Citroen DS4 2017 1.G Owner's Manual

299
DS4_en_Chap08_en-cas-de-panne_ed01-2016
08
In the event of a breakdown

DS4_en_Chap09_caracteristiques_ed01-2016
TECHNICAL DATA

DS4_en_Chap09_caracteristiques_ed01-2016
09

302
DS4_en_Chap09_caracteristiques_ed01-2016
Engines
Engine characteristics
The engine characteristics (capacity, maximum
power, maximum engine speed, fuel, CO
2
emissions, etc.) for your vehicle are given in
the registration document, as well as in sales
brochures.
These characteristics correspond to the
values type-approved on a test bed, under
conditions defined in European legislation
(Directive
1

999/99/EC).
For more information, contact a CITROËN
dealer or a qualified workshop.
Weights
Weights and towed loads
The maximum weights and towed loads for your
vehicle are given are given in the registration
document, as well as in sales brochures.
These values are also present on the
manufacturer's plate or label.
For more information, contact a CITROËN
dealer or a qualified workshop.
The kerb weight is equal to the unladen
weight
+ driver (75 kg).
The GTW and towed load values indicated
apply up to a maximum altitude of
1
000 metres; the towed load mentioned
must be reduced by 10 % for every additional
1
000 metres.
The weight of the braked trailer can be
increased, within the GTW limit, on condition
that the GV W of the towing vehicle is reduced
by the same amount.
The recommended nose weight is the vertical
load on the towbar ball (removable with or
without tools).
GV W:

g
ross vehicle weight, the maximum
authorised vehicle weight.
GT W:

g
ross train weight, the maximum
authorised weight of vehicle plus trailer. High exterior temperatures may result
in a reduction in the per formance of
the vehicle to protect the engine; when
the exterior temperature is higher than
37
°C, limit the towed weight.
If the exterior temperature is high, it
is recommended that the engine be
allowed to idle for 1 to 2 minutes after
the vehicle comes to a stop, to facilitate
its cooling. Towing with a lightly loaded vehicle can
adversely affect roadholding.
Braking distances are increased when
towing a trailer.
Never exceed 60 mph (100 km/h) when
towing (comply with the legislation in
force in your country).
09
Technical data

303
DS4_en_Chap09_caracteristiques_ed01-2016
Petrol engines
.../S: model fitted with Stop & Start.
.../1: model fitted with low rolling resistance tyres.
.../2: model fitted with very low rolling resistance tyres.
*
The maximum power corresponds to the value type-approved on a test bed, under conditions defined in European legislation (Directive 1999/99/EC).
Engine
V Ti 120PureTech 130 S&S THP 15 0
Gearbox Manual

(5 - speed) Manual

(6- speed) Automatic

(6- speed)
Model code:
NX... 5FS0

5FS0/1 HNYM/S
HNYM/1S
HNYM/2S 5FEA
Cubic capacity (cc) 1 5981 1991 598
Max power*: EU standard (kW) 889611 0
Fuel UnleadedUnleadedUnleaded
Braked trailer (within GTW limit)
o
n 12% gradient (Kg)
1 200
1 200 800
Unbraked trailer (Kg) 640675715
Recommended nose weight (Kg) 757575
09
Technical data

304
DS4_en_Chap09_caracteristiques_ed01-2016
.../S: model fitted with Stop & Start.
.../1: model fitted with low rolling resistance tyres.
*

T
he maximum power corresponds to the value type-approved on a test bed, under conditions defined in European legislation (Directive 1999/99/EC).
Engine
THP 160THP 165 S&S THP 210 S&S
Gearbox Automatic

(6- speed) EAT6 automatic

(6- speed) Manual

(6- speed)
Model code:
NX... 5FMA5GZT/S
5GZ T/1S 5GMM/S
Cubic capacity (cc) 1 5981 5981 598
Max power*: EU standard (kW) 120121155
Fuel UnleadedUnleadedUnleaded
Braked trailer (within GTW limit)
o
n 12% gradient (Kg)
800
1 400 1 000
Unbraked trailer (Kg) 715690 655
Recommended nose weight (Kg) 757575
09
Technical data

305
DS4_en_Chap09_caracteristiques_ed01-2016
Diesel engines
.../S: model fitted with Stop & Start.
.../1: model fitted with low rolling resistance tyres.
.../2: model fitted with very low rolling resistance tyres.
*

T
he maximum power corresponds to the value type-approved on a test bed, under conditions defined in European legislation (Directive 1999/99/EC).
Engine
BlueHDi 100e-HDi 115 BlueHDi 115 S&S
Gearbox Manual
(5 - speed) Manual
(6- speed) Manual
(6- speed) EAT6 automatic
(6- speed)
Model code:
NX... BHY9HD8/6

9HD8 /1S BHXM/S
BHXM/1S -/2S -/3S BHX T/1S
BHX T/2S
Cubic capacity (cc) 1 5601 560 1 560
Max power*: EU standard (kW) 7384 85
Fuel DieselDiesel Diesel
Braked trailer (within GTW limit)
o
n 12% gradient (Kg)
1 250
1 300 1 300 1 200
Unbraked trailer 630680 680640
Recommended nose weight 75757575
09
Technical data

306
DS4_en_Chap09_caracteristiques_ed01-2016
* The maximum power corresponds to the value type-approved on a test bed, under conditions defined in European legislation (Directive 1999/99/EC).
.../S: model fitted with Stop & Start.
.../1: model fitted with low rolling resistance tyres.
.../2: model fitted with very low rolling resistance tyres.
Engine
BlueHDi 120 S&SBlueHDi 150 S&S BlueHDi 180
Gearbox Manual
(6- speed) EAT6 automatic
(6- speed) Manual
(6- speed) EAT6 automatic
(6- speed)
Model code:
NX... BHZM/S
BHZM/1S -/2S -/3S BHZT/SAHRM/S
AHRM/1S
AHRM/2S AHW T/S
AHW T/1S
AHW T/2S
Cubic capacity (cm
3) 1 5601 9971 997
Max power*: EU standard (kW) 8811 0132
Fuel DieselDieselDiesel
Braked trailer (within GTW limit)
o

n 12% gradient (Kg) 1 300
1 2001 300 1 300
Unbraked trailer 680640 74 074 5
Recommended nose weight 75757575
09
Technical data

307
DS4_en_Chap09_caracteristiques_ed01-2016
Dimensions (in mm)
These dimensions have been measured on an unladen vehicle.
CROSSBACK
09
Technical data

308
DS4_en_Chap09_caracteristiques_ed01-2016
Identification markingsVarious visible markings for the identification of your vehicle.
A.
Vehicle identification number (VIN) under the bonnet.This number is engraved on the bodywork near
the suspension damper mounting.
B.
Vehicle identification number on the dashboard.This number is indicated on a self-adhesive
label which is visible through the windscreen. D. Tyre/paint label.
This label is affixed to the driver's front pillar.
Low tyre pressures increase fuel
consumption. The original tyres fitted to the vehicle
may have a load index or speed rating
higher than those given on the label;
this has no effect on the inflation
pressures.
C. Manufacturer's label.
The VIN is indicated on a self-destroying label
affixed to the driver's centre pillar. It bears the following information:
-
t he tyre pressures, for unladen and laden
conditions,
-

t
he tyre sizes (including the load index and
speed rating),
-

t
he spare tyre inflation pressure,
-

t
he paint colour code.Checking tyre pressures
The tyre pressures should be checked when
cold at least monthly.
The pressures given on the label are valid for
cold tyres. If you have driven for more than
10
minutes or more than 6 miles (10 kilometres)
at more than 30 mph (50 km/h), the tyres will be
warm; in this case 0.3 bar (30 kPa) should be
added to the pressures given on the label.
Never reduce the pressure of a warm
tyre.
