2016 Citroen BERLINGO MULTISPACE 2016 2.G Owner's Manual

 99
Berlingo-2-VP_en_Chap04_Ergonomie_ed01-2016
From insideFrom outside
Rear box
This roof box can be accessed from the
  rear   seats   and   the   boot.
From
  the   rear   seats,   slide   the   flaps   to
open.
Vents
a 3-position control allows you to
adjust   the   air   flow   through   the   vents.
The
  vents   are   also   fitted   with   a   scented
air

  freshener.
From

the

boot,

place

your

thumb

on
 the recess then pull the handle to
open.
Open

carefully

to

prevent

objects

stored


in

this

interior

roof

box

from

fallin

g

out.
The

maximum

authorised

load

is

10

kg.
EASE OF USE and COMFORT
4
Practical information

100
Berlingo-2-VP_en_Chap04_Ergonomie_ed01-2016
SCENTED AIR FRESHENER
The scented air freshener diffuses
a fragrance in the passenger
compartment  from   the   roof   console
vents.
Adjusting the flow
Turn the chromed button to adjust the diffusion:
-

to the left to decrease,
-


to
  the   right   to   increase.
To
  stop   the   diffusion,   turn   the   chromed
button

  fully   to   the   left.
Removing the scented air
freshener
- Press the button down while turning
it a quarter of a turn to the left to
the  stop.
-

Remove
  the   scented   air   freshener
from

  the   roof   console.
-

Replace
  the   cartridge.
Practical information

101
Berlingo-2-VP_en_Chap04_Ergonomie_ed01-2016
Replacing a cartridge
The scented air freshener refill consists of a cartridge B and its sealing case C.
-

Remove
  the   protective   film   D.
-

Place the head of the cartridge
B
on the button A of the scented air
freshener.
-

T
urn   it   a   quarter   of   a   turn   to   lock   it
on

  the   button   and   remove   the   case.
-

Insert the scented air freshener in
its

  location.
You can change the cartridges at any
time
  and   store   cartridges   which   have
already been started in their original
case.
The scented air freshener button

A is
independent
  of   the   cartridge.
The cartridges are supplied without the
button A.
Inserting the scented air
freshener
After fitting or changing the cartridge:
-
Put
  the   scented   air   freshener   back
in

  place   in   its   location.
-

T
urn it a quarter of a turn to the
right.
Good practice
as a safety precaution, only use the
cartridges   provided   for   this   purpose.
Do

  not   dismantle   the   cartridges.
k

eep the cartridge sealing cases
which
  are   used   as   packaging   when   the
cartridges

  are   not   in   use.
Never
  try   to   refill   the   cartridges   with
fragrances other than those available
from

  CITROËN   dealers.
k

eep out of reach of children and
animals.

A
void   contact   with   the   skin
and

  eyes.   If   swallowed,   consult   a
doctor

  and   show   him   the   packaging   or
product

  label.
The scented air freshener button A can
only

be

fixed

on

the

multifunction

roof

console


with

a

cartridge.
Therefore, always retain button A and
a

cartridge.
The

cartridges

are

available

from

CITROËN


dealers.
EaSE oF USE and CoMFoRT
4
Practical information

102
Berlingo-2-VP_en_Chap04_Ergonomie_ed01-2016
MODUTOP ROOF BARS
The maximum authorised weight on each
  roof   bar   is   35   kg. In
  all   cases,   the   load   must   rest   on
the non-slip bands provided for this
purpose

  and   must   not   touch   the   roof   or
the

  glazing   of   the   roof.
Recommendations for loading the
roof
This procedure requires the use of
a spanner supplied with the tools for
changing
  a   wheel.
These two longitudinal Modutop roof
bars   can   be   removed.
Chapter   9,   "Changing   a   wheel"  section.
-

Open
  the   protective   covers.
-

Slacken
  the   four   screws   using   the
spanner

  and   remove   them.
-

T
urn   the   bars   90°   placing   the
hollow

  parts   towards   the   front.
-

Refit
  the   the   4   screws   and   tighten
them

  using   the   spanner.
-

Close
  the   protective   covers.
-

Use the strap passages
A only to
secure
  the   load   firmly.
Practical information

103
Berlingo-2-VP_en_Chap04_Ergonomie_ed01-2016
ExTERIOR ROOF BARS
If you install transverse bars on these bars, refer to the weight values\
indicated
by  the   manufacturer   but   do   not   exceed:   75   kg.
EaSE oF USE and CoMFoRT
4
Practical information

104
Berlingo-2-VP_en_Chap04_Ergonomie_ed01-2016
Automatic switching on/off
The front courtesy lamp comes on when the  key   is   removed   from   the   ignition,   when the

  vehicle   is   unlocked,   when   one   of   the
 front doors is opened and for location of


the
  vehicle   using   the   remote   control.
It goes off gradually after the ignition is
switched on and when the vehicle is
locked.Front seats: comes on when one of the front doors is
opened. These are switched on and of
f by
means   of   a   manual   switch,   with
the

  ignition   on.
Rear
  seats:   comes   on   when
one of the rear doors is
opened.
If

  the   doors   remain   open   for
a

  few   minutes,   the   courtesy
lamps

  go   off.
Permanently
  off.
Permanently

on,

ignition

on.
Front courtesy lamp
COURTESY
LAMPS
Rear courtesy lamp Front individual reading lamps
Practical information

105
Berlingo-2-VP_en_Chap04_Ergonomie_ed01-2016
LOAD SPACE COVER (5 SEAT VERSION)
This rigid shelf conceals the objects stored  in   the   boot. Removing
Fold
  the   load   space   cover.
Detach   it   from   the   notches   A and B
pulling
  it   towards   you.
Raise
  it   and   remove   the   assembly.
Refitting
Place the load space cover in front
of A and B.
Push it forwards to insert the lugs in
the
  notches.
Unfold and clip into the notches C.
Folding
From
  the   boot,   fold   the   half-shelf,
raising

  it   to   detach   it   from   the   notch   C. Storing (according to version)
A
location   is   provided   in   the   back   of   the  rear
  seats   to   accommodate   the   load
space

  cover   folded   onto   itself.
Slide it vertically between the side
guides
  located   at   mid   seat   back   height.
Insert
  the   hinge   first,   with   the   free   flaps
turned

  upwards.
This rigid load space cover can
form
  a   shelf.   However,   as   a   safety
measure,

  do   not   place   objects
on

  it   which   could   become   dangerous
projectiles

  in   the   event   of   sharp   braking
or

  rear   impact.
EaSE oF USE and CoMFoRT
4
Practical information

106
Berlingo-2-VP_en_Chap04_Ergonomie_ed01-2016
12 volt socket (120 W max)
It is advisable to limit the use of this socket  to   avoid   discharging   the   battery.
Protective net
Open the cover located in the hook support.
Fix the top of the net in the notches,
having
  first   turned   the   bar   1/4   of   a   turn.
Ensure that the end of the bar engages
correctly
  in   the   metal   part   of   its
location.
Fix the straps in the locations provided
on

  the   floor.
Tighten
  the   net   using   the   straps.
Stowing rings
Use these rings to secure loads on the
floor.
The connection of an electrical
device not approved by CITR
o
Ë
n
,
such

as

a

USB

charger,

may

adversely af

fect the operation of
vehicle

electrical

systems,

causing

faults such as poor telephone reception
or interference with displays in the
screens.
Practical information

 107
Berlingo-2-VP_en_Chap04_Ergonomie_ed01-2016
REAR FITTINGS
(7 SEAT VERSION )
Cup holder
Any liquid carried in a cup (mug or other) on board which could spill,
presents   a   risk.
Take
  care.
12 volt socket (120 W max)
It is advisable to limit the use of this socket   to   avoid   discharging   the   battery.
Stowing rings
Use the stowing rings on the floor to secure  and   retain   your   loads   firmly.
The
  seat   belt   anchorages   must   not   be
used

  for   this   purpose.
 It

  is   recommended   that   the   load   is
immobilised

  by   securing   it   firmly
using the stowing rings on the
floor

.
EASE OF USE and COMFORT
4
Practical information

108
Berlingo-2-VP_en_Chap04_Ergonomie_ed01-2016
Storage flaps
Raise the corresponding flap.next to the boot sill, the recess is
intended to receive the roller tube
containing
  the   load   space   cover.
Seat belts
Ensure that the centre seat belt has
reeled in correctly to its carrier in the
roof.
Prevent
  the   row   3   seat   belt   buckles
from

  knocking   by   raising   them   as   close
as possible to the anchorages in the
roof.
The

  seat   belt   buckle   attachment   rings
on

  each   side   of   the   boot   must   not   be
used

  to   retain   loads.
