 8Wa-53-3
Body Control Module............... 8Wa-53-3, 5
Diagnostic Junction Port.............. 8Wa-53-5
Front Control Module.......... 8Wa-53-2, 3, 4, 5
Front Washer Pump Motor............ 8Wa-53-3
Front Wiper Hi/Low Relay............ 8Wa-53-2
Front Wiper On/Off Relay............. 8Wa-53-2
Fuse 4 (IPM)....................... 8Wa-53-2
Fuse 11 (IPM)...................... 8Wa-53-3
Fuse 30 (IPM)...................... 8Wa-53-4
Fuse 33 (IPM)...................... 8Wa-53-3
G102............................. 8Wa-53-4
G300............................. 8Wa-53-2
G400............................. 8Wa-53-3
Headlamp Washer Pump Motor........ 8Wa-53-4
Headlamp Washer Relay.............. 8Wa-53-4
Instrument Panel Switch Bank......... 8Wa-53-5
Intelligent Power Module....... 8Wa-53-2, 3, 4, 5
Multi- Function Switch............... 8Wa-53-5
Rear Washer Pump Motor............. 8Wa-53-3
Rear Wiper Motor................... 8Wa-53-3
Washer Fluid Level Switch............ 8Wa-53-4
Wiper Module...................... 8Wa-53-2
RG8W-53 WIPERS8Wa-53-1

8W-54 TRAILER TOW
Component Page
Body Control Module................ 8Wa-54-2
Brake Lamp Switch................. 8Wa-54-2
Front Control Module................ 8Wa-54-2
Fuse 2 (IPM)....................... 8Wa-54-2
G302............................. 8Wa-54-2
Intelligent Power Module............. 8Wa-54-2
Left Combination Relay.............. 8Wa-54-3
Left Rear Lamp Assembly............. 8Wa-54-2
Left Stop/Turn Signal Relay......... 8Wa-54-2, 3
Park Lamp Relay................... 8Wa-54-2
Right Combination Relay........... 8Wa-54-2, 3
Right Stop/Turn Signal Relay.......... 8Wa-54-3
Trailer Tow Connector.............. 8Wa-54-2, 3
RG8W-54 TRAILER TOW8Wa-54-1
