Page 90 of 337
81
IV
A C C E S S
Emergency boot lid release
System for mechanical unlocking of
the boot in the event of a battery or
central locking malfunction.
Unlocking
Fold back the rear seats to gain
access to the lock from inside
the boot.
Insert a small screwdriver into
hole A of the lock to unlock the
tailgate.
Push the white part, located
inside the lock, to the left to
unlock the boot.
PANORAMIC GLASS ROOF
System which consists of a pano-
ramic tinted glass surface to increase
the light and visibility in the passenger
compartment.
Fitted with an electric blind in several
sections to improve thermal and
aural comfort.
Opening the roof blind
Rotate the control B to slide the
roof blind to the position desired
(positions 1 to 9 ). Closing the roof blind
Rotate the control B to posi-
tion 0 to close the roof blind.
Recommendations
- Pressing the locking button on the remote control for more than
two seconds will close the blind
(practical when, for example,
you leave your vehicle on a sun-
lit car park).
- On returning to your vehicle, a press on the button B reposi-
tions the blind to the last position
selected.
Anti-pinch
The blind has an anti-pinch function.
At the end of its travel, when the blind
encounters an obstacle on closing, it
stops and moves back slightly.
Following a fault or after a battery
disconnection during the movement
of the blind or after it has stopped,
you have to re-initialise the anti-
pinch function:
place the blind in the closed
position,
press button B for approximately
two seconds.
Page 91 of 337
80
A C C E S S
BOOT
After unlocking the vehicle com-
pletely using the remote control
or the key, with the rear screen
closed, pull on the handle 1 and
raise the tailgate.
Lower the tailgate using one of
the two handholds 3 , located on
the interior boot trim. -
when the engine is run-
ning , this warning lamp
comes on, accompanied
by a message on the
multifunction screen for a
few seconds,
- when the vehicle is moving
(speed above 6 mph (10 km/h)),
this warning lamp comes on, ac-
companied by an audible signal
and a message on the multifunc-
tion screen for a few seconds.
If the tailgate is not closed correctly:
REAR SCREEN
This opening gives easy access
to the boot, even if you are parked
close to a wall or another vehicle. Closing
Lower the rear screen guiding
it with the wiper arm until it is
closed.
If the rear screen is not closed
correctly: - when the engine is run-
ning , this warning lamp
comes on, accompanied
by a message on the
multifunction screen for a
few seconds,
- when the vehicle is moving
(speed above 6 mph (10 km/h)),
this warning light comes on, ac-
companied by an audible signal
and a message on the multifunc-
tion screen for a few seconds.
The boot and the rear screen
cannot both be open at the same
time.
When the rear screen is open, you
can access the boot by raising the
rear shelf using its tab (C4 Picasso).
After unlocking the vehicle com-
pletely using the remote control
or the key, with the boot closed,
press the control 2 and raise the
rear screen using the base 4 of
the wiper arm.
Past the balancing point, allow
the tailgate to lower and close
itself (do not assist it or slow it
down).
Opening
Opening
Closing
Page 92 of 337
81
IV
A C C E S S
Emergency boot lid release
System for mechanical unlocking of
the boot in the event of a battery or
central locking malfunction.
Unlocking
Fold back the rear seats to gain
access to the lock from inside
the boot.
Insert a small screwdriver into
hole A of the lock to unlock the
tailgate.
Push the white part, located
inside the lock, to the left to
unlock the boot.
PANORAMIC GLASS ROOF
System which consists of a pano-
ramic tinted glass surface to increase
the light and visibility in the passenger
compartment.
Fitted with an electric blind in several
sections to improve thermal and
aural comfort.
Opening the roof blind
Rotate the control B to slide the
roof blind to the position desired
(positions 1 to 9 ). Closing the roof blind
Rotate the control B to posi-
tion 0 to close the roof blind.
Recommendations
- Pressing the locking button on the remote control for more than
two seconds will close the blind
(practical when, for example,
you leave your vehicle on a sun-
lit car park).
- On returning to your vehicle, a press on the button B reposi-
tions the blind to the last position
selected.
Anti-pinch
The blind has an anti-pinch function.
At the end of its travel, when the blind
encounters an obstacle on closing, it
stops and moves back slightly.
Following a fault or after a battery
disconnection during the movement
of the blind or after it has stopped,
you have to re-initialise the anti-
pinch function:
place the blind in the closed
position,
press button B for approximately
two seconds.
Page 93 of 337
82
IV
A C C E S S
FUEL TANK
Capacity of the tank: approxi-
mately 60 litres.
Low fuel level
When the minimum level in the
tank is reached, this warning
lamp on the instrument panel
comes on, accompanied by
an audible warning and a message
on the multifunction screen.
You have enough fuel left to drive
approximately 30 miles (approx.
50 kms).
Press on the the control A , situ-
ated on the control panel on the
r i g h t h a n d s i d e . T h e f u e l fl a p a u -
tomatically opens up. The petrol or diesel engine of your
v e h i c l e i s fi t t e d w i t h a c a t a l y t i c c o n -
verter, a device which helps to re-
duce the level of harmful emissions
in the exhaust gases.
For petrol engines, unleaded fuel
is obligatory.
T h e fi l l e r n e c k i s n a r r o w e r , p e r m i t -
ting unleaded petrol only.
Take care to select the pump
that corresponds to the correct
fuel type for your vehicle.
Introduce the nozzle so as to
push in the metallic gate valve B.
Make sure that the nozzle is
pushed in as far as possible
before starting to refuel (risk of
blowback).
Maintain this position throughout
the refuelling operation.
P u s h t h e f u e l fl a p t o r e c l o s e i t .
Fuel cut-off switch
Your vehicle is equipped with a safe-
ty device which cuts off the fuel sup-
ply in the event of a collision.
Refuelling
I f y o u a r e fi l l i n g y o u r t a n k t o t h e
top, do not persist after the third
cut-off; this could cause your
vehicle to malfunction.
Page 94 of 337
83
IV
A C C E S S
UNLEADED PETROL After switching off the ignition, the
control
A is active for only a few
minutes. If necessary, switch on
the ignition again to reactivate it.
If you have put in fuel that is
wrong for your vehicle, it is es-
sential to have the tank drained
before you start the engine.
Fuel quality
A l a b e l a f fi x e d t o t h e i n s i d e o f t h e
f u e l fl a p i n d i c a t e s t h e f u e l s t h a t a r e
authorised.
DIESEL FUEL
The petrol engines are designed to
run on RON 95.
However, for better vehicle perform-
ance (petrol engines), we recom-
mend RON 98.
Page 95 of 337
84
V I S I B I L I T Y
LIGHTING CONTROLS
System for selection and control of
the various front and rear lamps pro-
viding the vehicle's lighting.
Main lighting
The various front and rear lamps of
the vehicle are designed to adapt
the driver's visibility progressively in
relation to the climatic conditions:
- sidelamps, to be seen,
- dipped headlamps to see with-out dazzling other drivers,
- main beam headlamps to see clearly when the road is clear,
- directional headlamps for im- proved visibility when cornering.
Additional lighting
O t h e r l a m p s a r e fi t t e d t o f u l fi l t h e r e -
quirements of particular driving con-
ditions:
- a rear foglamp to be seen from a distance,
- front foglamps for even better forward vision,
- daytime running lamps to be seen during the day. Programming
Various automatic lighting control
modes are also available depending
on options:
- guide-me-home lighting,
- automatic lighting,
- directional lighting.
Manual controls
lamps off,
automatic switching on of
the lamps,
sidelamps only,
dipped headlamps or
main beam headlamps.
B. stalk for switching headlamps by
pulling: dipped headlamps/main
beam headlamps.
In the lamps off and sidelamps
modes, the driver can switch on the
main beam headlamps temporarily
( " h e a d l a m p fl a s h " ) b y m a i n t a i n i n g a
pull on the stalk.
Displays
Lighting of the corresponding indi-
cator lamp on the instrument panel
c o n fi r m s t h e s e l e c t i v e s w i t c h i n g o n
of the lighting selected.
The lighting commands are issued
directly by the driver by means of
the ring
A and the stalk B .
A. main lighting mode selection ring,
with:
Page 97 of 337
86
V I S I B I L I T Y
V
* According to country.
Daytime-running lamps *
System which switches on the ve-hicle's dipped headlamps automati-cally on starting.
This safety system makes the vehi-cle more visible to other road users during the day.
The lighting of the instruments and controls (instrument panel, multi-function screen, air conditioning c o n t r o l p a n e l , . . . ) i s i n d e p e n d e n t o f this function. It is provided by the automatic lighting mode or when the lamps are switched on manually.
Manual guide-me-home
lighting
The temporary lighting of dipped
headlamps after the vehicle's igni-
tion has been switched off makes
the driver's exit easier when the light
is poor.
Switching on
W i t h t h e i g n i t i o n o f f , " fl a s h " t h e
headlamps using the lighting
stalk B .
A s e c o n d " h e a d l a m p fl a s h "
switches the function off again.
Switching off
The manual guide-me-home lighting
switches off automatically after a set
time.
The manual guide-me-home light-
ing is also available by pressing the
lighting button on the remote con-
trol (refer to the section "Access -
§ R e m o t e c o n t r o l k e y " ) . Automatic lighting
The sidelamps and dipped head-
lamps are switched on automatically,
without any action on the part of the
driver, when a low level of external
light is detected or in certain cases of
activation of the windscreen wipers.
As soon as the brightness returns
t o a s u f fi c i e n t l e v e l o r a f t e r t h e w i n d -
screen wipers are switched off, the
lights are switched off automatically.
Activation
Turn ring A to the "AUTO" posi-
tion. The automatic lighting is ac-
companied by a message on the
multifunction screen.
Deactivation
Turn ring A to a position other
than "AUTO" . Deactivation is
accompanied by a message on
the multifunction screen.
regulations:
-by default, this function is activated,
-the sidelamps and the number plate lamps are also switched on.
Page 98 of 337
87
V I S I B I L I T Y
V
Linking with the automatic
"Guide-me-home" lighting
Association with the automatic light-
ing provides the "guide-me-home"
lighting with the following additional
options:
- selection of the lighting duration for 15, 30 or 60 seconds in the
vehicle parameters on the mul-
t i f u n c t i o n s c r e e n c o n fi g u r a t i o n
menu (in the case of the mono-
chrome screen A, the duration is
fi x e d ) ,
- automatic activation of "guide- me-home" lighting when auto-
matic lighting is in operation.
Operating fault
In the event of a malfunction of
the brightness sensor, the lighting
comes on, a message appears on
the multifunction screen, accompa-
nied by an audible signal.
Consult a CITROËN dealer. In fog or snow, the brightness
s e n s o r m a y d e t e c t s u f fi c i e n t l i g h t .
Therefore, the lights will not come
on automatically.
Do not cover the brightness sen-
sor, linked with the rain sensor and
located in the centre of the wind-
screen behind the interior mirror;
the associated functions would no
longer be controlled.
EXTERIOR SIDE SPOTLAMPS
These illuminate:
- the zones facing the driver’s and passenger’s doors,
- the zones forward of the door mirrors and rearward of the front
doors.
Switching on
The side spotlamps come on:
- when you unlock the vehicle or press on the lighting button on
the remote control,
- when you remove the key from the ignition,
- when you open a door,
- when you use the remote control.
Switching off
They are timed to go out automati-
cally.
THE HEADLAMPS
To avoid dazzling other road users,
the height of the halogen bulb head-
lamps must be adjusted according
to the load in the vehicle. To do this,
turn the control, located below the
fascia to the right of the driver, to the
appropriate position:
0. 1 or 2 people in the front seats.
-. 3 people.
1. 4 to 7 people.
-. Intermediate setting.
2. 4 to 7 people + maximum author-
ised loads.
-. Intermediate setting.
3.
Driver + maximum authorised loads.
Initial setting is position "0".
Page 100 of 337
86
V I S I B I L I T Y
V
* According to country.
Daytime-running lamps *
System which switches on the ve-hicle's dipped headlamps automati-cally on starting.
This safety system makes the vehi-cle more visible to other road users during the day.
The lighting of the instruments and controls (instrument panel, multi-function screen, air conditioning c o n t r o l p a n e l , . . . ) i s i n d e p e n d e n t o f this function. It is provided by the automatic lighting mode or when the lamps are switched on manually.
Manual guide-me-home
lighting
The temporary lighting of dipped
headlamps after the vehicle's igni-
tion has been switched off makes
the driver's exit easier when the light
is poor.
Switching on
W i t h t h e i g n i t i o n o f f , " fl a s h " t h e
headlamps using the lighting
stalk B .
A s e c o n d " h e a d l a m p fl a s h "
switches the function off again.
Switching off
The manual guide-me-home lighting
switches off automatically after a set
time.
The manual guide-me-home light-
ing is also available by pressing the
lighting button on the remote con-
trol (refer to the section "Access -
§ R e m o t e c o n t r o l k e y " ) . Automatic lighting
The sidelamps and dipped head-
lamps are switched on automatically,
without any action on the part of the
driver, when a low level of external
light is detected or in certain cases of
activation of the windscreen wipers.
As soon as the brightness returns
t o a s u f fi c i e n t l e v e l o r a f t e r t h e w i n d -
screen wipers are switched off, the
lights are switched off automatically.
Activation
Turn ring A to the "AUTO" posi-
tion. The automatic lighting is ac-
companied by a message on the
multifunction screen.
Deactivation
Turn ring A to a position other
than "AUTO" . Deactivation is
accompanied by a message on
the multifunction screen.
regulations:
-by default, this function is activated,
-the sidelamps and the number plate lamps are also switched on.
Page 101 of 337
87
V I S I B I L I T Y
V
Linking with the automatic
"Guide-me-home" lighting
Association with the automatic light-
ing provides the "guide-me-home"
lighting with the following additional
options:
- selection of the lighting duration for 15, 30 or 60 seconds in the
vehicle parameters on the mul-
t i f u n c t i o n s c r e e n c o n fi g u r a t i o n
menu (in the case of the mono-
chrome screen A, the duration is
fi x e d ) ,
- automatic activation of "guide- me-home" lighting when auto-
matic lighting is in operation.
Operating fault
In the event of a malfunction of
the brightness sensor, the lighting
comes on, a message appears on
the multifunction screen, accompa-
nied by an audible signal.
Consult a CITROËN dealer. In fog or snow, the brightness
s e n s o r m a y d e t e c t s u f fi c i e n t l i g h t .
Therefore, the lights will not come
on automatically.
Do not cover the brightness sen-
sor, linked with the rain sensor and
located in the centre of the wind-
screen behind the interior mirror;
the associated functions would no
longer be controlled.
EXTERIOR SIDE SPOTLAMPS
These illuminate:
- the zones facing the driver’s and passenger’s doors,
- the zones forward of the door mirrors and rearward of the front
doors.
Switching on
The side spotlamps come on:
- when you unlock the vehicle or press on the lighting button on
the remote control,
- when you remove the key from the ignition,
- when you open a door,
- when you use the remote control.
Switching off
They are timed to go out automati-
cally.
THE HEADLAMPS
To avoid dazzling other road users,
the height of the halogen bulb head-
lamps must be adjusted according
to the load in the vehicle. To do this,
turn the control, located below the
fascia to the right of the driver, to the
appropriate position:
0. 1 or 2 people in the front seats.
-. 3 people.
1. 4 to 7 people.
-. Intermediate setting.
2. 4 to 7 people + maximum author-
ised loads.
-. Intermediate setting.
3.
Driver + maximum authorised loads.
Initial setting is position "0".
