6
FAMILIARISATION


A.
Central locking

B.
Unlocking

C.
Remote lighting control

D.
Folding/unfolding the key

Press control A
, located on the switch
panel to the right of the dashboard. The
fuel fl ap automatically opens up fully.
Insert the pump nozzle so as to push in
the metal fl ap B
.
Push the fuel fi ller fl ap to close it.

After switching off the ignition, con-
trol A
is only active for a few minutes.
If necessary, switch on the ignition
again to reactivate it.
Bonnet stay: Unclip the stay and insert
it into the notch.



78



Bonnet opening/closing

To release the bonnet, pull the lever
located under the dashboard left hand
end towards you. Then operate the
safety catch at the front of the bonnet,



174



92



Selective opening

Using the multifunction screen, you can
choose from the following options for
opening your vehicle with the remote
control:


- either all of the doors and the tail-
gate,

- or the driver’s door with a fi rst press,
then all of the other doors with a
second press.
To close:
move the stay back to
its initial position, lower the bon-
net, then allow it to slam shut at
the end of its travel.
OPENING

Remote control key
Fuel tank


Capacity: approximately 60 litres.

14
FAMILIARISATION

Adjusting the steering wheel

The steering wheel can be adjusted for
height and reach.
Release the steering wheel by pulling
lever A
towards you.
Adjust the position of the steering
wheel then lock it pushing the lever fully
back.



77
It automatically and progressively
changes between day use and night
use. This operates with the ignition switched
on.
From the driver’s seat, select the door
mirror by moving control 1
to the left or
right, then adjust the door mirror as re-
quired in four directions using control 2
.
Demisting-defrosting of the door mirrors
is linked to that of the rear screen.



105



76

For safety reasons, these adjust-
ments must not be carried out whilst
driving.
This additional mirror 1
allows you to
monitor the rear passengers. It can be
tilted to avoid dazzle.

Door mirror foldback

When the vehicle is parked, the door
mirrors can be folded back either man-
ually or automatically.
SITTING COMFORTABLY

Automatic photochromatic rear
view mirror
Door mirror adjustment




77



Child surveillance mirror

20
FAMILIARISATION
Take care to attach the third-row pas-
senger seat belts to the rings provided
for this purpose.

Do not attach the belts to the load
anchorage points marked with a red
cross (see illustration above).

Stowing the tongue of the third-row
seat belt




133


Using the third-row passenger seat
belts (CITROËN Grand C4 Picasso)
PASSENGER SAFETY



)
Insert tongue C
into the buckle on
the right, then insert the second
tongue D
into the buckle on the left.



132



Seat belts


Second row centre seat belt

23
FAMILIARISATION
Fold the concertina boards ( 1 2 3
) ar-
ranged above each of the third-row
seats.
Pull on the black strap F
, located on the
seat backrest.



74
Before moving the third-row seats,
do not forget to lock in the rigid pan-
els fi rst (located at the base of the
second-row seat backrests).

Installing the seats

Put the three sections of the concertina
boards ( 1 2 3
) to their vertical position,
then pull on the red strap G
.
Before moving the third-row seats, re-
turn the rigid panels to the upright posi-
tion and lock them. Pull on control E
, located at the top of
the second-row seats backrest.



73


INTERIOR


Stowing the seats
Access to third-row seats

Do not leave objects either on or un-
derneath the second-row seats when
you are folding them.


THIRD ROW SEATS (CITROËN GRAND C4 PICASSO)

29
FAMILIARISATION
Eco-driving is a range of everyday practices that allow the motorist to optimise their fuel consumption and CO2 emissions.


Optimise the use of your
gearbox

With a manual gearbox, move off
gently, change up without waiting and
drive by changing up quite soon. If
your vehicle has the system, the gear
effi ciency indicator invites you to
change up; it is displayed in the instru-
ment panel, follow its instructions.

With an automatic or electronic gear-
box, stay in Drive "D"
or Auto "A"
, ac-
cording to the type of gearbox, without
pressing the accelerator pedal heavily
or suddenly.



Drive smoothly


Maintain a safe distance between ve-
hicles, use engine braking rather than
the brake pedal, and press the accel-
erator progressively. These practices
contribute towards a reduction in fuel
consumption and CO
2 emissions and
also helps reduce the background traf-
fi c noise.

If your vehicle has cruise control, make
use of the system at speeds above
25 mph (40 km/h) when the traffi c is
fl owing well.



Control the use of your
electrical equipment

Before moving off, if the passenger
compartment is too warm, ventilate it
by opening the windows and air vents
before using the air conditioning.
Above 30 mph (50 km/h), close the
windows and leave the air vents
open.
Remember to make use of equipment
that can help keep the temperature
in the passenger compartment down
(sunroof and window blinds...).
Switch off the air conditioning, unless
it has automatic digital regulation, as
soon as the desired temperature is at-
tained.
Switch off the demisting and defrost-
ing controls, if not automatic.
Switch off the heated seat as soon as
possible.
ECO-DRIVING

30
FAMILIARISATION

Limit the causes of excess
consumption

Spread loads throughout the vehicle;
place the heaviest items in the bottom
of the boot, as close as possible to the
rear seats.
Limit the loads carried in the vehicle
and reduce wind resistance (roof bars,
roof rack, bicycle carrier, trailer...). Use
a roof box in preference.
Remove roof bars and roof racks after
use.

At the end of winter, remove snow tyres
and refi t your summer tyres.



Observe the recommendations
on maintenance

Check the tyre pressures regularly,
when cold, referring to the label in the
door aperture, driver's side.
Carry out this check in particular:


- before a long journey,

- at each change of season,

- after a long period out of use.
Don't forget the spare wheel and the
tyres on any trailer or caravan.


Have your vehicle serviced regularly (en-
gine oil, oil fi lter, air fi lter...) and observe
the schedule of operations recommended
by the manufacturer.




When refuelling, do not continue after
the 3 rd cut-off of the nozzle to avoid
any overfl ow.

At the wheel of your new vehicle,
it is only after the fi rst 1 800 miles
(3 000 kilometres) that you will see
the fuel consumption settle down to a
consistent average.

Switch off the headlamps and front
foglamps when the level of light does
not require their use.

Avoid running the engine before mov-
ing off, particularly in winter; your ve-
hicle will warm up much faster while
driving.

As a passenger, if you avoid connect-
ing your multimedia devices (fi lm, mu-
sic, video game...), you will contribute
towards limiting the consumption of
electrical energy, and so of fuel.
Disconnect your portable devices be-
fore leaving the vehicle.

I
33
MONITORING









Indicator and warning lamps

Visual indicators informing the driver that a system is in
operation (operation or deactivation indicator lamps) or of
the occurrence of a fault (warning lamp).

When the ignition is switched on
Certain warning lamps come on for a few seconds when
the vehicle's ignition is switched on.
When the engine is started, these same warning lamps
should go off.
If they remain on, before moving off, refer to the informa-
tion on the warning lamp concerned.
Associated warnings
The illumination of certain warning lamps may be accompanied
by an audible signal and a message in the multifunction screen.

Operation indicator lamps
If one of the following indicator lamps comes on, this confi rms
that the corresponding system has come into operation.
The warning lamps may come on continuously (fi xed)
or fl ash.
Certain warning lamps may come on in two different
modes. Only by relating the type of illumination to the
operating status of the vehicle can it be ascertained whether
the situation is normal or whether a fault has occurred.


Warning lamp


is on


Cause


Action/Observations





Left-hand
direction
indicato

r


fl ashing with
buzzer. The lighting stalk is pushed down.





Right-hand
direction
indicator


fl ashing with
buzzer. The lighting stalk is pushed up.






Sidelamps


fi xed. The lighting stalk is in the
"Sidelamps" position.




Dipped beam
headlamps


fi xed. The lighting stalk is in the "Dipped
beam headlamps" position.




Main beam
headlamps


fi xed. The lighting stalk is pulled towards
you. Pull the stalk to return to dipped
beam headlamps.





Hazard
warning
lamps


fl ashing with
audible signal. The hazard warning lamps switch,
located on the dashboard, has been
operated. The left-hand and right-hand direction
indicators and their associated indicator
lamps fl ash simultaneously.

III
73
COMFORT

"Cinema seat" position

This position allows you to free up
space between the fi rst row and the
second row.
Pull the lever E
under the seat.
This position is only possible with
the outer seats.

Access to the third row seats

Access to the third-row seats is via
the outer second-row seats.


)
Pull the lever E
. The seat unlocks
and the seat cushion comes up
against the backrest.

)
Hold the lever E
in the raised
position, pushing forwards. The
whole seat slides towards the
front seat.
Space becomes free behind the
seat, the third-row passengers can
get to their seats.



Exit from the third row seats



)
Hold the lever E
in the raised po-
sition. The seat unlocks and the
seat cushion comes up against
the backrest.

)
Push the seat backrest, still hold-
ing the lever E
in the raised posi-
tion.
If the table on the back of the fi rst-
row seat is down, close it to enable
this operation.


Repositioning a seat, from
the outside, with the door
open
If there are passengers seated in
the third row:


)
manually return the assembly as
far as possible rearwards; the
seat does not return as far as the
maximum rearwards position so
as to retain legroom for the third-
row passengers,

)
fold the seat cushion until it
locks.
Ensure that there is no object on
or under the seat that you want to
move.
Emergency exit: should the fi rst
system fail (strap C
), use of the le-
ver E
allows third-row passengers
to leave.
Do not allow children to operate
the seats without supervision.

III
74
COMFORT
THIRD ROW SEATS (GRAND
C4 PICASSO)

Concertina boards

Two rigid concertina boards, which
cannot be separated from the vehi-
cle, cover the 2 third-row seats, when
these are in the folded position.

Folding the concertina boards
Pull on the control, the 3 sections of
the board will fold like a concertina.
When the third-row seats are up-
right, these concertina boards can
be left either:


- fl at behind the seats,

- in the vertical position,
thereby leaving a storage area avail-
able.



Unfolding the seat



)
Return the second-row rigid
panels to their initial position and
lock them.

)
Having folded your concertina
board, pull on the control F
lo-
cated behind the seat backrest.
The backrest pivots rearwards,
pulling the seat base with it. The
seat locks in the open position.


Repositioning the seat



)
Return the second-row rigid
panels to their initial position and
lock them.

)
Lower the head restraints.

)
Correctly position the concertina
board vertically behind the seat.
)
Pull on the control G
, located at
the bottom of the seat backrest.
The seat unlocks.

)
Next push the backrest gently
forwards. The backrest pivots,
folding onto the seat base. The
seat base then folds into the
stowage area provided for that
purpose.

)
Reposition the concertina boards
over the folded seats.

Before moving the third-row seats,
return the rigid plates of the second-
row seats to the upright position
and lock them.
Do not try to fold a third-row seat
that has not fi rst had the backrest
fully locked in place.
Do not leave objects either on or
underneath the seat bases of the
third-row seats when you are fold-
ing them.
Do not leave your hand on the con-
trol G
as you fold the seats, as you
risk trapping your fi ngers.
Do not allow children to operate
the seats without supervision.
