Page 132 of 306
132
9
D R I V I N G
Mode selection
Displays on the instrument panel
automatic mode: selector in po-
sition D ,
sequential mode: selector in po-
sition M ,
SPORT mode: selector in posi-
tion D and button A pressed,
SNOW mode: selector in posi-
tion D and button B pressed. The position of the selector and the
driving mode are displayed on the
instrument panel dial
C .
A position grille relating to the selec-
tor allows you to view the position
that is selected. For safety:
- position P can be dis-
engaged only if you
press the brake pedal,
- when a door is opened, a sound signal is heard if the selector is
not in position P ,
- always make sure that the se- lector is in position P before
you leave your vehicle.
If the gearbox is in position P but
the position of the selector is differ-
ent, reposition the selector on P so
that you can start the vehicle.
Page 136 of 306
136
9
D R I V I N G
FIXED CENTRED CONTROLS STEERING WHEEL
1 Rotation
- Scrolling of the various pages of information
on the instrument panel display.
- Movement through the various menus on the instrument panel display.
- Increasing/decreasing of the values.
Short press - Opening of the menu on the instrument panel di
splay (only when stationary).
- S e l e c t i o n a n d c o n fi r m a t i o n o f t h e i n f o r m a t i o n .
Long press Trip computer zero reset (if the trip computer page is displayed).
2 Short press
- Cancellation of the current operation.
- Return to the previous screen on the instrument panel disp
lay.
Long press Return to the initial screen on the instrument panel display.
3 Short press Increasing of the speed in steps of 1 km/h (1 mph)/
storing of the speed.
Maintained press Increasing of the speed in steps of 5 km/h (5 mph).
4 Short press Decreasing of the speed in steps of 1 km/h (1 mph)/
storing of the speed.
Maintained press Decreasing of the speed in steps 5 km/h (5 mph).
5 Short press Suspension or resumption of the cruise control/speed limiter (depe
nding on
the mode selected).
6 Short press Selection of the cruise control or speed limiter mode (the cycle o
n this
button will always begin with selection of the speed limi ter).
7 Short press Deactivation of the cruise control/speed limit er.
8 Short press - Pick up an incoming call.
- Hang up the current call.
- Opening of the telephone short-cut menu.
- C o n fi r m a t i o n o n t h e l i s t a n d t h e t e l e p h o n e m e n u .
Long press Refuse an incoming call.
9 Short press/Long press Horn.
10 Short press Activation/deactivation of the Black Panel mode (night driving).
11 Short press Activation of the voice command.
Long press Navigation instruction repeat.
Page 137 of 306
137
9
D R I V I N G
12 Rotation
- Radio source: Scrolling of the pre-set stations.
- CD/MP3 CD/CD changer/jukebox source: Scrolling
of the CDs or
directories.
- On the multifunction display menus: Movement a nd increasing/decreasing.
Short press - O n t h e m u l t i f u n c t i o n d i s p l a y m e n u s : c o n fi r m a t i o n .
- Opening of the short-cut menus (in accordance with the mult
ifunction
display page).
Long press Opening of the multifunction display main men u.
13 Short press Cancellation of the current operation and return to the p
revious screen on
the multifunction display.
When an incoming telephone call is received: Refuse the cal l.
Long press Return to the initial screen on the multifun ction display.
14 Short press Access to the multifunction display general menu .
15 Short press/Maintained press Volume increase.
16 Short press/Maintained press Volume decrease.
17 Short press - First press: mute.
- Second press: restoring of the sound.
18 Short press
- Radio source: Automatic search of higher frequencies.
- CD/MP3 CD/CD changer/jukebox source: Search for the next track.
Maintained press - CD/MP3 CD/CD changer/jukebox source: Fa st forward play.
19 Short press
- Radio source: Automatic search of lower frequencies.
- CD/MP3 CD/CD changer/jukebox source: Search for
the previous track.
Maintained press CD/MP3 CD/CD changer/jukebox source: Rewind .
20 Short press - Radio source: displaying of the list of radio stations
available.
- CD/MP3 CD and CD changer source: displaying of the list o f CD tracks
and directories.
- Jukebox source: displaying of the list of albums.
Long press Updating of the list of radio stations.
21 Short press/Long press Horn.
22 Short press MODE: selection of the type of inform ation presented on the multifunction display.
Page 138 of 306
138
9
D R I V I N G
SPEED LIMITER
System which prevents the vehi-
cle from exceeding the speed pro-
grammed by the driver.
When the limit speed is reached, the
accelerator pedal no longer has any
effect.
The speed limiter is switched
on manually: a speed of at least
20 mph (approx. 30 km/h) must be
programmed.
The speed limiter can in no way
replace respect for speed limits or
vigilance and responsibility on the
part of the driver.
Steering wheel controls
The speed limiter switches are lo-
cated on the left-hand side of the
steering wheel.
Displays on the instrument panel
The speed limiter information is dis-
played in zone
A of the instrument
panel.
Programming
Press on button 4 to select speed
limiter mode " LIMIT ".
T h e s e l e c t i o n i s c o n fi r m e d b y t h e
display of the function in zone A of
the instrument panel. Activation
Press on button 3 when the de-
sired maximum speed is dis-
played.
The information "ON" then appears
in zone A .
When the function is selected, the
last memorised speed and the infor-
mation "PAUSE" are displayed.
With the engine running, you can
adjust the memorised maximum
speed, displayed in zone A , by
pressing on:
Button 1 to increase the memo-
rised maximum speed.
Button 2 to decrease the memo-
rised maximum speed. Successive presses will modify the
cruise speed in steps of 1 mph and a
continuous press in steps of 5 mph.
Page 139 of 306
139
9
D R I V I N G In the event of a steep descent or
under excessive acceleration, the
speed limiter (which does not act
on the brakes) may not be able to
prevent the vehicle from exceeding
the programmed speed.
U s e o f a fl o o r m a t o t h e r t h a n t h a t
recommended by CITROËN may
affect the normal operation of the
accelerator pedal and hamper the
operation of the speed limiter.
Floor mats approved by CITROËN
a r e fi t t e d w i t h a 3 r d fi x i n g l o c a t e d i n
the pedal area to avoid any risk of
interference with the pedals.
Suspension/Resumption
Press on button 3 .
This action causes the information
"PAUSE" to appear in zone A of the
instrument panel.
This action does not cancel the
memorised maximum speed which
remains displayed in zone A of the
instrument panel. Overriding the programmed
speed
The accelerator pedal has an end-
of-travel switch. In order to exceed
the memorised maximum speed at
any time, you can press the pedal
all the way down. While the speed
is being exceeded, the speed dis-
played in zone
A w i l l fl a s h . Y o u h a v e
only to release the accelerator pedal
to return below the maximum speed,
to restore the function.
T h e s p e e d w i l l a l s o fl a s h i f t h e s p e e d
limiter is not able to prevent the vehi-
cle from exceeding the programmed
speed (e.g. on a steep descent or
under excessive acceleration).
To reactivate the speed limiter, re-
lease the accelerator to slow to a
speed lower than the programmed
speed. Return to normal driving
Press on button 5 .
Select the speed limiter function.
Or stop the engine.
Operating fault
If there is a malfunction, a mes-
sage is displayed accompanied by
a sound signal and lighting of the
SERVICE warning lamp.
Have it checked by a CITROËN
dealer.
Page 140 of 306
140
9
D R I V I N G
CRUISE CONTROL
System which automatically main-
tains the vehicle speed programmed
by the driver, without any action on
the accelerator pedal.
The cruise control is switched on
manually: the vehicle speed must be
at least 25 mph (40 km/h) and you
must engage at least:
- 4th gear for manual gearboxes,
- 2nd gear for automatic gearboxes. Displays on the instrument
panel
The programmed information is
grouped together in zone
A of the
instrument panel.
Programming
Press button 4 to select cruise
control mode " CRUISE ".
Steering wheel switches
The cruise control switches are lo-
cated on the left-hand side of the
steering wheel. T h e s e l e c t i o n i s c o n fi r m e d b y t h e
display of the function in zone
A of
the instrument panel.
When the function is selected, no
cruising speed has yet been
memorised. Once the desired speed has been
reached using the accelerator, press
button
1 or button 2 . The cruising
speed is then memorised and cruise
control is activated. The cruising
speed is displayed in zone A of the
instrument panel, and "ON" is dis-
played.
Adjustment of the memorised
speed while cruise control is
in operation
Y o u c a n a d j u s t t h e m e m o r i s e d
speed, displayed in zone A , by
pressing:
- Button 1 to increase the speed.
- Button 2 to reduce the speed.
Successive presses will modify the
cruise speed in steps of 1 mph and a
continuous press in steps of 5 mph.
Y o u c a n t h e n r e l e a s e t h e a c c e l e r a -
tor pedal. The vehicle will automati-
cally keep to the speed chosen.
The vehicle speed may vary slightly
from that memorised.
If during cruise control the system
cannot keep to the cruise speed
(e.g. on a steep descent), then the
s p e e d fl a s h e s . I f n e c e s s a r y , b r a k e t o
curb your speed.
Page 141 of 306
141
9
D R I V I N G Cruise control must only be
u s e d w h e r e t h e t r a f fi c c o n -
ditions permit driving at a
constant speed.
Do not use it on congested roads
or when the weather or the road
conditions are poor.
The driver still has to remain atten-
tive and in complete control of his
vehicle.
Y o u a r e r e c o m m e n d e d t o k e e p y o u r
feet within range of the pedals.
Overriding the programmed
speed
While cruise control is in operation,
it is always possible to go above the
programmed speed simply by press-
ing the accelerator pedal (for exam-
ple to overtake another vehicle).
The speed displayed in zone
A
fl a s h e s .
Y o u o n l y h a v e t o r e l e a s e t h e a c -
celerator pedal to return to the pro-
grammed speed.
Suspension/Resumption
Either by pressing the brake
pedal or the clutch pedal.
Or by pressing button 3 .
Or by the ESP or ASR systems
being active.
For vehicles with a manual gearbox,
cruise control is deactivated if the
gear lever is in neutral. Reactivation
-
By recalling the memorised
speed
After deactivation, press button 3 .
Y o u r v e h i c l e a u t o m a t i c a l l y r e t u r n s
to the memorised cruising speed.
The memorised speed and "ON"
are displayed in zone A .
If the memorised cruising speed is higher than the current speed,
the vehicle will accelerate strong-
ly to reach the current speed.
- By selecting the current speed
Press button 1 or 2 once the de-
sired speed has been reached.
The new speed and "ON" will
appear in zone A .
Return to normal driving
Press on button 5 .
Select the cruise control function.
Or stop the engine.
The speed that was chosen is no
longer memorised.
"PAUSE" will be displayed in zone
A of the instrument panel.
These actions do not cancel the
cruising speed which remains dis-
played on the instrument panel. Operating fault
If there is a malfunction, a mes-
sage is displayed accompanied by
a sound signal and lighting of the
SERVICE warning lamp.
Have it checked by a CITROËN
dealer.
Page 142 of 306
142
9
D R I V I N G
LANE DEPARTURE WARNING SYSTEM
System which detects the involun-
t a r y c r o s s i n g o f l o n g i t u d i n a l t r a f fi c
lane markings on the ground (con-
tinuous or discontinuous line).
S e n s o r s , fi t t e d b e l o w t h e f r o n t
bumper, trigger a warning if the vehi-
cle drifts (speed higher than 50 mph
(80 km/h)).
This system operates to its full
potential above all when used on
motorways and main roads. Activation
Press button A , the indicator light
comes on.
Deactivation
Press button A again, the indica-
tor light switches off.
The status of the system remains
in the memory when the ignition is
switched off.
Detection
Y o u a r e w a r n e d b y t h e v i b r a t i o n o f
the driver's seat cushion:
- on the right-hand side, if the marking on the ground has been
crossed on the right,
- on the left-hand side, if the mark- ing on the ground has been
crossed on the left.
No warning is transmitted while the
direction indicator is active and for
approximately 20 seconds after the
direction indicator is switched off.
A warning may be transmitted if a
direction marking (e.g. arrow) or
n o n - s t a n d a r d m a r k i n g ( e . g . g r a f fi t i )
is crossed. Operating fault
In the event of a malfunction, the
service warning light comes on, ac-
companied by an audible signal and a
message on the multifunction display.
Consult a CITROËN dealer.
The lane departure warning sys-
tem cannot, in any circumstances,
replace the need for vigilance and
responsibility on the part of the
driver. The detection may be disrupted:
- if the sensors are dirty (mud,
snow...),
- if the markings on the ground are worn,
- if there is little contrast between the markings on the ground and
the road surface.
Page 143 of 306
143
9
D R I V I N G
PARKING SPACE SENSOR
System which measures the parking
space available between two vehi-
cles or obstacles. It measures the
size of the space and gives you in-
formation on:
- t h e p o s s i b i l i t y o f fi t t i n g i n t o a free space, depending on the
dimensions of your vehicle and
the distances necessary for your
manoeuvring,
- t h e l e v e l o f d i f fi c u l t y o f t h e m a - noeuvre to be performed.
The system does not measure spac-
es which are clearly much smaller or
larger than the size of the vehicle. Displays on the instrument
panel
The parking space sensor function
warning lamp can have three differ-
ent statuses:
-
off: the function is not selected,
- o n fi x e d : the function is selected
but the conditions for measuring
are not yet met (direction indi-
cator not operating, speed too
high) or the measuring phase is
terminated.
- fl a s h i n g : the measuring is in
progress or the message is be-
ing displayed. Y o u c a n s e l e c t t h e " p a r k i n g s p a c e
sensor" function by pressing button
A. T h e fi x e d l i g h t i n g o f t h e w a r n i n g
lamp indicates that the function is
selected.
During the measurement, the mes-
sage "Measurement in progress -
Vmax 20 km/h (12 mph)" is displayed
on the instrument panel screen.
Page 144 of 306
144
9
D R I V I N G If there is a malfunction, have the
system checked by a CITROËN
dealer.
Operation
Y o u h a v e i d e n t i fi e d a p a r k i n g
space:
Press button A to select the function.
Activate the direction indicator
on the side where the space is to
be measured.
During the measuring, go for-
ward the length of the space, at
a speed less than 12 mph (ap-
prox. 20 km/h), to prepare for
your manoeuvre.
The system then measures the size
of the space.
The system informs you of the
l e v e l o f d i f fi c u l t y o f t h e m a n o e u -
vre via a message on the instru-
ment panel display accompanied
by a gong.
Depending on the message is-
sued by the system, you may or
may not be able to perform the
manoeuvre. The function displays the following
types of message:
Parking YES
P a r k i n g d i f fi c u l t
Parking NO The function deselects itself auto-
matically:
- when you engage reverse gear,
- when you switch off the ignition,
- if measuring is not requested,
- w i t h i n fi v e m i n u t e s o f s e l e c t i o n o f
the function,
- if the vehicle speed exceeds the threshold of 45 mph (approx.
70 km/h) for one minute.
If the lateral distance between your
vehicle and the parking space is too
large, the system may not be able
the measure the space.
The function remains available after
each measurement and thus can
measure more than one space dur-
ing your search.
In bad weather conditions or in
winter, make sure that the sensors
are not covered by dirt, or by ice or
snow.
The parking space sensor function
deactivates the front parking assist-
ance during the space measuring
phase when you are in forward gear.
