Downloaded from www.Manualslib.com manuals search engine ENGINE
68
AUXILIARY EQUIPMENT DRIVE BELT
Engine : 4HX
With air conditioning
B1BP271DB1BP273D
TOOLS
[1] Dynamic tensioner compression lever: (-).0188.Z
[2] Ø 4 mmpeg: (-).0188.Q1
Remove.
WARNING :mark the direction of fitting in case the belt is to be reused.
- Compress the tensioner roller(4) by action at «c»(anti-clockwise), using tool [1].
- Peg at «d», using tool [2].
- Remove the auxiliaries drive belt.
Refit.
- Refit the auxiliaries drive belt.
- Compress the tensioner roller(4)by action at «c»(anti-clockwise), using tool [1].
- Remove the tool [2] at «d».
Page 72 of 259
Downloaded from www.Manualslib.com manuals search engine ENGINE
69 Petrol Diesel
EW ES DW
7 10 9 10 12
J4 J4D J4 TD ATED TED4
1.8i 16V 2.0i 16V 3.0i V6 2.0 HDi 2.2 HDi
Engine plate 6FZ RFN RLZ XFX RHY RHZ 4HX
CITROËN C5 X X X X X X X
See pages 70 to 73 74 to 79 80 to 84 85 to 90
CHECKING AND SETTING THE VALVE TIMING
Page 73 of 259
Downloaded from www.Manualslib.com manuals search engine ENGINE
70 TOOLS
[1]Camshaft setting pegs : (-).0189.A
[2]Crankshaft setting peg : (-).0189.B Tool kit C.0189.
[3]Belt retaining pin : (-).0189.K
[4]Adaptor for angular tightening : 4069-T
[5]Hub immobilising tool : 6310-T
Checking the valve timing.
- Turn the engine by the crankshaft pinion screw (1)to bring it to pegging position.
- Peg the crankshaft, using tool [2].
- Peg the camshaft pulleys, using tools [1].
NOTE : The pegs [1] should engage without effort.
WARNING : If the pegs do not engage without effort, restart the fitting and
tensioning of the timing belt (see below).
Setting the valve timing.
Remove.- Remove the screws (2), the pulley (1), upper valve cover (4), lower valve cover (3).
- Turn the engine by the screw (13)of the pinion (12)to bring it to pegging position.
- Peg the pulleys (8) and (9)using tools [1].
- Peg the pinion(12)using tool [2].
- Loosen the screw(7)of the tensioner roller (6).
- Turn the tensioner roller(6)(clockwise).
- Remove the timing belt(10).
CHECKING AND SETTING THE VALVE TIMING
Engines : 6FZ - RFN - RLZ
B1EP14JDB1BP23XCB1BP25PCB1BP22SC
Page 74 of 259
Downloaded from www.Manualslib.com manuals search engine ENGINE
71
Refit (continued)
- Refit the belt (10)on the pinion (12).
- Hold the belt(10)with tool [3].
- Position the belt (10)in the following order :
- The guide roller (11), the inlet camshaft pinion(9), the exhaust camshaft pinion (8), the water pump(5), the
tensioner roller (6).
NOTE :Make sure that the belt (10)is as flush as possilble with the outer face of the various pinions and rollers.
- Remove the tools [3]and[1].
T
iming belt.Adjusting the tension.- Turn the roller(6)in the direction of the arrow «b» ; using an Allen key at «a».
- Position the index «c»in its maximum setting at «d».
IMPERATIVE : The index «c» must stand proud of the notch «f» by an angular value of 10°. If it does not,
replace the tensioner roller (6) or the timing belt and the tensioner roller (6)
Bring the index «c»to its adjusting position «f»by turning the tensioner roller (6)in the direction of the arrow «e».
WARNING: The index«c»must not stand proud of the notch «f»: if it does, restart the timing belt tensioning
operation.
IMPERATIVE : The tensioner roller (6) must not turn while its fixing is being tightened up. If it does,
recommence the adjusting operation.
CHECKING AND SETTING THE VALVE TIMING
Engines : 6FZ - RFN - RLZ
B1EP14KCB1EP14JD
Page 75 of 259
Downloaded from www.Manualslib.com manuals search engine ENGINE
72
Adjusting the tension (continued).- Tighten the screw (7) of the the tensioner roller(6) to 2.1 ± 0.2 m.daN.
IMPERATIVE : The hexagonal drive of the tensioner roller (6) must be at 15° below the level of the cylinder
head gasket «g». If not, replace the tensioner roller (6) or the timing belt and the tensioner roller (6).
Refit (continued).
- Remove the tools [1]et [2].
- Turn the crankshaft 10 timesin the normal direction of rotation.
IMPERATIVE : No pressure or outside action must be brought to bear on the timing belt.
- Peg the inlet camshaft pulley, using the tool [1].
Checks.
Timing belt tension.
IMPERATIVE : Check the position of the index «c», it should be facing the notch «f». If the position of index «c»
is not correct, restart the adjustment of its position.
Positioning of the crankshaft.
- Fit tool [2].
- As long as it is possible to fit tool[2], continue with the refit operations.
IMPERATIVE : If it is not possible to fit tool [2], reposition the flange (14).
CHECKING AND SETTING THE VALVE TIMING
Engines : 6FZ - RFN - RLZ
B1EP14VCB1EP14MC
Page 76 of 259
Downloaded from www.Manualslib.com manuals search engine ENGINE
73
Checks (continued)
Repositioning the flange.- Immobilise the crankshaft using tool [5].
- Loosen the screw(13).
- Release the pinion (12) of the crankshaft.
- Bring the flange (14) to the pegging position; using tool [5].
- Fit the tool [2].
- Immobilise the crankshaft using tool [5].
- Tighten screw (13) to 4 ± 0.4 m.daN, then angular tighten to :
53°±4°(Assembly with steel washer, gold in colour)
40°±4°(Assembly with sintered washer, metallic in colour)
using the tool [4].
- Remove tools [1]. [2]and [5].
Refit :
- The lower valve cover (3).
- The upper valve cover(4).
- The crankshaft pulley (1).
- The screws(2).
- Pretighten the screws (2)to 1.5 m.daN.
- Tighten the screws (2)to 2.1 ± 0.5 m.daN.
CHECKING AND SETTING THE VALVE TIMING
Engines : 6FZ - RFN - RLZ
B1BP23XCB1EP14PC
Page 77 of 259
Downloaded from www.Manualslib.com manuals search engine ENGINE
74
CHECKING AND SETTING THE VALVE TIMING
Engine : XFX
TOOLS
[1] Camshaft setting pegs(-).0187.B
[2] Crankshaft setting peg(-).0187.A
[3] Fuel pressure take-off union4192-T
[4] Belt retaining pin(-).0187.J
[5]Exhaust camshaft hubs immobilising tool(-).0187.F
[6] Inlet camshaft hubs immobilising tool(-).0187.F
Remove the auxiliaries drive belt (See corresponding operation).
Checking the valve timing setting.
Remove :
- The power steering pulley.
- The roller / dynamic tensioner assembly(11).
- The crankshaft pulley (12).
- The upper timing covers (9)and (10).
- The lower timing cover (13).
B1BP2BKC
Page 78 of 259
Downloaded from www.Manualslib.com manuals search engine ENGINE
75
CHECKING AND SETTING THE VALVE TIMING
Engine : XFX
Checking the valve timing setting (continued).
- Peg the crankshaft, using tool[1].
- Check that the tool [2]engages without effort in the cylinder heads at the camshaft pulleys.
- Remove the tools [1] and [2].
Refit :
- The lower timing cover(13).
- The upper timing covers (9)and(10).
- The crankshaft pulley (12).
- The roller / dynamic tensioner assembly (11).
- The power steering pulley.
- Complete the refitting of components.
- Initialise the ignition injection ECU.
B1EP15UDB1EP08TC
Page 79 of 259
Downloaded from www.Manualslib.com manuals search engine ENGINE
76
CHECKING AND SETTING THE VALVE TIMING
Engine : XFX
Setting the valve timing
- Remove the components as necessary for the operation.
- Remove the screws (19)and the plate (20).
- Peg the crankshaft, using tool[2].
NOTE : Damp the rotation of the camshafts (15)and (17), using tool [6].
- Untighten the camshaft pulley screws (15)and (17).
NOTE : Damp the rotation of the camshafts(14)and (18), using tool[5].
- Untighten the camshaft pulley screws (14) and (18).
NOTE :Lubricate the tools [1], with grease G6(TOTAL MULTIS).
Peg the camshafts, using tools [1], [5]and [6].
Remove the screw(21) of the panel (25).
Untighten the nut (23)of the tensioner roller (24).
Untighten the screws (22) of the panel (25).
Remove the guide roller (16).
WARNING :mark the direction of fitting of the timing belt, in case the belt is to be reused
- Remove the timing belt.
B1EP15VD
Page 80 of 259
Downloaded from www.Manualslib.com manuals search engine ENGINE
77
CHECKING AND SETTING THE VALVE TIMING
Engine : XFX
Setting the valve timing (continued)
Refit.
- Check that the camshafts and the crankshaft are correctly pegged.
- Check that the rollers and the water pump pulley are turning freely. (No tightness)
- Loosen the camshaft pulley screws by a 1/4 turn.
- Make sure that the pulleys are turning freely on the camshaft hub.
- Turn the camshaft pulleys in a clockwise direction, to end of slots.
WARNING : Respect the direction of fitting of the belt : facing the timing, the inscriptions
on the belt should be readable the correct way up.
- Fit the timing belt on the crankshaft pinion.
- Position the tool [6].
- Position the timing belt in the following sequence :(Belt well tensioned).
- The roller (26), the pulley (18), the pulley(17),
- Keep the timing belt well tensioned :
- Refit the guide roller (16),tighten to 8 ± 0.8 m.daN.
- Position the timing in the following sequence :
- The camshaft pulley (15), the camshaft pulley (14), the tensioner roller (24), the water pump
pulley, and the guide roller(27).
NOTE :When positioning the belt on the camshaft pulleys, turn these clockwise so as to engage
the next tooth. The angular displacement of the pulleys should not be more than the equivalent of
one tooth.
B1EP15VDB1BP2BLC
