Citroen C ZERO 2015 1.G Owner's Manual

C-zero_en_Chap00_Couv-debut_ed01-2014
Handbook

C-zero_en_Chap00_Couv-debut_ed01-2014
On-line handbook
If the "MyCITRoËn" function is not available on the CITRoËn public website for your country, you
can find your handbook at the following address:
http://service.citroen.com/ddb/ Find your handbook on the CITROËN website, under "MyCITROËN".
Select:
Select one of the following means of access to
view your handbook on-line... This personal and customisable space allows you to establish direct and special contact with
CITROËN.
the language,
the vehicle, its body style,
the print edition of your handbook appropriate for the date of registration of your vehicle.
Scan this code for direct access to your handbook.
Referring to the handbook on-line also gives you
access to the latest information available, easily
identified by the bookmark, associated with this
symbol:

We draw your attention to the following...
keysa

fety warning
additional information
contributes to the protection of the environment
refer to the page indicated
Reading the detailed sections is essential to
make the most of your vehicle, in complete
safety.
Your vehicle is fitted with only some of the
equipment described in this document,
depending on the trim level, version and the
specifications for the country in which it is sold.
The fitting of electrical equipment or
accessories which are not recommended
by CITROËN may result in a failure of
your vehicle's electronic system. Contact
a CITROËN dealer for information on the
recommended equipment and accessories.
CITRoËn h
as a presence on every continent,
a complete product range,
bringing together technology and a permanent spirit of innovation,
for a modern and creative approach to mobility.
We thank you and congratulate you on your choice.
Happy motoring!
at the wheel of your new vehicle,
g etting to know each system,
each control, each setting,
makes your trips, your journeys
more comfortable and more enjoyable.

.
.
C-zero_en_Chap00a_sommaire_ed01-2014
Instrument panel 9
In dicator and warning lamps
10
M

ain battery state of charge indicator
18
E

nergy consumption
/ g
eneration indicator
19
D

istance recorder
20
T

rip distance recorder
20
L

ighting dimmer
21
S

ervice indicator
21
R

ange indicator
23
Monitoring
over
view
Eco-driving
Remote control key 24
D oors
27
Boo

t
28
E

lectric windows
29
C

harging flaps
30
access
Front seats 31
R ear seats
33
M

irrors
35
In

terior fittings
37
V

entilation
40
H

eating
42
A

ir conditioning
42
F

ront demist - defrost
45
R

ear screen demist - defrost
45
Comfort
Driving recommendations 46
S tarting - stopping the vehicle
47
P

arking brake
48
D

rive selector
49
Driving
Lighting controls 51
A utomatic illumination of headlamps
53
H

eadlamp adjustment
53
W

iper control
54
C

ourtesy lamp
55
Visibility
Contents

.
.
C-zero_en_Chap00a_sommaire_ed01-2014
Direction indicators 56
A utomatic operation of brake lamps
56
H

azard warning lamps
56
H

orn
57
E

mergency or assistance call
57
U

nder-inflation detection
58
B

raking assistance systems
62
T

rajectory control systems
64
F

ront seat belts
65
A

irbags
68
Safety
Child seats 72
D eactivating the passenger's front airbag
75
I

SOFIX child seats
81
C

hild lock
84
Child safety
Charging the main battery 85
A ncillaries battery
93
T

emporary puncture repair kit
97
C

hanging a wheel
10
1
Snow chains
10

5
Changing a bulb
10

6
Changing a fuse
11

4
Changing a wiper blade
11

9
Towing the vehicle
11

9
Precautions for washing
12

0
Accessories
12

0
Practical information
Bonnet 123
F ront compartment
12
4
Rear compartment
12

5
Checking levels
12

6
Chec ks
128
Checks
Motor and main battery 12 9
Weights
13 0
D

imensions
13
1
Identification markings
13

2
Technical data
Emergency or assistance 133
Audio system / Bluetooth
13
5
Audio and telematics
Visual search
Alphabetical index

Contents

85
91
64
97
4
C-zero_en_Chap00b_vue-ensemble_ed01-2014
Normal charging flap
This flap should be used to recharge your
vehicle from a domestic power point.
Fast charging flap
Available according to equipment, this flap
should be used to recharge your vehicle from a
special fast charging station.
Temporary puncture repair kit
This kit is a complete system consisting of a
compressor and a sealant cartridge, to allow
the temporary repair of a tyre.
Exterior
ASR and ESP systems
These are associated systems that assure the
directional stability of the vehicle, within the
limits of the laws of physics
Over view

30135
49 42
5
C-zero_en_Chap00b_vue-ensemble_ed01-2014
Interior
Drive selector
Four-position drive selector: P, R, N and D .
Charging flap interior opening
controls
Air conditioning
After setting the desired level of comfort, the
system controls this level according to the
exterior climatic conditions.
Audio system
This system benefits from the latest
technology: MP3 compatible audio system,
USB player, Bluetooth hands-free system, ...
Normal charging flap.
Fast charging flap (according to equipment).
.
Over view

6
C-zero_en_Chap00b_vue-ensemble_ed01-2014
Instruments and controls
1. Lighting and direction indicator stalk.
2. In strument panel.
3.
Dr

iver's airbag.
Ho

rn.
4.
US

B port.
5.
Op

ening control for the fast charging flap
(vehicle left hand side).
6.
El

ectric window switches and switch
for deactivating the the front and rear
passenger electric window controls.
7.
Fus

ebox.
8.
Op

ening control for the normal charging
flap (vehicle right hand side).
9.
He

adlamp height adjustment.
AS

R /ESP deactivation switch.
10.
Do

or mirror controls.
11.
Cu

p holder.
12 .
Si

de vents.
13.
Wi

ndow demisting vent.
Over view

7
C-zero_en_Chap00b_vue-ensemble_ed01-2014
Instruments and controls
1. Steering lock and ignition switch.
2. Wi per stalk.
3.
Wi

ndscreen demisting vents.
4.
Gl

ove box.
Pa

ssenger's airbag deactivation.
5.
Bo

nnet release lever.
6.
Pa

rking brake.
7.
Dr

ive selector.
8.
12 V a

ccessory socket.
9.
He

ating
/ a
ir conditioning controls.
10.
Em

ergency or assistance call.
11.
Ha

zard warning switch.
12 .
Ce

ntre vents.
13.
Au

dio system.
.
Over view

8
C-zero_en_Chap00c_Eco-conduite_ed01-2014
For more economical driving, and increased rangePractical advice for everyday use to optimise the range of your vehicle by conserving battery power.
Adopt a smooth driving
style
The electrical consumption of your vehicle
depends greatly on your journey, your driving
style and your speed.
In all cases, adopt a smooth driving style.
Stay in the "Eco" zone indicated in the energy
consumption
/ g
eneration meter: depress
the accelerator pedal progressively, without
sudden movement, and if the conditions permit,
drive at steady and moderate speed.
Recover energy
Anticipating the driving conditions allows you to
recover energy and increase the range of your
vehicle.
Use the "Charge" zone of the energy
consumption
/ g

eneration meter whenever
possible: anticipate the traffic slowing
down and if the the conditions permit, use
deceleration rather than the brakes.
Control the use of your
electrical equipment
The heating and air conditioning systems
operate on energy from the main battery.
Excessive use of these systems greatly
reduces the range of your vehicle. Remember
to switch them off once the desired level of
comfort is reached and check their settings
every time you set off.
Control also the use of demisting
/ d

efrosting
and the heated seat.
Limit the causes of excess
consumption
As with any vehicle, limit the loads carried
in the vehicle and reduce wind resistance
(windows open above 30 mph (50 km/h), roof
bars, roof box, …).
Observe the recommendations
on maintenance
Check the tyre pressures regularly and
follow the schedule for routine servicing
recommended by CITROËN.
Eco-driving
