Downloaded from www.Manualslib.com manuals search engine ENGINE
38
X = MAXI reusable
Engines : 6FZ - RFN - RLZ
Cylinder head tightening (m.daN) Cylinder head bolts
A= Washer thickness : 4 ± 0.2 mm.
X= Length under heads of the new bolts = 144.5 ± 0.5 mm. - Pre-tightening1.5 ± 0.1
- Tightening5 ± 0.1
- Untightening360° ± 2°
- Tightening2 ± 0.2
- Angular tightening285° ± 5°
(in the order 1 to 10)
NOTE : Oil the threads and
under the heads of the cylinder
head bolts. (Use engine oil or
Molykote G Rapid Plus.)
B1BP05BC
6FZ - RFN - RLZ
6FZ - RFN - RLZ
X= 147 mm
CYLINDER HEAD
B1DP16FC
NOTE : Retightening of the cylinder head
after a completed repair is prohibited.
Intervention est interdit.
Page 42 of 259
Downloaded from www.Manualslib.com manuals search engine ENGINE
39
CYLINDER HEAD (Continued)
Engines : 6FZ - RFN - RLZCamshafts
The camshafts are identified by the
following markings :
- Paint rings.
- Cold stamp at the camshaft extremity
(Distribution end).
(1) Inlet camshaft.
(2) Exhaust camshaft.
"j" Camshaft position sensor target.
"h"Paint rings : repair reference.
Valve clearances when cold :
Hydraulic followers with clearance
B1EP15YDInlet camshaft Exhaust camshaft
6FZ RFN-RLZ 6FZ RFN-RLZ
Marking at «g» 9630426980 9624727280 9630426680 9624728080
Lifting law marking at «f» D1269 D1149 D5016 D1148
Paint rings Blue at «k» Green at «i»
Page 43 of 259
Downloaded from www.Manualslib.com manuals search engine ENGINE
40
Engines : 6FZ-RFN-RLZ-RHY-RHZ-4HX
CrankshaftDiesel Petrol
6FZ RFN RLZ RHY RHZ 4HX
SPECIAL FEATURES : TIGHTENING TORQUES ( m.daN)
Bearing cap screws.
- Pre-tightening2 ± 0.1 2.5 ± 0.2
- Angular tightening60°±6° 60°
Con-rod cap screws.
- Tightening1
- Untightening180°
- Tightening2.3 ± 0.2 2.3 ± 0.1
- Angular tightening46°+2°-4° 46°±5°
Con-rod nuts.
- Pre-tightening2 ± 0.2
- Angular tightening70°
Accessories drive pulley
- Tightening2.1 ± 0.1 4 ± 0.4 7 ± 0.25
- Angular tightening51° 60°
Accessories drive pulley hub
- Pre-tightening4 ± 0.4
- Angular tightening(Sintered washer)40°±4°
Angular tightening(Steel washer)53°±5°
Page 44 of 259
Downloaded from www.Manualslib.com manuals search engine Piston skirt spray jet1 ± 0.1
Sump
- Pre-tightening1
- Tightening0.8 ± 0.2 1.6 ± 0.2 1.6 ± 0.3
Timing belt guide roller
- Pre-tightening1.5
- Tightening3.7 ± 0.3 2.5 ± 0.2 4.3 ± 0.4
Timing guide roller
- Pre-tightening1.5
- Tightening2.5 ± 0.2 4.3 ± 0.4
Timing belt tensioner roller 2.1 ± 0.2 2.5 ± 0.2
RH engine mounting
- Pre-tightening1(4 screws)
- Tightening2 ± 0.2 (Ø 8)
- Tightening6.1 ± 0.6 2.7 ± 0.2 4.5±0.2 (Ø10)
ENGINE
41
Engines : 6FZ-RFN-RLZ-RHY-RHZ-4HX
Cylinder blockDiesel Petrol
6FZ RFN RJZ RHY RHZ 4HX
SPECIAL FEATURES : TIGHTENING TORQUES ( m.daN)
Page 45 of 259
Downloaded from www.Manualslib.com manuals search engine ENGINE
42 Camshaft bearing cover
- Tightening1 ± 0.1
- Pre-tightening0.5 ± 0.1 0.5 (Ø6)
- Tightening0.9 ± 0.1 1 ± 0.1 1±0.1(Ø10)
Exhaust manifold
- Pre-tightening1.5
- Tightening3.5 ± 0.3 2 ± 0.2 3 ± 0.3
Valve cover
- Pre-tightening0.5 0.5 ± 0.15
- Tightening1.1 ± 0.1 0.9 ± 0.1 0.8 ± 0.1 0.9 ± 0.1
Camshaft pulley hub 7.5 ± 0.7 4.3 ± 0.5
Hub pulley2 ± 0.2
Flywheel / Clutch
Flywheel
- Pre-tightening2 ± 0.2 1.5
- Tightening21° ± 3° 4.8 ± 0.5 4.7 ± 0.4
Clutch plate 2 ± 0.2 2 ± 0.2
Engines : 6FZ-RFN-RLZ-RHY-RHZ-4HX
Cylinder headDiesel Petrol
6FZ RFN RLZ RHY RHZ 4HX
SPECIAL FEATURES : TIGHTENING TORQUES ( m.daN)
Page 46 of 259
Downloaded from www.Manualslib.com manuals search engine ENGINE
43 Oil pump
- Pre-tightening0.7
- Tightening0.9 ± 0.1 1.3 ± 0.1 0.9 ± 0.1
Water / oil heat exhanger5.8 ± 0.5
Lubrication pipe
- Engine end3 ± 0.3
- Turbocompressor end2 ± 0.2
Injection circuit
Injector(Flange nut)
- Tightening3 ± 0.3 4 ± 0.3
- Angular tightening45°±5°
Union on injection rail2 ± 0.2
Injection pump0.5 ± 0.1 2.25 ±0.3
Union on injector 2 ± 0.2
Common rail fixing screw 0.9 ± 0.1 0.8 ± 0.1
Injection pump pulley5 ± 0.5
Union on injection pump 2.6 ± 0.3 2 ± .02
Cooling circuit
Water pump 1.4 ± 0.1 1.6 ± 0.3
Water inlet housing 0.9 ± 0.1 2 ± .02
Engines : 6FZ-RFN-RLZ-RHY-RHZ-4HX
Lubrication circuit Diesel Petrol
6FZ RFN RJZ RHY RHZ 4HX
SPECIAL FEATURES : TIGHTENING TORQUES ( m.daN)
Page 47 of 259
Downloaded from www.Manualslib.com manuals search engine ENGINE
44
ENGINE SPECIFICATIONS
Engine : XFX
B1BP27CD
Compusory engine plate :
(1) Identification plate
"a"Engine legislation type.
"b"Component reference.
"c" Factory serial no.
Page 48 of 259
Downloaded from www.Manualslib.com manuals search engine ENGINE
45
Engine : XFX
SPECIAL FEATURES : TIGHTENING TORQUES ( m.daN)
(1) Pencil type ignition coil 0.8 ± 0.3.
(2) Valve cover
- Pre-tightening0.5 ± 0.1
- Tightening1 ± 0.1
(3) Camshaft bearing cap cover
- Pre-tightening0.2 ± 0.1
- Tightening1 ± 0.1
(4) Cylinder head
- Pre-tightening2 ± 0.2
- UntighteningYES
- Tightening1.5 ± 0.2
- Angular tightening225°
B1BP27DP
Page 49 of 259
Downloaded from www.Manualslib.com manuals search engine ENGINE
46
Engine : XFX
SPECIAL FEATURES : TIGHTENING TORQUES ( m.daN)
(5) Exhaust manifold
(Equipped with a new seal).
- Pre-tightening1 ± 0.1
- Tightening3 ± 0.3
(6) Con-rod caps
- Tightening2 ± 0.2
- Angular tightening74°
(7) Flywheel.
- Tightening2 ± 0.2
- Angular tightening60°
B1JP02LD
Page 50 of 259
Downloaded from www.Manualslib.com manuals search engine ENGINE
47
Engine : XFX
SPECIAL FEATURES : TIGHTENING TORQUES ( m.daN)
(8) Crankshaft bearings
Carry out the following operations :
- Clean the threads of the screws with a brush.
- Refit the screws with a coating of grease, on threads and under
heads "MOLYKOTE G RAPID PLUS".
- Check that the 8 centring pins are in place.
Tightening :
- Pre-tighteningM11to 3 ± 0.3 (Order from 1to8)
- Pre-tighteningM8to 1 ± 0.1(Orer fromAto H)
- TighteningM6 to 1 ± 0.1(Order from a to m)
- UntighteningM11to M8
Proceed screw by screw :
- TighteningM11to 3 ± 0.3(order from 1to 8), then
One angular tightening of 180°
- TighteningM8 to 1 ± 0,1(Order from Ato H), then
One angular tightening of180°
Max. length under heads of the screws M11 = 131.5 mm.
Max. length under heads of the screws M8 = 119 mm.
B1BP1GYD
