Page 27 of 222
30
MULTIFUNCTION SCREENS
MONOCHROME SCREEN A Controls
Displays in the screen
This displays the following information:
- time,
- date,
- a m b i e n t t e m p e r a t u r e ( t h i s fl a s h e s i f there is a risk of ice),
- state of the openings (doors, boot, ...),
- audio sources (radio, CD, ...),
- trip computer (refer to the end of the section).
Warning messages or information mes-
sages may appear temporarily. These
can be cleared by pressing the "ESC"
button. Main menu
Press the "MENU" button for access
to the main menu , then press the
" " or " " buttons to scroll through
the various menus:
- radio-CD,
- v e h i c l e c o n fi g u r a t i o n ,
- options,
- display settings,
- language,
- units.
Press the "OK" button to select the
menu required.
From the audio equipment control panel,
you can:
press the "MENU" button for access
to the main menu ,
press the " " or " " buttons to scroll
through the items on the screen,
press the "MODE" button to change
the permanent application (trip com-
puter, audio source, ...),
press the " " or " " buttons to
change a setting value,
press the "OK" b u t t o n t o c o n fi r m ,
or
press the "ESC" button to abandon
the operation in progress. Radio-CD
With the audio equipment switched on,
once the "Radio-CD" menu has been
selected you can activate or deacti-
vate the functions linked with use of the
radio (RDS, REG) or the CD (introscan,
s h u f fl e , C D r e p e a t ) .
For more information on the "Radio-
CD" application, refer to the Audio sys-
tem part of the "Audio and Telematics"
section.
Page 29 of 222
32
MULTIFUNCTION SCREENS
MONOCHROME SCREEN A ASSOCIATED
WITH THE MYWAY SATELLITE
NAVIGATION COLOUR SCREEN
Main menu
Displays in screen A
This displays the following information:
- a m b i e n t t e m p e r a t u r e ( t h i s fl a s h e s i f there is a risk of ice),
- trip computer (refer to the end of the section).
Warning messages or information mes-
sages may appear temporarily. These
can be cleared by pressing the "ESC"
button. Controls
There are three display control buttons:
- "ESC" to abandon the operation in
progress,
- "MENU" to scroll through the menus
or sub-menus,
- "OK" to select the menu or sub-
menu required.
Press the "MENU" button to scroll
through the various menus of the
main menu :
- v e h i c l e c o n fi g u r a t i o n ,
- options,
- language,
- units.
Press the "OK" button to select the
menu required.
V e h i c l e c o n fi g u r a t i o n
O n c e t h e " V e h i c l e c o n fi g u r a t i o n " m e n u
has been selected, you can activate or
deactivate the following systems:
- wiper linked with reverse gear (refer to the "Visibility" section),
- "guide-me-home" lighting (refer to the "Visibility" section).
Page 31 of 222
34
MULTIFUNCTION SCREENS
Displays in the screen
This displays the following information:
- time,
- date,
- a m b i e n t t e m p e r a t u r e ( t h i s fl a s h e s i f there is a risk of ice),
- state of the openings (doors, boot, etc.),
- audio sources (radio, CD, USB port, etc.),
- trip computer (refer to the end of the section).
Warning messages or information mes-
sages may appear temporarily. These
can be cleared by pressing the "ESC"
button. From the audio system control panel,
you can:
press the "MENU" button to gain
access to the main menu ,
press the " " or " " buttons to scroll
through the items on the screen,
press the "MODE" button to change
the permanent application (trip com-
puter, audio source, ...),
press the " " or " " buttons to
change a setting value,
press the "OK" b u t t o n t o c o n fi r m ,
or
press the "ESC" button to abandon
the operation in progress. Main menu
Press the "MENU" button to gain
access to the main menu :
- audio functions,
- the trip computer (refer to the end of the section),
- p e r s o n a l i s a t i o n - c o n fi g u r a t i o n ,
- telephone (hands-free kit).
Press the " " or " " buttons to se-
l e c t t h e m e n u r e q u i r e d , t h e n c o n fi r m
by pressing the "OK" button.
MONOCHROME SCREEN C Controls
"Audio functions" menu
With the audio equipment switched on,
once this menu has been selected you
can activate or deactivate the functions
linked with use of the radio (RDS, REG,
R a d i o T e x t ) , t h e C D ( i n t r o s c a n , s h u f fl e ,
CD repeat) or the MP3 player (USB
port).
For more information on the "Audio func-
tions" application, refer to the Audio sys-
tems part of the "Audio and Telematics"
section.
Page 32 of 222
35
MULTIFUNCTION SCREENS
"Trip computer" menu
Alert log
This summarises the active warning
messages, displaying them in succes-
sion in the multifunction screen.
Once this menu has been selected, you
can consult information concerning the
status of the vehicle (alert log, status of
functions, etc.)
D e fi n e t h e v e h i c l e p a r a m e t e r s
Once this menu has been selected, you
can activate or deactivate the following
systems:
- wiper linked with reverse gear (refer
to the "Visibility" section),
- "guide-me-home" lighting "Personalisation-
Configuration" menu
Once this menu has been selected, you
can gain access to the following func-
tions:
- d e fi n e t h e v e h i c l e p a r a m e t e r s ,
- d i s p l a y c o n fi g u r a t i o n ,
- choice of language.
Status of functions
This summarises the status (active or
inactive) of the vehicle’s functions.
Enter distance to destination
This allows you to enter an approximate
d i s t a n c e u n t i l y o u r fi n a l d e s t i n a t i o n .
Press the "MENU" button for ac-
cess to the main menu.
Press the arrows, then the "OK"
button to select the " Trip computer "
menu.
In the " Trip computer " menu, select
one of the following applications :
Page 34 of 222
37
MULTIFUNCTION SCREENS
TRIP COMPUTER
Press the button, located at the end
of the wiper stalk , to display the
various items of trip computer data
in succession. The trip computer provides the following
information:
System which provides current informa-
tion concerning the trip travelled (range,
fuel consumption...).
Press the control for more than two
seconds to reset to zero the distance
travelled, the average fuel consump-
tion and the average speed.
Monochrome screen A
Zero reset
Information displays - range,
- current fuel consumption,
- distance travelled,
- average fuel consumption,
- average speed.
The next press then returns you to
the normal display.
Page 36 of 222
i
i
!
39
MULTIFUNCTION SCREENS
A few definitions…
When the range falls below 20 miles
( 3 0 k m ) , d a s h e s a r e d i s p l a y e d . A f t e r fi l l -
ing with at least 5 litres of fuel, the range
is recalculated and is displayed when it
exceeds 60 miles (100 km).
If dashes are displayed continu-
ously while driving in place of the
digits, contact a CITROËN dealer. This function is only displayed from
20 mph (30 km/h).
This value may vary following
a change in the style of driving
or the relief, resulting in a sig-
n i fi c a n t c h a n g e i n t h e c u r r e n t f u e l
consumption. Range
(miles or km)
This indicates the distance
which can still be travelled
with the fuel remaining in the tank in
relation to the average fuel consump-
tion over the last few miles (kilometres)
travelled. Current fuel consumption
(mpg or l/100 km or km/l)
This is the average fuel con-
sumption during the last few
seconds.
Average fuel consumption
(mpg or l/100 km or km/l)
This is the average fuel
consumption since the last
trip computer zero reset. Distance travelled
(miles or km)
This indicates the distance
travelled since the last trip
computer zero reset.
Average speed
(mph or km/h)
This is the average speed
calculated since the last trip
computer zero reset (igni-
tion on). Distance remaining to
destination
(miles or km)
This is the distance remaining
t o b e t r a v e l l e d t o t h e fi n a l d e s t i n a t i o n . I t
is either calculated instantly by the navi-
gation system, if guidance is activated,
or entered by the user.
If the distance is not entered, dashes
are displayed in place of the digits.
Page 170 of 222
155
The MyWay is protected in such a way that it will only operate in your vehicle. If it is to be installed in another v e h i c l e , c o n t a c t a C I T R O Ë N d e a l e r f o r c o n fi g u r a t i o n o f operate in your vehicle. If it is to be installed in another operate in your vehicle. If it is to be installed in another
the system.
Certain functions described in this handbook will become available during the year.
MYWAY
For safety reasons, the driver must carry out operations which require prolonged attention while the vehicle is stationary.
When the engine is switched off and to prevent discharging of the battery, the MyWay switches off following the activation of the Energy Economy mode.
MULTIMEDIA AUDIO SYSTEM/BLUETOOTH TELEPHONE
SATELLITE NAVIGATION SYSTEM FOR EUROPE BY SD CARD
01 First steps
CONTENTS
02 Steering mounted controls
03 General operation
04 Navigation - Guidance
05 Traffic information
06 Radio
07 Music media players
08 Bluetooth telephone
09 Configuration
10 Trip computer p.
p.
p.
p.
p.
p.
p.
p.
p.
p.
11 Screen menu map
Frequently asked questions p.
p. 156
157
158
161
169
171
172
175
177
178
179
183
Page 171 of 222
01
11
55
1010
22
334466
1313
1111
99
14141515
778812121616
156
1. Engine not running - S h o r t p r e s s : o n / o f f . - L o n g p r e s s : C D p a u s e , m u t e f o r t h e r a d i o . Engine running - S h o r t p r e s s : C D p a u s e , m u t e f o r t h e r a d i o . - L o n g p r e s s : r e i n i t i a l i s a t i o n o f t h e s y s t e m . 2. Volume adjustment (each source is independent, including also navigation m e s s a g e s a n d a l e r t s ) . 3 . A c c e s s t o t h e " R a d i o " M e n u . D i s p l a y t h e l i s t o f stations. 4 . A c c e s s t o t h e " M u s i c " M e n u . D i s p l a y t h e tracks.
5 . A c c e s s t o t h e " S E T U P " m e n u . L o n g p r e s s : a c c e s s t o t h e G P S c o v e r a g e a n d the demonstration mode. 6 . A c c e s s t o t h e " P h o n e " M e n u . D i s p l a y t h e c a l l list. 7 . A c c e s s t o t h e " M O D E " m e n u . S e l e c t i o n o f t h e s u c c e s s i v e d i s p l a y o f : R a d i o , M a p , N A V ( i f n a v i g a t i o n i s i n p r o g r e s s ) , T e l e p h o n e ( i f a c o n v e r s a t i o n i s i n p r o g r e s s ) , Trip computer. L o n g p r e s s : d i s p l a y o f a b l a c k s c r e e n ( D A R K ) . 8 . A c c e s s t o t h e " N a v i g a t i o n " M e n u . D i s p l a y t h e last destinations. 9 . A c c e s s t o t h e " T r a f fi c " M e n u . D i s p l a y t h e c u r r e n t t r a f fi c a l e r t s . 1 0 . E S C : a b a n d o n t h e o p e r a t i o n i n p r o g r e s s . 1 1 . C D e j e c t .
1 2 . S e l e c t i o n o f t h e p r e v i o u s / n e x t r a d i o s t a t i o n from the list. S e l e c t i o n o f t h e p r e v i o u s / n e x t M P 3 f o l d e r . S e l e c t i o n o f t h e p r e v i o u s / n e x t p a g e o f a l i s t . 1 3 . S e l e c t i o n o f t h e p r e v i o u s / n e x t r a d i o s t a t i o n . S e l e c t i o n o f t h e p r e v i o u s / n e x t C D o r M P 3 t r a c k . S e l e c t i o n o f t h e p r e v i o u s / n e x t l i n e o f a l i s t . 1 4 . B u t t o n s 1 t o 6 : S e l e c t i o n o f t h e s t o r e d r a d i o s t a t i o n . L o n g p r e s s : s t o r e t h e c u r r e n t r a d i o s t a t i o n . 1 5 . S D c a r d r e a d e r ( n a v i g a t i o n S D c a r d o n l y ) . 1 6 . D i a l f o r s e l e c t i o n o f t h e s c r e e n d i s p l a y a n d according to the context of the menu. S h o r t p r e s s : c o n t e x t u a l m e n u o r c o n fi r m a t i o n . L o n g p r e s s p r e s s : c o n t e x t u a l m e n u s p e c i fi c t o the list displayed.
FIRST STEPS
MyWay CONTROL PANEL
3 - 4 . L o n g p r e s s : a c c e s s t o t h e a u d i o s e t t i n g s : f r o n t / r e a r f a d e r a n d l e f t / r i g h t b a l a n c e , b a s s /treble, equaliser, loudness, automatic volume adjustment, initialise the settings.
Page 172 of 222
03
158
GENERAL OPERATION
For a detailed global view of the menus available, refer to the " S c r e e n m e n u m a p " s e c t i o n .
P r e s s t h e M O D E b u t t o n s e v e r a l t i m e s i n s u c c e s s i o n f o r a c c e s s t o t h e f o l l o w i n g m e n u s :
F o r c l e a n i n g t h e s c r e e n , t h e u s e o f a s o f t , n o n - a b r a s i v e c l o t h ( s p e c t a c l e s c l o t h ) i s r e c o m m e n d e d , w i t h n o a d d i t i o n a l p r o d u c t .
RADIO/MUSIC MEDIA PLAYERS
TELEPHONE
( I f a c o n v e r s a t i o n i s i n p r o g r e s s )
FULL SCREEN MAP
NAVIGATION
( I f g u i d a n c e i s i n p r o g r e s s )
SETUP:
system language * , date and time * , display, vehicle s e t t i n g s * , u n i t a n d s y s t e m s e t t i n g s , " D e m o m o d e " . TRAFFIC:
TMC information and messages.
* Available according to model.
TRIP COMPUTER
Page 173 of 222
03
159
GENERAL OPERATION
A p r e s s o n t h e O K d i a l g i v e s a c c e s s t o s h o r t - c u t m e n u s a c c o r d i n g t o t h e d i s p l a y on the screen.
DISPLAY ACCORDING TO THE CONTEXT
NAVIGATION (IF GUIDANCE IS IN PROGRESS):
TRIP COMPUTER:
Abort guidance
Repeat advice
Block road
Route info
S h o w d e s t i n a t i o n
Trip info
Route type
Avoid
S a t e l l i t e s
Z o o m / S c r o l l
Voice advice
Route options
Alert log
Status of functions
1
2
3
3
2
1
1
1
3
1
1
1
1
2 TELEPHONE:
End call
Hold call
Dial
DTMF-Tones
Private mode
Micro off
1
1
1
1
1
1
