REFUELLING
Low fuel level
Filling
The  fuel   tank   must   be   filled   with
the
engine off.
-

Open
  the   fuel   filler   flap.
-

Insert
  the   key,   then   turn   it   a   quarter
turn.
-


Remove
  the   cap   and   hook   it   onto
the clip located on the inside of the
flap.
When

  filling   with   fuel,   a
mechanical

  system   prevents
opening

  of   the   left-hand   side   door.
When

  the   fuel   filler   flap   is   open,   ensure
that

  no   one   tries   to   slide   this   door.
Once
  the   flap   has   been   closed,   the
sliding

  side   door   may   jam,   push   the
door

  to   close   it   then   open   it.
When the low fuel level is
reached,

this

warning

lamp

comes


on. A


label   affixed   to   the   inside   of   the   flap
reminds

  you   of   the   type   of   fuel   to   be
used.
Y

ou   must   fill   with   at   least   5   litres   of   fuel
for

  it   to   be   registered   by   the   fuel   gauge.
When
  the   fuel   filler   cap   is   opened,
there

  may   be   a   slight   inrush   of   air.
This

vacuum

  is   entirely   normal   and   is   due   to
the

  sealing   of   the   fuel   system.
When
  filling   the   fuel   tank,   do   not
continue after the 3rd cut-off of the
nozzle.
 This

could

cause   malfunctions.
The

capacity

of

the

fuel   tank   is
approximately


60

litres.
-

After


filling

the

fuel   tank,   lock   the
cap


and

close

the   flap.
Fuel used for petrol engines
The petrol engines are compatible with E10 bio-petrol (containing 10 %
ethanol),   conforming   to   European
standards

  EN   228   and   EN   15376.
E85 type fuels (containing up to 85 %
ethanol) are reserved exclusively for
vehicles
  marketed   for   the   use   of   this
type

  of   fuel   (BioFlex   vehicles).
The

quality

  of   the   ethanol   must   comply   with
European

  standard   EN   15293.
You then have approximately 8 litres
of

fuel

remaining.
Fill up without delay to avoid running
out

of

fuel.
Never

risk

driving

until

you

run

out

of

fuel


as

this

may

damage

the

emissions

control


and

injection

systems.
CHECKS
7
Fuel

DIESEL
160
Berlingo-2-VP_en_Chap07_Verification_ed01-2015Berlingo-2-VP_en_Chap07_Verification_ed01-2015
FUEL CUT- OFF
In a serious collision, a mechanism automatically
  prevents   fuel   from
reaching

  the   engine.
The
  flashing   of   this   warning
lamp

  is   accompanied   by   a
message

  in   the   screen.
Check
  that   there   is   no   odour   or
leakage

  of   fuel   outside   the   vehicle   and
re-establish

  the   fuel   supply:
-

switch of
f the ignition (ST
o
P
position),
-

remove
  the   key,
-

put
  the   key   back   in   the   ignition,
-

switch
  on   the   ignition   and   start.
DIESEL PRIMING PUMP
Refer to chapter 7, "Under the bonnet"
  section.
Fuel used for Diesel engines
The Diesel  engines  are  compatible  with  biofuels
  which   conform   to   current   and
future European standards (

d iesel fuel
which
  complies   with   standard   EN   590
mixed

  with   a   biofuel   which   complies
with standard E

n 14214) available at
the
  pumps   (containing   up   to   7   %   Fatty
Acid

  Methyl   Ester).
B30 biofuel can be used in certain
Diesel
  engines.   However,   this   use,
even occasional, requires strict
application of the special servicing
conditions.

  Contact   a   CITROËN   dealer
or

  a   qualified   workshop.
The use of any other type of (bio)
fuel
  (vegetable   or   animal   oils,   pure
or

  diluted,   domestic   fuel...)   is   strictly
prohibited

  (risk   of   damage   to   the
engine

  and   fuel   system). If you run out of fuel, it is necessary to
prime
  the   fuel   circuit.
-

Fill
  the   fuel   tank   with   at   least   five
litres

  of   Diesel.
-

Squeeze
  and   release   the   manual
priming

  pump,   under   the   bonnet,
under

  the   protective   cover.
-
o perate the starter until the engine
starts.
Fuel

 161
Berlingo-2-VP_en_Chap07_Verification_ed01-2015Berlingo-2-VP_en_Chap07_Verification_ed01-2015
BLUEHDI
AND A D B LUE
® ADDITIVE
The technology
adBlue® is the brand name of the solution needed for operation of the
SCR

system. BlueHDI
  vehicles   have   a   specific
a dBlue
® additive tank with a capacity
of 17 litres .
It

has

an   exterior   filler   with   a   blue filler
cap, located to the left of the
d iesel
fuel

filler   cap.
Filling of the
a

dBlue
® tank can be done using 5 or 10 litre containers,
1.89

litre

bottles,

or

when   at   a   fuel
fillin

g

station

equipped   with   a   special
a
dBlue
® delivery pump for light vehicles.
The

objective

of

BlueHDi

is

to

reduce

by


up

to

90%

the

emissions

of

NOx

(nitrous oxides) in the air

, using a
system

that

converts

NOx

into

water

vapour and nitrogen in a dedicated
catalytic


converter:

SCR

(Selective

Catalytic


Reduction).
This

objective

meets

the

"Euro"

emissions


standard

adopted

by

the

European


Union

aimed

at

limiting

the

emissions


of

pollutants

from

internal

combustion


engines.
The BlueH
d
i generation of engines
allow

the

"Euro

6"

European

standard

to


be

met,

with

an

extra

tank

to

hold

the

a
dBlue
® fluid for the treatment of exhaust

gases.
This operation can also be carried
out by a CITR
o Ë n dealer or a
qualified
  workshop.
Please note that the high delivery
pumps
  at   some   filling   stations,
intended only for lorries and coaches,
are not suitable for cars or light
commercial

  vehicles.
Never
  use   these   pumps.
CHECKS
7
AdBlue® additive

162
Berlingo-2-VP_en_Chap07_Verification_ed01-2015Berlingo-2-VP_en_Chap07_Verification_ed01-2015
Good practice
While the quantity of
a
dBlue® in
the

additive

tank

is

sufficient,

no

information


is

displayed.
o

n the other hand, once the additive
level drops to the quantity needed
for

a

range

of

1

500

miles

(2

400

km)
driving, you are warned by dif

ferent
temporary

signals

(warning

lamp,

message,


audible

signal).
As

more

miles

are

covered,

these

signals


intensify

and

the

message
becomes


permanent.
When the
a
dBlue
® tank is empty, restarting

becomes   impossible.
It

is

strongly

recommended   that   you
do not wait for the successive alerts
before topping-up the a

dBlue
® tank, but

do

this

as

soon

as

possible.
Filling the additive tank
For light vehicles, 5 or 10 litre
containers

and

1.89

litre

(1/2

US

gallon)


bottles

are

available

from

CITR

o
Ë
n
dealers, until they are
equipped with
a
dBlue
® delivery pumps.
If

you

want

to

fill

the

AdBlue® tank yourself, ensure that you have a
suitable

filler

pipe,

which

may   or   may
not be supplied with the additive
container

.
AdBlue® additive

 163
Berlingo-2-VP_en_Chap07_Verification_ed01-2015Berlingo-2-VP_en_Chap07_Verification_ed01-2015
Range indicators
Rules on the display of alertsFor   more   information   on   the
displays

  and   warning   lamps,   refer
to

  chapter   3,   "Instruments   and
controls"

  section. Range greater than 1 500 miles
(2 400 km)
No
  information   displayed.
Once   the   1   500   miles   (2   400   km)
threshold is reached, the URE

a

warning

  lamp   comes   on   temporarily
and

  the   remaining   range   message   is
displayed.
The

  alert   is   repeated   every   200   miles
(300

  km)   until   the   next   threshold   is
reached.
Every

  time   the   ignition   is   switched
on, the alert is given, together with an
audible

  signal.
Remaining range less than
1 500 miles (2 400 km) and greater
than 375 miles (600 km)
Driving range
With
  the   touch   screen   tablet:
If
  the   range   is   greater   than   3   100   miles
(5

  000   km),   a   range   value   is   not   given.
Press this button to display
the
  information.
-

select the "
d riving
assistance"
  menu,
-

select "
d iagnostic",
-

select
  CHECK.
d
ifferent levels of alert are triggered
according
  to   the   remaining   driving
range

  threshold.
You
  will   be   informed   as   each   mileage
threshold is reached and the alerts will
change

  from   temporary   to   permanent.
-

The 1st is triggered at a remaining driving
  range   of   1   500   miles
(2

400
  km).
-
The 2nd is triggered at a remaining driving
  range   of   375   miles   (600 km).
-

Up


to

0   miles,   at   which   point   it   will
be


impossible   to   restart   the   engine
after


a

stop.
CHECKS
7
AdBlue® additive

164
Berlingo-2-VP_en_Chap07_Verification_ed01-2015Berlingo-2-VP_en_Chap07_Verification_ed01-2015
Once the 350 miles (600 km) threshold is  reached,   the   UREA  warning   lamp
flashes

  and   the   Service   warning   lamp
comes

  on,   accompanied   by   a   message
on

  the   remaining   driving   range.
The alert is repeated every 30 seconds
with
  an   update   of   the   remaining   driving
range

  in   steps   of   30   miles   (50   km)
travelled.
Every

  time   the   ignition   is   switched
on, the alert is given together with an
audible

  signal.
At 0 miles the system installed in
the vehicle to meet the emissions
standard will prevent engine
starting. The 0 level of
a

dBlue
® additive has
been

reached.
Your

vehicle's

exhaust   emissions   no
longer


meet

the

"Euro
  6"   standard   and
the


engine

will

not

start.
To be able to restart the vehicle, you
must

add

at

least

4 litres of a dBlue
®.
-

Pour


the

additive

into

the

tank

(by
the


filler

with

the

blue

cap).
-

Switch on the ignition without
starting.
-


W

ait 10 seconds before starting the
engine.
Remaining range less than 350 miles
(600 km) and more than 0 miles
Starting prevented, breakdown
related to a lack of AdBlue
® additive
in the special tank
Avoid waiting until the
remaining range is 0 miles!
The alert is repeated when driving until
the

additive

tank

has

been

topped-up

with


sufficient

additive.
Unless the additive in the special
additive

tank

is

topped-up,

you

risk

immobilisation


of

the

vehicle.
Following

this,

make

a

further   fill
to


the

special

additive

tank,   the
capacity of which is

17 litres.
o

r go to a CITR
o
Ë
n
dealer or a
qualified

workshop.
adBlue® additive

 165
Berlingo-2-VP_en_Chap07_Verification_ed01-2015Berlingo-2-VP_en_Chap07_Verification_ed01-2015
Fault with the SCR system
The UREa, Service and diagnostic
warning   lamps   comes   on.
Every
  time   the   ignition   is   switched   on,
the

  emissions   fault   is   confirmed   by   an
audible

  signal   and   a   message.
If
  it   is   a   temporary   fault,   the   alert
disappears as soon as the exhaust
emissions

  return   to   the   levels   required
by

  the   standard. Fault confirmed
In addition to the previous signals,
the
  UREA

warning   lamp   flashes   and
the

  remaining   range   allowed   will   be
displayed

  in   miles   (kilometres).
The alert will be repeated every
30 seconds with an update of the
driving   range   in   steps   of   30   miles
(50 km).
Go

  to   a   CITROËN   dealer   or   a   qualified  workshop
  as   soon   as   possible.
You   risk   not   being   able   to   start   the
engine.Starting prevented, having
covered the 700 miles (1 100 km)
Detection
At
  each   attempt   at   starting,   the   alert   is
activated

  and   the   message   "Emissions
fault:

  Starting   prevented"   is   displayed.
o

n the other hand, if the warning
lamps
  are   still   on   after   30   miles
(50

  km)   of   driving,   the   fault   is
confirmed.
An

  engine   start   prevention   system
will

  be   activated   automatically   after
700 miles

  (1   100   km)   travelled
following

  this   confirmation.
Go
  to   a   CITROËN   dealer   or   a   qualified
workshop.
CHECKS
7
AdBlue® additive

166
Berlingo-2-VP_en_Chap07_Verification_ed01-2015Berlingo-2-VP_en_Chap07_Verification_ed01-2015
Refilling / Topping-up the
AdBlue® additive
Precautions to take
Use only a dBlue® additive that meets the

ISO

22241

standard.
The
a
dBlue
® additive is an urea-based
solution.
This

liquid


is


non-flammable,

colourless

and


odourless.
To

be

kept

in   a   cool   area.
Containers (5 or 10 litres) and
bottles (1.89 litres) of AdBlue
®
Please check the use-by date.
Read   the   instructions   on   the   label.
Ensure that you have a suitable
filler
  pipe,   which   may   or   may   not   be
supplied

  with   the   container.
Filling
In the event of an overflow, wipe around  the   filler   mouth   using   a
damp

  cloth.
If any
a dBlue
® fluid is split or splashed on

to

you,

wash   immediately   with   cold
water or wipe yourself with a clean
damp


cloth.
If the additive has crystallised, clean it
off

using

a

sponge   and   hot   water.
Ensure
  that   the   vehicle   is   parked   on   a
flat

  and   level   surface.
Pour
  the   contents   of   the   container   /
bottle

  into   the   dedicated   tank.
After
  filling   the   additive   tank,   observe
the

  following   procedure:
-

Switch on the ignition without
starting.
-


W
ait 10 seconds before starting the
engine.
Never
  dispose   of   empty
AdBlue®
containers and bottles in the
household

waste.
Place

them

in

a

special

container

provided


this

purpose

or

take

them

to
your


dealer.
AdBlue® additive

 167
Berlingo-2-VP_en_Chap07_Verification_ed01-2015Berlingo-2-VP_en_Chap07_Verification_ed01-2015
keep adBlue® out of the reach of
children,

in

its
  original   container.
n

ever transfer
a
dBlue
® to another
container:

it

would

loose   its   purity.
Never

dilute

the

additive   with   water.
n

ever pour the additive into the d iesel
fuel

tank.
Recommendations on storage
never store containers or bottles of a dBlue® in your vehicle.
Freezing of the AdBlue
® additive
a

dBlue® freezes at about -11°C (12.2°F)
  and   deteriorates   above   25°C.
It

is

recommended   that   containers   and
bottles be stored in a cool area and
protected

  from   direct   sunlight.
Under these conditions, the additive
can

be

kept   for   at   least   a   year.
a

dditive that has been frozen can be
used

once   it   has   thawed   out   in   ambient
air

. The
  SCR   system   includes   an
a dBlue
® tank heater that ensures operation
  of   the   vehicle   in   normal
conditions.
In exceptional situations, such as when
the


vehicle

is   kept   at   temperatures
below


-15°C
  (5°F)   for   a   long   period,   an
emission


fault   alert   may   be   related   to
freezing of the a

dBlue
® additive.
Park

the

vehicle

in

an

area   at   a   more
moderate


temperature

for   a   few   hours
until


the

additive

becomes   a   liquid
again.
The


emissions

warning   lamp   does   not
go


off

immediately,

but
  does   so   after   a
few


miles

of

driving.
CHECkS
7
adBlue® additive

168
Berlingo-2-VP_en_Chap08_aide-rapide_ed01-2015
BATTERY
Before disconnecting the battery, you
must  wait   for   2   minutes   after   switching
of

f   the   ignition.
Never
  disconnect   a   terminal   when   the
engine

  is   running.
Never
  charge   a   battery   without   first
disconnecting

  the   terminals.
a

fter every reconnection of the battery,
switch
  on   the   ignition   and   wait   1   minute
before starting to allow the electronic
systems

  to   be   initialised.   If   problems
remain

  after   doing   this,   please   contact
a

  CITROËN   dealer   or   a   qualified
workshop.
a

fter changing bulbs, wait
approximately
  3   minutes   before
reconnecting

  the   battery.
It is advisable to disconnect the
battery if the vehicle is not to be used
for  a   period   of   more   than   one   month.
To charge the battery using a
battery charger
- Disconnect  the   battery.
-
Follow the instructions for use
given by the battery charger
manufacturer

.
-

Reconnect starting with the
negative

  (-)   terminal.
-

Check
  that   the   terminals   and
connectors

  are   clean.   If   they   are
covered with sulphate (white or
greenish

  deposit),   disconnect   them
and

  clean   them.
To start the vehicle from
another battery
- Connect the red cable to the
positive  (+)   terminals   of   the
two batteries.
-


Connect one end of the green
or

  black   cable   to   the   negative   (-)
terminal

  of   the   slave   battery.
-

Connect the other end of the green
or

  black   cable   to   an   earth   point   on
the

  broken   down   vehicle   as   far   as
possible

  from   the   battery.
-
 Operate

  the   starter,   let   the   engine   run.
-

W
ait for the engine to return to idle,
then
  disconnect   the   cables.
The presence of this label
indicates the use of a 12 V
lead-acid battery with special
technology

and

specification,

for

which

the


involvement

of

a

CITROËN

dealer

or


qualified

workshop

is

required

when

replacing


or

disconnecting

the

battery.
Failure to observe this
recommendation

may

cause

premature
 wear

of

the

battery.
After

refitting

the

battery,

the

Stop &

Start


system

will

only

be

active

after

several hours depending on the
climatic


conditions

and

the

state

of

charge of the battery (up to about
8 hours).
The Stop & Start battery does not have
to


be

disconnected

for

charging.
Battery
