IV
80
A C C E S S
STARTING
1. "S": Steering lock
To unlock the steering, gently move
the steering wheel while turning the
key, without forcing it.
2. "M": Ignition on
Depending on the version of your
vehicle, the orange and red warn-
ing lamps should also come on for
a short time.
3. "D": Starter
Release the key as soon the engine
has started.
If the fi rst attempt fails, switch off the
ignition. Wait ten seconds then oper-
ate the starter again. Steering lock

1. "
S": After removing the key, turn
the steering wheel to lock the
steering. The key can only be re-
moved in position S .

2. "M": Ignition switched on, the
steering is unlocked (by turning
the key to position M , move
the steering wheel gently if
necessary).

3. "D": Starter position.
Key left in position "M"
audible warning
If you forget to remove the key from
the ignition, the ignition is switched
off automatically after one hour.
To switch the ignition back on, turn
the key to position S then back to
position M .

Do not run the engine in an en-
closed space or where there is
insuffi cient ventilation
.

You must always to keep the
engine running when moving in
order to retain braking and steer-
ing power assistance .

Never remove the ignition key
before the vehicle has come to a
complete stop.
STOPPING
Vehicles equipped with a
turbocharger
Never stop the engine without having
allowed it to run for a few seconds at
idle, this being the time required for
the turbocharger to return to a normal
speed.
Flicking the accelerator at the mo-
ment of switching off the ignition
could cause serious damage.
A heavy object (key fob...), attached
to the key and weighing down on
its shaft in the ignition switch, could
cause a malfunction.
Never turn the key to this position
when the engine is running.

IV
81
A C C E S S
Remote control problem
Following disconnection of the ve-
hicle battery, replacement of the
remote control battery or in the event
of a remote control malfunction, you
can no longer unlock, lock or locate
your vehicle.

 First of all, use the key in the lock
to unlock or lock your vehicle.

 Then, reinitialise the remote
control.
If the problem persists, contact a
CITROËN dealer as soon as possible.
Reinitialisation

 Switch off the ignition.

 Turn the key to position 2
(Ignition on) .

 Press the closed padlock imme-
diately for a few seconds.

 Switch off the ignition and re-
move the key from the ignition
switch.
The remote control is fully opera-
tional again. Battery ref.: CR0523/3 volts.
This replacement battery is avail-
able from CITROËN dealers.
If the remote control bat-
tery is fl at, you are in-
formed by lighting of this
warning lamp, an audible
signal and a message on
the multifunction screen.

 Unclip the casing using a coin at
the notch.

 Slide the fl at battery out of its
location.

 Slide the new battery into its
location observing the original
direction.

 Clip the casing together.

 Reinitialise the remote control.
Changing the battery

IV
82
A C C E S S
Lost keys
Visit a CITROËN dealer with the vehi-
cle's V5 registration document and your personal identifi cation documents.
The CITROËN dealer will be able to
retrieve the key code and the trans-
ponder code required to order a
replacement key.
Remote control
The high frequency remote control is
a sensitive system; do not operate it
while it is in your pocket as there is a
possibility that it may unlock the vehi-
cle, without you being aware of it.
Do not repeatedly press the buttons
of your remote control out of range
and out of sight of your vehicle. You
run the risk of stopping it from work-
ing and the remote control would
have to be reinitialised.
The remote control does not operate
when the key is in the ignition, even
when the ignition is switched off, ex-
cept for reinitialisation.
Locking the vehicle
Driving with the doors locked may
make access to the passenger com-
partment by the emergency services
more diffi cult in an emergency.
As a safety precaution (with children
on board), remove the key from the
ignition when you leave the vehicle,
even for a short time. Anti-theft protection
Do not make any modifi cations to the
electronic engine immobiliser sys-
tem; this could cause malfunctions.
When purchasing a second-
hand vehicle
Have the key codes memorised by a
CITROËN dealer, to ensure that the
keys in your possession are the only
ones which can start the vehicle.

Do not throw the remote
control batteries away, they
contain metals which are
harmful to the environment.
Take them to an approved collection
point.

IV
79
A C C E S S
Deadlocking using the key

 Turn the key to the right in the driv-
er's door lock to lock the vehicle
completely and hold it in this posi-
tion for more than two seconds to
close the windows automatically
in addition to locking.

 Turn the key to the right again
within fi ve seconds to deadlock
the vehicle.
Deadlocking renders the exterior and
interior door controls inoperative.
It also deactivates the manual cen-
tral control button.
Therefore, never leave anyone inside
the vehicle when it is deadlocked.
Deadlocking also triggers the timed
illumination of the exterior side spot
lamps and guide-me-home lighting,
if this is activated.

 First press this button to fold the
key.
Locating your vehicle
This function allows you to identify
your vehicle from a distance, especial-
ly when the light is poor. Your vehicle
must be locked.

 Press the closed padlock on the
remote control.
This will bring on the courtesy lamps
and exterior side spotlamps, as well
as fl ashing the direction indicators
for a few seconds. Guide-me-home lighting
Anti-theft protection
Electronic engine immobiliser
The key contains an electronic chip
which has a special code. When the
ignition is switched on, this code
must be recognised in order for
starting to be possible.
This electronic engine immobiliser
locks the engine management sys-
tem a few minutes after the ignition
is switched off and prevents starting
of the engine by anyone who does
not have the key.
In the event of a mal-
function, you are in-
formed by lighting of
this warning lamp, an
audible signal and a
message on the multifunction screen.
In this case, your vehicle does not
start; contact a CITROËN dealer as
soon as possible.
Folding the key
A press on this button oper-
ates the guide-me-home light-
ing (lighting of the sidelamps,
dipped beam headlamps,
number plate lamps and exte-
rior side spotlamps (located underneath
the door mirrors)).
A second press before the end of the
timing cancels the guide-me-home
lighting.
Deadlocking is confi rmed by fi xed
lighting of the direction indicators for
approximately two seconds.
According to version, the door mir-
rors fold at the same time.

IV
82
A C C E S S
Lost keys
Visit a CITROËN dealer with the vehi-
cle's V5 registration document and your personal identifi cation documents.
The CITROËN dealer will be able to
retrieve the key code and the trans-
ponder code required to order a
replacement key.
Remote control
The high frequency remote control is
a sensitive system; do not operate it
while it is in your pocket as there is a
possibility that it may unlock the vehi-
cle, without you being aware of it.
Do not repeatedly press the buttons
of your remote control out of range
and out of sight of your vehicle. You
run the risk of stopping it from work-
ing and the remote control would
have to be reinitialised.
The remote control does not operate
when the key is in the ignition, even
when the ignition is switched off, ex-
cept for reinitialisation.
Locking the vehicle
Driving with the doors locked may
make access to the passenger com-
partment by the emergency services
more diffi cult in an emergency.
As a safety precaution (with children
on board), remove the key from the
ignition when you leave the vehicle,
even for a short time. Anti-theft protection
Do not make any modifi cations to the
electronic engine immobiliser sys-
tem; this could cause malfunctions.
When purchasing a second-
hand vehicle
Have the key codes memorised by a
CITROËN dealer, to ensure that the
keys in your possession are the only
ones which can start the vehicle.

Do not throw the remote
control batteries away, they
contain metals which are
harmful to the environment.
Take them to an approved collection
point.

IV
80
A C C E S S
STARTING
1. "S": Steering lock
To unlock the steering, gently move
the steering wheel while turning the
key, without forcing it.
2. "M": Ignition on
Depending on the version of your
vehicle, the orange and red warn-
ing lamps should also come on for
a short time.
3. "D": Starter
Release the key as soon the engine
has started.
If the fi rst attempt fails, switch off the
ignition. Wait ten seconds then oper-
ate the starter again. Steering lock

1. "
S": After removing the key, turn
the steering wheel to lock the
steering. The key can only be re-
moved in position S .

2. "M": Ignition switched on, the
steering is unlocked (by turning
the key to position M , move
the steering wheel gently if
necessary).

3. "D": Starter position.
Key left in position "M"
audible warning
If you forget to remove the key from
the ignition, the ignition is switched
off automatically after one hour.
To switch the ignition back on, turn
the key to position S then back to
position M .

Do not run the engine in an en-
closed space or where there is
insuffi cient ventilation
.

You must always to keep the
engine running when moving in
order to retain braking and steer-
ing power assistance .

Never remove the ignition key
before the vehicle has come to a
complete stop.
STOPPING
Vehicles equipped with a
turbocharger
Never stop the engine without having
allowed it to run for a few seconds at
idle, this being the time required for
the turbocharger to return to a normal
speed.
Flicking the accelerator at the mo-
ment of switching off the ignition
could cause serious damage.
A heavy object (key fob...), attached
to the key and weighing down on
its shaft in the ignition switch, could
cause a malfunction.
Never turn the key to this position
when the engine is running.

IV
81
A C C E S S
Remote control problem
Following disconnection of the ve-
hicle battery, replacement of the
remote control battery or in the event
of a remote control malfunction, you
can no longer unlock, lock or locate
your vehicle.

 First of all, use the key in the lock
to unlock or lock your vehicle.

 Then, reinitialise the remote
control.
If the problem persists, contact a
CITROËN dealer as soon as possible.
Reinitialisation

 Switch off the ignition.

 Turn the key to position 2
(Ignition on) .

 Press the closed padlock imme-
diately for a few seconds.

 Switch off the ignition and re-
move the key from the ignition
switch.
The remote control is fully opera-
tional again. Battery ref.: CR0523/3 volts.
This replacement battery is avail-
able from CITROËN dealers.
If the remote control bat-
tery is fl at, you are in-
formed by lighting of this
warning lamp, an audible
signal and a message on
the multifunction screen.

 Unclip the casing using a coin at
the notch.

 Slide the fl at battery out of its
location.

 Slide the new battery into its
location observing the original
direction.

 Clip the casing together.

 Reinitialise the remote control.
Changing the battery

IV
83
A C C E S S
ALARM
System which protects and provides
a deterrent against theft and break-
ins. It provides the following types of
monitoring.
- Exterior perimeter
The system checks for opening of
the vehicle.
The alarm is triggered if anyone tries
to open a door, the boot, the bonnet...
- Interior volumetric
The system checks for any variation
in the volume in the passenger com-
partment.
The alarm is triggered if anyone
breaks a window, enters the passen-
ger compartment or moves inside the
vehicle.
Self-protection function
The system checks for the putting
out of service of its components.
The alarm is triggered if the battery,
the central control or the wires of
the siren are put out of service or
damaged. Locking the vehicle with full
alarm system
Activation

 Switch off the ignition and get out
of the vehicle.

 Press the locking button on the
remote control. Deactivation

 Press the unlocking button on
the remote control.
The alarm system is deactivated:
the indicator lamp on the button
switches off.
If an opening (door, boot...) is not
closed fully, the vehicle is not locked
but the exterior perimeter monitor-
ing will be activated after a delay of
45 seconds at the same time as the
interior volumetric monitoring.
The monitoring system is active: the
indicator lamp on the button fl ashes
once per second.
After the locking button on the re-
mote control is pressed, the exterior
perimeter monitoring is activated
after a delay of 5 seconds and the
interior volumetric monitoring after a
delay of 45 seconds.
For all work on the alarm system,
contact a CITROËN dealer.

IV
84
A C C E S S
Locking the vehicle with
exterior perimeter monitoring
only
Deactivate the interior volumetric
monitoring to avoid unwanted trig-
gering of the alarm in certain cases
such as:
- leaving a pet in the vehicle,
- leaving a window partially open,
- washing your vehicle, To be effective, this deactivation
must be carried out each time the
ignition is switched off.
Deactivation of the interior
volumetric monitoring

 Switch off the ignition.

 Within ten seconds, press the
button until the indicator lamp is
lit continuously.

 Get out of the vehicle.

 Press the locking button on the
remote control immediately.
The exterior perimeter monitoring
alone is activated: the indicator lamp
on the button fl ashes once per second.
Triggering of the alarm
The monitoring functions remain
active until the alarm has been trig-
gered eleven times in succession.
When the vehicle is unlocked using
the remote control, rapid fl ashing
of the indicator lamp on the button
informs you that the alarm was trig-
gered during your absence. When
the ignition is switched on, this
fl ashing stops immediately. Failure of the remote control
To deactivate the monitoring func-
tions:
Locking the vehicle without
activating the alarm
Malfunction
Automatic activation *

 Lock or deadlock the vehicle us-
ing the key in the driver's door
lock.
When the ignition is switched on, fi xed
lighting of the indicator lamp on the
button indicates a malfunction of the
system.
Have it checked by a CITROËN dealer.
2 minutes after the last door or the
boot is closed, the system is activated
automatically.

 To avoid triggering the alarm on
entering the vehicle, fi rst press
the unlocking button on the re-
mote control.

 Unlock the vehicle using the key
in the driver's door lock.

 Open the door; the alarm is trig-
gered.

 Switch on the ignition; the alarm
stops. The indicator lamp on the
button switches off.
This is indicated by sounding of the
siren and fl ashing of the direction in-
dicators for thirty seconds.
Reactivation of the interior
volumetric monitoring

 Press the unlocking button on the
remote control to deactivate the
exterior perimeter monitoring.

 Press the locking button on the
remote control to activate all the
monitoring functions.
The indicator lamp on the button
again fl ashes once per second.
* According to country.

IV
85
A C C E S S
ELECTRIC WINDOWS
System intended to open or close a
window manually or automatically.
Fitted with a safety anti-pinch system
and a system for deactivation in the
event of misuse of the rear controls.

1.
Driver's electric window control.

2.

Passenger's electric window control.

3. Rear right electric window control.

4. Rear left electric window control.

5. Deactivation of the rear electric win-
dow and door controls. One-touch electric windows
There are two options:
-
automatic mode

 Press or pull the control
fi rmly. The window opens or
closes fully when the control is
released.

 Pressing the control again
stops the movement of the
window.
The electric window controls re-
main operational for approximately
45 seconds after the ignition is
switched off or until the vehicle is
locked after a door is opened.
If one of the passenger windows
cannot be operated from the driv-
er's door control panel, carry out
the operation from the control
panel of the passenger door con-
cerned, and vice versa. Safety anti-pinch
When the window rises and meets
an obstacle, it stops and partially
lowers again.
If the window cannot be closed (for
example, in the presence of ice),
immediately after the movement is
reversed:

 press and hold the control until
the window opens fully,


then pull the control immediately
and hold it until the window closes,

 continue to hold the control for
approximately one second after
the window has closed.

The safety anti-pinch function
is not operational during these
operations.
-
manual mode

 Press or pull the control gently.
The window stops when the
control is released.
