CHRYSLER VOYAGER 2004 Service Manual

8W-18 BUS COMMUNICATIONS
Component Page
A/C-Heater Control................... 8W-18-6
Adjustable Pedals Module............. 8W-18-5
Airbag Control Module................ 8W-18-6
Auto Temp Control................... 8W-18-6
Battery............................ 8W-18-2
Body Control Module............. 8W-18-3, 4, 5
Cabin Heater Assist.................. 8W-18-4
Cd Changer........................ 8W-18-6
Controller Antilock Brake............ 8W-18-3, 4
Data Link Connector........... 8W-18-2, 3, 4, 5
Dvd/Cd Changer..................... 8W-18-6
Engine Control Module................ 8W-18-4
Front Control Module............. 8W-18-3, 4, 5
G100.............................. 8W-18-2
G101.............................. 8W-18-2Component Page
G300.............................. 8W-18-2
Instrument Cluster................... 8W-18-6
Integrated Power Module........ 8W-18-2, 3, 4, 5
Left Sliding Door Control Module........ 8W-18-5
Memory Seat/Mirror Module........... 8W-18-5
Overhead Console.................... 8W-18-5
Power Liftgate Module................ 8W-18-5
Powertrain Control Module............ 8W-18-3
PTC7............................. 8W-18-2
Radio............................. 8W-18-6
Right Sliding Door Control Module...... 8W-18-5
Sentry Key Remote Entry Module....... 8W-18-6
Siren............................. 8W-18-6
Thatcham Alarm Module.......... 8W-18-3, 4, 6
RS8W-18 BUS COMMUNICATIONS8W-18-1
