Citroen BERLINGO MULTISPACE 2015 2.G Owner's Manual

179
Berlingo-2-VP_en_Chap08_aide-rapide_ed01-2015Berlingo-2-VP_en_Chap08_aide-rapide_ed01-2015
CHANGING A BULB
Type A
All  glass   bulb:   pull   gently
as

  it   is   fitted   by   pressure.
Type C
Halogen
  bulb:   release   the
retaining

  spring   from   its
housing. T
ype B
Bayonet
  bulb:   press
on the bulb then turn it
anticlockwise.
T

ypes of bulb
Various

types
  of   bulb   are   fitted   to   your
vehicle.


T

o

remove   them:
Type D
Light-emitting   diode
(LED):

  for   replacement
of

  the   daytime   running
lamps,

  contact   a
CITR

o Ë n dealer or a
qualified
  workshop.
QUICk HELP
8
Changing a bulb

180
Berlingo-2-VP_en_Chap08_aide-rapide_ed01-2015Berlingo-2-VP_en_Chap08_aide-rapide_ed01-2015
2. Sidelamps
T ype A, W5W - 5W
-

Remove
  the   cover   by   pulling   the
flexible

  rubber   tab.
-

Remove
  the   bulb   holder   fitted   by
pressure

  by   pulling   the   connector.
-

Change
  the   bulb.
-

Ensure
  that   the   cover   is   refitted
correctly all round to assure correct
sealing.
Front lamps
1. Dipped / Main beam headlamps
T ype C, H4 - 55W
-

Remove
  the   centre   cover   by   pulling
the

  flexible   rubber   tab.
-

Disconnect
  the   electrical   connector.
-

Release
  the   retaining   tab.
-

Change
  the   bulb   taking   care
to

  align   the   metal   part   with   the
grooves

  on   the   lamp.
-

Reposition
  the   retaining   tab.
-

Ensure
  that   the   cover   is   refitted
correctly all round to assure correct
sealing.
High pressure washing Open


the

bonnet.

T

o

access

the

bulbs,

reach


behind

the

headlamp

unit.
Carry out the operations in reverse
order

to

refit

each

bulb

and

check

that

the


bonnet

is

closed

securely.
Halogen

bulbs

must

be

changed

with


the

headlamp

off.

Wait

a

few

minutes


(risk

of

serious

burns).

d
o not touch the bulb directly with your
fingers,

use

a

lint-free

cloth.
It

is

normal

for

condensation

to

form

inside


the

headlamps.

Regular

use

of
 the

vehicle

eliminates

this

misting.
The

bulbs

must

be

changed

with

the ignition of

f or with the battery
disconnected.

Wait

approximately


3

minutes

after

changing

the

bulb

before


reconnecting

the

battery.
Check

that

the

lamps

operate

correctly

after


each

operation.
When using this type of washing
on stubborn dirt, do not persist on
the

headlamps,

the

lamps

and

their

edges


to

avoid

damaging

their

coating

and


seals.
Changing a bulb

181
Berlingo-2-VP_en_Chap08_aide-rapide_ed01-2015Berlingo-2-VP_en_Chap08_aide-rapide_ed01-2015
3. Direction indicators
T ype B,   PY21W   -   21W   (amber)
-

Remove
  the   cover   by   pulling   the
flexible

  rubber   tab.
-

T
urn the bulb holder a quarter turn
anticlockwise.
-

Remove
  the   bulb   by   pressing   it
lightly

  while   turning   it   anticlockwise.
-

Change
  the   bulb.
-

Ensure
  that   the   cover   is   refitted
correctly all round to assure correct
sealing. 4.

Front foglamps
T ype C, H1 - 55W
-

Remove
  the   three   clips   and   the
screw securing the wheel arch liner

,
located
  below   the   bumper.
-

Move
  the   wheel   arch   liner   upwards.
-
d isconnect the bulb holder
connector by pressing the tab at
the
  top.-

Remove
  the   bulb   holder   by
squeezing the two clips (at top and
bottom)

  using   a   finger   and   thumb.
-

Replace
  the   module   (bulb   holder
and

  bulb.
-

Carry out the operations in reverse
order

  to   fit   the   module   and   refit   the
wheel

  arch   liner.
QUICk HELP
8
Changing a bulb

182
Berlingo-2-VP_en_Chap08_aide-rapide_ed01-2015Berlingo-2-VP_en_Chap08_aide-rapide_ed01-2015
Side repeater
Type A, WY5W - 5W (amber)
-
Push the repeater towards the rear
and disengage it by pullin

g the
front.
-

Contact a CITR
o Ë n dealer to
obtain a new repeater which is a
sealed
  component.
-

T
o   refit,   engage   the   repeater
towards the rear and bring it
towards

  the   front.
Courtesy lamps
Type A, 12V5W - 5W
-
Unclip the lens by sliding a
screwdriver in the slots on each
side

  of   the   courtesy   lamp.
-

Pull
  the   bulb   out   and   change   it.
-

Clip the lens in its housing and
ensure

  that   it   is   secured   correctly.
Front / Rear
Changing a bulb

183
Berlingo-2-VP_en_Chap08_aide-rapide_ed01-2015Berlingo-2-VP_en_Chap08_aide-rapide_ed01-2015
Rear lamps
This procedure requires the use of
the spanner supplied with the tools for
changing  a   wheel.
When
  refitting,   take   care   to
reposition the tabs and the wiring
correctly to avoid trapping the
wiring.
a

fter changing the rear direction
indicator
  bulb,   the   reinitialisation   time   is
above

  2   minutes.
-
Move aside the 4 tabs then extract
the
  bulb   holder.
-

Remove
  the   faulty   bulb   by
pressing it lightly while turning it
anticlockwise.
-


Change
  the   bulb.
When
  removing   the   lamp   unit:
-

with
  tailgate,   pull   the   lamp   unit
towards the centre of the vehicle,
-


with
  hinged   doors,   pull   the   lamp
unit

  towards   you.
For

more

information

on

bulbs,

refer

to
 the

"Types

of

bulb".
1.

Brake lamps / sidelamps


T

ype B,

P21/5W

-

21/5W
2.

Direction indicators


T

ype B,

PY21W

-

21W

(amber)
3.

Reversing lamps


T

ype B, P21W - 21W
4.

Foglamps


T

ype B, P21W - 21W
High pressure jet washing When using this type of washing
on stubborn dirt, do not persist on
the

headlamps,

the

other

lamps

and


their

edges

to

avoid

damaging

their


coating

and

seals. Chapter
  9,   "Changing   a   wheel"
section.
-


Identify the failed bulb, then open
the

  rear   doors   to   180°.
Chapter
  3,   "Access"   section.
-

Remove
  the   two   fixing   bolts   using
the

  spanner   provided.
-

Pull
  the   lamp   unit   from   the   outside.
-

Holding
  the   lamp,   disconnect   the
electrical

  connector.
QUICk HELP
8
Changing a bulb

184
Berlingo-2-VP_en_Chap08_aide-rapide_ed01-2015Berlingo-2-VP_en_Chap08_aide-rapide_ed01-2015
Number plate lamps
- Unscrew  the   two   nuts.
-
Push
  the   pins.
-

If necessary
, disconnect the
connector
  to   remove   the   lamp.
-

Change
  the   bulb.
Third brake lamp
Type A, W16W - 16W
T
ype A, W5W - 5W
With tailgate
-
d
isengage the plastic lens using a
screwdriver.
-

Change


the

bulb.
-

Replace the plastic lens and press
on


it. With hinged doors
-

Unclip


the

interior

trim.
-
d
isconnect the connector by
moving

aside

its

tab.
-

T

urn the bulb holder a quarter turn
anticlockwise.
-

Change


the

bulb.
-

Put


the

bulb

holder

back

in

place

and


reconnect

the

connector.
-

Put


the

trim

back

in

place.
Changing a bulb

185
Berlingo-2-VP_en_Chap08_aide-rapide_ed01-2015Berlingo-2-VP_en_Chap08_aide-rapide_ed01-2015
CHANGING A FUSE
The fuseboxes are located:
-
in the lower dashboard on the left-
hand side (behind the cover),
-


under
  the   bonnet   (near   the   battery).
The
  information   given   concerns   only
those fuses which can be changed by
the user using the tweezer

, located
behind the dashboard storage
compartment
  on   the   right-hand   side.
For

  any   other   work,   visit   a   CITROËN
dealer

  or   a   qualified   workshop.
Removing and fitting a fuse
Always replace a failed fuse with a
fuse of the same rating.
Motor

trade

technicians:

for

complete


information

on

the

fuses

and relays, refer to the "Repair
Manual"


diagrams

via

the

dealer

network.
CITR

o
Ë
n
will not accept responsibility
for the cost incurred in repairing
your vehicle or for rectifying the
malfunctions

resulting

from

the
 installation of accessories not
supplied

and

not

recommended

by

the

CITROËN


network

and

not

installed

in accordance with its instructions,
in


particular

when

the

combined

consumption


of

all

of

the

additional

equipment


connected

exceeds


10

milliamperes. Before replacing a fuse, the cause of
the
  incident   must   be   identified   and
rectified.
●


Use
  the   tweezer.
QUICk HELP
8
Changing a fuse

186
Berlingo-2-VP_en_Chap08_aide-rapide_ed01-2015Berlingo-2-VP_en_Chap08_aide-rapide_ed01-2015
Dashboard fuses
Tilt the cover to gain access to the
fuses.Fuses
F Amperes  Aa
llocation
1 15 Rear wiper
2 -
n

ot used
3 5
a

irbag
4 10 Air
  conditioning,   diagnostic   socket,   mirror   control,
headlamp

  beam
5 30 Electric windows
6 30Locks
7 5Rear
  courtesy   lamp,   front   map   reading   lamp,   roof
console
8 20 Audio

  equipment,   screen,   tyre   under-inflation
detection,

  alarm   and   siren
9 30Front
  and   rear   12V   socket
10 15 Central
  column
11 15 Low current ignition switch
12 15 Rain and sunshine sensor, airbag
13 5 Instrument
  panel
14 15 Parking
  sensors,   digital   air   conditioning   controls,
hands-free

  phone   kit
15 30 Locks
16 -
n

ot used
17 40Rear
  screen/mirrors   demist/defrost
Changing a fuse

187
Berlingo-2-VP_en_Chap08_aide-rapide_ed01-2015Berlingo-2-VP_en_Chap08_aide-rapide_ed01-2015
Passenger compartment fuses
Fuses F Amperes

Aa
llocation
1 -
n

ot used
2 20 Heated seats
3 -
n

ot used
4 15 Folding
  mirrors   relay
5 15 Refrigeration
  equipment   socket   relay
QUICk HELP
8
Changing a fuse

188
Berlingo-2-VP_en_Chap08_aide-rapide_ed01-2015Berlingo-2-VP_en_Chap08_aide-rapide_ed01-2015
Fuses under the bonnet
after opening the bonnet, unclip and tilt
the corresponding box to gain access
to
  the   fuses. Fuses
F Amperes  Aa
llocation
1 20 Engine
  management
2 15 Horn
3 10 Front
  and   rear   wash-wipe   pump
4 20 Headlamp
  wash   pump
5 15 Engine
  components
6 10 Steering wheel angle sensor,
d SC
7 10Brake
  switch,   clutch   switch
8 25 Starter
  motor
9 10Headlamp
  beam   motor,   fleet   management   unit
10 30 Engine
  components
11 40
n

ot used
12 30 Wipers
13 40 Built-in
  systems   interface
14 30 Pump
15 10 Right-hand
  main   beam   headlamp
16 10Left-hand
  main   beam   headlamp
17 15Right-hand
  dipped   beam   headlamp
18 15 Left-hand
  dipped   beam   headlamp
Changing a fuse
